INVECS-II 4A/T

CIRCUIT DIAGRAMS

90-102

INVECS-II 4A/T <4G1 (RHD)> (CONTINUED)

A/T CONTROL
SOLENOID
VALVE ASSEMBLY

NOTE

:

:

:

:

:

UNDERDRIVE
SOLENOID VALVE
SECOND
SOLENOID VALVE

DAMPER CLUTCH
CONTROL
SOLENOID VALVE

OVERDRIVE
SOLENOID VALVE

LOW AND REVERSE
SOLENOID VALVE

A/T
CONTROL
RELAY

ENGINE CONTROL
SYSTEM

ENGINE-
A/T-ECU

FRONT
SIDE

A/T FLUID
TEMPERATURE
SENSOR

INVECS-II 4A/T

CIRCUIT DIAGRAMS

90-103

Wire colour code
B : Black     LG : Light green     G : Green     L : Blue     W : White     Y : Yellow     SB : Sky blue
BR : Brown     O : Orange     GR : Grey     R : Red     P : Pink     V : Violet     PU : Purple

ENGINE-
A/T-ECU

THROTTLE
BODY
THROTTLE
SENSOR

DIAGNOSIS
CONNECTOR

FUSIBLE
LINK

ENGINE CONTROL
SYSTEM

1

INVECS-II 4A/T

CIRCUIT DIAGRAMS

90-104

INVECS-II 4A/T <4G6 (LHD)>

M1901016201985

IGNITION
SWITCH (IG1)

BATTERY

A/T
CONTROL
RELAY

STOP
LAMP
SWITCH

ENGINE-
A/T-ECU

SOLENOID VALVE
POWER SOURCE

STOP LAMP

INVECS-II 4A/T

CIRCUIT DIAGRAMS

90-105

ENGINE
CONTROL
SYSTEM

METER AND
GAUGE

(FUSE     )

3

RELAY
BOX

OUTPUT
SHAFT
SPEED
SENSOR

INPUT
SHAFT
SPEED
SENSOR

ENGINE-
A/T-ECU

NOTE

·TAIL LAMP,
 POSITION LAMP,
 LICENCE PLATE
 LAMP AND LIGHTING
 MONITOR BUZZER
·WINDSHIELD
 WIPER AND WASHER

·FRONT
 FOG LAMP
·HEADLAMP
·HEADLAMP
 LEVELLING SYSTEM
·HEADLAMP
 WASHER
·REAR FOG LAMP
