7 – GLOSSARY



105

Piston Engine Fundamentals

TC010-05-01S

valve adjustment

— the process of

setting the valve clearance to proper
specifications; valves can be manually or
hydraulically adjusted.

valve clearance

— the small gap between

the end of the valve stem and the rocker
arm; also called lash.

valve face

— the tapered surface of the

valve head that seals against the valve
seat in the cylinder head.

valve guide

— a hollow insert or passage

in the cylinder head that holds the valve
stem.

valve head

— the larger end of the valve

that seals the valve port.

valve lash

— See valve clearance.


valve port

— a passage controlled by a

valve that lets the air-fuel mixture into the
cylinders through the intake port; lets
exhaust gases out through the exhaust
port after the mixture has burned.

valve seal

— seals the valve stem in the

valve guide, preventing oil from entering
the combustion chamber.

valve seat

— the surface on the cylinder

head where the valve head closes to seal
the valve port.

valve spring

— holds the valve closed

when the cam lobe is not pressing it open.

valve stem

— the long, narrow part of the

valve above the valve head.

valve train

— the engine components that

open and close the intake and exhaust
valves so that the four-stroke cycle is
timed properly.

vibration damper — controls torsional
vibration of the crankshaft; mounted on the
front end of the crankshaft, often as part of the
pulley; also called a torsional damper or
harmonic balancer.

viscous drive clutch

— a type of radiator

fan clutch controlled by a thermostat and
fluid coupling; a viscous drive clutch allows
the fan to turn slow at low temperatures
and fast at high temperatures.

water pump

— provides the “push” to

circulate coolant throughout the cooling
system.

working height

— the length of an

installed valve spring between the retainer
and the spring pad on the cylinder head
when the valve is fully closed.

wrist pin

— See piston pin.











© Copyright, 2005 Mazda Motor Corporation. All Rights Reserved

All materials (texts, images, graphics, and other materials) on the
documents are subject to the copyrights and other intellectual
property rights of Mazda Motor Corporation, its affiliated
companies, and its licensors. These materials may not be copied,
processed, sold, inspected, published not only for commercial
use but also for third party, and these materials may not be
modified or reproduced in any medium without the written
authorization of Mazda Motor Corporation.








L

L

E

E

V

V

E

E

L

L





F

F











A

A

i

i

r

r





C

C

o

o

n

n

d

d

i

i

t

t

i

i

o

o

n

n

i

i

n

n

g

g





F

F

u

u

n

n

d

d

a

a

m

m

e

e

n

n

t

t

a

a

l

l

s

s





T

T

C

C

0

0

7

7

0

0

-

-

0

0

5

5

-

-

0

0

1

1

S

S





S

S

G

G

































M

M

a

a

z

z

d

d

a

a





M

M

o

o

t

t

o

o

r

r





C

C

o

o

r

r

p

p

o

o

r

r

a

a

t

t

i

i

o

o

n

n





T

T

e

e

c

c

h

h

n

n

i

i

c

c

a

a

l

l





S

S

e

e

r

r

v

v

i

i

c

c

e

e





T

T

r

r

a

a

i

i

n

n

i

i

n

n

g

g





















Air Conditioning Fundamentals

TC070-05-01S



CONTENTS



page i

1 –INTRODUCTION
Overview............................................................................................... 1

Audience and Purpose .................................................................. 1
Content and Objectives ................................................................. 2

How to Use This Guide ......................................................................... 5

Section Objectives ......................................................................... 5
Text and Illustrations ...................................................................... 5
Review Exercises .......................................................................... 5





2 – WHAT IS AIR CONDITIONING?
Objectives ............................................................................................. 6
Basic Principle ...................................................................................... 6
Components Enhancing Comfort .......................................................... 7

Heater............................................................................................ 7
Air Conditioning ............................................................................. 7
Fan ................................................................................................ 7
Vent louvers ................................................................................... 7

Air Conditioning Components ............................................................... 8
Review Exercise 1 ................................................................................ 9





3 –A/C TERMS AND CONDITIONS
Objective ........................................................................................... 10
Introduction To Air Conditioning Terms................................................ 10
Pressure ............................................................................................. 10

Reducing the Size of the Container ............................................. 11
Adding Gas .................................................................................. 11
Heating the Contents ................................................................... 11
Effects of Pressure on Boiling Points ........................................... 11

Heat .......................................................................................................... 12

Measuring the Properties of Heat ................................................ 12
Latent Heat .................................................................................. 13

Humidity.............................................................................................. 13

Humidity as a Percent.................................................................. 14
High Humidity .............................................................................. 14

Review Exercise 2 .............................................................................. 15
