When Driving

i-ACTIVSENSE

the front doors to about 50 m (164 ft)

^ The BSM will not operate under the

behind the vehicle.

following circumstances.

^ The vehicle speed falls below

about 10 km/h (6.3 mph) even

though the i-ACTIVSENSE warning

indication/warning light is turned

off.

^ The selector lever is shifted to

reverse (R) and the vehicle is

reversing.

^ The turning radius is small (making

a sharp turn, turning at

intersections).

^ In the following cases, the

1. Your vehicle

i-ACTIVSENSE warning indication/

2. Detection areas

warning light turns on and operation

of the system is stopped. If the

WARNING

i-ACTIVSENSE warning indication/

warning light remains illuminated,

Always check the surrounding area

have the vehicle inspected at an

visually before making an actual lane

Authorized Mazda Dealer as soon as

change:

possible.

The system is only designed to assist

you in checking for vehicles at your rear

^ Some problem with the system

when making a lane change. Due to

including the BSM warning

certain limitations with the operation

indicator lights is detected.

of this system, the BSM warning

^ A large deviation in the installation

indicator light, the warning sound and

position of a rear side radar sensor

the warning screen indicator display

on the vehicle has occurred.

may not activate or they might be

^ There is a large accumulation of

delayed even though a vehicle is in an

snow or ice on the rear bumper

adjacent driving lane. Always make it

near a rear side radar sensor.

your responsibility as a driver to check

Remove any snow, ice or mud on

the rear.

the rear bumper.

^ Driving on snow-covered roads for

NOTE

long periods.

^ The temperature near the rear side

^ The BSM will operate when all of the

radar sensor becomes extremely

following conditions are met:

hot due to driving for long periods

^ The power switch is switched ON.

on slopes during the summer.

^ The i-ACTIVSENSE warning

^ The lead-acid battery voltage has

indication/warning light in the

decreased.

instrument cluster is turned off.

^ Under the following conditions, the

^ The vehicle speed is about 10

rear side radar sensor cannot detect

km/h (6.3 mph) or faster.

target objects or it may be difficult to

detect them.

4-88

When Driving

i-ACTIVSENSE

Objects such as guardrails and

^ A BSM warning indicator light may

concrete walls running alongside

flash or the warning beep may be

the vehicle.

activated several times when making

a turn at a city intersection.

^ Turn off the BSM while pulling a

trailer or while an accessory such as a

bicycle carrier is installed to the rear

of the vehicle. Otherwise, the radar’s

radio waves will be blocked causing

the system to not operate normally.

^ In the following cases, it may be

Places where the width between

difficult to view the illumination/

guardrails or walls on each side of

flashing of the BSM warning

the vehicle narrows.

indicator lights equipped on the

door mirrors.

^ Snow or ice is adhering to the door

mirrors.

^ The front door glass is fogged or

covered in snow, frost or dirt.

^ The rear side radar sensor of the BSM

may be regulated under the radio

wave related laws of the country

The walls at the entrance and exits

where the vehicle is driven. If this

of tunnels, turnouts.

system is used abroad, it may be

necessary to turn off the system.

Refer to Rear Side Radar Sensor on

page 4-79.

^ The system switches to the Rear

Cross Traffic Alert (RCTA) function

when the selector lever is shifted to

the reverse (R) position.

Refer to Rear Cross Traffic Alert

(RCTA) on page 4-107.

▼ Blind Spot Monitoring (BSM)

Warning Indicator Lights/Display

Indicator/Blind Spot Monitoring

(BSM) Warning Beep

The BSM system notifies the driver of

the presence of vehicles in adjacent

lanes or at the rear of the vehicle using

the BSM warning indicator light, the

warning sound and the display

indicator while the systems are

operational.

4-90

When Driving

i-ACTIVSENSE

BSM warning indicator lights

Multi-information Display

The BSM warning indicator lights are

equipped on the left and right door

mirrors. The warning indicator lights

turn on when a vehicle approaching

from the rear in an adjacent lane is

detected.

Active Driving Display (vehicles with

active driving display)

When the power switch is switched

The detected direction is displayed

ON, the warning indicator light turns

with a detection indicator (white)

on momentarily and then turns off

when an approaching vehicle is

after a few seconds.

detected. In addition, if the turn signal

Function for canceling illumination

lever is operated to signal a lane

dimmer

change while the vehicle is detected,

the display changes the color (amber)

If the BSM warning indicator lights turn

of the warning indicator.

on when the parking lights are turned

on, the brightness of the BSM warning

BSM warning beep

indicator lights is dimmed.

The BSM warning beep is activated

If the BSM warning indicator lights are

simultaneously with the flashing of a

difficult to see due to glare from

BSM warning indicator light.

surrounding brightness when traveling

on snow-covered roads or under foggy

▼ Canceling Operation of Blind Spot

conditions, press the dimmer

Monitoring (BSM)

cancellation button to cancel the

The BSM system can be set to

dimmer and increase the brightness of

BSM warning indicator lights when

inoperable.

they turn on.



(If only the BSM is turned off)

Refer to Dashboard Illumination on

Refer to the Settings section in the

page 4-14.

Mazda Connect Owner's Manual.



(If the BSM is turned off by

Display indicator

operating the i-ACTIVSENSE OFF

The detected approaching vehicle and

switch)

warning are displayed in the

Refer to i-ACTIVSENSE OFF Switch

multi-information display and active

on page 4-70.

driving display (vehicles with active

driving display).

4-91

When Driving

i-ACTIVSENSE

Traffic Sign Recognition System (TSR)*

▼ Traffic Sign Recognition System (TSR)

The TSR helps prevent the driver from overlooking traffic signs, and provides support

for safer driving by displaying traffic signs on the active driving display/instrument

cluster which are recognized by the Forward Sensing Camera (FSC) or recorded in

the navigation system while the vehicle is driven.

The TSR displays the speed limit (including auxiliary signs), do not enter, and traffic

stop signs.

If the vehicle speed exceeds the speed limit sign indicated in the active driving

display/instrument cluster while the vehicle is driven, the system notifies the driver

using the indication in the active driving display/instrument cluster and a warning

sound.

Speed limit and do not enter signs

1. Sign recognized

2. Sign displayed

3. Active driving display indication

*Some models.

4-93

When Driving

i-ACTIVSENSE

4. Instrument cluster

5. Basic display

6. i-ACTIVSENSE display

7. Recognized speed limit indication color changes.

Stop sign

1. Sign recognized and displayed at same time

2. Active driving display indication

3. Instrument cluster

WARNING

Always check the traffic signs visually while driving:

The TSR helps prevent the driver from overlooking traffic signs and provides support

for safer driving. Depending on the weather conditions or problems with traffic

signs, a traffic sign may not be recognized or a traffic sign different from the actual

traffic sign may be displayed. Always make it your responsibility as a driver to check

the actual traffic signs. Otherwise, it could result in an accident.

NOTE

^ The TSR is not supported in some countries or regions. For information concerning

the supported countries or regions, consult an Authorized Mazda Dealer.

^ The TSR operates only if the navigation system SD card (Mazda genuine) is

inserted in the SD card slot. Consult an Authorized Mazda Dealer for details.

^ The TSR does not operate if there is a malfunction in the Forward Sensing Camera

(FSC).

^ Under the following conditions, the TSR may not operate normally.

4-94

When Driving

i-ACTIVSENSE



An object placed on the dashboard is reflected in the windshield and picked up

by the camera.

^ Heavy luggage is loaded in the luggage compartment or on the rear seat and the

vehicle is tilted.

^ The tire pressures are not adjusted to the specified pressure.

^ Tires other than standard tires are equipped.

^ The vehicle is driven on the ramp and surrounding area to or from a rest area or

a tollgate on a highway.

^ When surrounding brightness suddenly changes such as when entering or exiting

a tunnel.

^ The illumination of the headlights is weakened because of dirt or the optical axis

is deviated.

^ The windshield is dirty or foggy.

^ The windshield and camera are fogged (water droplets).

^ Strong light is directed at the front of the vehicle (such as backlight or high-beam

headlights of on-coming vehicles).

^ The vehicle is making a sharp turn.

^ Strong light reflects off the road.

^ A traffic sign is in a position which makes it difficult to reflect the light from the

vehicle's headlights, such as when the vehicle is driven at night or in a tunnel.

^ The vehicle is driven under weather conditions such as rain, fog, or snow.

^ The stored map data for the navigation system is not current.

^ A traffic sign is obscured by mud or snow.

^ A traffic sign is concealed by trees or a vehicle.

^ A traffic sign is partially shaded.

^ A traffic sign is bent or warped.

^ A traffic sign is too low or too high.

^ A traffic sign is too bright or too dark (including electronic traffic signs).

^ A traffic sign is too big or too small.

^ There is an object similar to the traffic sign being read (such as another traffic

sign or other signs resembling it).

^ The TSR can be set to invisible on the active driving display.

Refer to the Settings section in the Mazda Connect Owner's Manual.

▼ Traffic Sign Display Indication

Stop signs

The following traffic signs are displayed

on the active driving display/

instrument cluster.

NOTE

Speed limit signs

Speed limit signs

^ When the vehicle speed is about 1

km/h (0.6 mph) or faster, the speed

Do not enter signs

limit sign is displayed when any one

of the following conditions are met.

4-95

When Driving

i-ACTIVSENSE

▼ Excessive Speed Warning

If the vehicle speed exceeds the speed limit sign displayed in the active driving

display/instrument cluster, the area around the speed limit sign flashes in amber and

the warning sound is activated at the same time. If the vehicle speed continues to

exceed the displayed speed limit sign, the indication stops flashing and remains on.

Check the surrounding conditions and adjust the vehicle speed to the legal speed

using the appropriate operation such as depressing the brake pedal.

1. Vehicle is doing 55 mph when 50 mph speed limit sign is recognized.

2. Vehicle continues to do 55 mph after 50 mph speed limit sign is recognized.

3. Active driving display indication

4. Instrument cluster

The excessive speed warning is initially set to inoperable. If you want to activate the

excessive speed warning, change the setting in the personalization features. In

addition, the warning pattern and the warning activation timing differ depending on

the setting contents.

Refer to the Settings section in the Mazda Connect Owner's Manual.

Speed Limit Sign Alert setting

^ Off: The excessive speed warning is not activated.

^ Visual: The area around the speed limit sign displayed in the display flashes in

amber, and if the vehicle speed continues to exceed the displayed speed limit

sign, the indication stops flashing and remains on.

^ Visual + Audible: The area around the speed limit sign displayed in the display

flashes in amber and the warning sound is activated at the same time. If the

vehicle speed continues to exceed the displayed speed limit sign, the indication

4-97

When Driving

i-ACTIVSENSE

^ The vehicle ahead is a vehicle with

Distance & Speed Alert

four wheels.

(DSA)*

NOTE

▼ Distance & Speed Alert (DSA)

^ The DSA may also operate in the

presence of motorcycles and

The DSA is designed to assist your

bicycles.

driving using the display indications so

^ The DSA does not operate with the

that the distance between your vehicle

following objects.

and a vehicle ahead can be maintained

appropriately.

^ On-coming vehicles

^ Pedestrians

WARNING

^ Stationary objects (such as

stopped vehicles, obstructions)

Do not rely completely on the DSA

^ If a vehicle ahead is traveling at an

and always drive carefully:

extremely low speed, the system may

The DSA may not be able to detect a

not detect it correctly.

vehicle ahead depending on the type

^ The DSA can be set to inoperable.

of vehicle ahead and its conditions, the

However, when the power switch is

weather conditions, and the road

switched OFF while the DSA is

conditions. In addition, the system is

canceled, the DSA is automatically

not for maintaining the distance

enabled the next time the power

between your vehicle and a vehicle

switch is switched ON.

ahead. If you neglect to operate the

Refer to the Settings section in the

accelerator and brake pedals correctly,

Mazda Connect Owner's Manual.

it could lead to an accident.

Refer to i-ACTIVSENSE OFF Switch

Always check the surrounding

on page 4-70.

conditions and depress the brake

▼ Vehicle Ahead Close Proximity

pedal or accelerator pedal while

Warning

keeping a safe distance from a vehicle

ahead or a vehicle following behind

When the distance between your

you.

vehicle and a vehicle ahead is close,

the i-ACTIVSENSE status symbol

Operation conditions

(Warning/risk avoidance support

The DSA operates when all of the

system) changes from green to amber

following conditions are met.

and the warning indication is displayed

on the multi-information display.

^ The power switch is switched ON.

^ The DSA is on.

^ The selector lever is in a position

other than R.

^ The vehicle speed is about 30 km/h

(19 mph) or faster.

^ i-ACTIVSENSE status symbol

(warning/risk avoidance support

system) (green) is displayed.

*Some models.

4-99

When Driving

i-ACTIVSENSE

Check the surrounding conditions and

Driver Attention Alert

keep a safe distance from the vehicle

ahead.

(DAA)*

▼ Driver Attention Alert (DAA)

The DAA is a system which detects

driver fatigue and decreased

attentiveness, and encourages the

driver to take a rest.

When the vehicle is driven inside traffic

lane lines at about 65 to 140 km/h

(41 to 86 mph), the DAA estimates the

amount of accumulated fatigue and

decreased attentiveness of the driver

based on the information from the

Forward Sensing Camera (FSC) and

other vehicle information, and

encourages the driver to take a rest

using an indication on the

multi-information display and a

warning sound.

Use the DAA on expressways or

highways.

Refer to Forward Sensing Camera

(FSC) on page 4-71.

4-100 *Some models.

When Driving

i-ACTIVSENSE

^ White (yellow) lane lines are less

WARNING

visible because of dirt or fading/

patchiness.

Do not rely completely on DAA and

^ The vehicle is jolted or swayed

always drive carefully:

continuously by strong winds or

The DAA detects driver fatigue and

rough roads.

decreased attentiveness and

^ The vehicle is driven aggressively.

encourages the driver to take a rest,

^ When making frequent lane

however, it is not designed to prevent

changes.

the vehicle from straying. If you rely too

^ The vehicle is making a curve.

much on the DAA it could lead to an

^ The DAA detects driver fatigue and

accident. Drive carefully and operate

decreased attentiveness based on

the steering wheel appropriately.

the driving data when the vehicle is

In addition, the system may not be

driven at about 65 to 140 km/h (41

able to detect driver fatigue and

to 86 mph) for about 20 minutes.

decreased attentiveness correctly

The driving data will be reset under

depending on the traffic and driving

the following conditions.

conditions. The driver must take

sufficient rest in order to drive safely.

^ The vehicle is stopped for 15

minutes or longer.

NOTE

^ The vehicle is driven at less than

about 65 km/h (41 mph) for

^ The DAA operates when all of the

about 30 minutes.

following conditions are met.

^ The power switch is switched off.

^ The vehicle speed is about 65 to

^ After the DAA has displayed the first

140 km/h (41 to 86 mph).

message encouraging rest, it does

^ The system detects white (yellow)

not display the next one until 60

lane lines.

minutes have passed.

^ The system has completed learning

▼ Driver Attention Alert (DAA)

of the driver’s driving data after 60

Display

minutes have passed since the

driver began driving vehicle.

When the system detects driver fatigue

^ The DAA does not operate under the

or decreased attentiveness, it activates

following conditions.

the warning sound and displays an

alert in the multi-information display.

^ The vehicle speed is less than

about 65 km/h (41 mph).

^ The vehicle speed exceeds about

140 km/h (86 mph).

^ The vehicle is making a sharp turn.

^ The vehicle is changing lanes.

^ The system cannot detect white

(yellow) lane lines.

^ The DAA may not operate normally

under the following conditions.

1.

“Time for a Break” message is

displayed

4-101

When Driving

i-ACTIVSENSE

▼ Canceling Driver Attention Alert

Driver Monitoring (DM)

(DAA)

The DAA can be set to inoperable.

▼ Driver Monitoring (DM)

Refer to the Settings section in the

The DM is a system which detects

Mazda Connect Owner's Manual.

driver fatigue and sleepiness, and

encourages the driver to take a rest.

While driving the vehicle at about 5

km/h (3 mph) or faster, the DM

detects changes in the driver's facial

features using the driver monitoring

camera. The system then estimates the

amount of accumulated fatigue and

sleepiness of the driver and encourages

the driver to take a rest using a warning

indication in the instrument cluster and

a warning sound.

Two types of warning indication

patterns are set for notifying the driver

based on the estimated amount of

accumulated fatigue and sleepiness of

the driver.

^ Fatigue and sleepiness are detected:

Warning pattern (caution)

^ Much more fatigue and sleepiness

are detected: Warning pattern

(warning)

4-102 *Some models.

When Driving

i-ACTIVSENSE

^ After displaying the warning

WARNING

pattern (caution), the next warning

pattern (caution) is not displayed

Do not rely completely on the DM

until 45 minutes have passed.

and always drive carefully:

^ After displaying the warning

The DM is a system which detects

pattern (warning), the next

driver fatigue and sleepiness, and

warning pattern (warning) is not

encourages the driver to take a rest.

displayed until 15 minutes have

This is not designed to prevent driver

passed.

fatigue and sleepiness, and

^ After displaying the warning

over-reliance on the system could lead

pattern (warning), the next

to an accident. Drive carefully and turn

warning pattern (caution) is not

the steering wheel appropriately.

displayed until 45 minutes have

In addition, the system may not be

passed.

able to detect driver fatigue and

sleepiness correctly depending on the

▼ Driver Monitoring (DM) Display

traffic and driving conditions. The

When the Driver Monitoring (DM)

driver must take sufficient rest in order

detects driver fatigue or sleepiness, it

to drive safely.

activates the warning sound and

Operation conditions

displays an alert in the instrument

cluster.

The DM begins monitoring after 20

Warning pattern (caution) (white)

minutes have passed since the driver

began driving the vehicle and when

the vehicle speed is about 5 km/h (3

mph) or faster.

NOTE

^ If the vehicle speed decreases to less

than about 5 km/h (3 mph) while

the DM is monitoring, the DM stops

monitoring for 6 minutes even if the

vehicle speed returns to about 5

1.

“Time for a Break” message is

km/h (3 mph) or faster.

displayed

^ If the driver monitoring camera does

not recognize the driver correctly, the

Warning pattern (warning) (amber)

DM may not monitor correctly.

Refer to Driver Monitoring Camera

on page 4-81.

^ After the DM has displayed the first

message encouraging the driver to

take a rest, it does not display it

again during the following periods.

1.

“Time for a Break” message is

displayed

4-103

When Driving

i-ACTIVSENSE

▼ Canceling Driver Monitoring (DM)

Front Cross Traffic Alert

The DM can be set to inoperable.

(FCTA)*

Refer to the Settings section in the

Mazda Connect Owner's Manual.

▼ Front Cross Traffic Alert (FCTA)

The FCTA is designed to assist the

driver in checking both sides of the

vehicle when the vehicle starts to drive

at an intersection.

The FCTA detects vehicles approaching

from the blind spots on the front left

and right sides of the vehicle when the

vehicle starts to drive at an

intersection, and notifies the driver of

possible danger using the warning

indication on the display and the

warning sound.

1. Your vehicle

WARNING

Always check the surrounding area

visually when the vehicle starts to

drive at an intersection:

Due to certain limitations with the

operation of this system, the warning

indication on the display or the

warning sound might be delayed even

though there is a vehicle approaching

from a blind spot. Always make it your

responsibility as a driver to check the

left and right sides.

Operation conditions

The system operates when all of the

following conditions are met:

4-104 *Some models.

When Driving

i-ACTIVSENSE



When your vehicle is driven at less

display (amber arrow) and the warning

than about 10 km/h (6 mph).

sound is activated at the same time.

^ The selector lever is in the D

Multi-information display

position.

^ When a vehicle approaches from the

front side of your vehicle at a vehicle

speed of about 5 km/h (3 mph) or

faster.

FCTA operation

When your vehicle is stopped

When a vehicle is approaching, the

system notifies the driver that a vehicle

is approaching on the following display

Active driving display (vehicles with

(white arrow).

active driving display)

Multi-information display

360°view monitor (vehicles with

360°view monitor)

Active driving display (vehicles with

NOTE

active driving display)

^ The system may operate under the

following conditions even if a vehicle

is not approaching.

^ An object that reflects the radio

360°view monitor (vehicles with

waves of the radar such as a

360°view monitor)

parked vehicle, guardrail, or wall is

directly next to your vehicle.

^ Vehicles are stopped in the area

around your vehicle such as during

heavy traffic.

^ A vehicle approaching from the

front or side of your vehicle slows

When your vehicle is being driven

down.

If there is a possibility of a collision

^ A vehicle approaching from the

with an approaching vehicle, a warning

front or left side of your vehicle

indication is displayed on the following

makes a right or left turn directly in

front of your vehicle.

4-105

When Driving

i-ACTIVSENSE

 (If only the FCTA is turned off)

Rear Cross Traffic Alert

Refer to the Settings section in the

Mazda Connect Owner's Manual.

(RCTA)*

 (If the FCTA is turned off by

operating the i-ACTIVSENSE OFF

▼ Rear Cross Traffic Alert (RCTA)

switch)

The RCTA system is designed to assist

Refer to i-ACTIVSENSE OFF Switch

the driver in checking the area to the

on page 4-70.

rear left and right sides of your vehicle

while your vehicle is reversing by

NOTE

alerting the driver to the presence of

If the power switch is switched OFF

vehicles approaching the rear of your

while you have canceled the system

vehicle.

using the i-ACTIVSENSE OFF switch,

The RCTA system detects vehicles

the system is automatically enabled the

approaching from the rear left and

next time the power switch is switched

right sides of your vehicle and the rear

ON. However, if the system is canceled

of your vehicle while your vehicle is

using [Settings] in Mazda Connect, the

being reversed out of a parking space,

system is not automatically enabled.

and notifies the driver of possible

danger using the Blind Spot Monitoring

(BSM) warning indicator lights and the

warning buzzer.

1. Your vehicle

2. Detection areas

*Some models.

4-107

When Driving

i-ACTIVSENSE

Monitoring (BSM) warning

WARNING

indicator light on the door mirrors.

Always check the surrounding area

visually before actually putting the

vehicle in reverse:

The system is only designed to assist

you in checking for vehicles at the rear

when putting the vehicle in reverse.

Due to certain limitations with the

operation of this system, the Blind Spot

Monitoring (BSM) warning indicator

lights may not flash or it might be

delayed even though a vehicle is

Function for canceling illumination

behind your vehicle. Always make it

dimmer

your responsibility as a driver to check

If the BSM warning indicator lights turn

the rear.

on when the parking lights are turned

RCTA operation

on, the brightness of the BSM warning

indicator lights is dimmed.

1.

The RCTA system operates when

If the BSM warning indicator lights are

the selector lever is shifted to the

difficult to see due to glare from

reverse (R) position.

surrounding brightness when traveling

2.

If there is the possibility of a

on snow-covered roads or under foggy

collision with an approaching

conditions, press the dimmer

vehicle, the Blind Spot Monitoring

cancellation button to cancel the

(BSM) warning indicator lights

dimmer and increase the brightness of

flashes and the warning beep is

BSM warning indicator lights when

activated simultaneously.

they turn on.

Rear view monitor (vehicles with

Refer to Dashboard Illumination on

Rear view monitor)

page 4-14.

The RCTA warning indication in the

rearview monitor also synchronizes

NOTE

with the Blind Spot Monitoring

^ The system may operate under the

(BSM) warning indicator light on

following conditions even if a vehicle

the door mirrors.

is not approaching.

360°view monitor (vehicles with

360°view monitor)

^ An object that reflects the radio

The RCTA warning indication in the

waves of the radar such as a

360°view monitor also

parked vehicle, guardrail, or wall is

synchronizes with the Blind Spot

directly next to your vehicle.

^ A vehicle approaching from the

rear left and right side of your

vehicle slows down.

^ A vehicle approaching from the

rear left and right side of your

vehicle makes a right or left turn

directly in front of your vehicle.

4-108

When Driving

i-ACTIVSENSE



A vehicle overtakes your vehicle

^ The rear side radar sensor

while it is stopped.

detection area is obstructed by a

^ Your vehicle is in an area where

nearby wall or parked vehicle.

strong radio waves or electrical

(Reverse the vehicle to a position

noise may occur such as near a

where the radar sensor detection

television tower or power plant.

area is no longer obstructed.)

^ In the following cases, the

i-ACTIVSENSE warning indication/

warning light turns on and operation

of the system is stopped. If the

i-ACTIVSENSE warning indication/

warning light remains illuminated,

have the vehicle inspected at an

Authorized Mazda Dealer as soon as

1. Your vehicle

possible.

^ A vehicle is approaching directly

^ Some problem with the system

from the rear of your vehicle.

including the Blind Spot

Monitoring (BSM) warning

indicator lights has occurred.

^ A large deviation in the installation

position of a rear side radar sensor

on the vehicle has occurred.

^ There is a large accumulation of

snow or ice on the rear bumper

near a rear side radar sensor.

^ Driving on snow-covered roads for

long periods.

^ The temperature near the radar

1. Your vehicle

sensors becomes extremely hot

due to driving for long periods on

^ The vehicle is parked at an angle.

slopes during the summer.

^ The lead-acid battery voltage has

decreased.

^ Under the following conditions, the

rear side radar sensor cannot detect

approaching vehicles or it might be

difficult to detect them, and the

system may not operate normally.

1. Your vehicle

^ The vehicle speed when reversing

^ Directly after the RCTA system

is about 15 km/h (9 mph) or

becomes operable using [Settings]

faster.

in Mazda Connect.

^ Radio wave interference from a

radar sensor equipped on a nearby

parked vehicle.

4-109

When Driving

i-ACTIVSENSE

Always check the surrounding

Mazda Radar Cruise

conditions and depress the brake

Control with Stop & Go

pedal or accelerator pedal while

keeping a safe distance from a vehicle

function (MRCC with

ahead or a vehicle following behind

Stop & Go function)*

you.

▼ Mazda Radar Cruise Control with

Do not use the system under the

Stop & Go function (MRCC with

following conditions. Otherwise, it

Stop & Go function)

may result in an accident:

The MRCC with Stop & Go function is

¾ The vehicle is driven on roads other

a system designed to enable

than highways.

constant-speed driving at a set speed

¾ The vehicle is driven on roads with

and headway control to maintain a

sharp curves or with heavy traffic

constant distance with a vehicle ahead

where sufficient distances between

according to your vehicle speed. The

vehicles cannot be kept.

system automatically accelerates,

¾ The vehicle is driven on roads where

decelerates, and stops your vehicle

acceleration and deceleration are

without you having to depress the

frequently repeated.

accelerator or brake pedal.

¾ The vehicle is exiting the main lane

on an expressway to enter an

Also refer to the following information

interchange, a rest area, or a parking

before using the MRCC with Stop &

area.

Go function.

¾ The vehicle is driven on slippery

roads such as icy roads,

^ Refer to Forward Sensing Camera

snow-covered roads, and unpaved

(FSC) on page 4-71.

roads.

^ Refer to Front Radar Sensor on page

¾ The vehicle is driven on a long

4-77.

downslope.

¾ The vehicle is driven on a steep

WARNING

slope.

¾ A two-wheeled vehicle such as a

Do not rely completely on the MRCC

motorcycle or bicycle is traveling

with Stop & Go function and always

ahead.

drive carefully:

¾ The vehicle is being towed.

The MRCC with Stop & Go function

¾ Proximity warnings activate

may not be able to detect a vehicle

frequently.

ahead depending on the type of

vehicle and its conditions, the weather

Switch the MRCC with Stop & Go

conditions, and the road conditions.

function off when it is not being used.

Additionally, the system might be

Leaving the MRCC with Stop & Go

unable to decelerate sufficiently if the

function on when it is not in use is

vehicle ahead applies the brakes

dangerous as it could operate

suddenly or another vehicle cuts into

unexpectedly, resulting in an accident.

your lane, which could result in an

accident.

*Some models.

4-111

When Driving

i-ACTIVSENSE

Do not get out of the vehicle while

multi-information display and the

the stop hold control is operating.

active driving display.

Getting out of the vehicle while the

Multi-information Display (Basic

stop hold control is operating is

display)

dangerous as the vehicle may move

unexpectedly and result in an accident.

Before leaving the vehicle, switch the

MRCC with Stop & Go function off,

shift the selector lever to the P

position, and apply the parking brake.

NOTE

^ The MRCC with Stop & Go function

does not operate with the following

objects.

^ On-coming vehicles

1. Vehicle ahead display

^ Pedestrians

2. MRCC with Stop & Go function set

^ Stationary objects (such as

vehicle speed

stopped vehicles, obstructions)

^ If a vehicle ahead is traveling at an

Multi-information Display

extremely low speed, the system may

(i-ACTIVSENSE display)

not detect it correctly.

^ A brake operation sound may be

heard by the MRCC with Stop & Go

function control, however it does not

indicate a problem.

^ The brake lights turn on while the

brakes and stop hold control are

operating by the MRCC with Stop &

Go function control.

^ If the distance between vehicles

control is disabled using [Settings] in

Mazda Connect, the MRCC with

1. Vehicle ahead display

Stop & Go function switches to

2. MRCC with Stop & Go function set

cruise control.

vehicle speed

Refer to the Settings section in the

Mazda Connect Owner's Manual.

Active driving display

▼ Mazda Radar Cruise Control with

Stop & Go function (MRCC with

Stop & Go function) Display

Indication

The setting status and operation

1. Vehicle ahead display

conditions of the MRCC with Stop &

Go function are indicated on the

4-112

When Driving

i-ACTIVSENSE

2. MRCC with Stop & Go function set

¾ Your vehicle is being driven at the

vehicle speed

same speed as the vehicle ahead.

¾ Immediately after the MRCC with

If there is a problem with the MRCC

Stop & Go function is set.

with Stop & Go function, messages are

¾ Immediately after the accelerator

displayed on the displays. Check the

pedal is released.

details of the problem and then have

¾ Another vehicle cuts into the

your vehicle inspected by an

driving lane.

Authorized Mazda Dealer.

Refer to If a Warning Light Turns On or

Flashes on page 7-21.

▼ Close Proximity Warning

If your vehicle approaches a vehicle

ahead while in headway control using

the Mazda Radar Cruise Control with

Stop & Go function (MRCC with Stop

& Go function), a warning sound is

activated and a brake warning is

displayed on the multi-information

display. Check the surrounding

conditions and keep a safe distance

from the vehicle ahead.

1.

“Depress Brake Pedal” message is

displayed

CAUTION

¾ While the accelerator pedal is being

depressed, the warnings and brake

control do not operate even if your

vehicle approaches the vehicle

ahead.

¾ In the following cases, the warnings

and brakes may not operate even if

your vehicle approaches the vehicle

ahead.

4-113

When Driving

i-ACTIVSENSE

▼ Setting the System

Operation switch

1. CANCEL switch

2. RES switch

3. MRCC switch

Operation conditions

The MRCC with Stop & Go function operates when all of the following conditions

are met.

^ The MRCC with Stop & Go function is on.

^ The selector lever is in the D position.

^ The parking brake is released.

^ All the doors are closed.

^ The driver's seat belt is fastened.

^ Vehicle speed is 0 to 140 km/h (0 to 87 mph)

NOTE

^ In the following cases, the MRCC with Stop & Go function system is canceled

when the vehicle is traveling at 30 km/h (20 mph) or less and “Mazda Radar

Cruise Control Disabled Under 30 km/h” is displayed in the multi-information

display.

^ The Forward Sensing Camera (FSC) cannot detect target objects.

^ There is a problem with the stop hold control function.

^ There is a problem with the Electric Parking Brake (EPB).

Setting the vehicle speed

1. Press the MRCC switch to turn the system on.

2. Accelerate the vehicle until it reaches the desired speed using the accelerator

pedal and press the RES switch up (SET+) or down (SET-) to set the speed.

NOTE

^ When the system is turned on, the MRCC standby indication (white) turns on and

the MRCC display indications are displayed on the multi-information display and

the active driving display.

4-114

When Driving

i-ACTIVSENSE



When the vehicle speed is set, the set vehicle speed is displayed on the displays

and the MRCC standby indication (white) changes to the MRCC set indication

(green).

^ The minimum speed setting is 30 km/h (19 mph).

Indication on multi-information

Indication on active driving dis-

Travel status

display

play

During travel at constant speed

During travel under headway

control

Setting the distance between vehicles

The distance between vehicles is set to a shorter distance by pressing the CANCEL

switch down, and to a longer distance by pressing the CANCEL switch up. The

distance between vehicles can be set to 4 levels: Long, medium, short, and

extremely short distance.

The distance between vehicles increases or decreases depending on the vehicle

speed.

Distance-between-vehicles

guideline

Indication on multi-information

Indication on active driving dis-

(at 80 km/h (50 mph) vehicle

display

play^*1

speed)

Long (about 50 m (164 ft))

4-115

When Driving

i-ACTIVSENSE

Distance-between-vehicles

guideline

Indication on multi-information

Indication on active driving dis-

(at 80 km/h (50 mph) vehicle

display

play^*1

speed)

Medium (about 40 m (131 ft))

Short (about 30 m (98 ft))

Extremely short (about 25 m (82

ft))

^*1

Displays a pop-up image in the active driving display only when the driver operates the switch.

Changing the set vehicle speed

How to change the set vehicle speed using the RES switch

When the RES switch is pressed up (SET+), the vehicle accelerates, and when the

RES switch is pressed down (SET-), the vehicle decelerates.

^ Press and release immediately: 1 km/h (1 mph)

^ Press and hold: 10 km/h (5 mph)

How to change the set vehicle speed using the accelerator pedal

Depress the accelerator pedal until the vehicle speed reaches the desired speed,

then press the RES switch up (SET+) or down (SET-) and release the switch.

Temporary cancellation

If any of the following conditions is met, the MRCC with Stop & Go function is

canceled temporarily.

^ The MRCC with Stop & Go function operation conditions are not met.

^ The CANCEL switch is pressed.

^ The brake pedal is depressed.

^ The front radar sensors cannot detect target objects.

4-116

When Driving

i-ACTIVSENSE



The DSC has operated.

^ The Smart Brake Support (SBS) has operated.

^ The frequency of the braking operation by the MRCC with Stop & Go function is

high.

^ There is a problem in the system.

Resuming the control

If the MRCC with Stop & Go function is temporarily canceled, it will resume

operation at the previously set speed by pressing the RES switch after all of the

operation conditions have been met again.

Turning off the system

When the MRCC switch is pressed while the MRCC is operating, the MRCC turns

off.

▼ Stop Hold Control

^ Press the RES switch.

^ Depress the accelerator pedal.

While in headway control using the

MRCC with Stop & Go function, your

NOTE

vehicle will stop when a vehicle ahead

If the vehicle ahead starts moving

stops. When your vehicle is stopped

within three seconds after your vehicle

and the stop hold control operates, the

is stopped, the headway control will

MRCC with Stop & Go function

continue even if you do not resume

indicator light turns on.

driving your vehicle.

Resume driving information

If you do not resume driving within a

few seconds after the vehicle ahead

starts moving during stop hold control,

NOTE

the vehicle-ahead indication on the

^ The parking brake is automatically

multi-information display flashes to

applied and the vehicle is held in its

urge you to resume driving. If you still

stopped position when 10 minutes

do not resume driving after the

or longer have passed since the stop

indicator light flashes, a sound is

hold control operated. When this

activated to urge you to resume

occurs, the MRCC with Stop & Go

driving.

function is temporarily canceled.

Resuming driving

While in stop hold control, if the

vehicle ahead starts moving and the

distance from the vehicle increases, the

stop hold control will be canceled and

your vehicle will resume driving by

performing any of the following

operations.

4-117

When Driving

i-ACTIVSENSE

¾ Set a vehicle speed within the speed

Traffic Jam Assist (TJA)*

limit according to the road

conditions and the weather

▼ Traffic Jam Assist (TJA)

conditions.

The TJA is a system designed to reduce

¾ The TJA may not be able to detect a

driver fatigue during traffic jams when

vehicle ahead depending on the type

driving on expressways or highways.

of vehicle ahead and its conditions,

The TJA consists of a headway control

the weather conditions, and the road

function and a steering assist function.

conditions. Additionally, the system

might be unable to decelerate

Headway control function

sufficiently if the vehicle ahead

The function performs headway

applies the brakes suddenly or

control to maintain a constant distance

another vehicle cuts into your lane,

between your vehicle and a vehicle

which could result in an accident.

ahead at a preset vehicle speed

without you having to depress the

Do not use the system under the

accelerator or brake pedal.

following conditions. Otherwise, it

may result in an accident:

Steering assist function

¾ The vehicle is driven on roads other

When vehicle lane lines are detected,

than expressways and highways.

the function assists your steering

operation to follow the vehicle lane

¾ The vehicle is driven on roads with

sharp curves or with heavy traffic

lines.

When vehicle lane lines are not

where sufficient distances between

vehicles cannot be kept.

detected, the function assists your

steering operation to follow the

¾ The vehicle is driven on roads where

trajectory of the vehicle ahead.

acceleration and deceleration are

frequently repeated.

Also refer to the following information

¾ The vehicle is exiting the main lane

before using the TJA.

on an expressway to enter an

interchange, a rest area, or a parking

^ Refer to Forward Sensing Camera

area.

(FSC) on page 4-71.

¾ The vehicle is driven on slippery

^ Refer to Front Radar Sensor on page

roads such as icy roads,

4-77.

snow-covered roads, and unpaved

roads.

WARNING

¾ The vehicle is driven on a long

downslope.

Do not rely completely on the TJA and

¾ The vehicle is driven on a steep

always drive carefully:

slope.

¾ A two-wheeled vehicle such as a

¾ The TJA is not an automated driving

motorcycle or bicycle is traveling

system. Therefore, the function has

ahead.

limitations. Do not rely completely

¾ The vehicle is being towed.

on the system and always stay on

¾ Proximity warnings activate

course using the steering wheel.

frequently.

4-118 *Some models.

Content      ..     6      7      8      9     ..
