DAYTIME RUNNING LIGHT (DRL) <HALOGEN TYPE>

TSB Revision

CIRCUIT DIAGRAMS

90-109

FRONT SIDE

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

ENGINE CONTROL MODULE

JOINT
CONNECTOR
(CAN2)

JOINT
CONNECTOR
(CAN4)

<M/T>

<TC-SST>

DAYTIME RUNNING LIGHT (DRL) <DISCHARGE TYPE>

TSB Revision

CIRCUIT DIAGRAMS

90-110

DAYTIME RUNNING LIGHT (DRL) <DISCHARGE TYPE>

M1901030700088

:

NOTE

:

FUSIBLE
LINK

36

DAYTIME
RUNNING
LIGHT
RELAY

RELAY BOX

ENGINE
COMPARTMENT

HEADLIGHT
ASSEMBLY
(DRL: LH)

HEADLIGHT
ASSEMBLY
(DRL: RH)

:

VEHICLES
WITH
AUTOMATIC
LIGHT

·ABS, ASC, ACD, AYC AND S-AWC
·AIR CONDITIONING SYSTEM
·CENTRAL DOOR LOCKING SYSTEM
·DOME LIGHT, LUGGAGE
 COMPARTMENT LIGHT
 AND IGNITION KEY HOLE
 ILLUMINATION LIGHT
·HEATED SEAT
·IGNITION KEY REMINDER TONE
 ALARM
·IMMOBILIZER SYSTEM
·KEYLESS OPERATING SYSTEM
 (KOS)
·REAR WINDOW DEFOGGER
·SEAT BELT WARNING TONE ALARM
·SHIFT LOCK MECHANISM
·SUNROOF
·SUPPLEMENTAL RESTRAINT
 SYSTEM (SRS)
·TC-SST
·THEFT-ALARM SYSTEM
·TIRE PRESSURE MONITORING
 SYSTEM (TPMS)
·TRUNK LID OPENER

·AIR CONDITIONING SYSTEM
·BRAKE WARNING LIGHT,
 FUEL WARNING LIGHT
 AND OIL PRESSURE WARNING LIGHT
·CENTRAL DOOR LOCKING SYSTEM
·DOME LIGHT,
 LUGGAGE COMPARTMENT
 LIGHT AND IGNITION KEY
 HOLE ILLUMINATION LIGHT
·HEADLIGHT
·IGNITION KEY REMINDER TONE ALARM
 <VEHICLES WITH KOS>
·IMMOBILIZER SYSTEM
·KEYLESS OPERATION SYSTEM (KOS)
·METER AND GAUGE
·SEAT BELT WARNING TONE ALARM
·TAILLIGHT, POSITION LIGHT,
 LICENSE PLATE LIGHT
 AND LIGHTING MONITOR TONE ALARM
·THEFT-ALARM SYSTEM
·TIRE PRESSURE
 MONITORING SYSTEM (TPMS)
·TRUNK LID OPENER
·WINDSHIELD WIPER AND WASHER

DAYTIME RUNNING LIGHT (DRL) <DISCHARGE TYPE>

TSB Revision

CIRCUIT DIAGRAMS

90-111

COLUMN
SWITCH

(LIGHTING SWITCH)

COLUMN-ECU

LIN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

JOINT
CONNECTOR
(2)

IGNITION
SWITCH (IG1)

FUSIBLE
LINK

34

IG1
RELAY

RELAY BOX

(FUSE     )

30

ETACS-
ECU

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

(HEAD)

(TAIL)

(AUTO)

HEATED
SEAT

DAYTIME RUNNING LIGHT (DRL) <DISCHARGE TYPE>

TSB Revision

CIRCUIT DIAGRAMS

90-112

DAYTIME RUNNING LIGHT (DRL) <DISCHARGE TYPE> (CONTINUED)

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

PARKING
BRAKE
SWITCH

DATA LINK
CONNECTOR

CAN
TRANSCEIVER
CIRCUIT

CPU

INTERFACE
CIRCUIT

COMBINATION
METER

JOINT
CONNECTOR
(CAN1)

INTERFACE
CIRCUIT

CAN DRIVE
CIRCUIT

34

FUSIBLE
LINK

ETACS-ECU

JOINT CONNECTOR
(CAN3)

INPUT SIGNAL

·FRONT WHEEL
 SPEED SENSOR
·REAR WHEEL
 SPEED SENSOR

ASC-ECU
