TROUBLESHOOTING

MULTIPORT FUEL INJECTION (MPI) <4G1>

13B-25

Code No. P0090: Fuel Pressure control Solenoid Valve System

AK402717

3

1

2

4

19

21

20

18

17

16

15

14

1213

11

8 9

L

10

37
52 53 54 555657585960616263646566

38 39 404142434445464748495051

22 23 24 252627282930313233343536

7

5

3

1

6

4

2

1 2

Fuel pressure solenoid valve

1

2

57

Engine-ECU

G-W

Wire colour code
B: Black  LG: Light green  G: Green  L: Blue  W: White  Y: Yellow  SB: Sky blue  BR: Brown  O: Orange  GR: Gray
R: Red  P: Pink  V: Violet

AE

Fuel Pressure Solenoid Valve Circuit

J/B

Engine
control
relay

4

2

3

1

6

4

To engine-ECU

R

R

B-106

B-112

A-17

1

1

R

Fusible link

16

20A

B-108

A-114

     A-136
(MU802722)

Main

Index

Group

TOC

TROUBLESHOOTING

MULTIPORT FUEL INJECTION (MPI) <4G1>

13B-26

OPERATION

• Power is supplied to the fuel pressure control

solenoid valve (terminal No. 1) from the engine
relay (terminal No. 4).

• The engine-ECU (terminal No. 57) makes the

power transistor in the unit be in ON position, and
that makes currents go to the fuel pressure con-
trol solenoid valve (terminal No. 2).

FUNCTION

• In response to a signal from the engine-ECU, the

fuel pressure control solenoid valve switches the
introduction pressure into the fuel pressure regu-
lator between negative pressure of the intake
manifold and barometric pressure.

TROUBLE JUDGMENT

Check Condition

• While engine running

• Battery voltage is more than 10 V and is less than

16 V.

Judgement Criterion

• Surge voltage cannot be detected within the time

when the fuel pressure solenoid valve has
changed from ON to OFF.

PROBABLE CAUSES

• Failed fuel pressure control solenoid valve

• Open/short circuit in fuel pressure control sole-

noid valve circuit or loose connector contact

• Failed engine-ECU

DIAGNOSIS PROCEDURE

STEP 1. M.U.T.-III actuator test

• Item 09: Fuel pressure control solenoid valve

OK: Operating sound can be heard and the
valve vibrates.

Q: Is the check result normal?

YES :

Intermittent malfunction (Refer to GROUP

00

− How to Use

Troubleshooting/Inspection Service Points

−

How to Cope with Intermittent Malfunctions

P.00-13

).

NO :

Go to Step 2 .

STEP 2. Connector check: A-136 fuel pressure
control solenoid valve connector

Q: Is the check result normal?

YES :

Go to Step 3 .

NO :

Repair or replace.

STEP 3. Perform resistance measurement at
A-136 fuel pressure control solenoid valve
connector.

• Disconnect connector, and measure at solenoid

valve side.

• Resistance between Terminals No. 1 and No. 2.

OK: 29

− 35 Ω (at 20°C)

Q: Is the check result normal?

YES :

Go to Step 4 .

NO :

Replace fuel pressure control solenoid
valve.

AK402120

1

2

AC

Connector: A-136

Harness side
connector

A-136(B)

AK402120

1

2

AC

Connector: A-136

Harness side
connector

A-136(B)

Main

Index

Group

TOC

TROUBLESHOOTING

MULTIPORT FUEL INJECTION (MPI) <4G1>

13B-27

STEP 4. Perform voltage measurement at A-136
fuel pressure control solenoid valve connector.

• Disconnect connector and measure at harness

side.

• Ignition switch: ON

• Voltage between Terminal No. 1 and earth.

OK: System voltage

Q: Is the check result normal?

YES :

Go to Step 6 .

NO :

Go to Step 5 .

STEP 5. Connector check: B-106 engine control
relay connector

Q: Is the check result normal?

YES :

Check intermediate connectors A-17 and

B-112, and repair if necessary. If
intermediate connectors are normal, check
and repair harness between A-136 (terminal
No. 1) fuel pressure control solenoid valve
connector and B-106 (terminal No. 4)
engine control relay connector.

• Check power supply line for

open/short circuit.

NO :

Repair or replace.

AK402120

1

2

AC

Connector: A-136

Harness side
connector

A-136(B)

3

2

1

4

AK402084

J/B side
connector

B-106

Connector: B-106
J/B (front side)

AC

AK402120

1

2

AC

Connector: A-136

Harness side
connector

A-136(B)

Main

Index

Group

TOC

TROUBLESHOOTING

MULTIPORT FUEL INJECTION (MPI) <4G1>

13B-28

STEP 6. Perform voltage measurement at A-114
