GENERAL INFORMATION

00-00–27

00-00

JACKING POSITIONS, VEHICLE LIFT (2 SUPPORTS) AND SAFETY STAND (RIGID RACK) POSITIONS

id000000800500

Jacking Positions

Warning

• Improperly jacking a vehicle is dangerous. The vehicle can slip off the jack and cause serious

injury. Use only the correct front and rear jacking points and block the wheels.

• Use safety stands to support the vehicle after it has been lifted.

Front

Note

• To prevent obstruction between the jack body and front bumper when the jack body is inserted, use a low-

floor type jack (frame height is 170 mm or less).

• Near the center or the front crossmember.

Rear
2WD

• Near the center of the rear crossmember.

AWD

• At the center of the rear differential.

acxuuw00000066

acxuuw00000064

acxuuw00000065

GENERAL INFORMATION

00-00–28

Vehicle Lift Positions
Front and rear

Warning

• Lifting a vehicle that is not stabilized is dangerous. The vehicle can slip off the lift and cause

serious injury and/or vehicle damage. Make sure that the vehicle is on the lift horizontally by
adjusting the height of the support at the end of the arm of the lift.

Note

• The arrow at the rear of the vehicle indicates that it is the same as the illustration for the front of the

vehicle.

• Both sides of the vehicle, on side sills.

Safety Stand Positions
Front and rear

Note

• The arrow at the rear of the vehicle indicates that it is the same as the illustration for the front of the

vehicle.

• Both sides of the vehicle, on side sills.

End Of Sie

acxuuw00000068

acxuuw00000069

GENERAL INFORMATION

00-00–29

00-00

TOWING

id000000800600

• Proper lifting and towing are necessary to prevent damage to the vehicle.

Particularly when towing a AWD vehicle, where all the wheels are connected to the drive train, proper
transporting of the vehicle is absolutely essential to avoid damaging the drive system. Government and local
laws must be followed.

• A towed 2WD vehicle should have its front wheels off the ground. If excessive damage or other conditions

prevent this, use wheel dollies.

• When towing a 2WD vehicle with the rear wheels on the ground, release the parking brake.

• A towed AWD vehicle must have all its wheels off

the ground.

Towing a 2WD Vehicle

Caution

• Don't tow with sling-type equipment. This

could damage the vehicle. Use wheel-lift
or flatbed equipment.

Caution

• Don't tow the vehicle pointed backward

with driving wheels on the ground. This
may cause internal damage to the
transaxle.

WHEEL DOLLIES

acxuuw00000512

acxuuw00000513

acxuuw00000514

GENERAL INFORMATION

00-00–30

Towing a AWD Vehicle

Warning

• Towing a AWD vehicle with either the

front or rear wheels on the ground is
dangerous as the drive train could be
damaged, or the vehicle could trail away
from the tow truck and cause an
accident. Always tow a AWD vehicle with
all four wheels off the ground. If the drive
train has been damaged, transport the
vehicle on a flat bed truck.

Towing/Tiedown Hooks

Caution

• Don't use the tiedown hooks under the front and rear for towing. They are designed ONLY for tying

down the vehicle when it's being transported. Using them for towing will damage the bumper.

Tiedown Hooks

1. Remove the tiedown eyelet, lug wrench, and jack lever from the trunk.
2. Wrap a screwdriver or similar tool with a soft cloth

to prevent damage to the bumper and open the
cap located on the front and rear bumper.

Caution

• The cap cannot be completely removed.

Do not use excessive force as it may
damage the cap or scratch the painted
bumper surface.

3. Securely install the tiedown eyelet using the

wheel brace.

acxuuw00000515

acxuuw00000516

acxuuw00000517

acxuuw00000518
