Mazda Training manual - part 175

T008/03

6 of 14

49 G011 103

Bolts

49 H010 401

Oil seal installer

49 E033 101

Dust cover

installer

49 0107 680A

Engine stand

49 L010 1A0

Engine

hanger

set

49 E011 1A0

Ring gear

brake set

49 0636 100B

Valve

spring

lifter arm

49 B012 0A2

Pivot

49 S120 170

Valve seal

remover

49 B012 015

Valve guide

installer

49 L012 0A0B

Valve seal

and valve

guide installer

set

49 T032 302

Bearing

installer

49 L011 0A0C

Piston pin

setting set

49 E011 001A

Piston pin

guide

49 E011 002A

Screw

49 H018 001

Knock sensor

wrench

49 D015 001

Box wrench

49 G014 001

Wrench oil filter

Lubrication system

49 0187 280A

Oil pressure

gauge

(LF Engine)

(Z6 Engine)

49 E019 001

Adapter

(LF Engine)

-

Cooling System

49 B015 0A0

Adapter set

-

-

T008/03

7 of 14

Fuel and Emission control system

49 L018 001

O2 sensor

wrench

49 N013 1A0C

Fuel pressure

gauge set

49 F042 001

Wrench

49 L018 901

Injector

checker

(Z6 Engine)

-

-

Clutch

49 SE01 310A

Clutch disc

centering tool

49 1285 071

Bearing puller

49 F028 202

Bush installer

(Z6 Engine)

49 B001 797

Handle

(Z6 Engine)

49 E011 1A0

Ring gear

brake set

1: 49 UN30 8157

2: 308-157

Pilot bearing

installer

(LF Engine)

1: 49 UN20 5153

2: 205-153

Handle

(LF Engine)

-

-

Manual Transaxle (G35M-R)

49 E017 5A0

Engine

support set

49 0107 680A

Engine stand

49 G019 0A0

Transaxle

hanger set

49 G030 440

Primary shaft

holder

49 FT01 361

Bearing

remover

49 F401 366A

plate

T008/03

8 of 14

49 B017 207

Attachment G

49 B017 208

Attachment H

49 B017 209

Attachment J

49 0636 145

Fan pulley

boss puller

49 0839 425C

Bearing

puller set

49 G030 370

Removing plate

49 G030 795

Oil seal installer

49 F401 330B

Bearing

Installer set

49 G030 380D

Shim selector

set

49 G017 202

Preload adapter

49 B017 102

Preload adapter

49 G030 338

Attachment E

49 G030 455

Diff. side

gear holder

-

-

Manual Transaxle (F35M-R)

49 E017 5A0

Engine

support set

49 B027 006

Diff. side

gear holder

49 G030 795

Oil seal installer

49 0107 680A

Engine stand

49 G019 0A0

Transaxle

hanger set

49 F401 440

Primary shaft

holder

49 FT01 361

Bearing

remover

49 0187 520

Rear axle

shaft bearing

puller

49 0839 425C

Bearing

puller set

T008/03

9 of 14

49 0636 145

Fan pulley

boss puller

49 G030 370

Removing plate

49 F401 366A

Plate

49 B017 203

Attachment C

49 B017 205

Attachment E

49 F401 330B

Bearing

installer set

49 H010 401

Oil seal installer

49 D017 2A2A

Shim selector

set

49 T027 001

Preload

adapter

1: 49 UN30 3050

2: 303-050

Engine

lifting

bracket

-

-

Automatic Transaxle (FN4A-EL)

49 B019 901B

Oil pressure

gauge

49 0378 400C

Oil pressure

gauge set

49 E017 5A0

Engine

support set

49 E011 1A0

Ring gear

brake set

49 G030 795

Oil seal installer

49 0107 680A

Engine stand

49 B019 010

Transaxle

hanger

49 0378 390

Oil pump

puller

49 B019 009

Adapter

49 B019 0A1

Lock nut

remover set

49 W032 2A0

Bearing

remover set

49 0500 330

Bearing

installer
