DIAGNOSIS TSB Revision CONTROLLER AREA NETWORK (CAN) 54C-217 STEP 5. Check the wiring harness between joint connector resistance at the wiring harness side of joint connector (2) Measure the resistance between joint connector (CAN1) terminal 8 and body ground. OK: 1 kΩ or more (3) Measure the resistance between joint connector (CAN1) terminal 21 and body ground. OK: 1 kΩ or more Q: Do all the resistances measure 1 kΩ or more? YES : Go to Step 6. AC608179 TEST Harness side: C-105 CE AC608179 Harness side: C-105 CF TEST |
