Mitsubishi Fuso Canter. Manual - part 5

Spec. No. FB71, 8/9

CHASSIS LAYOUT

FB71AB8L

NOTE :
These drawings show left hand drive model. For right hand drive model, exterior rear view mirror and windshield wiper on
left and right sides are symmetric with respect to the chassis center line.

7.00-15-6PR

7.00-15-
10PR

2500

1000

1160

4660

2005 (APPROX)

1695

1360

700

1405

985

470

3190

2030

102

Spec. No. FB71, 9/9

FB71A SERIES OPTIONAL EQUIPMENT

CAB

INTERIOR

DIN size radio fitted to instrument panel, electronic tuning type,
with digital clock and one speaker

DIN size radio fitted to instrument panel, electronic tuning type,
with digital clock and two speakers

DIN size radio fitted to instrument panel, electronic tuning type,
with digital clock and cassette player with two speakers

Armrest for driver's seat

Adjustable type

Cigarette lighter

Electric type

Door pockets

Driver and passenger side

Fabric seat

Deluxe type seat

Floor mat

Carpet type. Only for R.H.D. model

Full trim

Side trim, rear pillar trim & rear panel trim. Installing "Seat belts" is necessary

Interior rear view mirror

Flat type

Large room lamp

10W x 1

Overhead shelf

Installed on right side

Seat back tray and

Tray on window side and center passenger seat back,

back panel console

console on back panel

Driver and window side passenger

…

3 point type with ELR

Center

…

2 point type

Sun visor

For window side passenger

Urethane foam steering wheel

Surface material

Urethane foam rubber

EXTERIOR

Fog lamps

White (35W x 2), fitted to front bumper

Under view mirror

Opposite to driver side

INSTRUMENT

Air conditioner

4.18 kW (3,600 kcal

h, 15,070 kJ

h), manual control type, includes heater

and defroster

Heater and defroster

4.47 kW (3,850 kcal

h, 16,116 kJ

h), manual control type

Power windows

Driver and passenger side

Tachometer

Electric driven type

2-DIN box with lid

Total 5-DIN space is provided

CHASSIS

Heavy duty battery

115 Ah (414 kC) at 20 hr rate (130E41L) x 1

92 Ah (331 kC) at 5 hr rate (130E41L) x 1

Lockable fuel tank cap

For protection from fuel thief

Power steering *

Integral type hydraulic power booster

Radial tire

With tube (Including spare tire carrier & spare tire)

Reverse warning buzzer

Synchronized with reverse gear of transmission

Spare tire
Spare tire carrier
Stabilizer, front
Standard tool set

Except for Central and South America

Installing front stabilizer and changing front tire size (6.50-15-8PR

b 7.00-15-6PR) are necessary.

ANNOTATION
SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE.

AM radio

AM/FM radio, stereo

AM/FM radio &

cassette stereo

Seat belts

Spec. No. FE71/73, 1/11

1. Model of Chassis

FE71PB8

2. Body applications classified by model of chassis (

¡: recommendable)

MODEL

TYPE

Cargo Truck

Dump Truck

Aluminum Van

Refrigerated Van

Cargo with Crane

FE71PBN4

FE73PB6

FE73PE6

4,700 (10,360)

5,700 (12,565)

4D34-3A

2,500 (98.4)

3,350 (131.9)

4,400 (9,700)

ANNOTATION
(1) These models are primarily designed for rigid application.

ANNOTATIONS
(1) The following optional equipments must be added when this chassis is used for dump body. (except for telescopic front end type)

・Transmission P.T.O. (on/off control lever type)
・Tire-lug pattern
・Heavy duty springs

(2) These models must not be used for dump or mixer application.
(3) Transmission P.T.O. and its control device are available as optional equipment.
(4) Suitable chassis reinforcement must be added for the cargo with crane or dump body.

FE71PBN4

FE71PB8

¡
¡
¡
¡

¡
¡
¡

FE73PB6

FE73PE6

(1)(4)

(2)

(3)(4)

MODEL

G.V.W.
kg (lb)

ENGINE
(Model)

WHEELBASE
mm (in.)

Spec. No. FE71/73, 2/11

MITSUBISHI FUSO TRUCK CHASSIS
CANTER
FE71P SERIES

TYPE: FORWARD CONTROL, TILT CAB
DRIVE SYSTEM: 4 x 2, CREW: 3
ENGINE: 4D34-3A, DIESEL, 80 kW (109 PS)/3,200 rpm
G. V. W. : 4,400 kg ( 9,700 lb), TIRE: 7.50-15-10PR

G. V. W. :

4,700 kg (10,360 lb), TIRE: 6.50-16-10PR

CHASSIS DIMENSIONS, WEIGHTS AND PERFORMANCE

MODEL

Dimensions mm (in.)

Weights

kg (lb)

Calculated Performance

Wheelbase
Overall length
Overall width
Overall height, approx.
Tread, front
Tread, rear
Ground clearance , approx.
Cab to rear axle
Cab to end of frame
Frame width
Front overhang
Rear overhang

Kerb weight (1)

front
rear

Max. G. V. W.

front
rear

Max. speed

km/h (mph)

Max. gradeability (tan

θ ) %

(with Max. G. V. W.)

Min. turning radius m (ft)

2,500 ( 98.4)
4,630 ( 182.3)
1,695 ( 66.7)
1,995 ( 78.5)
1,390 ( 54.7)
1,235 ( 48.6)

190 ( 7.5)

2,030 ( 79.9)
3,105 ( 122.2)

700 ( 27.6)

1,000 ( 39.4)
1,075 ( 42.3)

1,845 ( 4,065)
1,285 ( 2,835)

560 ( 1,235)

4,700 (10,360)
2,000 ( 4,410)
3,300 ( 7,275)

115 (71.5)

45.0

5.1 (16.7)

R . H . D .
L . H . D .

FE71PB8R

FE71PB8L

FE71PBN4R

FE71PBN4L

ANNOTATION
(1) Kerb weights shown are subject to 2.5% variation to allow for production tolerances. Kerb weights include weight of oil,

fuel, coolant but exclude spare tire carrier & bracket, spare tire & disc wheel and standard tool set.

2,500 ( 98.4)
4,660 ( 183.5)
1,695 ( 66.7)
2,005 ( 78.9)
1,390 ( 54.7)
1,380 ( 54.3)

200 ( 7.9)

2,030 ( 79.9)
3,095 ( 121.9)

700 ( 27.6)

1,000 ( 39.4)
1,065 ( 41.9)

1,735 ( 3,825)
1,270 ( 2,800)

465 ( 1,025)

4,400 ( 9,700)
2,000 ( 4,410)
2,560 ( 5,645)

120 (74.6)

47.0

5.1 (16.7)

7.50-15-10PR

1000

2500

1065

4660

2005 (APPROX)

985

470

3095

2030

102
