Exterior Care

The paintwork on your Mazda represents
the latest technical developments in
composition and methods of application.

Environmental hazards, however, can
harm the paint's protective properties, if
proper care is not taken.

Here are some examples of possible
damage, with tips on how to prevent them.

Etching Caused by Acid Rain or
Industrial Fallout

Occurrence

Industrial pollutants and vehicle emissions
drift into the air and mix with rain or dew
to form acids. These acids can settle on a
vehicle's finish. As the water evaporates,
the acid becomes concentrated and can
damage the finish.
And the longer the acid remains on the
surface, the greater the chance is for
damage.

Prevention

It is necessary to wash and wax your
vehicle to preserve its finish according to
the instructions in this section. These steps
should be taken immediately after you
suspect that acid rain has settled on your
vehicle's finish.

Damage Caused by Bird Dropping,
Insects, or Tree Sap

Occurrence

Bird droppings contain acids. If these are
not removed they can eat away the clear
and color base coat of the vehicle's
paintwork.

When insects stick to the paint surface and
decompose, corrosive compounds form.
These can erode the clear and color base
coat of the vehicle's paintwork if they are
not removed.

Tree sap will harden and adhere
permanently to the paint finish. If you
scratch the sap off while it is hard, some
vehicle paint could come off with it.

Prevention

It is necessary to have your Mazda washed
and waxed to preserve its finish according
to the instructions in this section. This
should be done as soon as possible.

Bird droppings can be removed with a soft
sponge and water. If you are traveling and
these are not available, a moistened tissue
may also take care of the problem. The
cleaned area should be waxed according to
the instructions in this section.
Insects and tree sap are best removed with
a soft sponge and water or a commercially
available chemical cleaner.

Another method is to cover the affected
area with dampened newspaper for one to
two hours. After removing the newspaper,
rinse off the loosened debris with water.

Maintenance and Care

Appearance Care

6-54

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

Water Marks

Occurrence

Rain, fog, dew, and even tap water can
contain harmful minerals such as salt and
lime. If moisture containing these minerals
settles on the vehicle and evaporates, the
minerals will concentrate and harden to
form white rings. The rings can damage
your vehicle's finish.

Prevention

It is necessary to wash and wax your
vehicle to preserve its finish according to
the instructions in this section. These steps
should be taken immediately after you find
water marks on your vehicle's finish.

Paint Chipping

Occurrence

Paint chipping occurs when gravel thrown
in the air by another vehicle's tires hits
your vehicle.

How to avoid paint chipping

Keeping a safe distance between you and
the vehicle ahead reduces the chances of
having your paint chipped by flying
gravel.

NOTE

The paint chipping zone varies with the
speed of the vehicle. For example, when
traveling at 90 km/h (56 mph), the paint
chipping zone is 50 m (164 ft).

In low temperatures a vehicle's finish
hardens. This increases the chance of
paint chipping.

Chipped paint can lead to rust forming
on your Mazda. Before this happens,
repair the damage by using Mazda
touch-up paint according to the
instructions in this section. Failure to
repair the affected area could lead to
serious rusting and expensive repairs.


Follow all label and container directions
when using a chemical cleaner or polish.
Read all warnings and cautions.

▼ Maintaining the Finish

Washing

CAUTION

When the wiper lever is in the

position and the ignition is switched ON,
the wipers may move automatically in
the following cases:

If the windshield above the rain sensor

is touched or wiped with a cloth.

If the windshield is struck with a hand

or other object from either outside or
inside the vehicle.

Keep hands and scrapers clear of the
windshield when the wiper lever is in the

 position and the ignition is

switched ON as fingers could be pinched
or the wipers and wiper blades damaged
when the wipers activate automatically.
If you are going to clean the windshield,
be sure the wipers are turned off
completely (when it is most likely that the
engine is left running) this is particularly
important when clearing ice and snow.

Maintenance and Care

Appearance Care

6-55

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

Do not spray water in the engine

compartment. Otherwise, it could result
in engine-starting problems or damage
to electrical parts.

When washing and waxing the vehicle,

be careful not to apply excessive force to
any single area of the vehicle hood.
Otherwise, you could dent the vehicle.

Do not use automatic car washing

machines and car washing devices using
high water pressure.

Make sure that the fuel-filler lid is closed

and lock the doors. Otherwise, the
fuel-filler lid may be forcefully opened by
water pressure causing damage to the
vehicle or fuel-filler lid.

To help protect the finish from rust and
deterioration, wash your Mazda
thoroughly and frequently, at least once a
month, with lukewarm or cold water.

If the vehicle is washed improperly, the
paint surface could be scratched. Here are
some examples of how scratching could
occur.

Scratches occur on the paint surface when:

The vehicle is washed without first
rinsing off dirt and other foreign matter.

The vehicle is washed with a rough, dry,
or dirty cloth.

The vehicle is washed at a car wash that
uses brushes that are dirty or too stiff.

Cleansers or wax containing abrasives
are used.

NOTE

Mazda is not responsible for scratches
caused by automatic car washes or
improper washing.

Scratches are more noticeable on
vehicles with darker paint finishes.

To minimize scratches on the vehicle's
paint finish:

Rinse off any dirt or other foreign matter
using lukewarm or cold water before
washing.

Use plenty of lukewarm or cold water
and a soft cloth when washing the
vehicle. Do not use a nylon cloth.

Rub gently when washing or drying the
vehicle.

Take your vehicle only to a car wash
that keeps its brushes well maintained.

Do not use abrasive cleansers or wax
that contain abrasives.

CAUTION

Do not use steel wool, abrasive cleaners,

or strong detergents containing highly
alkaline or caustic agents on
chrome-plated or anodized aluminum
parts. This may damage the protective
coating; also, cleaners and detergents
may discolor or deteriorate the paint.

Maintenance and Care

Appearance Care

6-56

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

Pay special attention to removing salt, dirt,
mud, and other foreign material from the
underside of the fenders, and make sure
the drain holes in the lower edges of the
doors and rocker panels are clean.

Insects, tar, tree sap, bird droppings,
industrial fallout, and similar deposits can
damage the finish if not removed
immediately. When prompt washing with
plain water is ineffective, use a mild soap
made for use on vehicles.

Thoroughly rinse off all soap with
lukewarm or cold water. Do not allow
soap to dry on the finish.

After washing the vehicle, dry it with a
clean chamois to prevent water spots from
forming.

WARNING

Dry off brakes that have become wet by
driving slowly, releasing the accelerator
pedal and lightly applying the brakes
several times until the brake performance
returns to normal:
Driving with wet brakes is dangerous.
Increased stopping distance or the vehicle
pulling to one side when braking could
result in a serious accident. Light braking
will indicate whether the brakes have been
affected.

Waxing

Your vehicle needs to be waxed when
water no longer beads on the finish.
Always wash and dry the vehicle before
waxing it. In addition to the vehicle body,
wax the metal trim to maintain its luster.

1. Use wax which contains no abrasives.

Waxes containing abrasive will remove
paint and could damage bright metal
parts.

2. Use a good grade of natural wax for

metallic, mica, and solid colors.

3. When waxing, coat evenly with the

sponge supplied or a soft cloth.

4. Wipe off the wax with a soft cloth.

NOTE
A spot remover to remove oil, tar, and
similar materials will usually also take off
the wax. Rewax these areas even if the rest
of the vehicle does not need it.

▼ Repairing Damage to the Finish

Deep scratches or chips on the finish
should be repaired promptly. Exposed
metal quickly rusts and can lead to major
repairs.

CAUTION

If your Mazda is damaged and needs metal
parts repaired or replaced, make sure the
body shop applies anti-corrosion materials
to all parts, both repaired and new. This
will prevent them from rusting.

Maintenance and Care

Appearance Care

6-57

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

▼ Bright-Metal Maintenance

Use tar remover to remove road tar and
insects. Never do this with a knife or
similar tool.

To prevent corrosion on bright-metal
surfaces, apply wax or chrome
preservative and rub it to a high luster.

During cold weather or in coastal areas,
cover bright-metal parts with a coating
of wax or preservative heavier than
usual. It would also help to coat them
with noncorrosive petroleum jelly or
some other protective compound.

CAUTION

Do not use steel wool, abrasive cleaners, or
strong detergents containing highly
alkaline or caustic agents on
chrome-plated or anodized aluminum
parts. This may result in damage to the
protective coating and cause discoloration
or paint deterioration.

▼ Underbody Maintenance

Road chemicals and salt used for ice and
snow removal and solvents used for dust
control may collect on the underbody. If
not removed, they will speed up rusting
and deterioration of such underbody parts
as fuel lines, frame, floor pan, and exhaust
system, even though these parts may be
coated with anti-corrosive material.

Thoroughly flush the underbody and
wheel housings with lukewarm or cold
water at the end of each winter. Try also to
do this every month.

Pay special attention to these areas
because they easily hide mud and dirt. It
will do more harm than good to wet
down the road grime without removing
it.

The lower edges of doors, rocker panels,
and frame members have drain holes that
should not be clogged. Water trapped there
will cause rusting.

Maintenance and Care

Appearance Care

6-58

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

WARNING

Dry off brakes that have become wet by
driving slowly, releasing the accelerator
pedal and lightly applying the brakes
several times until the brake performance
returns to normal:
Driving with wet brakes is dangerous.
Increased stopping distance or the vehicle
pulling to one side when braking could
result in a serious accident. Light braking
will indicate whether the brakes have been
affected.

▼ Aluminum Wheel Maintenance

A protective coating is provided over the
aluminum wheels. Special care is needed
to protect this coating.

CAUTION

Do not use any detergent other than mild
detergent. Before using any detergent,
verify the ingredients. Otherwise, the
product could discolor or stain the
aluminum wheels.

NOTE

Do not use a wire brush or any abrasive
cleaner, polishing compound, or solvent
on aluminum wheels. They may damage
the coating.

Always use a sponge or soft cloth to
clean the wheels.
Rinse the wheels thoroughly with
lukewarm or cold water. Also, be sure to
clean the wheels after driving on dusty
or salted roads to help prevent
corrosion.

▼ Convertible Top (Soft Top)

Maintenance

The convertible top is made of a special
high-grade material, but if it's not taken
good care of, hardening, staining, and loss
of luster will result. Maintain it under
these guidelines.

Washing

Do not wait until the convertible top gets
really dirty before cleaning it. Dirt that's
there too long will cause deterioration.
1. Before washing, remove dust and

coarse particulate with a soft brush.

2. Gently clean the convertible top with a

synthetic neutral detergent, lots of
water, and a soft brush.

3. Rinse it thoroughly with clean water to

remove all the soap.

4. Wipe it as dry as you can before the

water dries on it.

5. Then allow it to dry completely before

lowering it.

CAUTION

Automatic and high-pressure car washes

are harmful to a convertible top. Avoid
them.

Do not spray water directly on the area

where the window glass and the
convertible top meet. This would
probably cause water to enter the cabin.

Maintenance and Care

Appearance Care

6-59

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

Do not spray water directly on the seam

area of the body and the convertible top
as it could result in water penetrating the
cabin and trunk.

Some leather treatment products can

ruin the convertible top's gloss. Be careful
of the one you choose.

Test on an inconspicuous, small corner of

the convertible top if you are not sure.

Do not wipe the convertible top using

alcohol, chlorine bleach, or organic
solvents such as thinner, benzene, or
gasoline. Otherwise, they may cause
discoloration or stains.

Do not get any car wax on the

convertible top.
If you do, remove it with a good leather
cleaner or mild detergent (about 5%
solution).

Too much treatment on the convertible

top can be as damaging as too little.
Follow the manufacturer's directions.
Do not overdo it!

Let the convertible top dry completely

before lowering after applying treatment
or dressing.

Drain filter cleaning procedure

Drain filter

NOTE
If leaves or other matter block the drain
filter, water may enter the vehicle.
Clean the drain filter at least once a year.

1. Check the position of the drain filter

with your hand from behind the bow.

Drain filter

Bow

Maintenance and Care

Appearance Care

6-60

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

2. Remove the drain filter while pressing

the tab.

3. Remove leaves and other matter

accumulated in the drain filter.

4. Reinstall the drain filter in the reverse

order of the removal procedure.

CAUTION

When installing the drain filter, make sure
that the drain filter is securely attached to
its designated position by pushing it until
the tab locks. Water may enter the vehicle if
the drain filter is not secured to its
designated position.

▼ Convertible Top (Retractable

Hardtop) Maintenance

Washing

To help protect the retractable hardtop's
finish, use a soft cloth or sponge to wash
it.
Insects, tar, tree sap, bird droppings,
industrial fallout, and similar deposits can
damage the finish if they are not removed
immediately. When prompt washing with
plain water is ineffective use a mild soap
made for use on vehicles.

CAUTION

Do not use an automatic car wash.
Do not spray water directly on the area

where the window glass and the
retractable hardtop meet. This would
probably cause water to enter the cabin.

Do not use strong soap, chemical

detergents, or hot water, and do not
wash the retractable hardtop in direct
sunlight or when the surface is warm.

Thoroughly rinse with lukewarm or cold
water. Do not allow soap to dry on the
finish.

Waxing

Wax the retractable hardtop when water no
longer beads on the paint. Always wash
and dry it before waxing.

CAUTION

Wiping off dust or dirt with a dry cloth

will scratch the finish.

Do not use abrasive wax. This may

damage the protective coating and
discolor or deteriorate the paint.

NOTE
A spot remover to remove oil, tar, and
similar materials will usually also take off
the wax. Rewax these areas.

Maintenance and Care

Appearance Care

6-61

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

Drainage outlet cleaning procedure

There are drainage outlets on the left and
right of the lower side of the rear window.

Rear roof

Drainage
outlet

Rear window

NOTE
If leaves or other foreign matter block the
drainage outlets, water may enter the
cabin. Clean the drainage outlets at least
once a year.

1. Continue pressing the retractable

hardtop switch in the open direction
until the rear roof is raised up from the
fully closed position.
Refer to Opening the Roof on page
3-43.

2. Remove your finger from the

retractable hardtop switch after the rear
roof is raised up.

3. Make sure the drainage outlets are

visible.


Drainage
outlet

Rear roof links

4. Switch the ignition OFF.

WARNING

Verify that the ignition is switched off:
Closing the roof with the ignition not
switched off is dangerous as the motors
could turn on suddenly and cause
injury resulting from hands or fingers
being pinched in the mechanism.

5. Remove leaves and other foreign

matter accumulated in the drainage
outlet.

Maintenance and Care

Appearance Care

6-62

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

CAUTION

When cleaning the drainage outlets, be
careful not to touch the roof links or the
framework of the rear roof. Otherwise,
you could get injured.

Roof links

Rear roof

6. After cleaning is finished, continue

pressing the retractable hardtop switch
in the close direction to close the rear
roof.
Refer to Closing the Roof on page
3-43.


▼ Plastic Part Maintenance

When cleaning the plastic lenses of the
lights, do not use gasoline, kerosene,
rectified spirit, paint, thinner, highly
acidic detergents, or strongly alkaline
detergents. Otherwise, these chemical
agents can discolor or damage the
surfaces resulting in a significant loss in
functionality. If plastic parts become
inadvertently exposed to any of these
chemical agents, flush with water
immediately.

If plastic parts such as the bumpers
become inadvertently exposed to
chemical agents or fluids such as
gasoline, oil, engine coolant, or battery
fluid, it could cause discoloration,
staining, or paint peeling. Wipe off any
such chemical agents or fluids using a
soft cloth immediately.

High water temperature and high water
pressure car washers are available
depending on the type of high pressure
car washer device. If the car washer
nozzle is put too close to the vehicle or
aimed at one area for an extended period
of time, it could deform plastic parts or
damage the paint.

Do not use wax containing compounds
(polish). Otherwise, it could result in
paint damage.

In addition, do not use an electrical or
air tool to apply wax. Otherwise, the
frictional heat generated could result in
deformation of plastic parts or paint
damage.

Maintenance and Care

Appearance Care

6-63

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

Interior Care

WARNING

Do not spray water into the vehicle cabin:
Spraying water into the vehicle cabin is
dangerous as electrical devices such as the
audio and switches could get wet resulting
in a malfunction or vehicle fire.

NOTE

Do not wipe the interior using alcohol,
chlorine bleach, or organic solvents
such as thinner, benzene, and gasoline.
Otherwise, it may cause discoloration or
stains.

Rubbing hard with a stiff brush or cloth
may cause damage.

If the vehicle interior becomes soiled by
any of the following, wipe it off
immediately using a soft cloth.
Leaving it uncleaned could cause
discoloration, stains, cracks, or peeling of
the coating, and it will make it hard to
wipe off later.

Beverage or fragrance

Grease or oil

Soiling

▼ Seat Belt Maintenance

1. Clean the soiled area by lightly

dabbing it with a soft cloth soaked in a
mild detergent (approx. 5%) diluted
with water.

2. Wipe off the remaining detergent using

a cloth soaked in clean water and
wrung out well.

3. Before retracting seat belts which have

been pulled out for cleaning, dry them
off thoroughly and make sure there is
no remaining moisture on them.

WARNING

If a seat belt appears frayed or has
abrasions, have it replaced by an
Authorized Mazda Dealer:
If a seat belts is used under such a
condition, it cannot function at its full
capacity which could result in serious injury
or death.

Use a mild detergent to remove soiling
from a seat belt:
If organic solvents are used for cleaning the
seat belts or they become stained or
bleached, there is the possibility of them
becoming weakened and as a result, they
may not function at their full capacity
which could cause serious injury or death.

NOTE
Clean seat belts diligently if they get dirty.
Leaving them uncleaned will make it
difficult to clean them later, and it may
affect the smooth retracting of the seat
belt.

Maintenance and Care

Appearance Care

6-64

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

▼ Vinyl Upholstery Maintenance

Remove dust and dirt from the vinyl
upholstery using a brush or vacuum.
Remove soiling from vinyl upholstery
using a leather and vinyl upholstery
cleaner.

▼ Upholstery Maintenance

1. Clean the soiled area by lightly

dabbing it with a soft cloth soaked in a
mild detergent (approx. 5%) diluted
with water.

2. Wipe off the remaining detergent using

a cloth soaked in clean water and
wrung out well.

NOTE
Rubbing the interior side of the soft top
vigorously with a stiff brush or cloth may
cause damage.

▼ Leather Upholstery Maintenance

*

1. Remove dust and sand using a vacuum

cleaner.

2. Wipe off the soiled area with a soft

cloth and a suitable, special cleaner or
a soft cloth soaked in a mild detergent
(about 5%) diluted with water.

3. Wipe off the remaining detergent using

a cloth soaked in clean water and
wrung out well.

4. Remove moisture with a dry, soft cloth

and allow the leather to further dry in a
well-ventilated, shaded area. If the
leather gets wet such as from rain,
remove the moisture and dry it as soon
as possible.

NOTE

Because genuine leather is a natural
material, its surface is not uniform and
it may have natural scars, scratches,
and wrinkles.

To maintain the quality for as long as
possible, periodical maintenance, about
twice a year, is recommended.

If the leather upholstery comes into
contact with any of the following, clean
it immediately.
Leaving it uncleaned could cause
premature wear, mold, or stains.

Sand or dirt

Grease or oil, such as hand cream

Alcohol, such as in cosmetic or hair
dressing items

If the leather upholstery gets wet,
promptly remove moisture with a dry
cloth. Remaining moisture on the
surface may cause deterioration such as
hardening and shrinkage.

Exposure to direct sunlight for long
periods may cause deterioration and
shrinkage. When parking the car under
direct sunlight for long periods, shade
the interior using sunshades.

Do not leave vinyl products on the
leather upholstery for long periods.
They may affect the leather quality and
coloring. If the cabin temperature
becomes hot, the vinyl may deteriorate
and adhere to the genuine leather.

Maintenance and Care

Appearance Care

*Some models.

6-65

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

▼ Plastic Part Maintenance

CAUTION

Do not use polishing agents.
Depending on the product ingredients,
they could cause discoloration, stains,
cracks or peeling of the coating.

▼ Instrument Panel Top Maintenance

1. Wipe the soiled area with a soft cloth

soaked in a mild detergent (approx.
5%) diluted with water.

2. Wipe off the remaining detergent using

a cloth soaked in clean water and
wrung out well.

▼ Panel Maintenance

If a panel becomes soiled, wipe it off with
a soft cloth soaked in clean water and
thoroughly wrung out.
If some areas require further cleaning, use
the following procedure:
1. Wipe the soiled area with a soft cloth

soaked in a mild detergent (approx.
5 %) diluted with water.

2. Wipe off the remaining detergent using

a cloth soaked in clean water and
wrung out well.

NOTE
Be particularly careful when cleaning
shiny surface panels and metallic parts
such as plating as they can be scratched
easily.

▼ Cleaning the Window Interiors

If the windows become covered with an
oily, greasy, or waxy film, clean them with
glass cleaner. Follow the directions on the
container.

CAUTION

Do not scrape or scratch the inside of the

window glass. It could damage the
thermal filaments.

When washing the inside of the window

glass, use a soft cloth dampened in
lukewarm water, gently wiping the
thermal filaments.
Use of glass cleaning products could
damage the thermal filaments.

▼ Cleaning the Floor Mats

Rubber floor mats should be cleaned with
mild soap and water only.

WARNING

Do not use rubber cleaners, such as tire
cleaner or tire shine, when cleaning rubber
floor mats:
Cleaning the rubber floor mats with rubber
cleaning products makes the floor mats
slippery.
This may cause an accident when
depressing the accelerator, brake, or clutch
(Manual transmission) pedal or when
getting in or out of the vehicle.

After removing the floor mats for
cleaning, always reinstall them securely
(page 3-51).

Maintenance and Care

Appearance Care

6-66

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

7

If Trouble Arises

Helpful information on what to do if a problem arises with the vehicle.

Parking in an Emergency................. 7-2

Parking in an Emergency..............7-2

Flat Tire..............................................7-3

Tool Storage..................................7-3
Emergency Flat Tire Repair
Kit................................................. 7-5
Changing a Tire.......................... 7-16

Battery Runs Out............................ 7-23

Jump-Starting............................. 7-23

Emergency Starting.........................7-26

Starting a Flooded Engine.......... 7-26
Push-Starting.............................. 7-26

Overheating......................................7-27

Overheating................................ 7-27

When Fuel-Filler Lid Cannot be
Opened..............................................7-29

When Fuel-Filler Lid Cannot be
Opened........................................7-29

Emergency Towing.......................... 7-30

Towing Description.................... 7-30
Tiedown Hooks

*

......................... 7-31

Warning/Indicator Lights and
Warning Sounds.............................. 7-33

If a Warning Light Turns On or
Flashes........................................ 7-33
Message Indicated in Multi-
information Display

*

.................. 7-46

Message Indicated on
Display........................................7-47
Warning Sound is Activated....... 7-49

When Trunk Lid Cannot be
Opened..............................................7-53

When Trunk Lid Cannot be
Opened........................................7-53

When the Roof Cannot be
Closed............................................... 7-58

When the Roof Cannot be
Closed......................................... 7-58

*Some models.

7-1

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

Parking in an Emergency

The hazard warning lights should always
be used when you stop on or near a
roadway in an emergency.


The hazard warning lights warn other
drivers that your vehicle is a traffic hazard
and that they must take extreme caution
when near it.


Depress the hazard warning flasher and all
the turn signals will flash. The hazard
warning indicator lights in the instrument
cluster flash simultaneously.

NOTE

The turn signals do not work when the
hazard warning lights are on.

Check local regulations about the use of
hazard warning lights while the vehicle
is being towed to verify that it is not in
violation of the law.

If Trouble Arises

Parking in an Emergency

7-2

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

Tool Storage

NOTE
Your vehicle may or may not be equipped with a jack and lug wrench. For details, consult
an Authorized Mazda Dealer.

Tools are stored in the locations illustrated in the diagram.

Jack

Emergency flat tire repair kit

Jack

Some models.

Tool bag

Lug wrench

Jack lever

Tiedown eyelet

Soft top model

Emergency flat tire repair kit

Tool bag

Lug wrench

Jack lever

Tiedown eyelet

Hardtop model

If Trouble Arises

Flat Tire

7-3

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27















Content   ..  25  26  27  28   ..
