DIAGNOSIS CONTROLLER AREA NETWORK (CAN) 54D-590 disconnected. (4) Continuity between C-37 jumper connector terminal No.4 and C-07 centre display connector terminal No.5 OK: 2 ohms or less (5) Continuity between C-37 jumper connector terminal No.3 and C-07 centre display connector OK: 2 ohms or less CAUTION Strictly observe the specified wiring harness Q: Are the check result normal? YES : <All the resistances measure 2 Ω or less> Power supply to the centre display NO : <Either or all of the voltages measure more Ω> Repair the wiring harness between the jumper connector and the AC312553 Test Harness side: C-07 Test Harness side: C-37 BM AC312553 Harness side: C-07 Test Test Harness side: C-37 BN |
