ON-BOARD DIAGNOSTIC [AW6A-EL, AW6AX-EL] 05-02–25 05-02 Diagnostic procedure End Of Sie STEP INSPECTION ACTION 1 VERIFY FREEZE FRAME DATA HAS BEEN • Has the FREEZE FRAME DATA been recorded? Yes Go to the next step. No Record the FREEZE FRAME DATA on the repair order, 2 VERIFY RELATED REPAIR INFORMATION • Verify related Service Bulletins and/or on-line repair information availability. • Is any related repair information available? Yes Perform repair or diagnosis according to the available • If the vehicle is not repaired, go to the next step. No Go to the next step. 3 INSPECT ATF CONDITION • Inspect the ATF condition. (See 05-17-10 AUTOMATIC TRANSAXLE • Is it normal? Yes Go to the next step. No Replace the transaxle, then go to Step 8. 4 INSPECT ATF LEVEL • Start the engine. • Warm up the ATX. • Is the ATF level within the specification? (See 05-17-10 AUTOMATIC TRANSAXLE Yes Go to the next step. No Add ATF to the specified level, then go to Step 8. 5 INSPECT LINE PRESSURE • Start the engine. • Measure the line pressures. (See 05-17-3 MECHANICAL SYSTEM • Are the line pressures within the specifications? Yes Go to the next step. No All ranges: Replace the oil pump, then go to Step 8. 6 INSPECT STALL SPEED • Measure the stall speed in D range. (See 05-17-3 MECHANICAL SYSTEM • Is the stall speed within the specification? Yes Go to the next step. No Replace the automatic transaxle, then go to Step 8. 7 INSPECT SHIFT SOLENOID • Inspect the shift solenoid. (See 05-17-20 SOLENOID VALVE • Is it normal? Yes Go to the next step. No Replace the control valve body. 8 VERIFY TROUBLESHOOTING OF DTC P0730 • Make sure to reconnect all the disconnected connectors. • Clear the DTC from the memory using the M- MDS. • Drive the vehicle under the following conditions at least 12 times for more than 1 s: °C {68 °F} or more — Drive in the M range, 1GR — Accelerator opening angle (THOP PID):10% or more • Is same DTC present? Yes Replace the TCM, then go to the next step. No Go to the next step. 9 VERIFY AFTER REPAIR PROCEDURE • Perform the “After Repair Procedure”. (See 05-02-4 AFTER REPAIR • Are any DTCs present? Yes Go to the applicable DTC inspection. No DTC troubleshooting completed. 1871-1U-06B(05-02).fm 25 ページ 2006年3月15日 水曜日 午前11時18分 |
