IMMOBILIZER SYSTEM

CIRCUIT DIAGRAMS

90-173

IMMOBILIZER SYSTEM

IMMOBILIZER SYSTEM <LHD>

M1901013605083

FUSIBLE
LINK

23

FRONT
SIDE

ENGINE
CONTROL
RELAY

POWER
SOURCE

RELAY
BOX

BATTERY
BACK-UP

ENGINE-
ECU

Wire colour code
B : Black     LG : Light green     G : Green     L : Blue     W : White
Y : Yellow     SB : Sky blue     BR : Brown     O : Orange     GR : Grey
R : Red     P : Pink     V : Violet     PU : Purple     SI : Silver

J/B SIDE

IGNITION
SWITCH (IG1)

FUSIBLE
LINK

20

DIAGNOSIS
CONNECTOR

POWER SOURCE

KEY REMINDER
SWITCH

IGNITION KEY
RING ANTENNA

TRANSPONDER

IGNITION
KEY

ETACS-ECU

·CRUISE CONTROL SYSTEM
·DOOR AJAR WARNING BUZZER
·ENGINE CONTROL SYSTEM
·GLOW SYSTEM
·HEADLAMP
·METER AND GAUGE
·MMCS
·REAR DIFFERENTIAL LOCK SYSTEM
·RV METER
·SEAT BELT WARNING BUZZER
·TAIL LAMP, POSITION LAMP,
 LICENCE PLATE LAMP AND
 LIGHTING MONITOR BUZZER
 <VEHICLES WITH REAR BODY>
·WINDSHIELD WIPER AND WASHER

IMMOBILIZER SYSTEM

CIRCUIT DIAGRAMS

90-174

IMMOBILIZER SYSTEM <RHD>

M1901013605094

FUSIBLE
LINK

23

FRONT
SIDE

ENGINE
CONTROL
RELAY

POWER
SOURCE

RELAY
BOX

BATTERY
BACK-UP

ENGINE-
ECU

Wire colour code
B : Black     LG : Light green     G : Green     L : Blue     W : White
Y : Yellow     SB : Sky blue     BR : Brown     O : Orange     GR : Grey
R : Red     P : Pink     V : Violet     PU : Purple     SI : Silver

J/B SIDE

IGNITION
SWITCH (IG1)

FUSIBLE
LINK

20

DIAGNOSIS
CONNECTOR

POWER SOURCE

KEY REMINDER
SWITCH

IGNITION KEY
RING ANTENNA

TRANSPONDER

IGNITION
KEY

ETACS-ECU

·CRUISE CONTROL SYSTEM
·DOOR AJAR WARNING BUZZER
·ENGINE CONTROL SYSTEM
·GLOW SYSTEM
·HEADLAMP
·METER AND GAUGE
·MMCS
·REAR DIFFERENTIAL LOCK SYSTEM
·RV METER
·SEAT BELT WARNING BUZZER
·TAIL LAMP, POSITION LAMP,
 LICENCE PLATE LAMP AND
 LIGHTING MONITOR BUZZER
 <VEHICLES WITH REAR BODY>
·WINDSHIELD WIPER AND WASHER

CRUISE CONTROL SYSTEM

CIRCUIT DIAGRAMS

90-175

CRUISE CONTROL SYSTEM

CRUISE CONTROL SYSTEM <LHD>

M1901032901906

23

FUSIBLE
LINK

RELAY
BOX

ENGINE
CONTROL
RELAY

POWER
SOURCE

·ENGINE
 CONTROL
 SYSTEM
·GLOW
 SYSTEM

20

FUSIBLE
LINK

IGNITION
SWITCH (IG1)

COMBINATION
METER

BATTERY
BACK-UP

ENGINE-
ECU

ACCELERATOR
PEDAL
POSITION
SENSOR

HALL IC

(MAIN)

HALL IC

(SUB)

THROTTLE
VALVE
CONTROL
SERVO

THROTTLE POSITION
SENSOR

ELECTRONIC-CONTROLLED
THROTTLE VALVE

HALL IC

HALL IC

ENGINE-
ECU

CRUISE CONTROL SYSTEM

CIRCUIT DIAGRAMS

90-176

CRUISE CONTROL SYSTEM <LHD> (CONTINUED)

VEHICLE SPEED
SENSOR

<M/T>

CLUTCH
SWITCH

STOP LAMP

ELC-4A/T

RELAY BOX

(FUSE     )

12

STOP
LAMP
SWITCH

ENGINE-ECU

ENGINE
CONTROL
RELAY

CLOCK
SPRING

ENGINE-ECU

CRUISE
CONTROL
SWITCH

·MMCS
·RADIO AND
 CD PLAYER
·SPARE CONNECTOR
 (FOR AUDIO)

TAIL LAMP
RELAY

ETACS-
ECU

J/B SIDE

NOTE

EXCEPT EURO5
EURO5

CRUISE CONTROL SYSTEM <LHD> (CONTINUED)

DIAGNOSIS
CONNECTOR

(FUSE     )

12

ENGINE-ECU

A/T-ECU

<A/T>

<VEHICLES WITH ASTC>

ASTC-ECU

FRONT
SIDE

INPUT SIGNAL

INHIBITOR
SWITCH (N)
