POWER DISTRIBUTION SYSTEM

CIRCUIT DIAGRAMS

90-35

NOTES

STARTING SYSTEM

CIRCUIT DIAGRAMS

90-36

STARTING SYSTEM

M1901000501976

BATTERY

IGNITION
SWITCH (ST)

STARTER

Wire colour code
B : Black     LG : Light green     G : Green     L : Blue     W : White     Y : Yellow     SB : Sky blue
BR : Brown     O : Orange     GR : Grey     R : Red     P : Pink     V : Violet   PU: Purple

ENGINECONTROL
SYSTEM

IGNITION SYSTEM

CIRCUIT DIAGRAMS

90-37

IGNITION SYSTEM

IGNITION SYSTEM <LH drive vehicles>

M1901000602716

IGNITION
SWITCH (IG1)

IGNITION
COIL (2)

IGNITION
COIL (1)

SPARK PLUG

SPARK PLUG

ENGINE-
ECU

ENGINE SPEED
DETECTION
CONNECTOR

INPUT SIGNAL

·

BAROMETRIC

 PRESSURE
 SENSOR

·

CRANK ANGLE

 SENSOR
·DETONATION
 SENSOR
·ENGINE
 COOLANT
 TEMPERATURE
 SENSOR

·EXHAUST
 CAMSHAFT
 POSITION
 SENSOR
·IGNITION
 SWITCH

(ST)

·INTAKE AIR
 TEMPERATURE
 SENSOR

·INTAKE
 CAMSHAFT
 POSITION
 SENSOR

·OXYGEN
 SENSOR
·THROTTLE
 POSITION
 SENSOR
·VEHICLE SPEED
 SENSOR

IGNITION SYSTEM

CIRCUIT DIAGRAMS

90-38

IGNITION SYSTEM <RH drive vehicles>

M1901000602727

BATTERY

IGNITION
SWITCH (IG1)

RELAY
BOX

IGNITION
COIL RELAY

·ENGINE CONTROL
 SYSTEM
·IMMOBILIZER SYSTEM
