ON-BOARD DIAGNOSTIC [ENGINE CONTROL SYSTEM (ZM)]

01–02A–14

5. Stop vehicle and access ON BOARD SYSTEM READINESS menu of GENERIC OBD II FUNCTION to inspect

the Drive Mode completion status. If completed, RFC changes from NO to YES.

6. If not completed, turn the ignition key off then go back to Step 1.
7. Access DIAGNOSTIC MONITORING TEST RESULTS menu of GENERIC OBD II FUNCTION to inspect the

monitor results. If MEAS are not within specification, repair has not been completed.

8. Verify no DTCs are available.

End Of Sie

DIAGNOSTIC MONITORING TEST RESULTS [ZM]

A3U010218881W27

•

The purpose of this test mode is to confirm the OBD-II monitor diagnostic test results. The result values are
stored when a particular monitor is completed and displayed. If the monitor is not completed, initial value is
displayed.

End Of Sie

TEST ID

Description

Related system

Initial value (MEAS)

10:01:11 HO2S (Front) inversion cycles

HO2S

(0)

10:02:11 HO2S (Front) lean-to-rich response time

(0)

10:03:11 HO2S (Front) rich-to-lean response time

(0)

10:04:01 HO2S (Front) rich/lean inversion voltage

113

10:04:02 Middle/HO2S (Rear) rich/lean inversion voltage

113

10:05:01 HO2S (Front) lean threshold voltage

72

10:06:01 HO2S (Front) rich threshold voltage

113

10:11:11 Front and rear HO2S (RH) switching time ratio

TWC

(65535)

10:21:00 In-tank pressure evaporative purge system (small leak)

EVAP

(0)

10:22:00 In-tank pressure evaporative purge system (large leak)

(0)

10:41:00 EGR pressure variation

EGR

(32768)

1712-1U-01G(01-02A).fm  14 ページ  ２００１年６月２９日 金曜日 午後２時２０分

ON-BOARD DIAGNOSTIC [ENGINE CONTROL SYSTEM (ZM)]

01–02A–15

01–02A

DTC TABLE [ZM]

A3U010218881W28

DTC No.

Condition

MIL

O/D off

indicator

light

DC

Monitor

item

Memory

function

Page

P0031

HO2S heater (front) circuit
low

ON

—

2

O

2

 sensor

heater

×

(See 01–02A–19 DTC P0031
[ZM])

P0032

HO2S heater (front) circuit
high

ON

—

2

O

2

 sensor

heater

×

(See 01–02A–20 DTC P0032
[ZM])

P0037

HO2S heater (rear) circuit
low

ON

—

2

O

2

 sensor

heater

×

(See 01–02A–22 DTC P0037
[ZM])

P0038

HO2S heater (rear) circuit
high

ON

—

2

O

2

 sensor

heater

×

(See 01–02A–23 DTC P0038
[ZM])

P0102

MAF circuit low input

ON

—

1

CCM

×

(See 01–02A–25 DTC P0102
[ZM])

P0103

MAF circuit high input

ON

—

1

CCM

×

(See 01–02A–28 DTC P0103
[ZM])

P0106

BARO circuit performance
problem

ON

—

2

CCM

×

(See 01–02A–29 DTC P0106
[ZM])

P0107

BARO circuit low input

ON

—

1

CCM

×

(See 01–02A–31 DTC P0107
[ZM])

P0108

BARO circuit high input

ON

—

1

CCM

×

(See 01–02A–32 DTC P0108
[ZM])

P0111

IAT circuit performance
problem

ON

—

2

CCM

×

(See 01–02A–34 DTC P0111
[ZM])

P0112

IAT circuit low input

ON

—

1

CCM

×

(See 01–02A–35 DTC P0112
[ZM])

P0113

IAT circuit high input

ON

—

1

CCM

×

(See 01–02A–36 DTC P0113
[ZM])

P0117

ECT circuit low input

ON

—

1

CCM

×

(See 01–02A–39 DTC P0117
[ZM])

P0118

ECT circuit high input

ON

—

1

CCM

×

(See 01–02A–41 DTC P0118
[ZM])

P0122

TP circuit low input

ON

Flashing

1

CCM

×

(See 01–02A–42 DTC P0122
[ZM])

P0123

TP circuit high input

ON

Flashing

1

CCM

×

(See 01–02A–45 DTC P0123
[ZM])

P0125

Excessive time to enter
closed loop fuel control

ON

—

2

CCM

×

(See 01–02A–46 DTC P0125
[ZM])

P0130

HO2S (Front) circuit
malfunction

ON

—

2

O

2

 sensor

×

(See 01–02A–48 DTC P0130
[ZM])

P0134

HO2S (Front) circuit no
activity detected

ON

—

2

CCM

×

(See 01–02A–50 DTC P0134
[ZM])

P0138

HO2S (Rear) circuit high
input

ON

—

2

CCM

×

(See 01–02A–53 DTC P0138
[ZM])

P0140

HO2S (Rear) circuit no
activity detected

ON

—

2

CCM

×

(See 01–02A–55 DTC P0140
[ZM])

P0171

Fuel trim system too lean

ON

—

2

Fuel

×

(See 01–02A–57 DTC P0171
[ZM])

P0172

Fuel trim system too rich

ON

—

2

Fuel

×

(See 01–02A–60 DTC P0172
[ZM])

P0300

Random misfire detected

Flashing

or ON

—

1 or

2

Misfire

×

(See 01–02A–61 DTC P0300
[ZM])

P0301

Cylinder 1 misfire
detected

Flashing

or ON

—

1 or

2

Misfire

×

(See 01–02A–65 DTC P0301,
P0302, P0303, P0304 [ZM])

P0302

Cylinder 2 misfire
detected

Flashing

or ON

—

1 or

2

Misfire

×

(See 01–02A–65 DTC P0301,
P0302, P0303, P0304 [ZM])

P0303

Cylinder 3 misfire
detected

Flashing

or ON

—

1 or

2

Misfire

×

(See 01–02A–65 DTC P0301,
P0302, P0303, P0304 [ZM])

P0304

Cylinder 4 misfire
detected

Flashing

or ON

—

1 or

2

Misfire

×

(See 01–02A–65 DTC P0301,
P0302, P0303, P0304 [ZM])

P0335

CKP sensor circuit
malfunction

ON

—

1

CCM

×

(See 01–02A–67 DTC P0335
[ZM])

1712-1U-01G(01-02A).fm  15 ページ  ２００１年６月２９日 金曜日 午後２時２０分

ON-BOARD DIAGNOSTIC [ENGINE CONTROL SYSTEM (ZM)]

01–02A–16

P0401

EGR flow insufficient
detected

ON

—

2

EGR

×

(See 01–02A–69 DTC P0401
[ZM])

P0402

EGR flow excessive
detected

ON

—

2

EGR

×

(See 01–02A–70 DTC P0402
[ZM])

P0421

Warm-up catalyst system
efficiency below threshold

ON

—

2

Catalyst

×

(See 01–02A–71 DTC P0421
[ZM])

P0442

Evaporative emission
system leak detected
(small leak)

ON

—

2

Evaporative

×

(See 01–02A–72 DTC P0442
[ZM])

P0443

Evaporative emission
control system purge
solenoid valve circuit
malfunction

OFF

—

—

Other

—

(See 01–02A–75 DTC P0443
[ZM])

P0451

Fuel tank pressure sensor
performance problem

ON

—

2

CCM

×

(See 01–02A–77 DTC P0451
[ZM])

P0452

Fuel tank pressure sensor
low input

ON

—

2

CCM

×

(See 01–02A–78 DTC P0452
[ZM])

P0453

Fuel tank pressure sensor
high input

ON

—

2

CCM

×

(See 01–02A–80 DTC P0453
[ZM])

P0455

Evaporative emission
control system leak
detected (blockage or
large leak)

ON

—

2

Evaporative

×

(See 01–02A–83 DTC P0455
[ZM])

P0461

Fuel gauge sender unit
circuit range/performance

ON

—

2

CCM

×

(See 01–02A–87 DTC P0461
[ZM])

P0462

Fuel gauge sender unit
circuit low input

ON

—

2

CCM

×

(See 01–02A–88 DTC P0462
[ZM])

P0463

Fuel gauge sender unit
circuit high input

ON

—

2

CCM

×

(See 01–02A–90 DTC P0463
[ZM])

P0464

Fuel gauge sender unit
circuit performance (slosh
check)

ON

—

2

CCM

×

(See 01–02A–91 DTC P0464
[ZM])

P0480

Cooling fan relay
malfunction

OFF

—

2

CCM

×

(See 01–02A–92 DTC P0480
[ZM])

P0500

VSS circuit malfunction
(MTX)

ON

—

2

CCM

×

(See 01–02A–94 DTC P0500
[ZM])

VSS circuit malfunction
(ATX)

(See 05–02–6 AUTOMATIC TRANSAXLE ON-BOARD DIAGNOSTIC FUNCTION.)

P0506

Idle control system RPM
lower than expected

ON

—

2

CCM

×

(See 01–02A–96 DTC P0506
[ZM])

P0507

Idle control system RPM
higher than expected

ON

—

2

CCM

×

(See 01–02A–97 DTC P0507
[ZM])

P0550

PSP switch circuit
malfunction

ON

—

2

CCM

×

(See 01–02A–99 DTC P0550
[ZM])

P0703

Brake switch input
malfunction

ON

—

2

CCM

×

(See 01–02A–100 DTC P0703
[ZM])

P0704

Clutch switch input circuit
malfunction (MTX)

ON

—

2

CCM

×

(See 01–02A–102 DTC P0704
[ZM])

P0705

Neutral switch input circuit
malfunction (MTX)

ON

—

2

CCM

×

(See 01–02A–104 DTC P0705
[ZM])

P0705

TR switch circuit
malfunction (ATX)

(See 05–02–6 AUTOMATIC TRANSAXLE ON-BOARD DIAGNOSTIC FUNCTION)

P0706

TR switch circuit
malfunction (Open circuit)
(ATX)

(See 05–02–6 AUTOMATIC TRANSAXLE ON-BOARD DIAGNOSTIC FUNCTION)

P0710

Transaxle temperature
sensor circuit malfunction
(Open or short) (ATX)

(See 05–02–6 AUTOMATIC TRANSAXLE ON-BOARD DIAGNOSTIC FUNCTION)

DTC No.

Condition

MIL

O/D off

indicator

light

DC

Monitor

item

Memory

function

Page

1712-1U-01G(01-02A).fm  16 ページ  ２００１年６月２９日 金曜日 午後２時２０分

ON-BOARD DIAGNOSTIC [ENGINE CONTROL SYSTEM (ZM)]

01–02A–17

01–02A

P0711

Transaxle temperature
sensor circuit range/
performance (Stuck)
(ATX)

(See 05–02–6 AUTOMATIC TRANSAXLE ON-BOARD DIAGNOSTIC FUNCTION)

P0715

Input/turbine speed
sensor circuit malfunction
(ATX)

(See 05–02–6 AUTOMATIC TRANSAXLE ON-BOARD DIAGNOSTIC FUNCTION)

P0731

Gear 1 incorrect (ATX)

(See 05–02–6 AUTOMATIC TRANSAXLE ON-BOARD DIAGNOSTIC FUNCTION)

P0732

Gear 2 incorrect (ATX)

(See 05–02–6 AUTOMATIC TRANSAXLE ON-BOARD DIAGNOSTIC FUNCTION)

P0733

Gear 3 incorrect (ATX)

(See 05–02–6 AUTOMATIC TRANSAXLE ON-BOARD DIAGNOSTIC FUNCTION)

P0734

Gear 4 incorrect (ATX)

(See 05–02–6 AUTOMATIC TRANSAXLE ON-BOARD DIAGNOSTIC FUNCTION)

P0741

TCC (stuck off) (ATX)

(See 05–02–6 AUTOMATIC TRANSAXLE ON-BOARD DIAGNOSTIC FUNCTION)

P0742

TCC (stuck on) (ATX)

(See 05–02–6 AUTOMATIC TRANSAXLE ON-BOARD DIAGNOSTIC FUNCTION)

P0745

Pressure control solenoid
valve malfunction (ATX)

(See 05–02–6 AUTOMATIC TRANSAXLE ON-BOARD DIAGNOSTIC FUNCTION)

P0751

Shift solenoid A
malfunction (stuck off)
(ATX)

(See 05–02–6 AUTOMATIC TRANSAXLE ON-BOARD DIAGNOSTIC FUNCTION)

P0752

Shift solenoid A
malfunction (stuck on)
(ATX)

(See 05–02–6 AUTOMATIC TRANSAXLE ON-BOARD DIAGNOSTIC FUNCTION)

P0753

Shift solenoid A
malfunction (electrical)
(ATX)

(See 05–02–6 AUTOMATIC TRANSAXLE ON-BOARD DIAGNOSTIC FUNCTION)

P0756

Shift solenoid B
malfunction (stuck off)
(ATX)

(See 05–02–6 AUTOMATIC TRANSAXLE ON-BOARD DIAGNOSTIC FUNCTION)

P0757

Shift solenoid B
malfunction (stuck on)
(ATX)

(See 05–02–6 AUTOMATIC TRANSAXLE ON-BOARD DIAGNOSTIC FUNCTION)

P0758

Shift solenoid B
malfunction (electrical)
(ATX)

(See 05–02–6 AUTOMATIC TRANSAXLE ON-BOARD DIAGNOSTIC FUNCTION)

P0761

Shift solenoid C
malfunction (stuck off)
(ATX)

(See 05–02–6 AUTOMATIC TRANSAXLE ON-BOARD DIAGNOSTIC FUNCTION)

P0762

Shift solenoid C
malfunction (stuck on)
(ATX)

(See 05–02–6 AUTOMATIC TRANSAXLE ON-BOARD DIAGNOSTIC FUNCTION)

P0763

Shift solenoid C
malfunction (electrical)
(ATX)

(See 05–02–6 AUTOMATIC TRANSAXLE ON-BOARD DIAGNOSTIC FUNCTION)

P0766

Shift solenoid D
malfunction (stuck off)
(ATX)

(See 05–02–6 AUTOMATIC TRANSAXLE ON-BOARD DIAGNOSTIC FUNCTION)

P0767

Shift solenoid D
malfunction (stuck on)
(ATX)

(See 05–02–6 AUTOMATIC TRANSAXLE ON-BOARD DIAGNOSTIC FUNCTION)

P0768

Shift solenoid D
malfunction (electrical)
(ATX)

(See 05–02–6 AUTOMATIC TRANSAXLE ON-BOARD DIAGNOSTIC FUNCTION)

P0771

Shift solenoid E
malfunction (stuck off)
(ATX)

(See 05–02–6 AUTOMATIC TRANSAXLE ON-BOARD DIAGNOSTIC FUNCTION)

P0772

Shift solenoid E
malfunction (stuck on)
(ATX)

(See 05–02–6 AUTOMATIC TRANSAXLE ON-BOARD DIAGNOSTIC FUNCTION)

P0773

Shift solenoid E
malfunction (electrical)
(ATX)

(See 05–02–6 AUTOMATIC TRANSAXLE ON-BOARD DIAGNOSTIC FUNCTION)

DTC No.

Condition

MIL

O/D off

indicator

light

DC

Monitor

item

Memory

function

Page

1712-1U-01G(01-02A).fm  17 ページ  ２００１年６月２９日 金曜日 午後２時２０分
