Table 3-14

DTC C2112

Cause

Valve fuse and relay faults:

a) Main replay or fuse disconnection

b) Main relay short circuit

Note: If faults corresponding to more than 2 DTC can be

confirmed, delete the DTC (that can be deleted), drive the

vehicle at a speed of over 40 km/h, confirm the fault

corresponding to this DTC again and refer to the recorded

DTC (and confirm the same fault code).





177



Table 3-15

DTC C1

604

ECU internal circuit and valve coil

faults

Note: If faults corresponding to more than 2 DTC can be

confirmed, delete the DTC (that can be deleted), drive the

vehicle at a speed of over 40 km/h, confirm the fault

corresponding to this DTC again and refer to the recorded

DTC (and confirm the same fault code).

Cause





178

5. No DTC Fault Table is in Table 3-16, Table 3-17, Table 3-18, Table 3-19 and Table

3-20.



Table 3-16

Fault

Start the engine, but ABS warning lamp can not be turned on

 Fuse is blew out

①



 Bulb of ABS warning lamp is broken

②



Cause

 Circuit is open

③



 Warning lamp controller is broken

④









179



Table 3-17



Fault

Start the engine, but ABS warning lamp is always on

Cause

 Controller of ABS warning lam

①

p is broken

 Return circuit of warning lamp controller is open

②



 ECU is broken

③





























180
