Mitsubishi Fuso Canter. Manual - part 23

Spec. No. FG83W

-C, 1/2

MITSUBISHI FUSO CARGO TRUCK
CANTER
FG83P-W SERIES

TYPE: FORWARD CONTROL, FIXED DOUBLE CAB
DRIVE SYSTEM:

4 x

4, CREW: 7

ENGINE: 4D34-3A, DIESEL, 80 kW (109 PS)/3,200 rpm
G.V.W.: 5,500 kg (12,125 lb), TIRE: 7.50-16-10PR

MODEL

Wheelbase

(W.B.)

Overall length

(O.A.L.)

Overall width

(O.W.)

Overall height, approx.

(H.)

Tread, front

(T.F.)

Tread, rear

(T.R.)

Front overhang

(F.O.H.)

Rear overhang

(R.O.H.)

Body inside length

(B.L.)

Body inside width

(B.W.)

Body inside height

(B.H.)

Body offset

(O.S.)

Shipping space, approx.

cu.m (cu.ft.)

BODY TYPE
PAYLOAD CAPACITY

kg (Ib)

BODY CODE

FG83PE6WR

FG83PE6WL

Max. speed

/h (mph)

Max. gradeability

(tan

θ ) %

(with Max. G. V. W.)

Min. turning radius

m (ft)

Dimensions

mm (in.)

Weights

kg (lb)

Calculated Performance

3,460 ( 136.2)
6,225 ( 245.1)
2,080 (

81.9)

2,490 (

98.0)

1,665 (

65.6)

1,560 (

61.4)

1,130 (

44.5)

1,605 (

63.2)

3,350 ( 131.9)
1,980 (

78.0)

380 (

15.0)

90 (

3.5)

32.5 ( 1,148)

2,980 ( 6,570)
1,830 ( 4,035)
1,150 ( 2,535)
5,500 (12,125)
2,500 ( 5,510)
3,600 ( 7,935)

107 (66.4)

60.0

6.8 (22.3)

Empty vehicle weight

front
rear

Max. G. V. W.

front
rear

Wooden cargo

2,065 (4,550)

R . H . D .
L . H . D .

ANNOTATIONS
(1) Empty vehicle weight shown are subject to 2.5% variation to allow for production tolerances.
(2) Empty vehicle weight includes weight of oil, fuel, coolant but exclude spare tire carrier & bracket, spare tire & disc wheel

and standard tool set.

(3) Above drawings show left hand drive model. For right hand drive model, exterior rear view mirror and wiper on left and

right sides are symmetric with respect to the chassis center line.

(4) Three persons are excluded as payload capacity. One person’s weight is calculated by 65 kg.

DIMENSIONS, WEIGHTS AND PERFORMANCE

1995mm

T.F.

O.W.

T.R.

B.W.

B.L.

O.S.

B.H.

F.O.H.

W.B.

O.A.L.

R.O.H.

Engine

Model
Type
No. of cylinders
Bore x stroke
Piston displacement
Max. output (JIS)
Max. torque (JIS)
Alternator
Air cleaner

Clutch

Facing material, diameter

Transmission

Model

Type

Gear ratios

Transfer Ratio
Front Axle
Rear Axle

Final reduction gear

Model
Ratio

Tires and Disc Wheels

Tire size
Tread pattern
Disc wheel size

Steering

Suspensions

span x width x thickness

Front

–No. of leaves

Rear

Main

Helper

Brakes

Service
Parking

Exhaust System

Tail pipe

Frame

Electrical System

Batteries

Fuel Tank
Paint

Floor

Main sill height x width x thickness
Cross skill

height x width

Floor board

thickness

Floor frame

Guard Frame

Outside post

thickness

Upper rail

thickness

Horizontal rail

thickness

Vertical pillar

thickness

Header panel

thickness

Side & Rear Gate

Top rail

thickness

Side post

thickness

Bottom rail

thickness

Board & panel

thickness

Accessories

Rope hook

diameter

Rear fender

thickness

Side gate support

BODY TYPE

Steel pipe
Plywood
Plywood
Form-rolled steel

Pressed steel
Bended steel
Bended steel
Bended steel
Plywood

Form-rolled steel
Pressed steel
Form-rolled steel
Plywood overlaid with steel metal

Steel rod
Plastic (P.P.)

1 pair

90 mm x 40 mm x 2.3 mm (3.54 in. x 1.57 in. x 0.09 in.)

93 mm x 40 mm or 35 mm (3.66 in. x 1.57 in. or 1.38 in.)

14 mm (0.55 in.)

2.3 mm (0.09 in.)

3.2 mm (0.13 in.)
3.2 mm (0.13 in.)
2.3 mm (0.09 in.)
1.4 mm (0.06 in.)

11 mm (0.43 in.)

2.0 mm (0.08 in.)
1.6 mm (0.06 in.)
1.6 mm (0.06 in.)

13.3 mm (0.52 in.)

12.7 mm

φ (Dia. 0.47 in.)

3.0 mm (0.12 in.)

Wooden cargo

Spec. No. FG83W

-C, 2/2

MITSUBISHI FUSO 4D34-3A

4 stroke-cycle, water-cooled direct injection diesel engine

4 in line

104 mm x 115 mm (4.09 in. x 4.53 in.)

3.907 L (238.4 cu.in.)

80 kW (109 PS) / 3,200 rpm

255 N·m (26.0 kgf·m, 188 lb·ft) / 1,800 rpm

24 Volt, AC, 50 Amp.

Dry paper element type with snorkel

Hydraulic control, diaphragm spring, single dry plate

Woven (asbestos free), 275 mm (11.8 in.)

M035S5

5 forward and 1 reverse speed,

2nd to 5th synchromesh, 1st and Rev. constantmesh gears

5.380-3.028-1.700-1.000-0.722, Rev. 5.380

Low : 1.987, High : 1.090

Full floating type with constant velocity universal joints

Full floating type

Single reduction, hypoid gear

D3H

6.166

Single front, dual rear

7.50-16-10PR

Rib-Lug

16 x 6.00GS-127-9t, 6 studs, 2 pieces

Ball-nut type with integral type hydraulic power booster.

Telescopic and tilt steering column with steering lock

Semi-elliptic, laminated leaf springs

10 mm-2

0.39 in.

1,200 mm x 70 mm x 9 mm-2 47.2 in. x 2.76 in. x 0.35 in.

16 mm-1

0.63 in.

Semi-elliptic, laminated leaf springs

Hydraulic with vacuum servo assistance, dual circuit

Internal expanding type on propeller shaft at rear of transfer

Conventional (horizontal) type muffler

Drop tail type, blowing to chassis rearward

Parallel, tapered channel section with reinforcement and crossmembers

24 Volt, regulated control

12 Volt x 2, 65 Ah (234 kC) at 20 hr rate (75D26L)

52 Ah (187 kC) at 5 hr rate (75D26L)

100 lits. (dm

) (22.0 lmp.gals. or 26.4 U.S.gals.)

Finish coat, Natural White

FG83P-W SERIES CARGO BODY SPECIFICATIONS

FG83P-W SERIES CHASSIS SPECIFICATIONS

(

)

ANNOTATION
SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE.

span x width x thickness

–No. of leaves

1,250 mm x 70 mm x

10 mm-1

(

49.2 in. x 2.76 in. x

0.39 in.

)

11 mm-5

0.43 in.

(

)

990 mm x 70 mm x

8 mm-4

(

39.0 in. x 2.76 in. x

0.31 in.

)

9 mm-2

0.35 in.

(

)

FE71PBD4R

FE71PBD4L

MODEL

Max. speed

/h (mph)

Max. gradeability

(tan

θ ) %

(with Max. G. V. W.)

Min. turning radius

m (ft)

Spec. No. FE71

-D, 1/2

MITSUBISHI FUSO DUMP TRUCK
CANTER
FE71PBD4 SERIES

TYPE: FORWARD CONTROL, TILT CAB
DRIVE SYSTEM: 4 x 2, CREW: 3
ENGINE: 4D34-3A, DIESEL, 80 kW (109 PS)/3,200 rpm
G.V.W.: 4,700 kg (10,360 lb), TIRE: 6.50-16-10PR

DIMENSIONS, WEIGHTS AND PERFORMANCE

Dimensions

mm (in.)

Weights

kg (lb)

Calculated Performance

Wheelbase

(W.B.)

Overall length

(O.A.L.)

Overall width

(O.W.)

Overall height, approx.

(H.)

Tread, front

(T.F.)

Tread, rear

(T.R.)

Front overhang

(F.O.H.)

Rear overhang

(R.O.H.)

Body inside length

(B.L.)

Body inside width

(B.W.)

Body inside height

(B.H.)

Body offset

(O.S.)

Shipping space, approx.

cu.m (cu.ft.)

2,500 (

98.4)

4,740 ( 186.6)
1,695 (

66.7)

1,995 (

78.5)

1,390 (

54.7)

1,235 (

48.6)

1,000 (

39.4)

1,190 (

46.9)

2,850 ( 112.2)
1,600 (

63.0)

360 (

14.2)

240 (

9.4)

16.0 (

565)

2,455 ( 5,410)
1,385 ( 3,055)
1,070 ( 2,360)
4,700 (10,360)
2,000 ( 4,410)
3,300 ( 7,275)

108 (67.1)

49.0

5.1 (16.7)

Empty vehicle weight

front
rear

Max. G. V. W.

front
rear

BODY TYPE
BODY CAPACITY

cu.m (cu.yd)

BODY CODE

Drop side & tail

1.6 (2.1)

R . H . D .
L . H . D .

and standard tool set.

(3) Above drawings show left hand drive model. For right hand drive model, exterior rear view mirror and wiper on left and

right sides are symmetric with respect to the chassis center line.

O.W.

T.F.

B.W.

(1690)

T.R.

B.H.

F.O.H.

W.B.

O.S.

60˚

B.L.

O.A.L.

R.O.H.

Engine

Model
Type
No. of cylinders
Bore x stroke
Piston displacement
Max. output (JIS)
Max. torque (JIS)
Alternator
Air cleaner

Clutch

Facing material

Transmission

Model

Type

Gear ratios

Front Axle
Rear Axle

Final reduction gear

Model
Ratio

Tires and Disc Wheels

Tire size
Tread pattern
Disc wheel size

Steering
Suspensions

span x width x thickness

Front

–No. of leaves

Rear

span x width x thickness

Main

–No. of leaves

Helper

Brakes

Service
Parking

Exhaust System

Tail pipe

Frame
Electrical System

Batteries

Fuel Tank
Paint

MITSUBISHI FUSO 4D34-3A

4 stroke-cycle, water-cooled direct injection diesel engine

4 in line

104 mm x 115 mm (4.09 in. x 4.53 in.)

3.907L (238.4 cu.in.)

80 kW (109 PS) / 3,200 rpm

255 N·m (26.0 kgf·m / 188 lb·ft)

24 Volt, AC, 50 Amp.

Dry paper element type with snorkel

Hydraulic control, diaphragm spring, single dry plate

Woven (asbestos free), 275 mm (10.8 in.)

M025S5

5 forward and 1 reverse speed,

1st to 5th synchromesh, Rev. constantmesh gears

5.181-2.865-1.593-1.000-0.739, Rev. 5.181

Reverse Elliot, "

Ι" beam

Full floating type

Single reduction, hypoid gear

D2H

6.166

Single front, dual rear

6.50-16-10PR

Lug

16 x 5.50F-115-8t, 5 studs, 2 pieces

Ball-nut type. Telescopic and tilt steering column with steering lock

Semi-elliptic, laminated leaf springs

1,200 mm x 70 mm x

10 mm-1

(

47.2 in. x 2.76 in. x

0.39 in.

)

11 mm-3 0.43 in.

Semi-elliptic, laminated leaf springs

12 mm-3

0.47 in.

1,250 mm x 70 mm x 20 mm-1

49.2 in. x 2.76 in. x 0.79 in.

18 mm-1 0.71 in.

120 mm x 68 mm x 122 mm (4.72 in. x 2.68 in. x 4.8 in.) (Rubber)

Hydraulic with vacuum servo assistance, dual circuit

Internal expanding type on propeller shaft at rear of transmission

Conventional (horizontal) type muffler

Drop tail type, blowing to chassis rearward

Parallel, tapered channel section with reinforcement and crossmembers

24 Volt, regulated control

12 Volt x 2, 65 Ah (234 kC) at 20 hr rate (75D26L)

52 Ah (187 kC) at 5 hr rate (75D26L)

70 lits. (dm

) (15.4 lmp.gals. or 18.5 U.S.gals.)

Finish coat, Natural White

Spec. No. FE71

-D, 2/2

FE71PBD4 SERIES DUMP BODY SPECIFICATIONS

FE71PBD4 SERIES CHASSIS SPECIFICATIONS

BODY TYPE
Body

Floor

thickness

Front panel

thickness

Side panel

thickness

Tail panel

thickness

Type of Tipping Gear
Pump

Type
Capacity

Hoist

Type
Bore x stroke

Tipping Performance

Angle of tip

(approx.)

Lifting time

(approx.)

Lowering time

(approx.)

Drop side & tail

3.2 mm (0.13 in.)
2.3 mm (0.09 in.)
3.2 mm (0.13 in.)
3.2 mm (0.13 in.)

Under body, hydraulic cylinder with link mechanism

Gear type (KPC-25)

24.8 cc/rev (1.52 cu.in./rev)

Single piston type with link

130 mm x 422 mm (5.1 in. x 16.6 in.)

60 degree

20 sec.
20 sec.

ANNOTATION
SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE.

(

)

(

)
