SERVICE SPECIFICATIONS

HEATER, AIR CONDITIONER AND VENTILATION

55A-5

SERVICE SPECIFICATIONS

M1551000301708

Item

Standard value

Idle speed r/min (N or P range)

1600

750

± 50

1800 Petrol

M/T

650

± 50

CVT

700

± 50

1800 Diesel

650

± 50

2000

700

± 50

Idle-up speed r/min (N or P range)

1600

750

± 100

1800 Petrol, 2000

850

± 100

1800 Diesel

900

± 100

Air gap (magnetic clutch) mm

0.25

− 0.45

A/C refrigerant temperature switch
operating temperature

°C

Being turned off

135

Being turned on

120

LUBRICANTS

M1551000401385

Item

Specified lubricant

Quantity

Compressor refrigerant unit lubricant mL

1600
(M/T)

SUN PAG 56 or S10X

60

− 80 (target value:

60)

Except
1600 (M/T)

70

− 90 (target value:

70)

Each connection of refrigerant line

As required

Refrigerant g

HFC134a (R134a)

500

± 20

SPECIAL TOOLS

HEATER, AIR CONDITIONER AND VENTILATION

55A-6

SPECIAL TOOLS

M1551000601226

Tool

Number

Name

Use

MB990810

MB990810

Side bearing puller

A/C compressor rotor
removal and installation

MB992623

MB992623

Guide

MB992624

MB992624

Pusher

MD999566

Claw

B991367

MB991367

Special spanner

Removal and installation
of the A/C compressor
armature mounting nut

MB991386

Pin

MB990900

MB990900 or
MB991164

Door hinge adjusting
wrench

Removal and installation
of front deck cross
member heater unit
assembly

MB991658

MB991658

Test harness

Inspection of the A/C
pressure sensor

MB991223

a

d

c

b

DO NOT USE

BA

SPECIAL TOOLS

HEATER, AIR CONDITIONER AND VENTILATION

55A-7

MB991223

a. MB991219
b. MB991220
c. MB991221
d. MB991222

Harness set

a. Test harness
b. LED harness
c. LED harness adapter
d. Probe

Making voltage and
resistance
measurements during
troubleshooting

a. Connect pin contact

pressure inspection

b. Power circuit

inspection

c. Power circuit

inspection

d. Commercial tester

connection

MB992006

MB992006

Extra fine probe

Continuity check and
voltage measurement at
harness wire or
connector

Tool

Number

Name

Use

MB991910

MB991826

MB991955

MB991911

MB991824

MB991827

MB991825

a

b

c

d

e

f

DO NOT USE

TROUBLESHOOTING

HEATER, AIR CONDITIONER AND VENTILATION

55A-8

TROUBLESHOOTING

DIAGNOSIS TROUBLESHOOTING FLOW

M1554004700975

Refer to GROUP 00, How to Use Troubleshooting/
Inspection Service Points

− Contents of Trouble-

shooting

DIAGNOSIS FUNCTION

M1554004800905

READING DIAGNOSIS CODES

Refer to GROUP 00, How to Use Troubleshooting/
Inspection Service Points

− Diagnosis Function .

ERASING DIAGNOSIS CODES

Refer to GROUP 00, How to Use Troubleshooting/
Inspection Service Points

− Diagnosis Function .

MB991955

a. MB991824
b. MB991827
c. MB991910
d. MB991911
e. MB991825
f. MB991826

M.U.T.-III sub-assembly

a. Vehicle

Communication
Interface (V. C. I).

b. USB cable
c. M.U.T.-III main

harness A (applicable
to vehicles with CAN
communication)

d. M.U.T.-III main

harness B (applicable
to vehicles without
CAN communication)

e. Measurement

adapter

f. Trigger harness

CAUTION

For vehicles with CAN
communication, use
M.U.T.-III main harness
A to send simulated
vehicle speed. If you
connect M.U.T.-III main
harness B instead, the
CAN communication
does not function
correctly.
Check the A/C (The
M.U.T.-III diagnosis
codes display, service
data display and
actuator test)

Tool

Number

Name

Use
