5–130

Interior Features

 NOTE



  The rear cup holder is designed for use on the rear console and cannot be installed to

the front side.



Left-hand drive model





Right-hand drive model



/:A



5–131

Interior Features

 Storage  Compartments

 WARNING

 Keep storage boxes closed when
driving:
 Driving with the storage boxes open is
dangerous. To reduce the possibility of
injury in an accident or a sudden stop,
keep the storage boxes closed when
driving.

 Do not put articles in storage spaces
with no lid:
 Putting articles in storage spaces with
no lid is dangerous as they could be
thrown around the cabin if the vehicle
is suddenly accelerated and cause
injury depending on how the article is
stored.

 CAUTION

 Do not leave lighters or eyeglasses
in the storage boxes while parked
under the sun. A lighter could explode
or the plastic material in eyeglasses
could deform and crack from high
temperature.

 Console  Box

              To use, open the lid.

 Seat Side Box

 CAUTION

 When using the rear console cup
holders, remove any cups before
opening the seat side box.
 If the seat side box is opened with cups
still in them, the lid will hit the cups and
cause the contents to spill.

  To open, press the latch down to open the
seat side box.

/:A



5–132

Interior Features

  Insert the auxiliary key and turn it
clockwise to lock, anticlockwise to unlock.

Lock

Unlock

 Back Trim Storage Box

              Small  items  can  be  stored  in  the  back  trim
storage box.
(Soft top model)

(Retractable fastback model)

  To use the back trim storage box

     1.   Slide the seat all the way forward and

fold the seatback forward.



Refer to Seat Operation on page
 2-5 .

   2.   Remove  the  lids.

  When

¿ nished, return the seat to its

original position and secure it. After
returning the seat to its original position,
make sure the seat is secured by
attempting to lightly move it forward and
backward.

 CAUTION

 Do not forcefully push objects into the
back trim storage box. Otherwise, the
box could be damaged.

/:A



5–133

Interior Features

*Some models.

 Removable  Ashtray

*

            The  removable  ashtray  can  be

¿ xed and

used in either of the cup holders.

 WARNING

 Only use the removable ashtray in
its

¿ xed position, and make sure it is

completely inserted:
 Using an ashtray removed from
its

¿ xed position or not completely

inserted is dangerous. Cigarettes
could roll around or spill out of the
ashtray into the vehicle and start a
¿ re. Moreover, cigarette stubs will not
extinguish themselves completely even
if the ashtray lid is closed.

 CAUTION

 Do not use the ashtray for rubbish. You
might start a

¿ re.

  To use the ashtray, insert it straight into the
cup holder.
  To remove the ashtray, pull it upward.

 Windblocker

            This  windblocker  reduces  rear  wind  blast
into the cabin when driving with the
convertible top down.
(Soft top model)

Windblocker

(Retractable fastback model)

Windblocker

/:A



MEMO

5–134

/:A



6–1

6–1

6

Maintenance and Care

  How to keep your Mazda in top condition.

   Essential  Information  ........................................................................  6-2

  Introduction ...................................................................................  6-2

  Scheduled  Maintenance .....................................................................  6-3

  Scheduled  Maintenance  ................................................................  6-3
  Maintenance  Monitor ..................................................................  6-10

  Owner  Maintenance .........................................................................  6-12

  Owner  Maintenance  Precautions  ................................................  6-12
  Bonnet  .........................................................................................  6-14
  Engine  Compartment  Overview  .................................................  6-16
  Engine  Oil  ...................................................................................  6-17
  Engine  Coolant ............................................................................  6-20
  Brake/Clutch  Fluid ......................................................................  6-22
  Window and Headlight Washer Fluid .........................................  6-23
  Body  Lubrication  ........................................................................  6-24
  Wiper  Blades ...............................................................................  6-24
  Battery .........................................................................................  6-28
  Key  Battery  Replacement  ...........................................................  6-31
  Tyres ............................................................................................  6-33
  Light  Bulbs ..................................................................................  6-38
  Fuses  ...........................................................................................  6-47

  Appearance  Care..............................................................................  6-53

  Exterior  Care  ...............................................................................  6-53
  Interior  Care  ................................................................................  6-64

/:A



6–2

Maintenance and Care

Essential Information

                Introduction

    Be careful not to hurt yourself when inspecting your vehicle, replacing a tyre, or doing some
kind of maintenance such as car washing.
  In particular, wear thick work gloves such as cotton gloves when touching areas that
are dif

¿ cult to see while inspecting or working on your vehicle. Doing inspections or

procedures with your bare hands could cause injury.

  If you are unsure about any procedure it describes, we strongly urge you to have a reliable
and quali

¿ ed technician perform the work, we recommend an Authorised Mazda Repairer.

  Authorised Mazda technicians and genuine Mazda parts are dedicated to your vehicle.
Without this expertise and the parts that have been designed and made especially for your
Mazda, inadequate, incomplete, and insuf

¿ cient servicing may result in problems. This

could lead to vehicle damage or an accident and injuries.

  For expert advice and quality service, consult an expert repairer, we recommend an
Authorised Mazda Repairer.

  The owner should retain evidence that proper maintenance has been performed as
prescribed.

  A claim against a warranty will not qualify if it results from lack of maintenance and not
from defective material or authorised workmanship.

  The malfunction diagnosis connector is designed exclusively for connecting the specially
designed device to perform on-board diagnosis.
  Do not connect any devices other than the specially designed malfunction diagnosis devices
for servicing. If any device other than the malfunction diagnosis device is connected, it may
affect the vehicle's electrical devices or lead to damage such as battery depletion.

Malfunction
diagnosis
connector

/:A



6–3

Maintenance and Care

Scheduled Maintenance

                Scheduled Maintenance

 NOTE

 After the prescribed period, continue to follow the described maintenance at the
recommended intervals.

Emission control and related systems
  The ignition and fuel systems are highly important to the emission control system and to
ef

¿ cient engine operation. Do not tamper with them.

  All inspections and adjustments must be made by an expert repairer, we recommend an
Authorised Mazda Repairer.

 Europe

 Maintenance  Interval

 Number of months or kilometres (miles), whichever comes

¿ rst.

 Months

 12

 24

 36

 48

 60

 72

 84

 96

 108

 ×1000  km

 20

 40

 60

 80

 100

 120

 140

 160

 180

 ×1000  miles

 12.5

 25

 37.5

 50

 62.5

 75

 87.5

 100

 112.5

 Spark  plugs

*1



 Replace every 120,000 km (75,000 miles).

 Air

¿ lter

*2

  R

  R

  R

 Evaporative  system  (if  installed)

  I

  I

  I

 Drive  belts

*3

  I

  I

  I

 Engine oil &

¿ lter

 Flexible

*4

 Replace when indicator is ON. (Max interval: 12

months/20,000 km (12,500 miles))

 Other  than
À exible

*5

  R

  R

  R

  R

  R

  R

  R

  R

  R

 Cooling  system

  I

  I

  I

  I

 Engine  coolant

*6

 Replace  at

¿ rst 200,000 km (125,000 miles) or 10 years; after

that, every 100,000 km (62,500 miles) or 5 years.

 Fuel  lines  and  hoses

  I

  I

  I

  I

 Battery

*7

  I

  I

  I

  I

  I

  I

  I

  I

  I

 Brake  lines,  hoses  and  connections

  I

  I

  I

  I

  I

  I

  I

  I

  I

 Brake

À uid

*8

  R

  R

  R

  R

 Parking  brake

  I

  I

  I

  I

  I

  I

  I

  I

  I

 Disc  brakes

  I

  I

  I

  I

  I

  I

  I

  I

  I

 Steering  operation  and  linkages

  I

  I

  I

  I

 Manual  transmission  oil

  R

 Rear differential oil



*9

 Front and rear suspension, ball joints and wheel
bearing axial play

  I

  I

  I

  I

/:A



6–4

Maintenance and Care

Scheduled Maintenance

 Maintenance  Interval

 Number of months or kilometres (miles), whichever comes

¿ rst.

 Months

 12

 24

 36

 48

 60

 72

 84

 96

 108

 ×1000  km

 20

 40

 60

 80

 100

 120

 140

 160

 180

 ×1000  miles

 12.5

 25

 37.5

 50

 62.5

 75

 87.5

 100

 112.5

 Driveshaft  dust  boots

  I

  I

  I

  I

 Exhaust system and heat shields

 Inspect every 80,000 km (50,000 miles) or 5 years.

 Bolts  and  nuts  on  chassis  and  body

  T

  T

  T

  T

 Body condition (for rust, corrosion and
perforation)

 Inspect  annually.

 Tyres (including spare tyre) (with in

À ation

pressure adjustment)

*10*11

  I

  I

  I

  I

  I

  I

  I

  I

  I

 Emergency

À at tyre repair kit (if installed)

*12

 Inspect  annually.

    Chart  symbols:

 I :  Inspect: Inspect and clean, repair, adjust,

¿ ll up, or replace if necessary.

 R :   Replace
 C :   Clean
 T :   Tighten
 D :   Drain

  Remarks:

     *1   In the countries below, inspect the spark plugs at every 10,000 km (6,250 miles) or 12 months before replacing

them at the said interval.



Albania, Bosnia and Herzegovina, Bulgaria, Croatia, Latvia, Macedonia, Moldova, Montenegro, Romania,
Serbia, Ukraine

   *2   If the vehicle is operated in very dusty or sandy areas, clean and if necessary, replace the air

¿ lter more often

than the recommended intervals.

   *3   Also inspect the air conditioner drive belts, if installed.


If the vehicle is operated primarily under any of the following conditions, inspect the drive belts at every
20,000 km (12,500 miles) or 12 months.

   a)   Driving  in  dusty  conditions
   b)   Extended periods of idling or low speed operation
   c)   Driving for long period in cold temperatures or driving regularly at short distance only
   d)   Driving  in  extremely  hot  conditions
   e)   Driving  in  mountainous  conditions  continually

   *4   SKYACTIV-G 1.5 and SKYACTIV-G 2.0 vehicles can select

À exible setting only some countries in Europe.

Consult an Authorised Mazda Repairer for details. Flexible setting can be set if the vehicle is operated mainly
where none of the following conditions apply.

   a)   Purpose of vehicle use is police car, taxi or driving school car.
   b)   Driving  in  dusty  conditions
   c)   Extended periods of idling or low speed operation



Once  the

À exible maintenance is selected, the vehicle calculates the remaining oil life based on engine

operating conditions and lets you know when an oil change is due by illuminating the wrench indicator light in
the instrument cluster.



Replace the engine oil and

¿ lter when message/wrench indicator light is ON. And they must be changed at least

once a year or within 20,000 km (12,500 miles) since last engine oil and

¿ lter change.



The system must be reset whenever replacing the engine oil regardless of the message/wrench indicator light
display.

/:A



6–5

Maintenance and Care

Scheduled Maintenance

   *5   If the vehicle is operated primarily under any of the following conditions, replace the engine oil and oil

¿ lter at

every 10,000 km (6,250 miles) or shorter.

   a)   Purpose of vehicle use is police car, taxi or driving school car.
   b)   Driving  in  dusty  conditions
   c)   Extended periods of idling or low speed operation
   d)   Driving for long period in cold temperatures or driving regularly at short distance only
   e)   Driving  in  extremely  hot  conditions
   f)   Driving  in  mountainous  conditions  continually

   *6   Use of FL-22 is recommended when replacing engine coolant. Using engine coolant other than FL-22 may

cause serious damage to the engine and cooling system.

   *7   Inspect the battery electrolyte level, speci

¿ c gravity and outer appearance. The sealed battery only requires an

outer appearance inspection.

   *8   If the brakes are used extensively (for example, continuous hard driving or mountain driving) or if the vehicle

is operated in extremely humid climates, replace the brake

À uid annually.

   *9   If this component has been submerged in water, the oil should be replaced.
   *10  Tyre rotation is recommended every 10,000 km (6,250 miles).
   *11   The Tyre Pressure Monitoring System (TPMS) initialization must be performed so that the system operates

normally (if equipped).

   *12   Check  the  tyre  repair

À uid expiration date every year when performing the periodic maintenance. Replace the

tyre repair

À uid bottle with new one before the expiration date.

 Except  Europe

      Israel

 Maintenance  Interval

 Number of months or kilometres, whichever comes

¿ rst

 Months

 12

 24

 36

 48

 60

 72

 84

 96

 108   120   132   144

 ×1000  km

 15

 30

 45

 60

 75

 90

 105   120   135   150   165   180

 Spark plugs

 Replace every 120,000 km or 6 years.

 Fuel

¿ lter

 Replace every 135,000 km.

 Evaporative  system  (if  installed)

  I

  I

  I

 Fuel lines and hoses

  I

  I

  I

  I

  I

  I

 Drive  belts

*1

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

 Engine oil & oil

¿ lter

*2

  R

  R

  R

  R

  R

  R

  R

  R

  R

  R

  R

  R

 Air

¿ lter

*3

  C

  C

  C

  R

  C

  C

  C

  R

  C

  C

  C

  R

 Cooling  system

  I

  I

  I

  I

  I

  I

 Engine  coolant

*4

 Replace  at

¿ rst 195,000 km or 10 years; after that, every

90,000 km or 5 years.

 Battery

*5

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

 Brake  lines,  hoses  and  connections

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

 Brake

À uid

*6

  I

  R

  I

  R

  I

  R

  I

  R

  I

  R

  I

  R

 Parking  brake

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

 Power  brake  unit  (Brake  booster)  and  hoses

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

 Disc  brakes

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

/:A



6–6

Maintenance and Care

Scheduled Maintenance

 Maintenance  Interval

 Number of months or kilometres, whichever comes

¿ rst

 Months

 12

 24

 36

 48

 60

 72

 84

 96

 108   120   132   144

 ×1000  km

 15

 30

 45

 60

 75

 90

 105   120   135   150   165   180

 Steering  operation  and  linkages

  I

  I

  I

  I

  I

  I

 Manual  transmission  oil

  R

  R

 Rear differential oil



*7

 Front and rear suspension, ball joints and wheel
bearing axial play

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

 Driveshaft  dust  boots

  I

  I

  I

  I

 Exhaust system and heat shields

 Inspect every 75,000 km.

 Bolts  and  nuts  on  chassis  and  body

  T

  T

  T

  T

  T

  T

  T

  T

  T

  T

  T

  T

 Body condition (for rust, corrosion and
perforation)

 Inspect  annually.

 Tyres (including spare tyre) (with in

À ation

pressure adjustment)

*8

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

 Emergency

À at tyre repair kit (if installed)

*9

 Inspect  annually.

    Chart  symbols:

 I :  Inspect: Inspect and clean, repair, adjust,

¿ ll up, or replace if necessary.

 R :   Replace
 C :   Clean
 T :   Tighten
 D :   Drain

  Remarks:

     *1   Also inspect the air conditioner drive belts, if installed.


If the vehicle is operated primarily under any of the following conditions, inspect the drive belts at every
10,000 km or shorter.

   a)   Driving  in  dusty  conditions
   b)   Extended periods of idling or low speed operation
   c)   Driving for long period in cold temperatures or driving regularly at short distance only
   d)   Driving  in  extremely  hot  conditions
   e)   Driving  in  mountainous  conditions  continually

   *2   If the vehicle is operated primarily under any of the following conditions, replace the engine oil and oil

¿ lter at

every 10,000 km or shorter.

   a)   Purpose of vehicle use is police car, taxi or driving school car.
   b)   Driving  in  dusty  conditions
   c)   Extended periods of idling or low speed operation
   d)   Driving for long period in cold temperatures or driving regularly at short distance only
   e)   Driving  in  extremely  hot  conditions
   f)   Driving  in  mountainous  conditions  continually

   *3   If the vehicle is operated in very dusty or sandy areas, clean and if necessary, replace the air

¿ lter more often

than the recommended intervals.

   *4   Use of FL-22 is recommended when replacing engine coolant. Using engine coolant other than FL-22 may

cause serious damage to the engine and cooling system.

   *5   Inspect the battery electrolyte level, speci

¿ c gravity and outer appearance. The sealed battery only requires an

outer appearance inspection.

/:A



6–7

Maintenance and Care

Scheduled Maintenance

   *6   If the brakes are used extensively (for example, continuous hard driving or mountain driving) or if the vehicle is

operated in extremely humid climates, replace the brake

À uid annually.

   *7   If this component has been submerged in water, the oil should be replaced.
   *8   The Tyre Pressure Monitoring System (TPMS) initialization must be performed so that the system operates

normally (if equipped).

   *9   Check  the  tyre  repair

À uid expiration date every year when performing the periodic maintenance. Replace the

tyre repair

À uid bottle with new one before the expiration date.

    Except  Israel

 Maintenance

Interval

 Number of months or kilometres (miles), whichever comes

¿ rst.

 Months

 6

 12

 18

 24

 30

 36

 42

 48

 54

 60

 66

 72

 78

 84

 90

 96

 ×1000  km

 10

 20

 30

 40

 50

 60

 70

 80

 90   100   110   120   130   140   150   160

 ×1000  miles   6.25   12.5   18.75   25   31.25   37.5   43.75   50   56.25   62.5   68.75   75   81.25   87.5   93.75   100

 Fuel

¿ lter

 Replace every 60,000 km (37,500 miles).

 Spark  plugs

*1



 Replace every 120,000 km (75,000 miles).

 Evaporative  system  (if  installed)

  I

  I

  I

  I

  I

  I

  I

  I

 Drive  belts

*2

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

 Engine  oil

*3

 Except
below
countries

  R

  R

  R

  R

  R

  R

  R

  R

  R

  R

  R

  R

  R

  R

  R

  R

 Georgia/
Armenia/
Cambodia

 Replace every 5,000 km (3,125 miles) or 6 months.

 Engine  oil

¿ lter

*3

 Except
below
countries

  R

  R

  R

  R

  R

  R

  R

  R

  R

  R

  R

  R

  R

  R

  R

  R

 Georgia/
Armenia/
Cambodia

 Replace every 10,000 km (6,250 miles) or 1 year.

 Cooling  system

  I

  I

  I

  I

  I

  I

  I

  I

 Engine  coolant

*4

 Replace  at

¿ rst 200,000 km (125,000 miles) or 10 years; after that, every

100,000 km (62,500 miles) or 5 years.

 Air

¿ lter

*5

 Except
below
countries

  C

  C

  R

  C

  C

  R

  C

  C

 Georgia/
Armenia

  C

  R

  C

  R

  C

  R

  C

  R

 Fuel  lines  and  hoses

  I

  I

  I

  I

  I

  I

  I

  I

 Battery

*6

  I

  I

  I

  I

  I

  I

  I

  I

 Brake  lines,  hoses  and  connections

  I

  I

  I

  I

  I

  I

  I

  I

 Brake

À uid

*7

  I

  I

  I

  R

  I

  I

  I

  R

  I

  I

  I

  R

  I

  I

  I

  R

 Parking  brake

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

 Power brake unit (Brake booster)
and hoses

  I

  I

  I

  I

  I

  I

  I

  I

/:A



6–8

Maintenance and Care

Scheduled Maintenance

 Maintenance

Interval

 Number of months or kilometres (miles), whichever comes

¿ rst.

 Months

 6

 12

 18

 24

 30

 36

 42

 48

 54

 60

 66

 72

 78

 84

 90

 96

 ×1000  km

 10

 20

 30

 40

 50

 60

 70

 80

 90   100   110   120   130   140   150   160

 ×1000  miles   6.25   12.5   18.75   25   31.25   37.5   43.75   50   56.25   62.5   68.75   75   81.25   87.5   93.75   100

 Disc  brakes

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

 Steering  operation  and  linkages

  I

  I

  I

  I

  I

  I

  I

  I

 Manual  transmission  oil

  R

 Rear differential oil



*8

 Front and rear suspension, ball
joints and wheel bearing axial play

  I

  I

  I

  I

  I

  I

  I

  I

 Driveshaft  dust  boots

  I

  I

  I

  I

 Exhaust system and heat shields

 Inspect every 80,000 km (50,000 miles).

 Bolts  and  nuts  on  chassis  and  body

  T

  T

  T

  T

  T

  T

  T

  T

 Body condition (for rust, corrosion
and perforation)

 Inspect  annually.

 Tyres (including spare tyre) (with
in

À ation pressure adjustment)

*9

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

  I

 Tyre  rotation

*9



 Rotate every 10,000 km (6,250 miles).

 Emergency

À at tyre repair kit (if

installed)

*10

 Inspect  annually.

    Chart  symbols:

 I :  Inspect: Inspect and clean, repair, adjust,

¿ ll up, or replace if necessary.

 R :   Replace
 C :   Clean
 T :   Tighten
 D :   Drain

  Remarks:

     *1   In the countries below, inspect the spark plugs at every 10,000 km (6,250 miles) or 12 months before replacing

them at the said interval.



Armenia, Angola, Bolivia, Burundi, B.Virgin, Cambodia, Cameroon, Chile, Costa Rica, Curacao, El
Salvador, Gabon, Ghana, Georgia, Guatemala, Haiti, Honduras, Hong Kong, Iran, Jordan, Macau, Mongolia,
Mozambique, Myanmar, Nigeria, Nicaragua, Papua New Guinea, Peru, Philippines, Seychelles, Syria,
Tanzania, United Arab Emirates, Vietnam, Zaire, Zimbabwe

   *2   Also inspect the air conditioner drive belts, if installed.


If the vehicle is operated primarily under any of the following conditions, inspect the drive belts more often
than the recommended intervals.

   a)   Driving  in  dusty  conditions
   b)   Extended periods of idling or low speed operation
   c)   Driving for long period in cold temperatures or driving regularly at short distance only
   d)   Driving  in  extremely  hot  conditions
   e)   Driving  in  mountainous  conditions  continually

/:A



6–9

Maintenance and Care

Scheduled Maintenance

   *3   If the vehicle is operated primarily under any of the following conditions, replace the engine oil and oil

¿ lter

more often than the recommended intervals.

   a)   Purpose of vehicle use is police car, taxi or driving school car.
   b)   Driving  in  dusty  conditions
   c)   Extended periods of idling or low speed operation
   d)   Driving for long period in cold temperatures or driving regularly at short distance only
   e)   Driving  in  extremely  hot  conditions
   f)   Driving  in  mountainous  conditions  continually

   *4   Use of FL-22 is recommended when replacing engine coolant. Using engine coolant other than FL-22 may

cause serious damage to the engine and cooling system.

   *5   If the vehicle is operated in very dusty or sandy areas, clean and if necessary, replace the air

¿ lter more often

than the recommended intervals.

   *6   Inspect the battery electrolyte level, speci

¿ c gravity and outer appearance. If the vehicle is operated in

extremely hot and cold areas, inspect the battery electrolyte level, speci

¿ c gravity and appearance every 10,000

km (6,250 miles) or 6 months. The sealed battery only requires an outer appearance inspection.

   *7   If the brakes are used extensively (for example, continuous hard driving or mountain driving) or if the vehicle

is operated in extremely humid climates, replace the brake

À uid annually.

   *8   If this component has been submerged in water, the oil should be replaced.
   *9   The Tyre Pressure Monitoring System (TPMS) initialization must be performed so that the system operates

normally (if equipped).

   *10   Check  the  tyre  repair

À uid expiration date every year when performing the periodic maintenance. Replace the

tyre repair

À uid bottle with new one before the expiration date.

/:A



6–10

Maintenance and Care

Scheduled Maintenance

 Maintenance  Monitor

 Maintenance Monitor (Type A audio)

    “Oil  Change”  with

À exible setting

*1

  is available. Consult an Authorised Mazda Repairer for

details

*2

 . When the engine oil

À exible maintenance setting is selected, the wrench indicator

light in the instrument cluster will be illuminated when remaining oil life becomes less than
1,000 km (600 mile), or remaining days are less than 15 (Whichever comes

¿ rst).

  Reset  method

    Press and hold the selector with the ignition switched off, then switch it on. Keep pressing
the selector for more than 5 seconds. The master warning light will

À ash for a few seconds

when the reset is completed.

Selector

   *1   The  engine  oil

À exible maintenance setting is available (only some models). Based on

the engine operating conditions, the onboard computer in your vehicle calculates the
remaining oil life.

   *2   When  the  engine  oil

À exible maintenance setting is selected, the system must be reset

whenever replacing the engine oil regardless of the wrench indicator light display.

 Maintenance Monitor (Type B/Type C audio)

     1.   Select  the

  icon on the home screen to display the “Applications” screen.

2.  Select “Vehicle Status Monitor”.
   3.   Select “Maintenance” to display the maintenance list screen.
   4.   Switch the tab and select the setting item you want to change.

/:A



6–11

Maintenance and Care

Scheduled Maintenance

    You can customize settings in the setup display as follows:

 Tab

 Item

 Explanation

 Scheduled

 Setting

 Noti

¿ cation can be switched on/off.

 Time  (months)

 Displays the time or distance until maintenance is due.
  Select this item to set the maintenance period.
  The wrench indication/indicator light in the instrument cluster will
be illuminated when the remaining distance is less than
1,000 km or 600 mile, or the remaining number of days is less than
15 (whichever comes

¿ rst).

 Distance (mile or km)

 Reset

 Resets the time and distance to the initial values.
  Once the system turns on, it needs to be reset whenever carrying
out maintenance.

 Tyre  Rotation

 Setting

 Noti

¿ cation can be switched on/off.

 Distance (mile or km)

 Displays the distance until tyre rotation is due.
  Select this item to set the tyre rotation distance.
  The wrench indication/indicator light in the instrument cluster will
be illuminated when the remaining distance is less than 1,000 km
or 600 mile.

 Reset

 Resets the remaining distance to the initial value.
  Once the system turns on, it needs to be reset whenever rotating
the tyres.

 Oil  Change

 Setting

*1

 Noti

¿ cation can be switched on/off.

 Distance (mile or km)

 Displays the distance until the oil replacement is due.
  Select this item to set the oil replacement distance.
  The wrench indication/indicator light in the instrument cluster will
be illuminated when the remaining distance is less than 1,000 km
or 600 mile.

 Reset

 Resets the remaining distance to the initial value.
  Once the system turns on, it needs to be reset whenever replacing
the engine oil.

     *1   The  engine  oil

À exible maintenance setting is available (only some models). Consult an Authorised Mazda

Repairer for details.



When the engine oil

À exible maintenance setting is selected, you will see the following items in the display. The

vehicle calculates the remaining oil life based on the engine operating conditions and lets you know when an oil
change is due by illuminating the wrench indicator light in the instrument cluster.

 Tab

 Item

 Explanation

 Oil  Change

 Oil life (%)

 Displays the engine oil life until the oil replacement is due.
  The wrench indication/indicator light in the instrument cluster
will be illuminated when remaining oil life distance is less
than 1,000 km (600 mile), or remaining days are less than 15
(whichever comes

¿ rst).

 Reset

 Resets the remaining oil life to 100 %.
  The system must be reset whenever replacing the engine oil.

/:A
