POWER STEERING DIAGNOSIS
TSB Revision
POWER STEERING
37-11
INSPECTION PROCEDURE 11: Oil Leakage from Hose Assembly
DIAGNOSIS
STEP 1. Check the hose for damage or clogging.
Q: Is the hose damaged or clogged?
YES :
Repair or replace it. Then go to Step 2.
NO :
Go to Step 2.
STEP 2. Retest the system.
Check that no oil is leaking.
Q: Is there oil leakage?
YES :
Repeat from Step 1.
NO :
The procedure is complete.
INSPECTION PROCEDURE 12: Oil Leakage from Oil Reservoir
DIAGNOSIS
STEP 1. Check the oil reservoir for damage.
Q: Is there damage?
YES :
Repair or replace it. Then go to Step 3.
NO :
Go to Step 2.
STEP 2. Check for overflowing.
Q: Is there oil overflowing from the reservoir?
YES :
Adjust fluid level. Then go to Step 3.
NO :
Go to Step 3.
STEP 3. Retest the system.
Q: Is there oil leakage?
YES :
Repeat from to Step 1.
NO :
The procedure is complete.
INSPECTION PROCEDURE 13: Oil Leakage from Oil Pump
DIAGNOSIS
STEP 1. Check the oil pump body for damage.
Q: Is there damage?
YES :
Replace the part. Then go to Step 3.
NO :
Go to Step 2.
STEP 2. Check the O-ring or oil seal for damage.
Q: Is there damage?
YES :
Replace the part. Then go to Step 3.
NO :
Go to Step 3.
STEP 3. Retest the system.
Check that no oil is leaking.
Q: Is there oil leakage?
YES :
Repeat from Step 1.
NO :
The procedure is complete.
