BODY COMPONENTS
TSB Revision
BODY CONSTRUCTION
1-3
1.
Front bumper reinforcement
2.
Headlight support panel upper
3.
Front body frame to side sill brace
4.
Front sidemember rear
5.
Front inner sidemember
6.
Headlight support panel
7.
Front sidemember plate
8.
Front outer sidemember
9.
Front sidemember extension
10. Front fender gusset
11. Headlight support panel upper
12. Front fender shield
13. Fender shield frame upper outer
14. Fender shield frame upper inner
15. Spring house panel
16. Dash panel crossmember upper
17. Dash panel crossmember lower
18. Dash panel
19. Brake pedal support reinforcement
20. Cowl top panel
21. Brake pedal support bracket
22. Front deck crossmember
23. Hood panel inner
24. Hood panel outer
25. Front door side door beam
26. Front door panel inner
27. Front door panel outer
28. Rear door side door beam
29. Rear door panel inner
30. Rear door panel outer
31. Roof rail front lower
32. Roof rail front upper
33. Roof bow center lower <Vehicles without sunroof
(aluminum panel)>
34. Roof bow center upper <Vehicles without sunroof
(aluminum panel)>
35. Roof rail rear
36. Roof panel
37. Roof panel reinforcement <Vehicles with sunroof
(steel panel)>
38. Rear shelf panel
39. Trunk lid panel inner
40. Trunk lid panel outer
41. Fuel filler door panel (Left side)
42. Rear bumper reinforcement
43. Rear bumper reinforcement
44. Rear end panel outer
45. Rear end panel inner
46. Rear bumper side bracket
47. Rear seatback bracket lower
48. Rear floor
49. Rear floor rear end crossmember
50. Rear floor crossmember
51. Rear floor side panel
52. Rear floor sidemember extension
53. Rear floor sidemember lower
54. Rear seat under floor
55. Rear seat belt reinforcement (Left side)
56. Rear seat belt reinforcement (Right side)
57. Rear floor extension
58. Rear floor rear seat under crossmember
59. Front floor crossmember rear
60. Front floor backbone reinforcement
61. Front floor crossmember front
62. Front floor
63. Front floor side sill inner
64. Front floor sidemember
65. Front floor crossmember rear center
66. Front floor crossmember front
67. Front fender
68. Headlight support panel lower
69. Radiator bracket lower
70. Side outer panel
71. Front fender bracket
72. Upper frame to front pillar brace
73. Front deck frame upper outer
74. Side sill reinforcement outer front
75. Side sill reinforcement outer rear
76. Side sill inner support front
77. Front pillar lower reinforcement
78. Front pillar inner lower
79. Front pillar inner center
80. Front upper inner pillar
81. Roof side rail inner
82. Rear seatback brace
83. Rear wheel house panel inner
84. Rear wheel house panel front lower outer
85. Quarter panel lower inner (Left side)
86. Quarter panel inner
87. Quarter panel extension inner
88. Quarter panel extension lower outer
89. Quarter panel extension outer
90. Rear combination light housing panel
91. Rear pillar reinforcement
92. Roof side rail reinforcement rear
93. Rear pillar reinforcement lower
94. Center pillar reinforcement
95. Rear door hinge reinforcement
96. Rear door hinge reinforcement support
97. Roof side rail reinforcement
98. Center pillar inner lower
99. Center pillar inner upper
