TIRE PRESSURE MONITORING SYSTEM (TPMS) <TC-SST>

TSB Revision

CIRCUIT DIAGRAMS

90-297

ANTENNA

TPMS
TRANSMITTER

TPMS
TRANSMITTER

FRONT TIRE (LH)

CONTROL CIRCUIT

·PRESSURE SENSOR
·ROLL SWITCH

·PRESSURE SENSOR
·ROLL SWITCH

·PRESSURE SENSOR
·ROLL SWITCH

·PRESSURE SENSOR
·ROLL SWITCH

ANTENNA

FRONT TIRE (RH)

CONTROL CIRCUIT

ANTENNA

REAR TIRE (LH)

TPMS
TRANSMITTER

TPMS
TRANSMITTER

ANTENNA

REAR TIRE (RH)

CONTROL CIRCUIT

CONTROL CIRCUIT

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

TIRE PRESSURE MONITORING SYSTEM (TPMS) <TC-SST>

TSB Revision

CIRCUIT DIAGRAMS

90-298

TIRE PRESSURE MONITORING (TPMS) <TC-SST> (CONTINUED)

<VEHICLES WITHOUT KOS>

JOINT
CONNECTOR
(6)

WIRELESS CONTROL
MODULE

CAN DRIVE
CIRCUIT

JOINT
CONNECTOR
(CAN1)

(FUSE     )

12

(FUSE     )

8

ETACS-ECU

RECEIVER
ANTENNA
ASSEMBLY

RECEIVER

TIRE PRESSURE MONITORING SYSTEM (TPMS) <TC-SST>

TSB Revision

CIRCUIT DIAGRAMS

90-299

<VEHICLES WITH KOS>

JOINT
CONNECTOR
(6)

KOS-ECU

CAN DRIVE
CIRCUIT

JOINT
CONNECTOR
(CAN1)

(FUSE     )

8

(FUSE     )

12

ETACS-ECU

RECEIVER
ANTENNA
ASSEMBLY

POWER
SUPPLY

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

RECEIVER

TIRE PRESSURE MONITORING SYSTEM (TPMS) <TC-SST>

TSB Revision

CIRCUIT DIAGRAMS

90-300

TIRE PRESSURE MONITORING (TPMS) <TC-SST> (CONTINUED)

CAN DRIVE
CIRCUIT

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

INTERFACE
CIRCUIT

DATA LINK
CONNECTOR

ETACS-ECU

JOINT
CONNECTOR
(CAN3)

JOINT
CONNECTOR
(CAN2)

FUSIBLE
LINK

34

ETACS-
ECU

HEATED
SEAT
