Fig. 18: Terminals Continuity Chart

Fig. 19: Checking Continuity Between Sunroof Switch Terminals



2008 Mazda CX-9 Grand Touring

2008 BODY & ACCESSORIES Sunroof - Mazda CX-9



Microsoft



Sunday, November 15, 2009 10:38:25 AM

Page 19

© 2005 Mitchell Repair Information Company, LLC.

2008 SUSPENSION

Technical Data (Suspension) - Mazda CX-9

SUSPENSION TECHNICAL DATA

Front wheel alignment [2WD] (Unloaded)

*1





FRONT WHEEL ALIGNMENT SPECIFICATION - (2WD) (UNLOADED)

Front wheel alignment [AWD] (Unloaded)

*1





FRONT WHEEL ALIGNMENT SPECIFICATION - (AWD) (UNLOADED)

Rear wheel alignment [2WD] (Unloaded)

*1





REAR WHEEL ALIGNMENT SPECIFICATION - (2WD) (UNLOADED)

Item

Fuel gauge indication

Empty

1/4

1/2

3/4

Full

Maximum steering angle [Tolerance ± 3°]

Inner

38°

Outer

32°

Total toe-in

[Tolerance ± 4 {± 0.16}]

(mm {in})

2 {0.08}

(degree)

0°18' ± 0°32'

Caster angle

(1)

[Tolerance ± 1 °]

3°01'

3°02'

3°03'

3°04'

Camber angle

(1)

[Tolerance ± 1 °]

-0°19'

-0°20'

-0°21'

Steering axis inclination (Reference value)

11°31'

11°32' 11°33' 11°34' 11°35'

*1

 : Engine coolant and engine oil are at specified level. Jack and tools are in designated position.

(1)

Difference between left and right must not exceed 1°30'.

Item

Fuel gauge indication

Empty

1/4

1/2

3/4

Full

Maximum steering angle [Tolerance ± 3°]

Inner

38°

Outer

32°

Total toe-in

[Tolerance ± 4 {±0.16}]

(mm {in})

2 {0.08}

(degree)

0°18' ± 0°32'

Caster angle

(1)

 [Tolerance ± 1 °]

3°02'

3°03'

3°04'

3°05'

Camber angle

(1)

 [Tolerance ± 1 °]

-0°19'

-0°20'

-0°21'

Steering axis inclination (Reference value)

11°31'

11°32' 11°33' 11°34' 11°35'

*1

 : Engine coolant and engine oil are at specified level. Jack and tools are in designated position.

(1)

Difference between left and right must not exceed 1°30'.

Fuel gauge indication



2008 Mazda CX-9 Grand Touring

2008 SUSPENSION Technical Data (Suspension) - Mazda CX-9





2008 Mazda CX-9 Grand Touring

2008 SUSPENSION Technical Data (Suspension) - Mazda CX-9



Microsoft



Sunday, November 15, 2009 10:24:41 AM

Page 1

© 2005 Mitchell Repair Information Company, LLC.

Microsoft



Sunday, November 15, 2009 10:24:44 AM

Page 1

© 2005 Mitchell Repair Information Company, LLC.

Rear wheel alignment [AWD] (Unloaded)

*1





REAR WHEEL ALIGNMENT SPECIFICATION - (AWD) (UNLOADED)

Suspension

SUSPENSION SPECIFICATION

Standard tire

TIRE SPECIFICATION

Item

Empty

1/4

1/2

3/4

Full

Total toe-in

[Tolerance ± 4 {±0.16}]

(mm {in})

2 {0.08}

(degree)

0°09' ± 0°18'

Camber angle

(1)

 (Reference value) [Tolerance ± 1°]

-0°26'

-0°27' -0°29' -0°30' -0°32'

Thrust angle (Reference value) [Tolerance ± 0°48']

0°

*1

 : Engine coolant and engine oil are at specified level. Jack and tools are in designated position.

(1)

Difference between left and right must not exceed 1°30'.

Item

Fuel gauge indication

Empty

1/4

1/2

3/4

Full

Total toe-in

[Tolerance ± 4 {±0.16}]

(mm {in})

2 {0.08}

(degree)

0°09' ± 0°18'

Camber angle

(1)

 (Reference value) [Tolerance ± 1°]

-0°27'

-0°28' -0°30' -0°31' -0°33'

Thrust angle (Reference value) [Tolerance ± 0°48']

0°

*1

 : Engine coolant and engine oil are at specified level. Jack and tools are in designated position.

(1)

Difference between left and right must not exceed 1°30'.

Item

Specification

Front lower arm rotational torque

2.62 N.m {26.7 kgf.cm, 23.1 in.lbf} max.

Front stabilizer control link ball joint starting torque

0.2-2.0 N.m {3-20 kgf.cm, 2-17 in.lbf}

Rear stabilizer control link ball joint starting torque

0.2-2.0 N.m {3-20 kgf.cm, 2-17 in.lbf}

Item

Specification

Tire

Size

P245/60R18 104H

P245/50R20 102V

Air pressure

Front

250 {36}

230 {34}

(kPa {psi}) Rear

Remaining
treed

(mm {in})

1.6 {0.07}

Wheel

Size

18x7 1/2J

20x7 1/2J

Material

Aluminum alloy

Wheel offset

(mm {in})

45 {1.8}



2008 Mazda CX-9 Grand Touring

2008 SUSPENSION Technical Data (Suspension) - Mazda CX-9



Microsoft



Sunday, November 15, 2009 10:24:41 AM

Page 2

© 2005 Mitchell Repair Information Company, LLC.

Temporary spare tire

TIRE SPECIFICATION

Standard
tire

Wheel pitch
circle
diameter

(mm {in})

114.3 {4.5}

Wheel and tire
runout

Lateral
direction

2.0 {0.08}

(mm {in})

Radial
direction

1.5 {0.06}

Wheel and tire
imbalance

(g {oz})

Adhesive-type

*1

 : 10 {0.35}

max.

Knock-type

*2

 : 6 {0.21} max.

Adhesive-type

*1

 : 6 {0.21}

max.

Knock-type

*2

 : 4 {0.14} max.

*1

 : Total weight exceeds 160 g {5.65 oz} .

*2

 : One balance weight: 60 g {2.12 oz} max . If the total

weight exceeds 100 g {3.53 oz} on one side, rebalance after
moving the tire around on the rim. Do not use three or more
balance weights.

Wheel nut tightening
torque

(N.m

{kgf.m,

ft.bf})

107.8-147.0 {11.0-14.9, 79.6-108.4}

Item

Specification

Temporary spare
tire

Tire

Size

T155/90D 18

195/80R17 99M

Air pressure (kPa {psi})

420 {60}

250 {36}

Remaining treed

(mm {in})

1.6 {0.07}

Wheel

Size

18x4T

17x5 1/2J

Material

Steel

Wheel offset

(mm {in})

40 {1.57}

45 {1.8}

Wheel pitch circle
diameter

(mm {in})

114.3 {4.5}

Wheel and tire runout

Lateral direction

2.0 {0.08}

(mm {in}) Radial direction

1.5 {0.06}

Wheel nut tightening torque

(N.m {kgf.m,

ft.bf})

107.8-147.0 {11.0-14.9, 79.6-

108.4}
