ON-VEHICLE SERVICE
SMART WIRING SYSTEM (SWS) NOT USING SWS MONITOR
54B-303
Function
Configuration procedure
Keyless entry system hazard
answerback function
When the lock button of the transmitter is pressed twice continuously within
two seconds, the hazard answerback function during the lock state will be
switched between available or unavailable.
• Function available: Buzzer sounds once. (Initial state)
• Function not available: Buzzer sounds twice.
When the unlock button of the transmitter is pressed twice continuously
within two seconds, the hazard answerback function during the unlock
state will be switched between available or unavailable.
• Function available: Buzzer sounds once. (Initial state)
• Function not available: Buzzer sounds twice.
Vehicle speed-dependent
wiper function
When the windshield wiper mist switch is turned ON for more than two
seconds, the vehicle speed-dependent wiper function is switched between
available or unavailable.
• Function available: Buzzer sounds once. (Initial state)
• Function not available: Buzzer sounds twice.
Headlamp
automatic-shutdown function
When the passing switch is turned ON for more than two seconds with the
head lamp switch ON and the turn signal lamp switch turned to RH, the
headlamp automatic-shutdown function is switched between available or
unavailable.
• Function available: Buzzer sounds once. (Initial state)
• Function not available: Buzzer sounds twice.
Interior lamp
automatic-shutdown function
When the hazard switch is turned ON for more than two seconds, the
interior lamp automatic-shutdown function is switched between available or
unavailable.
• Function available: Buzzer sounds once. (Initial state)
• Function not available: Buzzer sounds twice.
Delayed lamp-off time of the
interior lamp
When the turn signal lamp switch is set in the order of RH to LH to RH to
LH within three seconds from the LH position, the delayed lamp-off time
switches (Returns to a after e, and repeats from a in order).
a. 15 seconds: Buzzer sounds four times. (Initial state)
b. 7.5 seconds: Buzzer sounds five times.
c. 30 seconds: Buzzer sounds once.
d. 10 seconds: Buzzer sounds twice.
e. 0 seconds (No delay time): Buzzer sounds three times.
Initialisation of all functions
When the windshield washer switch is ON for more than 20 seconds
continuously, the buzzer sounds twice, and all functions will be initialised
(Settings are returned to their initial states). The configuration mode entry
buzzer sounds after 10 seconds, however to initialise all functions, the ON
state should be continued for 20 seconds. When the windshield washer
switch is ON for more than 20 seconds continuously without the
configuration mode set, the configuration mode will be set after 10 seconds
without the initialisation of all functions.
