ON-BOARD DIAGNOSTIC [AUDIO]

09–02B–10

End Of Sie

DTC 05:ER01

A3U090266900W18

Diagnostic procedure

End Of Sie

DTC 05:ER07

A3U090266900W19

Diagnostic procedure

End Of Sie

DTC 05:Er01

CD changer (external type)

DETECTION

CONDITION

•

Changer function does not operate.

POSSIBLE

CAUSE

•

Defective CD (broken or foreign material)

•

Magazine malfunction

•

CD changer (external type) malfunction

STEP

INSPECTION

ACTION

1

VERIFY WHETHER MALFUNCTION IS IN CD
CHANGER OR OTHER PARTS

•

Operate changer function.

•

Is function okay?

Yes

Go to Step 4.

No

Not able to change particular CD. Go to next step.

Not able to change any CD.

Go to Step 3.

2

INSPECT CD

•

Inspect condition of CD where error has occurred.

•

Is CD okay?

Note

•

In some cases, not all CD-R/CD-RW will play.

Yes

Go to next step.

No

Repair (remove foreign material) or replace CD,
then go to next step.

3

INSPECT MAGAZINE

•

Inspect magazine.

•

Is magazine okay?

Yes

Go to next step.

No

Repair or replace magazine, then go to next step.

4

INSPECT CD CHANGER (EXTERNAL TYPE)

•

Clear DTC.

•

Operate changer.

•

Start on-board diagnostic test mode.

•

Is DTC 05:Er01 displayed?

Yes

Replace CD changer (external type).

No

Troubleshooting completed.

DTC 05:Er07

CD changer (external type)

DETECTION

CONDITION

Note

•

When error occurs, error message “CHECK CD” is displayed in the LCD.

•

Base unit detects CD reading error.

POSSIBLE

CAUSE

•

Defective CD (scratches or dirt)

•

CD changer (external type) malfunction

STEP

INSPECTION

ACTION

1

VERIFY WHETHER MALFUNCTION IS IN CD
CHANGER OR OTHER PARTS

•

Play all CD in magazine.

•

Is CD changer able to read them properly?

Yes

Go to Step 3.

No

Not able to change particular CD.

Go to next step.

Not able to change any CD.

Go to Step 3.

2

INSPECT CD

•

Inspect condition of CD where error has occurred.

•

Is CD okay?

Note

•

In some cases, not all CD-R/CD-RW will play.

Yes

Go to next step.

No

Repair (remove foreign material) or replace CD, then
go to next step.

3

INSPECT CD CHANGER (EXTERNAL TYPE)

•

Clear DTC.

•

Insert and play CD with no defect.

•

Start on-board diagnostic test mode.

•

Is DTC 05:Er07 displayed?

Yes

Replace CD changer (external type).

No

Troubleshooting completed.

1712-1U-01G(09-02B).fm  10 ページ  ２００１年６月２９日 金曜日 午前１０時２７分

ON-BOARD DIAGNOSTIC [AUDIO]

09–02B–11

09–02B

DTC 06:ER01

A3U090266900W20

Diagnostic procedure

End Of Sie

DTC 06:ER02

A3U090266900W21

Diagnostic procedure

End Of Sie

DTC 06:Er01

CD changer (upper module)

DETECTION

CONDITION

•

CD changer (upper module) cannot perform insert, eject, and disc change commands.

POSSIBLE

CAUSE

•

Defective CD (broken or foreign material stuck/attached)

•

CD changer (upper module) malfunction

STEP

INSPECTION

ACTION

1

•

Is CD able to be ejected?

Yes

Go to next step.

No

Replace CD changer (upper module).

2

INSPECT CD

•

Inspect condition of CD where error has occurred.

•

Is CD okay?

Note

•

In some cases, not all CD-R/CD-RW will play.

Yes

Go to next step.

No

Repair (remove foreign material) or replace CD, then
go to next step.

3

INSPECT CD CHANGER (UPPER MODULE)

•

Clear DTC.

•

Insert and eject CD with no defect.

•

Start on-board diagnostic test mode.

•

Is DTC 06:Er01 displayed?

Yes

Replace CD changer (upper module).

No

Troubleshooting completed.

DTC 06:Er02

CD changer (upper module)

DETECTION

CONDITION

Note

•

When error occurs, error message “CHECK CD” is displayed in the LCD.

•

Can not play CD normally or change tracks.

POSSIBLE

CAUSE

•

Defective CD (scratches or dirt)

•

CD changer (upper module) malfunction

STEP

INSPECTION

ACTION

1

VERIFY WHETHER MALFUNCTION IS IN CD
CHANGER (UPPER MODULE) OR CD

•

Play all CDs in changer and select other song
(change tracks).

•

Is CD changer able to change tracks?

Yes

Go to Step 3.

No

Not able to change
particular tracks.

Go to next step.

Not able to change any
tracks.

Change CD and perform
tracks-change again.

•

If CD changer changes
tracks, then go to Step 3.

•

If not, replace CD
changer (upper module).

2

INSPECT CD

•

Inspect condition of CD where error has occurred.

•

Is CD okay?

Note

•

In some cases, not all CD-R/CD-RW will play.

Yes

Go to next step.

No

Repair (remove foreign material) or replace CD, then
go to next step.

3

INSPECT CD CHANGER (UPPER MODULE)

•

Clear DTC.

•

Play CD and select other song (change tracks).

•

Start on-board diagnostic test mode.

•

Is DTC 06:Er02 displayed?

Yes

Replace CD changer (upper module).

No

Troubleshooting completed.

1712-1U-01G(09-02B).fm  11 ページ  ２００１年６月２９日 金曜日 午前１０時２７分

ON-BOARD DIAGNOSTIC [AUDIO]

09–02B–12

DTC 06:ER07

A3U090266900W22

Diagnostic procedure

End Of Sie

DTC 07:ER01

A3U090266900W23

Diagnostic procedure

End Of Sie

DTC 06:Er07

CD changer (upper module)

DETECTION

CONDITION

Note

•

When error occurs, error message “CHECK CD” is displayed in the LCD.

•

Base unit detects CD reading error.

POSSIBLE

CAUSE

•

Defective CD (scratches or dirt)

•

CD changer (upper module) malfunction

STEP

INSPECTION

ACTION

1

VERIFY WHETHER MALFUNCTION IS IN CD
CHANGER (UPPER MODULE) OR CD

•

Play all CDs in changer.

•

Is CD changer able to read them properly?

Yes

Go to Step 3.

No

Not able to read particular CD.

Go to next step.

Not able to read any CD.

Go to Step 3.

2

INSPECT CD

•

Inspect condition of CD where error has occurred.

•

Is CD okay?

Note

•

In some cases, not all CD-R/CD-RW will play.

Yes

Go to next step.

No

Repair (remove foreign material) or replace CD,
then go to next step.

3

INSPECT CD CHANGER (UPPER MODULE)

•

Clear DTC.

•

Insert and play CD for 12 seconds or more.

•

Start on-board diagnostic test mode.

•

Is DTC 06:Er07 displayed?

Yes

Replace CD changer (upper module).

No

Troubleshooting completed.

DTC 07:Er01

MD player (lower module)

DETECTION

CONDITION

•

MD player (lower module) cannot perform insert and eject commands.

POSSIBLE

CAUSE

•

Defective MD (broken or foreign material stuck/attached)

•

MD player (lower module) malfunction

STEP

INSPECTION

ACTION

1

•

Is MD able to be ejected?

Yes

Go to next step.

No

Replace MD player (lower module).

2

INSPECT MD

•

Inspect condition of MD where error has occurred.

•

Is MD okay?

Yes

Go to next step.

No

Repair (remove foreign material) or replace MD, then
go to next step.

3

INSPECT MD PLAYER (LOWER MODULE)

•

Clear DTC.

•

Insert and eject MD with no defect.

•

Start on-board diagnostic test mode.

•

Is DTC 07:Er01 displayed?

Yes

Replace MD player (lower module).

No

Troubleshooting completed.

1712-1U-01G(09-02B).fm  12 ページ  ２００１年６月２９日 金曜日 午前１０時２７分

ON-BOARD DIAGNOSTIC [AUDIO]

09–02B–13

09–02B

DTC 07:ER02

A3U090266900W24

Diagnostic procedure

End Of Sie

DTC 07:ER07

A3U090266900W25

Diagnostic procedure

End Of Sie

DTC 07:Er02

MD player (lower module)

DETECTION

CONDITION

Note

•

When error occurs, error message “CHECK MD” is displayed in the LCD.

•

Can not play MD normally or change tracks.

POSSIBLE

CAUSE

•

Defective MD (scratches or dirt)

•

MD player (lower module) malfunction

STEP

INSPECTION

ACTION

1

VERIFY WHETHER MALFUNCTION IS IN MD
PLAYER (LOWER MODULE) OR MD

•

Play MD and select other song (change tracks).

•

Is MD player able to change tracks?

Yes

Go to Step 3.

No

Not able to change
particular tracks.

Go to next step.

Not able to change any
tracks.

Change MD and perform
tracks-change again.

•

If MD player changes
tracks, then go to Step 3.

•

If not, replace MD player
(lower module).

2

INSPECT MD

•

Inspect condition of MD where error has occurred.

•

Is MD okay?

Yes

Go to next step.

No

Repair (remove foreign material) or replace MD, then
go to next step.

3

INSPECT MD PLAYER (LOWER MODULE)

•

Clear DTC.

•

Play MD and select other song (change tracks).

•

Start on-board diagnostic test mode.

•

Is DTC 07:Er02 displayed?

Yes

Replace MD player (lower module).

No

Troubleshooting completed.

DTC 07:Er07

MD player (lower module)

DETECTION

CONDITION

Note

•

When error occurs, error message “CHECK MD” is displayed in the LCD.

•

Base unit detects MD reading error.

POSSIBLE

CAUSE

•

Defective MD (scratches or dirt)

•

MD player (lower module) malfunction

STEP

INSPECTION

ACTION

1

INSPECT MD

•

Inspect condition of MD where error has occurred.

•

Is MD okay?

Yes

Go to next step.

No

Repair (remove foreign material) or replace MD, then
go to next step.

2

INSPECT MD PLAYER (LOWER MODULE)

•

Clear DTC.

•

Insert and play MD for 12 seconds or more.

•

Start on-board diagnostic test mode.

•

Is DTC 07:Er07 displayed?

Yes

Replace MD player (lower module).

No

Troubleshooting completed.
