Transfer

TRANSFER SPECIFICATION

Item

Specification

Transfer oil

Grade: API service GL-5

Viscosity: SAE 75W-140

Capacity (approximate quantity): 0.532 L {0.562 US qt, 0.468 lmp qt}



2008 Mazda CX-9 Grand Touring

2008 DRIVELINE/AXLE Technical Data (Driveline/Axle) - Mazda CX-9



Microsoft



Sunday, November 15, 2009 9:51:36 AM

Page 2

© 2005 Mitchell Repair Information Company, LLC.

2008 BRAKES

Dynamic Stability Control/Roll Stability Control - Mazda CX-9

DSC/RSC LOCATION INDEX



2008 Mazda CX-9 Grand Touring

2008 BRAKES Dynamic Stability Control/Roll Stability Control - Mazda CX-9





2008 Mazda CX-9 Grand Touring

2008 BRAKES Dynamic Stability Control/Roll Stability Control - Mazda CX-9



Microsoft



Sunday, November 15, 2009 9:40:24 AM

Page 1

© 2005 Mitchell Repair Information Company, LLC.

Microsoft



Sunday, November 15, 2009 9:40:27 AM

Page 1

© 2005 Mitchell Repair Information Company, LLC.

Fig. 1: Identifying DSC/RSC Parts Location
Courtesy of MAZDA MOTORS CORP.

DSC/RSC SYSTEM WIRING DIAGRAM



2008 Mazda CX-9 Grand Touring

2008 BRAKES Dynamic Stability Control/Roll Stability Control - Mazda CX-9



Microsoft



Sunday, November 15, 2009 9:40:24 AM

Page 2

© 2005 Mitchell Repair Information Company, LLC.

Fig. 2: DSC/RSC System Wiring Diagram
Courtesy of MAZDA MOTORS CORP.

DSC/RSC SYSTEM INSPECTION

PREPARATION

1. Verify that battery is fully charged.

2. Turn the ignition switch to the ON position, and verify that the ABS warning light goes out after approx.

3 s.

3. Turn the ignition switch off.

4. Jack up the vehicle and support it evenly on safety stands.

5. Shift to the N position.

6. Verify that all four wheels rotate.

7. Rotate the inspected wheels by hand, and verify there is no brake drag.



If there is any brake drag, perform regular brake inspection.



If there is no brake drag, perform DSC/RSC HU/CM operation inspection.

ABS CONTROL INSPECTION

1. Perform "Preparation".

2. Connect the M-MDS to the DLC-2.

3. Set up an active command mode inspection according to the combination of commands below.
