Mazda CX 7. Manual - part 438





CONTROL SYSTEM

09-40–3

09-40

1K

Power door lock
power supply

Main fuse block

Under any condition

B+

• Related wiring

harnesses

1L

Rear washer
motor control

Rear washer
motor

Ignition switch at
ON

Rear washer
switch on

1.0 or less

• Rear washer motor

• Related wiring

harnesses

Rear washer
switch off

B+

1M

Front turn light
(RH) control

Front turn light
(RH)

Turn switch (RH)
on

Front turn light
(RH) flashes

Alternates

between 1.0

or less and

B+

• Front turn light (RH)

• Related wiring

harnesses

Hazard warning
switch on

Other

1.0 or less

1N

Rear washer
motor power
supply

Rear washer
motor

Ignition switch at ON

B+

• Ignition switch

• Rear washer motor

• Related wiring

harnesses

Ignition switch off

1.0 or less

1O

Front turn light
(LH) control

Front turn light
(LH)

Turn switch (LH)
on

Front turn light
(LH) flashes

Alternates

between 1.0

or less and

B+

• Front turn light (LH)

• Related wiring

harnesses

Hazard warning
switch on

Other

1.0 or less

1P

Back-up light
power supply

Back-up light
relay

Back-up light on

B+

• Back-up light relay

• Back-up light

• Related wiring

harnesses

Back-up light off

1.0 or less

3A

Security light
control

Instrument
cluster

Security light on

1.0 or less

• Instrument cluster

• Related wiring

harnesses

Security light off

B+

3B

— —

—

—

—

3C

Key reminder
switch signal

• Steering lock

unit (with
advanced
keyless
system)

• Key reminder

switch (with
keyless entry
system)

Key inserted

B+

• Steering lock unit (with

advanced keyless
system)

• Key reminder

switch(with keyless
entry system)

• Related wiring

harnesses

Key removed

1.0 or less

3D

Ignition key
illumination
power supply

Ignition key
illumination

Under any condition

B+

• Related wiring

harnesses

3E

Ignition key
illumination
control

Ignition key
illumination

Ignition switch off and driver-side
door opened.

1.0 or less

• Ignition key illumination

bulb

• Related wiring

harnesses

15 s or more after all doors closed.

B+

3F

Key reminder
switch power
supply

Key reminder
switch

Under any condition

B+

• Related wiring

harnesses

3G

Serial
communication

Keyless control
module

Because this terminal is for
communication, good/no good
judgment by terminal voltage is not
possible.

—

• Keyless control module

• Related wiring

harnesses

3H

Horn switch
signal

Hor switch

Hor switch off

B+

• Hor switch

• Related wiring

harnesses

Hor switch on

1.0 or less

3I

Steering angle
sensor GND

Steering angle
sensor

Under any condition

1.0 or less

• Related wiring

harnesses

3J

Hazard warning
switch signal

Hazard warning
switch

Hazard warning switch on

1.0 or less

• Hazard warning switch

• Related wiring

harnesses

Hazard warning switch off

B+

3K

Steering angle
sensor signal (Z)

Steering angle
sensor

Under any condition: Inspect for
continuity to steering angle sensor.

Continuity

detected

• Related wiring

harnesses

Termin

al

Signal

Connected to

Measurement condition

Voltage (V)/

Continuity

Inspection item (s)

1871-1U-06B(09-40).fm  3 ページ  2006年3月15日 水曜日 午後1時9分

CONTROL SYSTEM

09-40–4

3L

Turn switch input
(LH)

Turn switch

Ignition switch at
ON

Turn switch at
left position

1.0 or less

• Turn switch

• Related wiring

harnesses

Other

B+

3M

Steering angle
sensor signal (C)

Steering angle
sensor

Under any condition: Inspect for
continuity to steering angle sensor.

Continuity

detected

• Related wiring

harnesses

3N

Turn switch input
(RH)

Turn switch

Ignition switch at
ON

Turn switch at
right position

1.0 or less

• Turn switch

• Related wiring

harnesses

Other

B+

3O

Steering angle
sensor signal (B)

Steering angle
sensor

Under any condition: Inspect for
continuity to steering angle sensor.

Continuity

detected

• Related wiring

harnesses

3P

— —

—

—

—

3Q

Steering angle
sensor signal (A)

Steering angle
sensor

Under any condition: Inspect for
continuity to steering angle sensor.

Continuity

detected

• Related wiring

harnesses

3R

Rear wiper
switch signal
(INT)

Windshield wiper
and washer
switch

Ignition switch at
ON

Rear wiper
switch at INT
position

1.0 or less

• Wiper and washer

switch

• Related wiring

harnesses

Other

B+

3S

Steering angle
sensor power
supply

Steering angle
sensor

Fifteen hours after key removed
and all doors closed.

approx. 2.5

• Steering angle sensor

• Related wiring

harnesses

Other

5

3T

Rear wiper
switch signal
(on)

Windshield wiper
and washer
switch

Ignition switch at
ON

Rear wiper
switch at ON
position

1.0 or less

• Wiper and washer

switch

• Related wiring

harnesses

Other

B+

3U

BCM GND

Body ground

Under any condition: Inspect for
continuity to ground.

Continuity

detected

• Related wiring

harnesses

3V

A/C on request
signal

Climate control
unit (manual air
conditioner)

A/C on

1.0 or less

• Climate control unit

(manual air conditioner)

• Related wiring

harnesses

A/C off

5

3W

CAN_H

—

Because this terminal is for
communication, good/no good
judgment by terminal voltage is not
possible.

—

• Related wiring

harnesses

3X

CAN_L

—

Because this terminal is for
communication, good/no good
judgment by terminal voltage is not
possible.

—

• Related wiring

harnesses

4A

BCM GND

Body ground

Under any condition: Inspect for
continuity to ground.

Continuity

detected

• Related wiring

harnesses

4B

Tail light power
supply

TNS relay

Light switch at TNS position

B+

• TNS relay

• Related wiring

harnesses

Light switch at OFF position

1.0 or less

4D

Rear wiper and
washer power
supply

• Fuse block

• Rear wiper

motor

Ignition switch at ON

B+

• Ignition switch

• Rear wiper motor

• Related wiring

harnesses

Ignition switch off

1.0 or less

4F

Rear washer
switch signal

Windshield wiper
and washer
switch

Ignition switch at
ON

Rear washer
switch on

1.0 or less

• Windshield wiper and

washer switch

• Related wiring

harnesses

Rear washer
switch off

B+

4G

— —

—

—

—

4H

Heated outer
mirror power
supply

Rear window
defloster relay

Rear window defloster relay on

B+

• Rear window defloster

relay

• Related wiring

harnesses

Rear window defloster relay off

1.0 or less

4I

BCM power
supply

Fuse block

Under any condition

B+

• Ignition switch

• Related wiring

harnesses

4J

BCM power
supply

Fuse block

Under any condition

B+

• Related wiring

harnesses

Termin

al

Signal

Connected to

Measurement condition

Voltage (V)/

Continuity

Inspection item (s)

1871-1U-06B(09-40).fm  4 ページ  2006年3月15日 水曜日 午後1時9分

CONTROL SYSTEM

09-40–5

09-40

5A

Driver-side door
key cylinder
switch signal

Driver-side door
key cylinder
switch

At the moment key cylinder is
unlocked

1.0 or less

• Driver-side door key

cylinder switch

• Related wiring

harnesses

At the moment key cylinder is
locked

2.5

Other

5

5B

Serial
communication

• Power

window main
switch

• Sunroof

motor

Because this terminal is for
communication, good/no good
judgment by terminal voltage is not
possible.

—

• Power window main

switch

• Sunroof motor

• Related wiring

harnesses

5C

CAN_L

—

Because this terminal is for
communication, good/no good
judgment by terminal voltage is not
possible.

—

• Related wiring

harnesses

5D

Lock/unlock
input (rear door
lock-link switch
(LH))

Rear door lock-
link switch (LH)

Rear door (LH) locked

5

• Rear door lock-link

switch (LH)

• Related wiring

harnesses

Rear door (LH) unlocked

1.0 or less

5E

Lock/unlock
input (rear door
lock-link switch
(RH))

Rear door lock-
link switch (RH)

Rear door (RH) locked

5

• Rear door lock-link

switch (RH)

• Related wiring

harnesses

Rear door (RH) unlocked

1.0 or less

5F

CAN_H

—

Because this terminal is for
communication, good/no good
judgment by terminal voltage is not
possible.

—

• Related wiring

harnesses

5G

Lock input
(Driver-side door
lock-link switch)

Driver-side door
lock-link switch

Driver-side door locked

1.0 or less

• Driver-side door lock-

link switch

• Related wiring

harnesses

Driver-side door unlocked

5

5H

Lock/unlock
input
(passenger-side
door lock-link
switch)

Passenger-side
door lock-link
switch

Passenger-side door locked

1.0 or less

• Passenger-side door

lock-link switch

• Related wiring

harnesses

Passenger-side door unlocked

5

5I

CAN_L

—

Because this terminal is for
communication, good/no good
judgment by terminal voltage is not
possible.

—

• Related wiring

harnesses

5J

Unlock input
(Driver-side door
lock-link switch)

Driver-side door
lock-link switch

Driver-side door locked

5

• Driver-side door lock-

link switch

• Related wiring

harnesses

Driver-side door unlocked

1.0 or less

5K

— —

—

—

—

5L

CAN_H

—

Because this terminal is for
communication, good/no good
judgment by terminal voltage is not
possible.

—

• Related wiring

harnesses

5M

Lock/unlock
signal

Door lock switch
(driver-side)

Door lock switch (driver-side) is
pressed to lock.

2.5

• Door lock switch (driver-

side)

• Related wiring

harnesses

Door lock switch (driver-side) is
pressed to unlock.

1.0 or less

Other

5

5N

Lock/unlock
signal

Door lock switch
(passenger-side)

Door lock switch (passenger-side)
is pressed to lock.

2.5

• Door lock switch

(passenger-side)

• Related wiring

harnesses

Door lock switch (passenger-side)
is pressed to unlock.

1.0 or less

Other

5

Termin

al

Signal

Connected to

Measurement condition

Voltage (V)/

Continuity

Inspection item (s)

1871-1U-06B(09-40).fm  5 ページ  2006年3月15日 水曜日 午後1時9分

CONTROL SYSTEM

09-40–6

5O

Rear turn light
(RH) control

Rear turn light
(RH)

Turn switch (RH)
on

Rear turn light
(RH) flashes

Alternates

between 1.0

or less and

B+

• Reat turn light (RH)

• Related wiring

harnesses

Hazard warning
switch on

Other

1.0 or less

5P

Liftgate latch
switch signal

Liftgate latch
switch

Liftgate is open.
 (Liftgate latch switch off)

B+

• Liftgate latch switch

• Related wiring

harnesses

Liftgate is closed.
 (Liftgate latch switch on)

1.0 or less

5Q

— —

—

—

—

5R

Rear turn light
(LH) control

Rear turn light
(LH)

Turn switch (LH)
on

Rear turn light
(LH) flashes

Alternates

between 1.0

or less and

B+

• Reat turn light (LH)

• Related wiring

harnesses

Hazard warning
switch on

Other

1.0 or less

5S

Rear door switch
(LH) signal

Rear door switch
(LH)

Any rear doors open
 (Rear door switch on)

1.0 or less

• Rear door switches

• Related wiring

harnesses

All rear doors closed
 (Rear door switch off)

B+

5T

Rear door switch
(RH) signal

Rear door switch
(RH)

Any rear doors open
 (Rear door switch on)

1.0 or less

• Rear door switches

• Related wiring

harnesses

All rear doors closed
 (Rear door switch off)

B+

5U

Back-up light
(RH) control

Back-up light
(RH)

Back-up light on

B+

• Back-up light relay

• Back-up light (RH)

• Related wiring

harnesses

Back-up light off

1.0 or less

5V

Front door switch
(passenger-side)
signal

Front door switch
(passenger-side)

Front door (passenger-side) open
 (Front door switch (passenger-
side) on)

1.0 or less

• Front door switch

(passenger-side)

• Related wiring

harnesses

Front door (passenger-side) closed
 (Front door switch (passenger-
side) off)

B+

5W

— —

—

—

—

5X

Back-up light
(LH) control

Back-up light
(LH)

Back-up light on

B+

• Back-up light relay

• Back-up light (LH)

• Related wiring

harnesses

Back-up light off

1.0 or less

5Y

Front door switch
(driver-side)
signal

Front door switch
(driver-side)

Front door (driver-side) open
 (Front door switch (driver-side) on)

1.0 or less

• Front door switch

(driver-side)

• Related wiring

harnesses

Front door (driver-side) closed
 (Front door switch (driver-side) off)

B+

5Z

— —

—

—

—

5AA

Heated outer
mirror control

Heated outer
mirror (driver-
side)

Rear window defloster relay on

B+

• Rear window defloster

relay

• Heated outer mirror

(driver-side)

• Related wiring

harnesses

Rear window defloster relay off

1.0 or less

5AB

Tail light (RH)
control

• License plate

light (RH)

• Tail light (RH)

• Rear side

marker light
(RH)

Light switch at TNS position

B+

• License plate light (RH)

• Taillight (RH)

• Rear side marker light

(RH)

• Related wiring

harnesses

Light switch at OFF position

1.0 or less

5AC

Tail light (LH)
control

• License plate

light (LH)

• Tail light (LH)

• Rear side

marker light
(LH)

Light switch at TNS position

B+

• License plate light (LH)

• Taillight (LH)

• Rear side marker light

(LH)

• Related wiring

harnesses

Light switch at OFF position

1.0 or less

Termin

al

Signal

Connected to

Measurement condition

Voltage (V)/

Continuity

Inspection item (s)
