DIAGNOSIS <TC-SST> TSB Revision TWIN CLUTCH- SPORTRONIC SHIFT TRANSMISSION (TC-SST) 22C-245 DIAGNOSTIC PROCEDURE STEP 1. Scan tool CAN bus diagnostics YES : Go to Step 2. − Troubleshooting .) After repairing the CAN bus line, go to Step 2. STEP 2. Check whether the DTC is reset. YES : Replace the TC-SST assembly. (Refer to NO : Intermittent malfunction. (Refer to GROUP 00 − How to Cope with Intermittent Malfunction .) DTC P2720: Clutch/Shift Pressure Solenoid 1 System (Short to ground) CAUTION • If there is any problem in the CAN bus lines, an incorrect diagnostic trouble code may be • Whenever the ECU is replaced, ensure that the CAN bus lines are normal. . DIAGNOSTIC FUNCTION TC-SST-ECU checks that the clutch/shift pressure . DESCRIPTIONS OF MONITOR METHODS The clutch/shift pressure solenoid 1 circuit is deter- . MONITOR EXECUTION • Continuous . MONITOR EXECUTION CONDITIONS Other Monitor (There is no temporary DTC stored in memory for the item monitored below) • P0841: Clutch 1 pressure sensor system (Poor performance) • P0842: Clutch 1 pressure sensor system (Output low range out) • P0843: Clutch 1 pressure sensor system (Output high range out) • P2733: Clutch/shift switching solenoid 1, spool stuck • P2736: Clutch/shift switching solenoid 1 system (Open circuit) • P2738: Clutch/shift switching solenoid 1 system (Short to ground) • P2739: Clutch/shift switching solenoid 1 system (Short to power supply) • P181B: Clutch 1 (Pressure low range out) • P181C: Clutch 1 (Pressure high range out) • P1859: Disengagement too late with clutch 1 Sensor (The sensor below is determined to be normal) • Clutch 1 pressure sensor • Clutch/shift switching solenoid 1 . |
