TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)

BODY DIMENSIONS

2-16

REAR BODY <SEDAN>

M4020008000148

AB300587AB

47

48

46

49

50

51

52

mm

463

521

567

703

750

1,460

1,114

1,271

990

653

1,200

1,025

1,268

Body centre point

No. Standard measurement point

Hole shape Size mm

46

Coner of roof panel

−

−

47

Centre of rear glass moulding mounting hole

Oblong

7

× 11

48

Centre of rear shelf body

−

−

49

Corner of side outer panel

−

−

50

Centre of rear combination lamp mounting hole (lower)

Round

10

51

Centre of rear end trim mounting hole

Round

8.5

52

Centre of rear end panel positioning hole

Round

16

AB201839AD

46

AB201840AD

47

AB201841AD

48

AB201842

AD

49,50

49

50

AB300586AB

51

AB300585 AB

52

TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)

BODY DIMENSIONS

2-17

TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)

BODY DIMENSIONS

2-18

INTERIOR <SEDAN>

M4020009000141

AB300628

AB

37

32

34

31

35

38

33

40

39

36

mm

1,395

1,145

1,388

1,368

1,289

1,112

1,297

1,407

1,379

1,235

AB300629

AB

31

33

35

37

39

40

38

36

54

53

34

32

Body centre point

1,041

1,136

1,100

1,016

1,084

1,054

809

683

706

856

AB300588 AB

55

51

825

580

1,110

1,151

No. Standard measurement point

Hole shape Size mm

31

Front pillar positioning notch (upper)

−

−

32

Front pillar positioning notch (lower)

−

−

33

Side roof rail positioning notch (front)

−

−

34

Side sill positioning notch (front)

−

−

35

Centre pillar positioning notch (upper)

−

−

36

Centre pillar positioning notch (lower)

−

−

37

Side roof rail positioning notch (rear)

−

−

38

Side sill positioning notch (rear)

−

−

39

Quarter panel positioning notch (upper)

−

−

40

Quarter panel positioning notch (lower)

−

−

51

Centre of rear end trim mounting hole

Round

8.5

53

Centre of front seat rail mounting hole

Round

14

54

Centre of floor carpet mounting hole (Body centre point)

Round

6

55

Centre of rear shock absorber mounting hole

Round

12

AB300586AB

51

AB201845

53

AD

AB200385AC

54

AB300845AB

55
