FOG LAMP

CHASSIS ELECTRICAL

54A-194

<VEHICLES WITH FRONT BUMPER (TYPE 2)>

AC801863

AC801795

AC801796

AC801794

AC801793

1

1

Front
bumper
face

AB

Front
bumper
face

Front
bumper
face

Section A - A

Section B - B

Section C - C

Claw

Claw

A

A

B

B

B

B

A

A

C

C

Claw

Claw

1

Front bumper
face

1

Removal steps

1.

Fog lamp bezel

2.

Fog lamp assembly

3.

Bulb

4.

Fog lamp unit

Removal steps (Continued)

Post-installation operation
Check the beam direction of the front fog lamp (Refer to
Front Fog Lamp Aiming ).

AC800354AC

1

2

0.9 ± 0.1 N·m

4

3

Front bumper face

FOG LAMP

CHASSIS ELECTRICAL

54A-195

REAR FOG LAMP REMOVAL AND INSTALLATION

M1542600300248

<LANCER>

Refer to tail lamp removal and installation .

<LANCER SPORTBACK>

AC800571

AC800374

AC800375

AC800376

AC800377

AC800378

1

1

1

1

Claw

1

1

B

B

A A

C

C

D

D

E

E

A

A

Front
bumper
face

AD

Front
bumper
face

Front bumper face

Front
bumper
face

Section A - A

Section B - B

Section C - C

Section D - D

Section E - E

Claw

Rib

Claw

Claw

Removal steps

1.

Fog lamp bezel

2.

Fog lamp assembly

3.

Bulb

4.

Fog lamp unit

Removal steps (Continued)

AC802121AB

4.5 ± 1.5 N·m

2

4

3

1

5

Removal steps

1.

Rear fog lamp assembly

2.

Bulb

3.

Socket

Removal steps (Continued)

FOG LAMP

CHASSIS ELECTRICAL

54A-196

INSPECTION

FRONT FOG LAMP RELAY CHECK

M1540402800108

4.

Rear fog lamp unit

5.

Spring nut

Removal steps (Continued)

AC700034

2

3

4

1

AD

Front fog lamp relay

Battery voltage

Terminal
number

Normal
condition

At no energisation

3

− 4

No
continuity

With current supply
[terminal 2 (+), terminal 1
(

−)]

Continuity
exists (2

Ω

or less)

SIDE TURN-SIGNAL LAMP

CHASSIS ELECTRICAL

54A-197

SIDE TURN-SIGNAL LAMP

REMOVAL AND INSTALLATION

M1541800200457

<LANCER>

<LANCER SPORTBACK>

REMOVAL SERVICE POINT

<<A>> SIDE TURN-SIGNAL LAMP REMOVAL

Push the side turn-signal lamp toward the vehicle
rear to bend the hook, and then remove by disengag-
ing the tab from the fender panel.

AC609819

1

AB

Removal step

<<

A

>>

>>

A

<<

1.

Side turn-signal lamp assembly

AC802267

1

AB

Removal step

<<

A

>>

>>

A

<<

1.

Side turn-signal lamp assembly

AC506856

Side turn-signal lamp

AC

Push

Forward of vehicle
