MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS TSB Revision MULTIPORT FUEL INJECTION (MFI) <3.0L ENGINE> 13B-327 STEP 14. Check the sensor power supply lines. flow through the harness ECM connector (terminal 42) <M/ Q: Is there any failure in the sensor power supply lines? When a failure is found : Repair if necessary. (Refer to GROUP 90, Circuit Diagrams − MFI System <M/T> STEP 15. Check the ground circuit voltage at ECM connector C-55 <A/T>. (2) Turn the ignition switch to the "ON" position. T> and ground by backprobing. • Voltage should be 0.5 volts or less. (4) Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the multi-meter reading below the specified value? YES : Check connectors D-16, C-90, C-28, C-58 <M/T> or C-55 <A/T> and repair or replace as required. Refer . If connectors D-16, C-90, C-28, C-58 <M/T> or C-55 <A/T> are in good condition, check the NO : Go to Step 16. STEP 16. Check ECM connector C-58 <M/T> or PCM C-55 <A/T>. Q: Is there any failure at ECM connector C-58 <M/T> or PCM connector C-55 <A/T>? Connector Inspection . Then go to Step 26. AC002085 HARNESS SIDE <M/T> C-58 <A/T> C-55 AC AC001689 CONNECTOR: C-58 <M/T>, C-55 <A/T> ECM <M/T> C-58 C-55 AO |
