2 INFORMATION AVAILABILITY Verify related Service Bulletins Is any related Service Bulletins Yes Perform repair or diagnosis according to the If the vehicle is not repaired, go to the next No Go to the next step. 3 INSPECT APP SENSOR CONNECTOR Turn the ignition switch off. Disconnect the APP sensor Inspect for poor connection (such as Are there any malfunction? Yes Repair or replace suspected part, then go to Step No Go to the next step. 4 INSPECT APP SENSOR NO.3 Turn the ignition switch off. Inspect for continuity between the APP sensor terminal F and APP sensor terminal D and APP sensor terminal G and APP sensor terminal C and APP sensor terminal B and Are there continuity? Yes Repair or replace suspected part, then go to Step No Go to the next step. 5 INSPECT APP SENSOR NO.3 Inspect APP sensor No.3. (See Is there any malfunction? Yes Replace the accelerator pedal, then go to Step 7. No Go to the next step. INSPECT PCM CONNECTOR FOR Yes Repair or replace suspected part, then go to Step
2008 Mazda CX-9 Grand Touring 2008 ENGINE PERFORMANCE On-Board Diagnostic (MZI-3.7) - Mazda CX-9
