INSTRUMENTATION/DRIVER INFO.
09–22–3
09–22
End Of Sie
Warning
alarms
Sound frequency
(Hz)
1,800—2,600
Output sound pressure level
(dB)
54.0—70.0
Lights-on reminder
warning alarm
Sound frequency
(Hz)
1,900
Sound cycle
Seat belt warning
alarm
Sound frequency
(Hz)
2,400
Sound cycle
Key reminder
warning alarm
Sound frequency
(Hz)
1,800
Sound cycle
Tire pressure
warning alarm
Sound frequency
(Hz)
2,600
Sound cycle
Flat tire warning
alarm
Sound frequency
(Hz)
2,600
Sound cycle
Advanced keyless
entry system
warning alarm
Sound frequency
(Hz)
1,800
Sound cycle
Item
Specification
CONTINUOUS
ON
OFF
ON
OFF
t1
t2
t1: approx. 0.25 s
t2: approx. 0.50 s
t3
t3: approx. 31.0 s
t4: approx. 0.10 s
t5: approx. 0.20 s
t6: approx. 0.05 s
t7: approx. 0.10 s
t4
t5
t3
t3
t6
t7
WHILE VEHICLE DRIVING
(VEHICLE SPEED 20 km/h {12.4 mph} OR MORE)
WHEN IGNITION SWITCH TURNED ON
ON
OFF
t1
t2
t3
t1: approx. 0.7 s
t2: approx. 1 s
t3: approx. 6 s
ON
OFF
CONTINUOUS
t1
t2
t1: approx. 0.22 s
t2: approx. 0.33 s
t3
t3: approx. 1.25 s
CONTINUOUS
ON
OFF
t1
t2
t1: approx. 0.3 s
t2: approx. 0.6 s
CONTINUOUS
ON
OFF
t1
t2
t1: approx. 0.05 s
t2: approx. 0.25 s
ON
OFF
CONTINUOUS
t1
t2
t1 : approx. 0.22 s
t2 : approx. 0.33 s
t3
t3 : approx. 1.25 s
