287

Practical hints

Fuses

왔

Fuses

The fuse chart is printed on the corre-
sponding fuse box cover. The amperages
of the fuses are also indicated there.

Fuse box in engine compartment

The fuse box is located in the engine com-
partment on the left-hand side.

1 Clamps
2 Fuse box cover

Removing / installing cover

왘

Release clamps 1.

왘

Lift fuse box cover 2 up.

왘

Install cover 1 in reverse order.

3 Fuse chart
4 Fuse extractor
5 Spare fuses

i

Only install fuses that have been tested
and approved by Mercedes-Benz and
that have the specified amperage rat-
ing.

Never attempt to repair or bridge a
blown fuse. Have the cause determined
and remedied by an authorized
Mercedes-Benz Light Truck Center.

288

Practical hints

Fuses

Auxiliary fuse box in front passenger
footwell

The auxiliary fuse box is located in the
front passenger compartment.

1 Lock
2 Cover

Removing / installing cover

왘

Turn both locks 1 90° counterclock-
wise.

왘

Remove cover 2 in direction of arrow.

왘

Install cover 2 in reverse order.

289

Technical data

Spare parts service

Warranty coverage

Identification labels

Layout of poly-V-belt drive

Engine

Rims and tires

Electrical system

Main Dimensions

Weights

Fuels, coolants, lubricants etc.

Consumer information

290

Technical data

Spare parts service

왔

The “Technical data” section provides the
necessary technical data for your vehicle.

Spare parts service

All authorized Mercedes-Benz Centers
maintain a stock of genuine
Mercedes-Benz Parts parts required for
maintenance and repair work. In addition,
strategically located parts distribution cen-
ters provide quick and reliable parts ser-
vice.

More than 300 000 different spare parts
for Mercedes-Benz models are available.

Genuine Mercedes-Benz spare parts are
subjected to stringent quality inspections.
Each part has been specifically developed,
manufactured or selected for and adapted
to Mercedes-Benz vehicles.

Therefore, genuine Mercedes-Benz spare
parts should be installed.

!

The use of non-genuine Mercedes-Benz
parts and accessories not authorized
by Mercedes-Benz could damage the
vehicle, which is not covered by the
Mercedes-Benz Limited Warranty, or
could compromise the vehicle’s dura-
bility or safety.
