ROOM LAMP AND LUGGAGE COMPARTMENT LAMP

CIRCUIT DIAGRAMS

90-142

ROOM LAMP AND LUGGAGE
COMPARTMENT LAMP <SEDAN (RHD)>

M1901017800329

IGNITION
SWITCH (ACC)

IGNITION
SWITCH (IG1)

COMBINATION
METER

RELAY
BOX

ETACS-ECU

INTERIOR LAMP CUT BACK-UP CIRCUIT

REAR
ROOM
LAMP

FRONT
ROOM
LAMP

POWER
SOURCE

ROOM LAMP AND LUGGAGE COMPARTMENT LAMP

CIRCUIT DIAGRAMS

90-143

RELAY
BOX

BATTERY

1

FUSIBLE
LINK

·FRONT FOG LAMP
·HEADLAMP
·TAIL LAMP,
 POSITION LAMP,
 LICENCE PLATE
 LAMP AND LIGHTING
 MONITOR BUZZER
·TURN-SIGNAL LAMP
 AND HAZARD
 WARNING LAMP
·WINDSHIELD
 WIPER AND WASHER

WITHOUT
KEYLESS ENTRY

WITH
KEYLESS ENTRY

LOAD
DETERMINATION
CIRCUIT

KEEP RELAY

TRUNK LID
LATCH
SWITCH

LUGGAGE
COMPARTMENT
LAMP

DIAGNOSIS
CONNECTOR

J/B SIDE

FRONT
SIDE

ROOM LAMP AND LUGGAGE COMPARTMENT LAMP

CIRCUIT DIAGRAMS

90-144

ROOM LAMP AND LUGGAGE COMPARTMENT LAMP <SEDAN (RHD)> (CONTINUED)

COMBINATION
METER

KEY
REMINDER
SWITCH
(WHEN
 REMOVING
 KEY: ON)

ETACS-
ECU

J/B SIDE

DOOR
SWITCH
(FRONT: LH)

DOOR
SWITCH
(REAR: LH)

DOOR
SWITCH

DOOR
SWITCH
(FRONT: RH)

(REAR: RH)

ROOM LAMP AND LUGGAGE COMPARTMENT LAMP

CIRCUIT DIAGRAMS

90-145

NOTES
