MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS

TSB Revision

MULTIPORT FUEL INJECTION (MFI) <2.4L>

13A-689

(2) Measure the voltage between terminal No. 80 <M/T> or No.

66 <A/T> and ground by backprobing.

• Voltage should be battery positive voltage.

Q: Is battery positive voltage (approximately 12 volts)

present?
YES : Go to Step 5.
NO :  Go to Step 3.

AK101116

7172 73 74 75 76 77 7879 80 81

82 8384 85 86 87 88 89 90

92

91

AI

<M/T>

C-60 HARNESS
CONNECTOR:
HARNESS SIDE

AK000731

C-54 HARNESS
CONNECTOR:
HARNESS SIDE

46
57
66

45
56
65

44
55

43
49

54

64

42
48
59

41
47
58

53
63

52
62

51
61

50
60

AS

<A/T>

MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS

TSB Revision

MULTIPORT FUEL INJECTION (MFI) <2.4L>

13A-690

STEP 3. Measure the backup power supply voltage at ECM
harness side connector C-60 <M/T> or PCM harness side
connector C-54 <A/T>.
(1) Disconnect the ECM connector C-60 <M/T> or PCM

connector C-54 <A/T> and measure at the harness side.

AK300415

82

78

8180

89

90

91

92

79

87

71

74 73 72

76 75

77

85

88

83

84

86

CONNECTOR: C-60 <M/T>

AB

C-60 (G)

HARNESS CONNECTOR:
COMPONENT SIDE

AK300412

42

43

48

49

50

51

52

53

54

55

56

57

46 45 44

58

59

60

61

62

63

64

65

66

47

41

C-54 (GR)

CONNECTOR: C-54 <A/T>

AB

HARNESS CONNECTOR:
COMPONENT SIDE

MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS

TSB Revision

MULTIPORT FUEL INJECTION (MFI) <2.4L>

13A-691

(2) Measure the voltage between terminal No. 80 <M/T> or No.

66 <A/T> and ground.

• Voltage should be battery positive voltage.

Q: Is battery positive voltage (approximately 12 volts)

present?
YES : Go to Step 4.
NO :  Check connector C-07 at intermediate connector for

damage, and repair or replace as required. Refer to
GROUP 00E, Harness Connector Inspection

P.00E-2

. If intermediate connector are in good

condition, repair harness wire between relay box (9)
and ECM connector C-60 (terminal No. 80) <M/T> or
PCM connector C-54 (terminal No. 66) <A/T>
because of open circuit or short circuit to ground.
Then go to Step 6.

AK000403 AN

71

72

73

74

75

76

77

78

79

80

81

82

83

84

85

86

87

88

89

90

91

92

<M/T>

C-60 HARNESS
CONNECTOR:
COMPONENT SIDE

AKX01436

46 45 44
57 56 55
66 65 64

54 53 52 51 50 49 48 47

43 42 41

63 62 61 60

59 58

C-54 HARNESS
CONNECTOR:
COMPONENT SIDE

<A/T>

BG

MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS

TSB Revision

MULTIPORT FUEL INJECTION (MFI) <2.4L>

13A-692

STEP 4. Check connector C-60 at ECM <M/T> or connector
C-54 at PCM <A/T> for damage.
Q: Is the harness connector in good condition?

YES : Check connector C-07 at intermediate connector for

damage, and repair or replace as required. Refer to
GROUP 00E, Harness Connector Inspection

P.00E-2

. If intermediate connector are in good

condition, repair harness wire between relay box (9)
and ECM connector C-60 (terminal No. 80) <M/T> or
PCM connector C-54 (terminal No. 66) <A/T>
because of harness damage. Then go to Step 6.

NO :  Repair or replace it. Refer to GROUP 00E, Harness

Connector Inspection

P.00E-2

. Then go to Step 6.

AK300415

82

78

8180

89

90

91

92

79

87

71

74 73 72

76 75

77

85

88

83

84

86

CONNECTOR: C-60 <M/T>

AB

C-60 (G)

HARNESS CONNECTOR:
COMPONENT SIDE

AK300412

42

43

48

49

50

51

52

53

54

55

56

57

46 45 44

58

59

60

61

62

63

64

65

66

47

41

C-54 (GR)

CONNECTOR: C-54 <A/T>

AB

HARNESS CONNECTOR:
COMPONENT SIDE
