Mazda MX-5 RF (2017 year). Instruction - part 2

2–4

Essential Safety Equipment

Seats

 CAUTION



  When operating a seat, be careful not to put your hands or

¿ ngers near the moving

parts of the seat or on the side trim to prevent injury.



  When moving the seats, make sure there is no cargo in the surrounding area. If the

cargo gets caught it could damage the cargo.



  When moving the seats forward and rearward or returning a rear-reclined seatback

to its upright position, make sure you hold onto the seatback with your hand while
operating. If the seatback is not held, the seat will move suddenly and could cause
injury.

/:A



2–5

Essential Safety Equipment

Seats

 Seat

 Seat  Operation

 Seat Slide

  To move a seat forward or backward, raise the lever and slide the seat to the desired position
and release the lever.
  Make sure the lever returns to its original position and the seat is locked in place by
attempting to push it forward and backward.

 Height Adjustment for Front Edge of Seat Bottom (Driver's Seat)

  To adjust the height for front edge of the seat bottom, rotate the dial to the desired position.

 Seat Recline

  To change the seatback angle, lean forward slightly while raising the lever. Then lean back
to the desired position and release the lever.
  Make sure the lever returns to its original position and the seatback is locked in place by
attempting to push it forward and backward.

/:A



2–6

Essential Safety Equipment

Seats

*Some models.

 Seat  Warmer

*

            The  seats  are  electrically  heated.  The
ignition must be switched ON.
  Press the seat warmer switch while the
ignition is switched ON to operate the seat
warmer. The indicator lights turn on to
indicate that the seat warmer is operating.
The mode changes as follows each time
the seat warmer switch is pressed.

Low

Mid

High

OFF

 WARNING

 Be careful when using the seat
warmer:
 The heat from the seat warmer may be
too hot for some people, as indicated
as follows, and could cause a low-
temperature burn.



  Infants, small children, elderly

people, and physically challenged
people



  People with delicate skin



  People who are excessively fatigued



  People who are intoxicated



  People who have taken sleep-

inducing medicine such as sleeping
pills or cold medicine

 Do not use the seat warmer with
anything having high moisture-
retention ability such as a blanket or
cushion on the seat:
 The seat may be heated excessively and
cause a low-temperature burn.

 Do not use the seat warmer even when
taking a short nap in the vehicle:
 The seat may be heated excessively and
cause a low-temperature burn.

 Do not place heavy objects with sharp
projections on the seat, or insert
needles or pins into it:
 This could cause the seat to become
excessively heated and result in injury
from a minor burn.

/:A



2–7

Essential Safety Equipment

Seats

 CAUTION

 Do not use organic solvents to clean the
seat. It may damage the seat surface and
the heater.

 NOTE



  If the ignition is switched off while

the seat warmer is operating (High,
Mid or Low) and then switched
ON again, the seat warmer will
automatically operate at the
temperature set before switching off
the ignition.



  Use the seat warmer when the engine

is running. Leaving the seat warmer
on for long periods with the engine
not running could cause the battery
power to be depleted.



  The temperature of the seat warmer

cannot be adjusted beyond High, Mid
and Low because the seat warmer is
controlled by a thermostat.

/:A



2–8

Essential Safety Equipment

Seats

 Head  Restraints

 Non-Adjustable Head Restraints

    Your vehicle is equipped with non-adjustable head restraints on the driver's and passenger's
seatbacks. The non-adjustable head restraints consist of a trimmed foam covering over the
upper structure of the seatbacks and are intended to help protect you and the passenger from
neck injury. Adjust the seatbacks to their upright, on-road positions so that the head restraint
is positioned as close as possible to the back of your head.

 WARNING

 Make sure the seatbacks are properly adjusted to their upright, on-road positions before
the vehicle is driven:
 Driving with the seatbacks not adjusted properly is dangerous. With no support behind
your head, your neck could be seriously injured in a collision.

/:A



2–9

Essential Safety Equipment

Seat Belt Systems

      Seat  Belt  Precautions

            Seat belts help to decrease the possibility of severe injury during accidents and sudden
stops. Mazda recommends that the driver and passengers always wear seat belts.
  All the seats have lap/shoulder belts. These belts have retractors with inertia locks that keep
them out of the way when not in use. The locks allow the belts to remain comfortable on
users, but they will lock in position during a collision.

 WARNING

 Always wear your seat belt and make sure all occupants are properly restrained:
 Not wearing a seat belt is extremely dangerous. During a collision, occupants not
wearing seat belts could hit someone or things inside the vehicle or even be thrown out
of the vehicle. They could be seriously injured or even killed. In the same collision,
occupants wearing seat belts would be much safer.

 Do not wear twisted seat belts:
 Twisted seat belts are dangerous. In a collision, the full width of the belt is not available
to absorb the impact. This puts more force on the bones beneath the belt, which could
cause serious injury or death. So, if your seat belt is twisted, you must straighten the
seat belt to remove any twists and to allow the full width of the belt to be used.

 Never use one seat belt on more than one person at a time:
 Using one seat belt for more than one person at a time is dangerous. A seat belt used
in this way cannot spread the impact forces properly and the two passengers could
be crushed together and seriously injured or even killed. Never use one belt for more
than one person at a time and always operate the vehicle with each occupant properly
restrained.

 Do not operate a vehicle with a damaged seat belt:
 Using a damaged seat belt is dangerous. An accident could damage the belt webbing
of the seat belt in use. A damaged seat belt cannot provide adequate protection in a
collision. Have an expert repairer, we recommend an Authorised Mazda Repairer
inspect all seat belt systems in use during an accident before they are used again.

 Have your seat belts changed immediately if the pretensioner or load limiter has been
expended:
 Always have an expert repairer, we recommend an Authorised Mazda Repairer
immediately inspect the seat belt pretensioners and air bags after any collision. Like the
air bags, the seat belt pretensioners and load limiters will only function once and must
be replaced after any collision that caused them to deploy. If the seat belt pretensioners
and load limiters are not replaced, the risk of injury in a collision will increase.

/:A



2–10

Essential Safety Equipment

Seat Belt Systems

 WARNING

 Positioning the Shoulder Portion of the Seat Belt:
 Improper positioning of the shoulder portion of the seat belt is dangerous. Always make
sure the shoulder portion of the seat belt is positioned across your shoulder and near
your neck, but never under your arm, on your neck, or on your upper arm.

 Positioning the Lap Portion of the Seat Belt:
 The lap portion of the seat belt worn too high is dangerous. In a collision, this would
concentrate the impact force directly on the abdominal area, causing serious injury.
Wear the lap portion of the belt snugly and as low as possible.

 Instructions for Use of Seat Belt Assemblies:
 Seatbelts are designed to bear upon the bony structure of the body, and should be worn
low across the front of the pelvis or the pelvis, chest and shoulders, as applicable;
wearing the lap section of the belt across the abdominal area must be avoided.
 Seatbelts should be adjusted as

¿ rmly as possible, consistent with comfort, to provide

the protection for which they have been designed. A slack belt will greatly reduce the
protection afforded to the wearer.
 Care should be taken to avoid contamination of the webbing with polishes, oils and
chemicals, and particularly battery acid. Cleaning may safely be carried out using mild
soap and water. The belt should be replaced if webbing becomes frayed, contaminated
or damaged.
 It is essential to replace the entire assembly after it has been worn in a severe impact
even if damage to the assembly is not obvious.
 Belts should not be worn with straps twisted.
 Each belt assembly must only be used by one occupant; it is dangerous to put a belt
around a child being carried on the occupant's lap.
 No  modi

¿ cations or additions should be made by the user which will either prevent

the seat belt adjusting devices from operating to remove slack, or prevent the seat belt
assembly from being adjusted to remove slack.

/:A



2–11

Essential Safety Equipment

Seat Belt Systems

 CAUTION

 Belt retraction may become dif

¿ cult if the belts and seat belt guides are soiled, so try

to keep them clean. For more details about cleaning the seat belts, refer to "Seat Belt
Maintenance" (page  6-64 ).

Seat belt guide

 Pregnant Women and Persons with Serious Medical Conditions

            Pregnant  women  should  always  wear  seat  belts.  Ask  your  doctor  for  speci

¿ c

recommendations.
  The lap belt should be worn SNUGLY AND AS LOW AS POSSIBLE OVER THE HIPS.
  The shoulder belt should be worn across your shoulder properly, but never across the
stomach area.
  Persons with serious medical conditions also should wear seat belts. Check with your doctor
for any special instructions regarding speci

¿ c medical conditions.

 Emergency Locking Mode

            When the seat belt is fastened, it will always be in the emergency locking mode.
  In the emergency locking mode, the belt remains comfortable on the occupant and the
retractor will lock in position during a collision.
  If the belt is locked and cannot be pulled out, retract the belt once, and then try pulling it out
slowly. If this fails, pull the belt strongly one time and loosen, then pull it out again slowly.

/:A



2–12

Essential Safety Equipment

Seat Belt Systems

 Seat  Belt

 WARNING

 Always wear the seat belt with it
correctly routed in its guide:
 Wearing a seat belt without the seat
belt routed in its guide is dangerous
because the seat belt would not be able
to provide adequate protection in an
accident, which could result in serious
injury.

Seat belt guide

 Fastening the Seat Belt

Seat belt tongue

Seat belt buckle

  Position the lap belt as low as possible,
not on the abdominal area, then adjust the
shoulder belt so that it

¿ ts snugly against

your body.

Keep low on
hip bone

Take up slack

Too high

/:A



2–13

Essential Safety Equipment

Seat Belt Systems

 Unfastening the Seat Belt

    Depress the button on the seat belt buckle.
If the belt does not fully retract, pull it out
and check for kinks or twists. Then make
sure it remains untwisted as it retracts.

Button

 NOTE

 If a belt does not fully retract, inspect
it for kinks and twists. If it is still not
retracting properly, have it inspected at
an expert repairer, we recommend an
Authorised Mazda Repairer.

 Seat  Belt  Warning
Systems

    If it detects that the occupant seat belt
is unfastened, the warning light or beep
alerts the occupant.
  Refer to Warning/Indicator Lights on page
 4-42 .
  Refer to Seat Belt Warning Beep on page
 7-50 .

/:A



2–14

Essential Safety Equipment

Seat Belt Systems

 Seat Belt Pretensioner
and Load Limiting
Systems

    For optimum protection, the driver and
passenger seat belts are equipped with
pretensioner and load limiting systems.
For both these systems to work properly
you must wear the seat belt properly.

Pretensioners:
  When a collision is detected, the
pretensioners deploy simultaneously with
the air bags.
  For deployment details, refer to the SRS
Air Bag Deployment Criteria (page
 2-44 ).
  The seat belt retractors remove slack
quickly as the air bags are expanding.
Any time the air bags and seat belt
pretensioners have

¿ red they must be

replaced.
  A system malfunction or operation
conditions are indicated by a warning.
  Refer to Warning/Indicator Lights on page
 4-42 .
  Refer to Air Bag/Seat Belt Pretensioner
System Warning Beep on page  7-49 .
(With Passenger Occupant
Classi

¿ cation System)

  In addition, the pretensioner system for
the passenger, like the front and side
passenger air bag, is designed to only
deploy when the passenger occupant
classi

¿ cation sensor detects a passenger

sitting on the passenger's seat.
  For details, refer to the passenger occupant
classi

¿ cation sensor (page  2-47 ).

Load limiter:
  The load limiting system releases belt
webbing in a controlled manner to reduce
belt force on the occupant's chest. While
the most severe load on a seat belt occurs
in frontal collisions, the load limiter has
an automatic mechanical function and
can activate in any accident mode with
suf

¿ cient occupant movement.

  Even if the pretensioners have not

¿ red,

the load limiting function must be checked
by an expert repairer, we recommend an
Authorised Mazda Repairer.

 WARNING

 Wear seat belts only as recommended
in this owner's manual:
 Incorrect positioning of the driver
and passenger seat belts is dangerous.
Without proper positioning, the
pretensioner and load limiting systems
cannot provide adequate protection
in an accident and this could result in
serious injury. For more details about
wearing seat belts, refer to "Fastening
the seat belts" (page  2-12 ).

 Have your seat belts changed
immediately if the pretensioner or load
limiter has been expended:
 Always have an expert repairer, we
recommend an Authorised Mazda
Repairer immediately inspect the
seat belt pretensioners and air bags
after any collision. Like the air bags,
the seat belt pretensioners and load
limiters will only function once and
must be replaced after any collision
that caused them to deploy. If the seat
belt pretensioners and load limiters
are not replaced, the risk of injury in a
collision will increase.

/:A



2–15

Essential Safety Equipment

Seat Belt Systems

 WARNING

 Do not modify the components or
wiring, or use electronic testing devices
on the pretensioner system:
 Modifying the components or wiring
of the pretensioner system, including
the use of electronic testing devices
is dangerous. You could accidentally
activate it or make it inoperable which
would prevent it from activating in an
accident. The occupants or repairers
could be seriously injured.

 Properly dispose of the pretensioner
system:
 Improper disposal of the pretensioner
system or a vehicle with non-
deactivated pretensioners is dangerous.
Unless all safety procedures are
followed, injury could result. Have
an expert repairer, we recommend an
Authorised Mazda Repairer safely
dispose of the pretensioner system or
scrap a pretensioner system equipped
vehicle.

 NOTE



  The pretensioner system may not

operate depending on the type of
the collision. For details, refer to the
SRS Air Bag Deployment Criteria
(page   2-44 ).



  Some smoke (non-toxic gas) will

be released when the air bags and
pretensioners deploy. This does not
indicate a

¿ re. This gas normally has

no effect on occupants, however,
those with sensitive skin may
experience light skin irritation. If
residue from the deployment of the
air bags or the pretensioner system
gets on the skin or in the eyes, wash
it off as soon as possible.

/:A



2–16

Essential Safety Equipment

Child Restraint

      Child-Restraint  Precautions

            Mazda strongly urges the use of child-restraint systems for children small enough to use
them.

  Mazda recommends use of a Mazda genuine child-restraint system or one that complies with
the   UNECE

*1

  44 regulation. If you would like to purchase a Mazda genuine child-restraint

system, please contact an Authorised Mazda Dealer.
  Check your local and state or provincial laws for speci

¿ c requirements regarding the safety

of children riding in your vehicle.

   *1  UNECE stands for United Nations Economic Commission for Europe.

  Whatever child-restraint system you consider, please pick the appropriate one for the age
and size of the child, obey the law and follow the instructions that come with the individual
child-restraint system.

  A child who has outgrown child-restraint systems should use seat belts, both lap and
shoulder. If the shoulder belt crosses the neck or face, move the child closer to the centre of
the vehicle.

  A rear-facing child-restraint system should  NEVER  be used on the passenger seat with the
air bag system activated.

(With Passenger Occupant Classi

¿ cation System)

  To reduce the chance of injuries caused by deployment of the passenger air bag, the
passenger occupant classi

¿ cation sensor work as a part of the supplementary restraint

system. This system deactivates the passenger front and side air bags and also the passenger
seat belt pretensioner system when the passenger air bag deactivation OFF indicator light
illuminates.

  When an infant or small child sits on the passenger seat, the system shuts off the passenger
front and side air bags and seat belt pretensioner system, so make sure the passenger air bag
deactivation OFF indicator light illuminates.

  For more details, refer to "Passenger occupant classi

¿ cation sensor" (page  2-47 ).

/:A



2–17

Essential Safety Equipment

Child Restraint

 WARNING

 Use the correct size child-restraint system:
 For effective protection in vehicle accidents and sudden stops, a child must be properly
restrained using a seat belt or child-restraint system depending on age and size. If not,
the child could be seriously injured or even killed in an accident.

 Follow the manufacturer's instructions and always keep the child-restraint system
buckled down:
 An unsecured child-restraint system is dangerous. In a sudden stop or a collision it
could move causing serious injury or death to the child or other occupants. Make sure
any child-restraint system is properly secured in place according to the child-restraint
system manufacturer's instructions. When not in use, remove it from the vehicle or
fasten it with a seat belt, or latch it down to BOTH ISOFIX anchors, and attach the
corresponding tether anchor.

 Always secure a child in a proper child-restraint system:
 Holding a child in your arms while the vehicle is moving is extremely dangerous. No
matter how strong the person may be, he or she cannot hold onto a child in a sudden
stop or collision and it could result in serious injury or death to the child or other
occupants. Even in a moderate accident, the child may be exposed to air bag forces that
could result in serious injury or death to the child, or the child may be slammed into an
adult, causing injury to both child and adult.

 Always make sure the passenger air bag deactivation OFF indicator light is illuminated
when using a child-restraint system (With Passenger Occupant Classi

¿ cation System):

 Seating a child in a child-restraint system that is installed on the passenger seat with
the passenger air bag deactivation OFF indicator light not illuminated is extremely
dangerous. In an accident, an air bag could in

À ate and cause serious injuries or even

death to the child seated in the child-restraint system. Always make sure the passenger
air bag deactivation OFF indicator light is illuminated.
 Refer to Passenger Occupant Classi

¿ cation System on page  2-47 .

/:A



2–18

Essential Safety Equipment

Child Restraint

 WARNING

 Extreme Hazard! Never use a rear-facing child-restraint system on the passenger seat
with an air bag that could deploy:
 NEVER use a rearward facing child restraint on a seat protected by an ACTIVE
AIRBAG in front of it, DEATH or SERIOUS INJURY to the CHILD can occur.
 Vehicles with a passenger air bag have a warning label attached as shown below. This
warning label is displayed in compliance with regulations.

(Except Taiwan)

(Taiwan)

 Even in a moderate collision, the child-restraint system can be hit by a deploying air
bag and moved violently backward resulting in serious injury or death to the child.
If your vehicle is equipped with a passenger occupant classi

¿ cation system, always

make sure the passenger air bag deactivation OFF indicator light is illuminated, when
installing a rear-facing child-restraint system on the passenger seat.

/:A



2–19

Essential Safety Equipment

Child Restraint

 WARNING

 Before installing child-restraint system on the passenger seat, move the passenger seat
as far back as possible:
 In a collision, the force of a deploying air bag could cause serious injury or death to the
child.
 Make sure the passenger air bag deactivation OFF indicator light is illuminated.

 Seating a child in a child-restraint system on the passenger seat is dangerous under
certain conditions (With Passenger Occupant Classi

¿ cation System):

 Your vehicle is equipped with passenger occupant classi

¿ cation sensor. Even with

the passenger occupant classi

¿ cation sensor, if you must use the passenger seat to

seat a child, using a child-restraint system on the passenger seat under the following
conditions increases the danger of the passenger air bag deploying and could result in
serious injury or death to the child.



  The passenger air bag deactivation OFF indicator light does not illuminate when

seating a child in the child-restraint system.



  Luggage or other items are placed on the seat with the child in the child-restraint

system.



  The seat is washed.



  Liquids are spilled on the seat.



  The passenger seat is moved backward, pushing into luggage or other items placed

behind it.



  Luggage or other items are placed between the passenger seat and driver seat.



  An electric device is put on the passenger's seat.



  An additional electrical device, such as a seat warmer is installed to the surface of

the passenger seat.

/:A
