Mazda CX-9 Grand Touring. Manual - part 223

P1336

CKP/CMP sensor
range/performance

ON

2 (See DTC P1336 [MZI-3.7].)

P1397

System voltage out of self-test
range

OFF

1 (See DTC P1397 [MZI-3.7].)

P1450

Unable to bleed up fuel tank
vacuum

ON

2 (See DTC P1450 [MZI-3.7].)

P145E PCV heater control circuit

OFF

1 (See DTC P145E [MZI-3.7].)

P1464 A/C demand out of self-test range

OFF

1 (See DTC P1464 [MZI-3.7])

P1500 Vehicle speed signal

OFF

1 (See DTC P1500 [MZI-3.7])

P1501

Vehicle speed sensor (VSS) out of
self-test range

OFF

1 (See DTC P1501 [MZI-3.7].)

P1633 Keep alive power voltage too low

ON

1 (See DTC P1633 [MZI-3.7].)

P1635 Tire/axle out of acceptable range

OFF

1 (See DTC P1635 [MZI-3.7].)

P1639

Vehicle ID block corrupted, not
programmed

ON

2 (See DTC P1639 [MZI-3.7].)

P1650 PSP switch out of self-test range

OFF

1 (See DTC P1650 [MZI-3.7].)

P1674 Control module software corrupted OFF

(2)

1 (See DTC P1674 [MZI-3.7].)

P1703 Brake switch out of self-test range

OFF

1 (See DTC P1703 [MZI-3.7].)

P2100 Throttle actuator circuit open

OFF

(2)

1 (See DTC P2100 [MZI-3.7].)

P2101

Throttle actuator circuit
range/performance

ON

(2)

2 (See DTC P2101 [MZI-3.7].)

P2104

Throttle actuator control system -
forced idle

ON

(2)

2

(See DTC P2104, P2105, P2106, P2110
[MZI-3.7].)

P2105

Throttle actuator control system -
forced engine shutdown

OFF

(2)

1

(See DTC P2104, P2105, P2106, P2110
[MZI-3.7].)

P2107

Throttle actuator control module
processor

ON

(2)

2 (See DTC P2107 [MZI-3.7].)

P2110

Throttle actuator control system -
forced limited RPM

ON

(2)

2

(See DTC P2104, P2105, P2106, P2110
[MZI-3.7].)

P2111

Throttle actuator control system -
stuck open

ON

(2)

2 (See DTC P2111 [MZI-3.7].)

P2112

Throttle actuator control system -
stuck closed

ON

(2)

2 (See DTC P2112 [MZI-3.7].)

P2121

APP sensor No.1 circuit
range/performance

OFF

(2)

1 (See DTC P2121, P2126, P2131 [MZI-3.7].)

P2122 APP sensor No.1 circuit low input

OFF

(2)

1 (See DTC P2122 [MZI-3.7].)

P2123 APP sensor No.1 circuit high input OFF

(2)

1 (See DTC P2123 [MZI-3.7].)

P2126

APP sensor No.2 circuit
range/performance

OFF

(2)

1 (See DTC P2121, P2126, P2131 [MZI-3.7].)

P2127 APP sensor No.2 circuit low input

OFF

(2)

1 (See DTC P2127 [MZI-3.7].)

P2128 APP sensor No.2 circuit high input OFF

(2)

1 (See DTC P2128 [MZI-3.7].)

APP sensor No.3 circuit



2008 Mazda CX-9 Grand Touring

2008 ENGINE PERFORMANCE On-Board Diagnostic (MZI-3.7) - Mazda CX-9



Microsoft



Sunday, November 15, 2009 10:08:34 AM

Page 25

© 2005 Mitchell Repair Information Company, LLC.

DTC B1342 [MZI-3.7]

DTC B1342 (MZI-3.7) DETECTION CONDITIONS AND POSSIBLE CAUSES

DIAGNOSTIC PROCEDURE

DTC B1342 (MZI-3.7) DIAGNOSTIC PROCEDURE

P2131 range/performance

OFF

(2)

1 (See DTC P2121, P2126, P2131 [MZI-3.7].)

P2132 APP sensor No.3 circuit low input

OFF

(2)

1 (See DTC P2132 [MZI-3.7].)

P2133 APP sensor No.3 circuit high input OFF

(2)

1 (See DTC P2133 [MZI-3.7].)

P2135

TP sensor No.1/No.2 voltage
correlation

ON

(2)

2 (See DTC P2135 [MZI-3.7].)

P2195 Front HO2S (RH) signal stuck lean

ON

2 (See DTC P2195, P2197 [MZI-3.7].)

P2196 Front HO2S (RH) signal stuck rich

ON

2 (See DTC P2196, P2198 [MZI-3.7].)

P2197 Front HO2S (LH) signal stuck lean

ON

2 (See DTC P2195, P2197 [MZI-3.7].)

P2198 Front HO2S (LH) signal stuck rich

ON

2 (See DTC P2196, P2198 [MZI-3.7].)

P2270 Rear HO2S (RH) signal stuck lean

ON

2 (See DTC P2270, P2272 [MZI-3.7].)

P2271 Rear HO2S (RH) signal stuck rich

ON

2 (See DTC P2271, P2273 [MZI-3.7].)

P2272 Rear HO2S (LH) signal stuck lean

ON

2 (See DTC P2270, P2272 [MZI-3.7].)

P2273 Rear HO2S (LH) signal stuck rich

ON

2 (See DTC P2271, P2273 [MZI-3.7].)

P260F

Evaporative emission system
monitoring processor performance

ON

2 (See DTC P260F [MZI-3.7].)

U0101 Communication error to TCM

(See PROCEDURES FOR DETERMINING THE

LOCATION OF A MALFUNCTION [MULTIPLEX

COMMUNICATION SYSTEM] .)

U0129

Communication error to DSC/RSC
HU/CM

U0155

Communication error to instrument
cluster

U0300

(2)

Internal control module software
incompatibility

(1)

The fuel cap warning light illuminates.

(2)

The electronic throttle control (ETC) warning light illuminates.

DTC B1342

PCM malfunction

DETECTION CONDITION



Malfunction in the PCM internal circuit.

POSSIBLE CAUSE



PCM EEPROM malfunction



PCM parameter reset has not been completed

STEP

INSPECTION

ACTION

VERIFY CURRENT STATUS OF
MALFUNCTION



2008 Mazda CX-9 Grand Touring

2008 ENGINE PERFORMANCE On-Board Diagnostic (MZI-3.7) - Mazda CX-9



Microsoft



Sunday, November 15, 2009 10:08:34 AM

Page 26

© 2005 Mitchell Repair Information Company, LLC.

DTC P0010 [MZI-3.7]

DTC P0010 (MZI-3.7) DETECTION CONDITIONS AND POSSIBLE CAUSES

1



Clear the DTC from the PCM memory using the
M-MDS.



Perform the PCM parameter reset using the M-
MDS.

(See IMMOBILIZER SYSTEM
COMPONENT REPLACEMENT/KEY
ADDITION AND CLEARING [ADVANCED
KEYLESS SYSTEM] .) (See IMMOBILIZER
SYSTEM COMPONENT
REPLACEMENT/KEY ADDITION AND
CLEARING [KEYLESS ENTRY
SYSTEM] .)



Is same DTC present?

Yes

Replace the PCM, then go to the next
step. (See PCM
REMOVAL/INSTALLATION
[MZI-3.7] .)

No

Go to the next step.

2

VERIFY AFTER REPAIR PROCEDURE



Perform the "AFTER REPAIR PROCEDURE".

(See AFTER REPAIR PROCEDURE [MZI-
3.7].)



Are any DTC present?

Yes

Go to the applicable DTC inspection.
(See DTC TABLE [MZI-3.7].)

No

Troubleshooting completed.

DTC P0010

CMP actuator circuit open (RH)

DETECTION

CONDITION



The PCM monitors the OCV (RH) circuit to the PCM for high and low voltage. The
test fails if the voltage exceeds or falls below a calibrated limit for a calibrated
amount of time.

POSSIBLE CAUSE



OCV (RH) malfunction



Connector or terminal malfunction



Open circuit between OCV (RH) terminal A and main relay No.1 terminal D



Open circuit between OCV (RH) terminal B and PCM terminal 2BP



Short to ground circuit between OCV (RH) terminal B and PCM terminal 2BP



Short to power supply between OCV (RH) terminal B and PCM terminal 2BP
