Mitsubishi Eclipse. Technical Information Manual (1994) - part 25





ENGINE <TURBO>   Control System

DIAGNOSTIC SYSTEM

DESCRIPTION OF

 SYSTEM

The engine control module (ECM) monitors its input/
output signals. Some signals are monitored all the
time, and others only under specified conditions.
When an irregularity has continued for a specified
time from when the irregular signal is initially moni-
tored, the engine control module judges that a fault
has occurred.

After detecting a fault, the engine control module
stores its diagnostic trouble code in memory when

it re-detects the same fault in an operation following

the next engine startup.

In regard to the items marked   however, the engine

control module stores the diagnostic trouble code
of any of them the first time the module detects

it.

There are 35 diagnostic items, and the diagnostic
results can be read out with a scan tool.

Moreover, since memorization of the diagnostic

trouble codes is backed up directly by the battery,
the diagnostic results are memorized even if the

ignition key is turned off. The diagnostic trouble
codes will, however, be erased when the battery

terminal or the engine control module connector

is disconnected.
In addition, the diagnostic trouble code can be also
be erased by turning the ignition switch to ON and
sending the diagnostic trouble code erase signal

from the scan tool to the engine control module.

NOTE
If the sensor connector is disconnected with the
ignition switch turned on, the diagnostic trouble code

Data item

Engine coolant temperature

Engine speed

Vehicle speed

Long term fuel trim

Short term fuel trim

Fuel control state

Calculated load value

Diagnostic trouble code associated with the data in
memory

is memorized. In this case, send the diagnostic

trouble code erase signal from the scan tool to the

engine control module and the diagnostic memory
will be erased.

The 35 diagnostic items are provided as follows,
and if plural items are activated, they are all indicated
sequentially from the smallest code number.

NOTE

The diagnostic trouble code of ignition timing adjust-

ment signal is outputted when terminal for ignition

timing adjustment is grounded. Therefore, it is not
abnormal that the code is outputted even when ter-

minal for ignition timing adjustment is grounded for
ignition timing adjustment.

The engine control module stores in memory not
only the diagnostic trouble code of a fault but also
the intra-module RAM data on the engine operating
conditions that existed when it detected the fault.
(The data is called freeze frame data.)
The data shows the engine operating conditions
that existed when the engine control module de-
tected the fault as well as those that existed when
the module did not detect any fault.

However, when the engine control module detects

a misfiring or fuel trim malfunction, it clears the
existing data and stores the new data.
The data can be read by a scan tool and can be
conveniently used in performing fault repetition tests
for troubleshooting.
The data items to be stored in memory are shown

below.

Unit

km/h

 Open loop

Closed loop

l

Open loop   drive condition

l

Open loop   DTC set

l

Closed loop     (rear)

trouble

ENGINE <TURBO>   Control System

Items indicated by Check Engine/Malfunction indicator lamp

NOTE

2.

After lighting the Engine Check/Malfunction

1.

After detecting a fault, the engine control module

 lamp, the

 turns it off when the ECM

(ECM) lights the

 Engine/Malfunction

 lamp when it re-detects the same fault

in an operation following the next engine start.
In regard to the items marked   however, the
ECM lights the Check Engine/Malfunction

 lamp the first time the ECM detects any

of them.

does not detect the same fault in three
tive operations (provided that the operations
are inclusive of power train component monitor
and that if the fault is a misfiring or fuel trim
malfunction, it occurs at the second and
quent times under much the same operating
conditions as at the first time), each following
an engine start.

Engine control module (ECM) malfunction

Volume air flow circuit malfunction

Barometric pressure circuit malfunction

Intake air temperature circuit malfunction

Engine coolant temperature circuit malfunction

Throttle position circuit malfunction

Excessive time to enter closed loop fuel control*

 sensor circuit malfunction (bank 1 sensor 1)

 sensor heater circuit malfunction (bank   sensor 1)

 sensor circuit malfunction (bank 1 sensor 2)

 sensor heater circuit malfunction (bank 1 sensor2)

Fuel trim malfunction (bank 1)

Injector circuit malfunction   cylinder 1

 circuit malfunction   cylinder 2

Injector circuit malfunction   cylinder 3

Injector circuit malfunction   cylinder 4

Random misfire detected*

Cylinder 1 misfire detected*

Cylinder 2 misfire detected*

Cylinder 3 misfire detected*

Cylinder 4 misfire detected*

Crankshaft position sensor circuit malfunction

Camshaft position sensor circuit malfunction

Exhaust gas recirculation

 malfunction

Catalytic efficiency below tlhreshold (bank 1)

Evaporative emission control system malfunction

Idle control system malfunction

Transmission*

Caution
When the Check Engine/Malfunction indicator

lamp lights because of a fault in the ECM, no

diagnostic trouble code can be read because

of disruption of communications between the
scan tool and ECM.

ENGINE

   Control System

DIAGNOSTIC TROUBLE CODES

The diagnostic items are shown in the following table.

Diagnostic trouble code No.

General scan tool

mode

Scan tool mode

PO1 00

PO100

PO105

PO105

PO110

PO110

PO115

PO115

PO1 20

PO120

PO1 25

PO1 30

PO1 35

PO136

PO141

PO1 70

PO201

PO201

PO202

PO202

PO203

PO203

PO204

PO204

PO300

PO301

PO302

PO303

PO304

PO325

PO325

PO335

PO335

PO340

PO340

PO400



PO420

PO440

PO443

Diagnostic items

Volume air flow circuit malfunction

Barometric pressure circuit malfunction

Intake air temperature circuit malfunction

Engine coolant temperature circuit malfunction

Throttle position circuit malfunction

Excessive time to enter closed loop fuel control*

 sensor circuit malfunction (bank 1 sensor 1)

 sensor heater circuit malfunction (bank 1 sensor 1)

 sensor circuit malfunction (bank 1 sensor 2)

 sensor heater circuit malfunction (bank 1 sensor 2)

Fuel trim malfunction (bank 1)

Injector circuit malfunction   Cylinder 1

Injector circuit malfunction   Cylinder 2

Injector circuit malfunction   Cylinder 3

Injector circuit malfunction   Cylinder 4

Random misfire detected*

Cylinder 1 misfire detected*

Cylinder 2 misfire detected*

Cylinder 3 misfire detected*

Cylinder 4 misfire detected*

Knock sensor 1 circuit malfunction

Crankshaft position sensor circuit malfunction

Camshaft position sensor circuit malfunction

Exhaust gas recirculation flow malfunction

Catalyst efficiency below threshold (bank 1)

Evaporative emission control system malfunction

Evaporative emission control system purge control valve circuit
malfunction

PO500

PO500

Vehicle speed sensor malfunction

NOTE:

 ECM stores the DTC in memory at the first detection of the malfunction.

ENGINE <TURBO>   Control Svstem

Diagnostic trouble code No.

General scan tool

mode

Scan tool mode

Diagnostic items

PO505

PO700

PO600

Idle control system malfunction

A cable from transmission control module for transmission of
torque reduction signal

Transmission*

Ignition timing adjustment circuit malfunction

Manifold Differential Pressure (MDP) sensor circuit malfunction

 Generator FR terminal circuit malfunction

NOTE:

 ECM stores the DTC in memory at the first detection of the malfunction.

SERVICE DATA REFERENCE TABLE
There are two modes for reading service data, general scan tool mode and scan tool (MUT-II) mode.

The service data readable in each mode is as follows.

Item No.

Inspection item

11

Heated oxygen sensor (Front)

12

Volume air flow sensor

13

Intake air temperature sensor

14

Throttle position sensor

16

Power supply voltage

18

Cranking signal (Ignition switch-ST)

21

Engine coolant temperature sensor

22

Crankshaft position sensor

2 4

Vehicle speed sensor

25

Barometric pressure sensor

26

Closed throttle position switch

27

Power steering pressure switch

28

A/C switch

29

Park/Neutral position switch

33

Electrical load switch

41

Injectors

44

Ignition coils and ignition power transistor

45

Idle air control (stepper) position

49

A/C compressor clutch relay

X

X

X

X

X

X

X

X

X

X

X

X

X

X

X

X

X

X

X

X

X

X

X

X

X
