Mazda CX-9 (2019 year). Instruction

How to use USB mode

Type

Playable data

USB mode

MP3/WMA/AAC/OGG file

This unit does not support a USB 3.0 device. In addition, other devices may not be
supported depending on the model or OS version.
The recommended capacity of the USB memory is 16 GB or less.
USB devices formatted to FAT32 are supported (USB devices formatted to other formats
such as NTFS are not supported).

▼ Playback

1. Select the icon on the home screen to display the Entertainment screen.
2. Select

to switch the USB mode. The following icons are displayed in the

lower part of the center display.

Icon

Function

Displays the Entertainment menu. Use to switch to a different audio source.

Category list is displayed.

Current track list is displayed.
Select a desired track to play it.

Plays the current track repeatedly.
Select it again to play the tracks in the current track list repeatedly.
When selected again, the function is canceled.

Tracks in the current track list are played randomly.
Select it again to cancel.

Starts playing a track similar to the current track using Gracenote

's More Like This™.

Select the desired song from the category list to cancel More Like This™.

If selected within a few seconds from the beginning of a song which has started to play,
the previous song is selected.
If more than a few seconds have elapsed, the song currently being played is replayed from
the beginning.
Long-press to fast reverse. It stops when you remove your hand from the icon or the
commander knob.

Track is played. When selected again, playback is temporarily stopped.

Advances to the beginning of the next song.
Long-press to fast forward.

Interior Features

Audio Set

5-36

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Icon

Function

Displays sound settings to adjust audio quality level.
Refer to Volume/Display/Sound Controls on page 5-24.

NOTE



If a file name in the USB memory is too long, it could cause operation problems such as
not being able to playback the song.
(Recommended: Within 80 characters)



The album art may not display depending on the album art size.



To move to the desired location on the track, move the slider indicating the playback time.



The appearance of the repeat and shuffle icons changes depending on the type of
operation in which the function is used.

Category list

Select the

icon to display the following category list.

Select a desired category and item.

Category

Function

Playlist

Displays playlists on the device.

Artist

Displays the artist name list.
All the tracks or tracks for each album of the selected artist can be played.

Album

Displays the album name list.

Song

All the tracks in the device are displayed.

Genre

Displays the genre list.
All the tracks or tracks per album or artist in the selected genre can be played.

Audiobook

Displays the audiobook list.
Chapters can be selected and played.

Podcast

Displays the podcast list.
Episode can be selected and played.

Apple Music Ra‐

dio

*2*

Displays Apple Music Radio stations.
A station can be selected and played.

Folder

Displays the folder/file list.

1 Playlist folders of Apple devices are not supported.

2 Apple device only

3 USB-Sticks and USB-Android™ device only

Example of use (to play all tracks in
USB device)

(Method 1)

1. Select

to display the category list.

2. Select

All the tracks in the USB device are
displayed.

3. Select a desired track.

Interior Features

Audio Set

*Some models.

5-37

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

The selected track is played. All the
tracks in the USB device can be played
by continuing playback.

NOTE
Only the tracks in the desired category
selected in Step 2 are played.

(Method 2)

1. Select

to display the category list.

2. Select

All the folders in the USB device are
displayed.

3. Select

All the tracks in the USB device are
displayed.

4. Select a desired track.

The selected track is played. All the
tracks in the USB device can be played
by continuing playback.

1 Can be operated using an Android™

device or USB flash memory.

NOTE
Only the tracks in the desired folder
selected in Step 3 are played.

Interior Features

Audio Set

5-38

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

▼ Gracenote

Database

When a USB device is connected to this unit and the audio is played, the album name, artist
name, genre and title information are automatically displayed if there is a match in the
vehicle's database compilation to the music being played. The information stored in this
device uses database information in the Gracenote

music recognition service.

CAUTION

For information related to the most recent Gracenote

database which can be used and how

to install it, go to the Mazda Hands Free Website:
http://www.mazdahandsfree.com

Introduction

Gracenote, the Gracenote logo and logotype are either a registered trademark or a trademark
of Gracenote, Inc. in the United States and/or other countries.

Interior Features

Audio Set

5-39

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Gracenote

End User License Agreement

This application or device contains software from Gracenote, Inc. of Emeryville, California
(“Gracenote”). The software from Gracenote (the “Gracenote Software”) enables this
application to perform disc and/or file identification and obtain music-related information,
including name, artist, track, and title information (“Gracenote Data”) from online servers or
embedded databases (collectively, “Gracenote Servers”) and to perform other functions. You
may use Gracenote Data only by means of the intended End-User functions of this
application or device.
You agree that you will use Gracenote Data, the Gracenote Software, and Gracenote Servers
for your own personal non-commercial use only. You agree not to assign, copy, transfer or
transmit the Gracenote Software or any Gracenote Data to any third party. YOU AGREE
NOT TO USE OR EXPLOIT GRACENOTE DATA, THE GRACENOTE SOFTWARE,
OR GRACENOTE SERVERS, EXCEPT AS EXPRESSLY PERMITTED HEREIN.
You agree that your non-exclusive license to use the Gracenote Data, the Gracenote
Software, and Gracenote Servers will terminate if you violate these restrictions. If your
license terminates, you agree to cease any and all use of the Gracenote Data, the Gracenote
Software, and Gracenote Servers. Gracenote reserves all rights in Gracenote Data, the
Gracenote Software, and the Gracenote Servers, including all ownership rights. Under no
circumstances will Gracenote become liable for any payment to you for any information that
you provide. You agree that Gracenote, Inc. may enforce its rights under this Agreement
against you directly in its own name.
The Gracenote service uses a unique identifier to track queries for statistical purposes. The
purpose of a randomly assigned numeric identifier is to allow the Gracenote service to count
queries without knowing anything about who you are. For more information, see the web
page for the Gracenote Privacy Policy for the Gracenote service.
The Gracenote Software and each item of Gracenote Data are licensed to you “AS IS.”
Gracenote makes no representations or warranties, express or implied, regarding the
accuracy of any Gracenote Data from in the Gracenote Servers. Gracenote reserves the right
to delete data from the Gracenote Servers or to change data categories for any cause that
Gracenote deems sufficient. No warranty is made that the Gracenote Software or Gracenote
Servers are error-free or that functioning of Gracenote Software or Gracenote Servers will
be uninterrupted. Gracenote is not obligated to provide you with new enhanced or additional
data types or categories that Gracenote may provide in the future and is free to discontinue
its services at any time.

Interior Features

Audio Set

5-40

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

GRACENOTE DISCLAIMS ALL WARRANTIES EXPRESS OR IMPLIED,
INCLUDING, BUT NOT LIMITED TO, IMPLIED WARRANTIES OF
MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, TITLE, AND
NON-INFRINGEMENT. GRACENOTE DOES NOT WARRANT THE RESULTS THAT
WILL BE OBTAINED BY YOUR USE OF THE GRACENOTE SOFTWARE OR ANY
GRACENOTE SERVER. IN NO CASE WILL GRACENOTE BE LIABLE FOR ANY
CONSEQUENTIAL OR INCIDENTAL DAMAGES OR FOR ANY LOST PROFITS OR
LOST REVENUES.
© Gracenote, Inc. 2009

Updating the database

The Gracenote

media database can be updated using USB device.

1. Connect a USB device containing the software for updating Gracenote

2. Select the

icon on the home screen to display the Settings screen.

3. Select the

tab and select

4. Select

. The list of the update package stored in the USB device and the version

are displayed.

5. Select the package to use the update.
6. Select

NOTE
Gracenote

can be downloaded from the Mazda Hands-free Website.

Interior Features

Audio Set

5-41

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

How to use Apple CarPlay™

▼ What is Apple CarPlay™?

Apple CarPlay™ allows you to make calls, send or receive messages, and listen to music
using your iPhone

with the vehicle's audio system, or search for destinations using the

maps. In addition, voice recognition operation is possible using Siri

CAUTION

YOU EXPRESSLY ACKNOWLEDGE AND AGREE THAT USE OF APPLE CARPLAY™ (“THE

APPLICATION”) IS AT YOUR SOLE RISK AND THAT THE ENTIRE RISK AS TO SATISFACTORY
QUALITY, PERFORMANCE, ACCURACY AND EFFORT IS WITH YOU TO THE MAXIMUM EXTENT
PERMITTED BY APPLICABLE LAW, AND THAT THE APPLICATION AND INFORMATION ON THE
APPLICATION IS PROVIDED “AS IS” AND “AS AVAILABLE”, WITH ALL FAULTS AND WITHOUT
WARRANTY OF ANY KIND, AND MAZDA HEREBY DISCLAIMS ALL WARRANTIES AND
CONDITIONS WITH RESPECT TO THE APPLICATION AND INFORMATION ON THE
APPLICATION, EITHER EXPRESS, IMPLIED OR STATUTORY, INCLUDING, BUT NOT LIMITED TO,
THE IMPLIED WARRANTIES AND/OR CONDITIONS OF MERCHANTABILITY, SATISFACTORY
QUALITY, FITNESS FOR A PARTICULAR PURPOSE, ACCURACY, QUIET ENJOYMENT, AND
NONINFRINGEMENT OF THIRD PARTY RIGHTS. AS EXAMPLES, AND WITHOUT LIMITATION,
MAZDA DISCLAIMS ANY WARRANTY REGARDING THE ACCURACY OF DATA PROVIDED BY
THE APPLICATION, SUCH AS THE ACCURACY OF DIRECTIONS, ESTIMATED TRAVEL TIME,
SPEED LIMITS, ROAD CONDITIONS, NEWS, WEATHER, TRAFFIC, OR OTHER CONTENT
PROVIDED BY APPLE, ITS AFFILIATES, OR THIRD PARTY PROVIDERS; MAZDA DOES NOT
GUARANTEE AGAINST LOSS OF APPLICATION DATA, WHICH MAY BE LOST AT ANY TIME;
MAZDA DOES NOT GUARANTEE THAT THE APPLICATION OR ANY SERVICES PROVIDED
THROUGH THEM WILL BE PROVIDED AT ALL TIMES OR THAT ANY OR ALL SERVICES WILL BE
AVAILABLE AT ANY PARTICULAR TIME OR LOCATION. FOR EXAMPLE, SERVICES MAY BE
SUSPENDED OR INTERRUPTED WITHOUT NOTICE FOR REPAIR, MAINTENANCE, SECURITY
FIXES, UPDATES, ETC., SERVICES MAY BE UNAVAILABLE IN YOUR AREA OR LOCATION, ETC.
IN ADDITION, YOU UNDERSTAND THAT CHANGES IN THIRD PARTY TECHNOLOGY OR
GOVERNMENT REGULATION MAY RENDER THE SERVICES AND/OR APPLICATIONS
OBSOLETE AND/OR UNUSABLE.
TO THE EXTENT NOT PROHIBITED BY LAW, IN NO EVENT SHALL MAZDA OR ITS AFFILIATES
BE LIABLE FOR PERSONAL INJURY, OR ANY INCIDENTAL, SPECIAL, INDIRECT OR
CONSEQUENTIAL DAMAGES WHATSOEVER, INCLUDING, WITHOUT LIMITATION, DAMAGES
FOR LOSS OF PROFITS, CORRUPTION OR LOSS OF DATA, FAILURE TO TRANSMIT OR RECEIVE
ANY DATA, BUSINESS INTERRUPTION OR ANY OTHER COMMERCIAL DAMAGES OR LOSSES,
ARISING OUT OF OR RELATED TO THE APPLICATION OR YOUR USE OF OR INABILITY TO USE
THE APPLICATION OR INFORMATION ON THE APPLICATION.

Interior Features

Audio Set

5-42

*Some models.

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

When using Apple CarPlay™, please avoid distraction and use Apple CarPlay™ responsibly.

Stay fully aware of driving conditions and always obey applicable laws.

NOTE



Apple CarPlay™ is provided by Apple

and its use is subject to your agreement to the

Apple CarPlay™ terms of use, which are included as part of the Apple iOS terms of use.



When using Apple CarPlay™, location, speed, and other vehicle data is transferred to
your iPhone

. For further details, refer to Apple

’s Privacy Policy.

▼ Switching to Apple CarPlay™

Connect the iPhone

by inserting the Apple

-genuine connector cord to the USB terminal

indicated by the mark.
Refer to How to connect USB port/Auxiliary jack on page 5-17.

NOTE



When you switch your iPhone

connection from Bluetooth

to the vehicle's USB terminal,

the system switches to Apple CarPlay™. The applications which was being used via
Bluetooth

connection can be used continuously. However, the available functions of the

applications using Bluetooth

connection and those on Apple CarPlay™ may differ.



If the iPhone

is connected to the USB terminal not indicated by the mark, the system

operates in USB mode.

Display of Apple CarPlay™ Screen

Use any of the following methods to display the Apple CarPlay™ screen in the center
display.



Select on the home screen.



Long press

on the commander switch.



Select on the home screen, and select

from the Applications screen.

Apple CarPlay™ home screen

Interior Features

Audio Set

5-43

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

NOTE
The icons and icon positions displayed on the Apple CarPlay™ home screen may differ
depending on the connected iPhone

and iOS version.

No.

Icon

Explanation

Icon for connected
iPhone

Launches the Apple CarPlay™ application.
Refer to the help information available with each application for the method
of using each application.

Switches to the Mazda Connect home screen.

Displays the Apple CarPlay™ home screen.

Convenient Ways to Use Apple CarPlay™

Item

Operation method

Activating the voice recognition function
(Siri

)

Activate Siri

using any of the following two methods to op‐

erate Apple CarPlay™ by voice.



Press the talk button on the audio control switch.



Press and hold

To display the Now Playing screen

When music is playing in Apple CarPlay™ and a screen oth‐

er than the Now Playing screen is being displayed, press
on the commander switch to display the Now Playing screen.

To display the MAP screen

When using map route guidance in Apple CarPlay™ and a
screen other than the MAP screen is being displayed, press

on the commander switch to display the MAP screen.

To return to Mazda Connect screen

Press and hold

on the commander switch.

1 The voice recognition function of Mazda Connect cannot be used while Apple

CarPlay™ is connected.

To End Apple CarPlay™

To end Apple CarPlay™, disconnect the Apple

-genuine connector cord from the USB

terminal and disconnect the iPhone

from the connector cord.

NOTE
If the connector cord is disconnected from the USB terminal during music playback using
Apple CarPlay™, the audio source selection will no longer be available and the vehicle's
audio device will be muted.

Interior Features

Audio Set

5-44

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

How to use Android Auto™ mode

▼ What is Android Auto™?

Android Auto™ is an application which allows the operation of an Android™ Smartphone
using the vehicle's audio. Android Auto™ functions such as the phone, messages, music,
and map can be used with the vehicle's audio system.

CAUTION

YOU EXPRESSLY ACKNOWLEDGE AND AGREE THAT USE OF ANDROID AUTO™ (“THE

APPLICATION”) IS AT YOUR SOLE RISK AND THAT THE ENTIRE RISK AS TO SATISFACTORY
QUALITY, PERFORMANCE, ACCURACY AND EFFORT IS WITH YOU TO THE MAXIMUM EXTENT
PERMITTED BY APPLICABLE LAW, AND THAT THE APPLICATION AND INFORMATION ON THE
APPLICATION IS PROVIDED “AS IS” AND “AS AVAILABLE,” WITH ALL FAULTS AND WITHOUT
WARRANTY OF ANY KIND, AND MAZDA HEREBY DISCLAIMS ALL WARRANTIES AND
CONDITIONS WITH RESPECT TO THE APPLICATION AND INFORMATION ON THE
APPLICATION, EITHER EXPRESS, IMPLIED OR STATUTORY, INCLUDING, BUT NOT LIMITED TO,
THE IMPLIED WARRANTIES AND/OR CONDITIONS OF MERCHANTABILITY, SATISFACTORY
QUALITY, FITNESS FOR A PARTICULAR PURPOSE, ACCURACY, QUIET ENJOYMENT, AND
NONINFRINGEMENT OF THIRD PARTY RIGHTS. AS EXAMPLES, AND WITHOUT LIMITATION,
MAZDA DISCLAIMS ANY WARRANTY REGARDING THE ACCURACY OF DATA PROVIDED BY
THE APPLICATION, SUCH AS THE ACCURACY OF DIRECTIONS, ESTIMATED TRAVEL TIME,
SPEED LIMITS, ROAD CONDITIONS, NEWS, WEATHER, TRAFFIC, OR OTHER CONTENT
PROVIDED BY GOOGLE, ITS AFFILIATES, OR THIRD PARTY PROVIDERS; MAZDA DOES NOT
GUARANTEE AGAINST LOSS OF APPLICATION DATA, WHICH MAY BE LOST AT ANY TIME;
MAZDA DOES NOT GUARANTEE THAT THE APPLICATION OR ANY SERVICES PROVIDED
THROUGH THEM WILL BE PROVIDED AT ALL TIMES OR THAT ANY OR ALL SERVICES WILL BE
AVAILABLE AT ANY PARTICULAR TIME OR LOCATION. FOR EXAMPLE, SERVICES MAY BE
SUSPENDED OR INTERRUPTED WITHOUT NOTICE FOR REPAIR, MAINTENANCE, SECURITY
FIXES, UPDATES, ETC., SERVICES MAY BE UNAVAILABLE IN YOUR AREA OR LOCATION, ETC.
IN ADDITION, YOU UNDERSTAND THAT CHANGES IN THIRD PARTY TECHNOLOGY OR
GOVERNMENT REGULATION MAY RENDER THE SERVICES AND/OR APPLICATIONS
OBSOLETE AND/OR UNUSABLE.
TO THE EXTENT NOT PROHIBITED BY LAW, IN NO EVENT SHALL MAZDA OR ITS AFFILIATES
BE LIABLE FOR PERSONAL INJURY, OR ANY INCIDENTAL, SPECIAL, INDIRECT OR
CONSEQUENTIAL DAMAGES WHATSOEVER, INCLUDING, WITHOUT LIMITATION, DAMAGES
FOR LOSS OF PROFITS, CORRUPTION OR LOSS OF DATA, FAILURE TO TRANSMIT OR RECEIVE
ANY DATA, BUSINESS INTERRUPTION OR ANY OTHER COMMERCIAL DAMAGES OR LOSSES,
ARISING OUT OF OR RELATED TO THE APPLICATION OR YOUR USE OF OR INABILITY TO USE
THE APPLICATION OR INFORMATION ON THE APPLICATION.

Interior Features

Audio Set

*Some models.

5-45

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

When using Android Auto™, please avoid distraction and use Android Auto™ responsibly.

Stay fully aware of driving conditions and always obey applicable laws.

NOTE



Android Auto™ is provided by Google and its use is subject to your agreement to the
Android Auto™ terms of use.



When using Android Auto™, location, speed, and other vehicle data is transferred to your
smart phone. For further details, refer to Google’s Privacy Policy.

▼ How to use the Android Auto™ mode

Insert an Android™ Smartphone-genuine connector cord into the USB terminal indicated by
the icon to connect the Smartphone.
Refer to How to connect USB port/Auxiliary jack on page 5-17.

NOTE



When an Android™ Smartphone connected to Bluetooth

is connected to the vehicle's

USB terminal, Bluetooth

is used by Android Auto™ and the system switches to Android

Auto™ mode.



If the Android™ Smartphone is connected to a USB terminal with no icon indicated,
the system operates in USB mode.

Display of Android Auto™ Mode Screen

Use any of the following methods to display the Android Auto™ mode screen in the center
display.



Select on the home screen, and select

from the Applications screen.



Select

on the home screen.



Press and hold

on the commander switch.

Android Auto™ mode home screen

Interior Features

Audio Set

5-46

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

NOTE
The media displayed on the Android Auto™ home screen may differ depending on the use
conditions and version of the connected Android™ Smartphone.

No.

Icon

Explanation

－

Displays the use history of each application. The displayed contents differ de‐
pending on the application that has been started and its status.

Switches to the map application.

Switches to the call mode.

Displays the Android Auto™ home screen.

Switches to the Music application.

Switches to the Mazda Connect home screen.

Convenient ways to use Android Auto™ mode

Item

Operation method

Operation using voice recognition

Any of the following methods can be used to start the voice
recognition mode and operate Android Auto™ by voice.



Speak the words, “OK Google”.



Select the icon on the Android Auto™ screen.



Press and hold the talk button on the audio remote control
switch.

To display the NowPlaying screen

When music is playing in Android Auto™ and a screen other

than the NowPlaying screen is being displayed, press

the commander switch to display the NowPlaying screen.

To display the MAP screen

When using map route guidance in Android Auto™ or a
screen other than the MAP screen is being displayed, press

on the commander switch to display the Android Au‐

to™ MAP screen.

To return to the Mazda Connect screen

Press and hold

on the commander switch.

1 The voice recognition function of Mazda Connect cannot be used while Android Auto™

is connected.

To end Android Auto™

To end the Android Auto™ mode, disconnect the Android™-genuine connector cord from
the USB terminal or disconnect the Android™ Smartphone from the connector cord.

Interior Features

Audio Set

5-47

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

If Android Auto™ cannot be connected

When the message, “Mobile Device Error”, is displayed and Android Auto™ cannot
be connected.

Make sure that the Android™ Smartphone in question is compatible with Android Auto™.
Before trying to reconnect your Android™ Smartphone to the connector cord, do the
Bluetooth

device pairing again.

If the Android Auto™ connection setting cannot be changed

Depending on your Android™ Smartphone, the connection setting may have been in
charging mode only when the connector cord is connected.
In this case, switch off the Android Auto™ connection setting once, and then switch it back
on while connected to USB mode.
The connection setting can be changed to the Android Auto™ connection in the

tab

on the Settings screen (page 5-77).

Interior Features

Audio Set

5-48

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Bluetooth

▼ Introduction

Bluetooth

Hands-Free outline

When a Bluetooth

device (mobile phone) is connected to the vehicle's Bluetooth

unit via

radio wave transmission, a call can be made or received by pressing the talk button, pick-up
button, or hang-up button on the audio remote control switch, or by operating the center
display. For example, even if a device (mobile phone) is in your coat pocket, a call can be
made without taking the device (mobile phone) out and operating it directly.

Bluetooth

audio outline

When a portable audio unit equipped with the Bluetooth

communication function is paired

to the vehicle, you can listen to music stored on the paired portable audio device from the
vehicle's speakers. It is not necessary to connect the portable audio device to the vehicle's
external input terminal. After programming, operate the vehicle audio control panel to play/
stop the audio.

NOTE



For your safety, a device can be paired only when the vehicle is parked. If the vehicle
starts to move, the pairing procedure will end. Park the vehicle in a safe place before
pairing.



The communication range of a Bluetooth

equipped device is about 10 meters (32 ft) or

less.



Basic audio operation is available using voice commands even if Bluetooth

is not

connected.



For safety reasons, operation of the center display is disabled while the vehicle is being
driven. However, items not displayed in gray can be operated using the commander
switch while the vehicle is being driven.

CAUTION

Some Bluetooth

mobile devices are not compatible with the vehicle. Consult an Authorized

Mazda Dealer, Mazda's call center or Web support center for information regarding
Bluetooth

mobile device compatibility:

U.S.A.

Phone: 800-430-0153
Web: www.mazdausa.com/mazdaconnect

Interior Features

Audio Set

5-49

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Canada

Phone: 800-430-0153
Web: www.mazdahandsfree.ca

Mexico

Center of Attention to Client (CAC)
Phone: 01-800-01-MAZDA
Web: www.mazdamexico.com.mx

Applicable Bluetooth

specification (Recommended)

Ver. 1.1/1.2/2.0 EDR/2.1 EDR/3.0 (conformity)

▼ Component Parts

Microphone

Talk button, Pick-up button and Hang-up button

Microphone

Talk button

Hang-up button

Pick-up button

Audio unit

Microphone (hands-free)

The microphone is used for speaking voice commands or when making a Hands-free call.

Talk button

Activates the voice recognition. In addition, it skips the voice guidance.

Pick-up button

Responds to incoming calls. In addition, after selecting a contact or dialing a number, it
places the call when the button is pressed.

Interior Features

Audio Set

5-50

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Hang-up button

Ends the call or refuses an incoming call. In addition, it ends the voice recognition
operation.

Commander switch

The commander switch is used for volume adjustment and display operation. Tilt or turn the
commander knob to move the cursor. Press the commander knob to select the icon.

Volume adjustment

The volume dial of the commander switch is used to adjust the volume. Turn the dial to the
right to increase volume, to the left to decrease it.
The volume can also be adjusted using the volume button on the steering wheel.

NOTE



Press the volume dial to switch the audio MUTE on and off.



If the volume is lower compared to other audio modes, increase the volume from the
device side.

Conversation volume and the volume of the voice guidance and ringtone can each be set in
advance.
1. Select the icon on the home screen to display the Communication screen.
2. Select

3. Adjust the

and the

using the slider.

Interior Features

Audio Set

5-51

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Mazda CX-9 (2019 year). Instruction - part 27
