TOWING AND HOISTING

TSB Revision

GENERAL

00-27

SAFETY PRECAUTIONS
The following precautions should be taken when towing the
vehicle:

1. DO NOT LIFT OR TOW THE VEHICLE BY ATTACHING

TO OR WRAPPING AROUND THE BUMPER.

2. Any loose, protruding, or damaged parts such as hoods,

doors, fenders, trim, etc. should be secured or removed
prior to moving the vehicle.

3. Operator should refrain from going under a vehicle when it

is lifted by the towing equipment, unless the vehicle is ade-
quately supported by safety stands.

4. Never allow passengers to ride in a towed vehicle.
5. State and local rules and regulations must be followed when

towing a vehicle.

TOWING AND HOISTING

TSB Revision

GENERAL

00-28

LIFTING, JACKING SUPPORT LOCATION

.

FLOOR JACK

CAUTION

• Never support any point other than the specified one,

or that point will be deformed.

• For lifting, put rubber or similar material between the

side sill and rigid rack, or the side sill area will be dam-
aged.

.

AC000072 AB

RIGID RACK

NOTCH

NOTCH

RUBBER

RUBBER

TOWING AND HOISTING

TSB Revision

GENERAL

00-29

POST TYPE
Special care should be taken when raising the vehicle on a
frame contact type hoist. The hoist must be equipped with the
proper adapters in order to support the vehicle at the proper
locations.

CAUTION

When service procedures require removing rear suspen-
sion, fuel tank and spare tire, place additional weight on
rear end of vehicle or anchor vehicle to hoist to prevent
tipping when the location of the center of gravity changes.

AC000073

NOTCH

NOTCH

AB

GENERAL DATA AND SPECIFICATIONS

TSB Revision

GENERAL

00-30

GENERAL DATA AND SPECIFICATIONS

M1001000900451

<ECLIPSE >

.

GENERAL SPECIFICATIONS (Model with 2.4L Engine)

AC002714

1

2

3

4

5

6

7

8

9

AB

ITEMS

RS
MNJEL4M/5M/
9M

RS
MRJEL4M/5M/
9M

GS
MNHEL4M/5M
/9M

GS
MRHEL4M/5M
/9M

Vehicle
dimension mm
(in)

Overall length

1

4,490 (176.8)

4,490 (176.8)

4,490 (176.8)

4,490 (176.8)

Overall width

2

1,750 (68.9)

1,750 (68.9)

1,750 (68.9)

1,750 (68.9)

Overall height
(unladen)

3

1,310 (51.6)

1,310 (51.6)

1,310 (51.6)

1,310 (51.6)

Wheelbase

4

2,560 (100.8)

2,560 (100.8)

2,560 (100.8)

2,560 (100.8)

Tread-front

5

1,510 (59.4)

1,510 (59.4)

1,510 (59.4)

1,510 (59.4)

Tread-rear

6

1,510 (59.4)

1,510 (59.4)

1,510 (59.4)

1,510 (59.4)

Overhang-front

7

1,010 (39.8)

1,010 (39.8)

1,010 (39.8)

1,010 (39.8)

Overhang-rear

8

920 (36.2)

920 (36.2)

920 (36.2)

920 (36.2)

Minimum running
ground
clearance

9

148 (5.8)

148 (5.8)

148 (5.8)

148 (5.8)

Vehicle weight
kg (lb)

Curb weight

1,320 (2,910)

1,350 (2,976)

1,345 (2,965)

1,375 (3,031)

Gross vehicle weight
rating

1,750 (3,859)

1,750 (3,859)

1,750 (3,859)

1,750 (3,859)

Gross axle weight
rating-front

1,005 (2,216)

1,005 (2,216)

1,005 (2,216)

1,005 (2,216)

Gross axle weight
rating-rear

795 (1,753)

795 (1,753)

795 (1,753)

795 (1,753)

Seating capacity

4

Engine

Model No.

4G64

Displacement

2.4L

Transaxle

Model No.

F5M42

F4A42

F5M42

F4A42

Type

5-speed
manual

4-speed
automatic

5-speed
manual

4-speed
automatic

Fuel system

Fuel supply system

Electronic controlled multiport fuel injection
