VEHICLE IDENTIFICATION

GENERAL

00-20

MANUFACTURER PLATE

M1001017600399

AC508918AB

The manufacturer plate is riveted to the cowl top
outer panel in the engine compartment.

AC511709

1

2

3

4

5

AB

6

7

No.

Content

1

Chassis No. (Vehicle identification number)

2

Gross vehicle weight

3

Gross combination weight

4

Gross axle weight front

5

Gross axle weight rear

6 or 7 NTA No. (National type approval number)

ENGINE MODEL STAMPING

M1001005700861

AC507123AD

Front suspension upper arm <left side>

The engine model is stamped on the cylinder block.
This engine model numbers is as shown as follow.

Engine model

Engine displacement

4D56

2,477 mL

The engine serial number is stamped near the
engine model number.

Engine serial number

AA0201 to YY9999

No.

Content

GENERAL DATA AND SPECIFICATIONS

GENERAL

00-21

GENERAL DATA AND SPECIFICATIONS

GENERAL DATA AND SPECIFICATIONS
<VEHICLES FOR EUROPE>

M1001000906642

SINGLE CAB

AC805672

1

2

3

4

5

6

7

9

8

12

10

11

13

Item

KA4T

KB4T

NENMZL6

NENMZL6/NENMZR6

Vehicle
dimension mm

Front track

1

1,505

1,505

Overall width

2

1,750

1,750

Front overhang

3

830

830

Wheel base

4

3,000

3,000

Rear overhang

5

1,210

1,210

Overall length

6

5,040

5,040

Ground clearance (unladen)

7

200

200

Overall height (unladen)

8

1,655

1,775

Rear track

9

1,500

1,500

Cargo bed interior length

10 2,220

2,220

Cargo bed interior width

11 1,470

1,470

Cargo bed interior height

12 405

405

Cargo floor height (unladen)

13 715

845

Vehicle weight
kg

Kerb
weight

Without optional parts

1,565

1,780 <LHD>
1,770 <RHD>

With full optional parts

1,595

1,840 <LHD>
1,810 <RHD>

Max. gross vehicle weight

2,630

2,850 <LHD>
2,890 <RHD>

Max. axle weight rating-front

1,030

1,260

Max. axle weight rating-rear

1,700

1,800

Max. towable
weight

With brake

1,800

2,700

Without brake

750

750

Max. trailer-nose weight

77

115

Max. gross combination weight

4,400

5,500 <LHD>
5,540 <RHD>

GENERAL DATA AND SPECIFICATIONS

GENERAL

00-22

NOTE:

.

•

Trailer specifications indicate the manufacturer’s recommendation.

•

When loading luggage and/or towing a trailer, make sure not to exceed any of the above maximum
weights all the time.

CLUB CAB

AC805455

1

2

3

4

5

6

7

9

8

12

10

13

11

Seating capacity (including a driver)

2

2

Engine

Model code

4D56

4D56

Total displacement mL

2,477

2,477

Type

DOHC diesel
Intercooled,
Turbocharger

DOHC diesel
Intercooled,
Turbocharger

Max. output kW/rpm (EEC net)

94/4,000

100/4,000

Max. torque N

⋅m/rpm (EEC net)

240/1,500

− 3,500

314/2,000

Transmission

Model code

R5MB1

V5MB1

Type

5M/T

5M/T

Drive system

Rear wheel drive 2WD

Easy select 4WD

Fuel system

Fuel supply system

Electrical fuel injection

Electrical fuel injection

Turning radius
m

Body

6.1

6.3

Wheel

5.7

5.9

Item

KA4T

KB4T

NENMZL6

NENMZL6/NENMZR6

Item

KB4T
NCNUZL6/NCNUZR6

GCNXZL6

Vehicle
dimension mm

Front track

1

1,505

1,520

Overall width

2

1,750

1,815

Front overhang

3

795

795

Wheel base

4

3,000

3,000

Rear
overhang

Without rear bumper

5

1,325

1,325

With rear bumper

1,400

1,400

Overall
length

Without rear bumper

6

5,120

5,120

With rear bumper

5,195

5,195

Ground clearance (unladen)

7

200

205

Overall height (unladen)

8

1,775/1,790*

1,780

Rear track

9

1,500

1,515

Cargo bed interior length

10 1,805

1,805

Cargo bed interior width

11 1,470

1,470

Cargo bed interior height

12 460

460

Cargo floor height (unladen)

13 855

860

Vehicle weight
kg

Kerb
weight

Without optional parts

1,800

1,815

With full optional parts

1,900 <LHD>
1,880 <RHD>

1,910

Max. gross vehicle weight

2,850

2,850

Max. axle weight rating-front

1,260

1,260

Max. axle weight rating-rear

1,800

1,800

Max. towable
weight

With brake

2,700

2,700

Without brake

750

750

Max. trailer-nose weight

115

115

Max. gross combination weight

5,500

5,500

Seating capacity (including a driver)

4

4

Engine

Model code

4D56

4D56

Total displacement mL

2,477

2,477

Type

DOHC diesel
Intercooled,
Turbocharger

DOHC diesel
Intercooled,
Turbocharger

Max. output kW/rpm (EEC net)

100/4,000

100/4,000

Max. torque N

⋅m/rpm (EEC net)

314/2,000

314/2,000

Transmission

Model code

V5MB1

V5MB1

Type

5M/T

5M/T

Drive system

Easy select 4WD

Super select 4WD

Fuel system

Fuel supply system

Electrical fuel injection

Electrical fuel injection

Turning radius
m

Body

6.3

6.3

Wheel

5.9

5.9
