LEXUS RX350, RX350L (2019 year). Instruction - part 41

653

8-2. Steps to take in an emergency

When trouble

ari

ses

RX350/RX350L_U

Follow the procedure below to restart the engine after the system is activated.

Turn the engine switch to ACCESSORY mode or turn it off.
Restart the engine.

Fuel pump shut off system

To minimize the risk of fuel leakage when the engine stalls or when an airbag
inflates upon collision, the fuel pump shut off system stops the supply of fuel to
the engine.

NOTICE

■

Before starting the engine
Inspect the ground under the vehicle.

If you find that fuel has leaked onto the ground, the fuel system has been damaged and

is in need of repair. Do not restart the engine.

654

8-2. Steps to take in an emergency

RX350/RX350L_U

If a warning light turns on or a warning buzzer
sounds

Calmly perform the following actions if any of the warning lights comes on or
flashes. If a light comes on or flashes, but then goes off, this does not necessar-
ily indicate a malfunction in the system. However, if this continues to occur,
have the vehicle inspected by your Lexus dealer.

Warning light and warning buzzer list

Warning light

Warning light/Details/Actions

(U.S.A.)

(Canada)

Brake system warning light

Indicates that:

• The brake fluid level is low; or

• The brake system is malfunctioning

 Immediately stop the vehicle in a safe place and contact your

Lexus dealer. Continuing to drive the vehicle may be dangerous.

Brake system warning light

Indicates a malfunction in the electric parking brake

 Have the vehicle inspected by your Lexus dealer immediately.

(If equipped)

Charging system warning light

Indicates a malfunction in the vehicle’s charging system

 Immediately stop the vehicle in a safe place and contact your

Lexus dealer. Continuing to drive the vehicle may be dangerous.

(U.S.A.)

(Canada)

Malfunction indicator lamp

Indicates a malfunction in:

• The electronic engine control system;

• The electronic throttle control system; or

• The electronic automatic transmission control system

 Have the vehicle inspected by your Lexus dealer immediately.

SRS warning light

Indicates a malfunction in:

• The SRS airbag system;

• The front passenger occupant classification system; or

• The seat belt pretensioner system

 Have the vehicle inspected by your Lexus dealer immediately.

(U.S.A.)

(Canada)

ABS warning light

Indicates a malfunction in:

• The ABS; or

• The brake assist system

 Have the vehicle inspected by your Lexus dealer immediately.

655

8-2. Steps to take in an emergency

When trouble

ari

ses

RX350/RX350L_U

(Flashes)

(U.S.A.)

(Flashes)

(Canada)

Parking brake indicator

It is possible that the parking brake is not fully engaged or released

 Operate the parking brake switch once again.

This light comes on when the parking brake is not released. If the

light turns off after the parking brake is fully released, the system is

operating normally.

(Flashes)

Brake hold operated indicator

Indicates a malfunction in the brake hold system

 Have the vehicle inspected by your Lexus dealer immediately.

Electric power steering system warning light (warning buzzer)

Indicates a malfunction in the EPS (Electric Power Steering) sys-

tem

 Have the vehicle inspected by your Lexus dealer immediately.

LKA indicator

Indicates a malfunction in the LKA (Lane-Keeping Assist)

 When “Lane Keeping Assist Unavailable” is displayed on the

multi-information display, turn the LKA system off, drive the

vehicle for a short time, and then turn the LKA system back on.

(

P. 295)

When a message other than above is displayed, follow the

instructions displayed in the message.

Slip indicator

When the warning light is illuminated:

Indicates a malfunction in:

• The VSC system;

• The TRAC system;

• The Trailer Sway Control; or

• The hill-start assist control system

 Have the vehicle inspected by your Lexus dealer immediately.

When the warning light flashes:

Indicates that the VSC, TRAC or Trailer Sway Control system is

operating

Warning light

Warning light/Details/Actions

656

8-2. Steps to take in an emergency

RX350/RX350L_U

(Flashes or illuminates)

PCS warning light

Indicates a malfunction in the PCS (Pre-Collision System) or that

the system is temporarily unavailable due to the vehicle being

extremely hot/cold, or dirt around a front sensor, etc.

(

P. 290, 664)

 Follow the instructions displayed on the multi-information dis-

play. (

P. 290, 664 )

If the PCS (Pre-Collision System) or VSC (Vehicle Stability Con-

trol) system is disabled, the PCS warning light will illuminate.

 P. 290

(Flashes)

(If equipped)

ICS OFF indicator

When a buzzer sounds:

Indicates a malfunction in the Intelligent Clearance Sonar system

 Have the vehicle inspected by your Lexus dealer immediately.

When a buzzer does not sound:

Indicates that the system is temporarily unavailable, possibly due to

a sensor being dirty or covered with ice, etc.

 Clear the dirt, etc.

Low fuel level warning light

Indicates that remaining fuel is approximately 2.8 gal. (10.8 L,

2.3 Imp. gal.) or less

 Refuel the vehicle.

Driver’s and front passenger’s seat belt reminder light (warning
buzzer)

Warns the driver and/or front passenger to fasten their seat belts

 Fasten the seat belt.

If the front passenger’s seat is occupied, the front passenger’s

seat belt also needs to be fastened to make the warning light

(warning buzzer) turn off.

(RX350)

(RX350L)

Rear passengers’ seat belt reminder light (warning buzzer)

Warns the rear passengers to fasten their seat belts

 Fasten the seat belt.

Tire pressure warning light

Indicates the following:

• Low tire pressure due to flat tire;

• Low tire pressure due to natural causes; or

• The tire pressure warning system is malfunctioning

 Immediately stop the vehicle in a safe place.

Handling method (

P. 658)

Warning light

Warning light/Details/Actions

657

8-2. Steps to take in an emergency

When trouble

ari

ses

RX350/RX350L_U

: Driver's and front passenger's seat belt warning buzzer:

The driver’s seat belt warning buzzer sounds to alert the driver that his or her seat belt

is not fastened. Once the engine switch is turned to IGNITION ON mode, the

buzzer sounds for 6 seconds. If the vehicle reaches a speed of 12 mph (20 km/h), the

buzzer sounds once. If the seat belt is still unfastened after 24 seconds, the buzzer will

sound intermittently for 10 seconds. Then, if the seat belt is still unfastened, the buzzer

will sound in a different tone for 20 more seconds.

The front passenger’s seat belt warning buzzer sounds to alert the front passenger

that his or her seat belt is not fastened. The buzzer sounds once if the vehicle reaches

a speed of 12 mph (20 km/h). If the seat belt is still unfastened after 24 seconds, the

buzzer will sound intermittently for 10 seconds. Then, if the seat belt is still unfastened,

the buzzer will sound in a different tone for 20 more seconds.

: Rear passengers’ seat belt warning buzzer:

The rear passengers’ seat belt warning buzzer sounds to alert the rear passengers
that his or her seat belt is not fastened. The buzzer sounds for 6 seconds after the
vehicle reaches a speed of 20 km/h (12 mph). Then, if the seat belt is still unfastened,
the buzzer will sound in a different tone for 24 more seconds.

■

SRS warning light
This warning light system monitors the airbag sensor assembly, front impact sensors, side

impact sensors (front door), side impact sensors (rear), driver’s seat position sensor,

driver’s seat belt buckle switch, front passenger occupant classification system (ECU and

sensors), “AIR BAG ON” indicator light, “AIR BAG OFF” indicator light, front passen-

ger’s seat belt buckle switch, driver’s seat belt pretensioner, front passenger’s seat belt

pretensioner and force limiter, airbags, interconnecting wiring and power sources.

(

P. 36)

■

Front passenger detection sensor, seat belt reminder and warning buzzer

●

If luggage is placed on the front passenger seat, the front passenger detection sensor

may cause the warning light to flash and the warning buzzer to sound even if a passen-

ger is not sitting in the seat.

●

If a cushion is placed on the seat, the sensor may not detect a passenger, and the warn-

ing light may not operate properly.

■

Electric power steering system warning light (warning buzzer)
When the battery charge becomes insufficient or the voltage temporarily drops, the

electric power steering system warning light may come on and the warning buzzer may

sound.

Master warning light

A buzzer sounds and the warning light comes on and flashes to

indicate that the master warning system has detected a malfunc-

tion.

 P. 661

Warning light

Warning light/Details/Actions

658

8-2. Steps to take in an emergency

RX350/RX350L_U

■

If the malfunction indicator lamp comes on while driving
First check the following:

●

Is the fuel tank empty?

If it is, fill the fuel tank immediately.

●

Is the fuel tank cap loose?

If it is, tighten it securely.

The light will go off after several driving trips.

If the light does not go off even after several trips, contact your Lexus dealer as soon as

possible.

■

When the tire pressure warning light comes on
Inspect the tires to check if a tire is punctured.
If a tire is punctured:

P. 666

If none of the tires are punctured:

Turn the engine switch off then turn it to IGNITION ON mode. Check if the tire pressure

warning light comes on or blinks.



If the tire pressure warning light comes on
After the temperature of the tires has lowered sufficiently, check the inflation pressure

of each tire and adjust them to the specified level.
If the warning light does not turn off even after several minutes have elapsed, check

that the inflation pressure of each tire is at the specified level and perform initialization.

(

P. 606)

If the warning light does not turn off several minutes after the initialization has been per-

formed, have the vehicle inspected by your Lexus dealer immediately.



If the tire pressure warning light blinks for 1 minute then stays on

There may be a malfunction in the tire pressure warning system. Have the vehicle

inspected by your Lexus dealer immediately.

■

The tire pressure warning light may come on due to natural causes
The tire pressure warning light may come on due to natural causes such as natural air

leaks and tire inflation pressure changes caused by temperature. In this case, adjusting

the tire inflation pressure will turn off the warning light (after a few minutes).

■

When a tire is replaced with a spare tire
The compact spare tire is not equipped with a tire pressure warning valve and transmit-

ter. If a tire goes flat, the tire pressure warning light will not turn off even though the flat

tire has been replaced with the spare tire. Replace the spare tire with the repaired tire

and adjust the tire inflation pressure. The tire pressure warning light will go off after a few

minutes.

■

Conditions that the tire pressure warning system may not function properly
P. 609

■

Warning buzzer
In some cases, the buzzer may not be heard due to being in a noisy location or audio

sound.

■

Customization
Some functions can be customized. (

P. 722)

659

8-2. Steps to take in an emergency

When trouble

ari

ses

RX350/RX350L_U

WARNING

■

If both the ABS and the brake system warning lights remain on
Stop your vehicle in a safe place immediately and contact your Lexus dealer. The vehi-

cle will become extremely unstable during braking, and the ABS system may fail, which

could cause an accident resulting in death or serious injury.

■

When the electric power steering system warning light comes on
When the light comes on yellow, the assist to the power steering is restricted. When the

light comes on red, the assist to the power steering is lost and handling operations of

the steering wheel become extremely heavy. When steering wheel operations are

heavier than usual, grip the steering wheel firmly and operate it using more force than

usual.

■

If the tire pressure warning light comes on
Be sure to observe the following precautions. Failure to do so could cause a loss of

vehicle control and result in death or serious injury.

●

Stop your vehicle in a safe place as soon as possible. Adjust the tire inflation pressure

immediately.

●

If the tire pressure warning light comes on even after tire inflation pressure adjust-

ment, it is probable that you have a flat tire. Check the tires. If a tire is flat, change it

with the spare tire and have the flat tire repaired by the nearest Lexus dealer.

●

Avoid abrupt maneuvering and braking. If the vehicle tires deteriorate, you could lose

control of the steering wheel or the brakes.

■

If a blowout or sudden air leakage should occur
The tire pressure warning system may not activate immediately.

660

8-2. Steps to take in an emergency

RX350/RX350L_U

WARNING

■

Maintenance of the tires
Each tire, including the spare (if provided), should be checked monthly when cold and

inflated to the inflation pressure recommended by the vehicle manufacturer on the

vehicle placard or tire inflation pressure label (tire and load information label). (If your

vehicle has tires of a different size than the size indicated on the vehicle placard or tire

inflation pressure label [tire and load information label], you should determine the

proper tire inflation pressure for those tires.)
As an added safety feature, your vehicle has been equipped with a tire pressure moni-

toring system (TPMS-tire pressure warning system) that illuminates a low tire pressure

telltale (tire pressure warning light) when one or more of your tires is significantly

under-inflated. Accordingly, when the low tire pressure telltale (tire pressure warning

light) illuminates, you should stop and check your tires as soon as possible, and inflate

them to the proper pressure. Driving on a significantly under-inflated tire causes the

tire to overheat and can lead to tire failure. Under-inflation also reduces fuel efficiency

and tire tread life, and may affect the vehicle’s handling and stopping ability.
Please note that the TPMS (tire pressure warning system) is not a substitute for proper

tire maintenance, and it is the driver’s responsibility to maintain correct tire pressure,

even if under-inflation has not reached the level to trigger illumination of the TPMS low

tire pressure telltale (tire pressure warning light).
Your vehicle has also been equipped with a TPMS (tire pressure warning system) mal-

function indicator to indicate when the system is not operating properly. The TPMS

(tire pressure warning system) malfunction indicator is combined with the low tire pres-

sure telltale (tire pressure warning light). When the system detects a malfunction, the

telltale will flash for approximately one minute and then remain continuously illumi-

nated. This sequence will continue upon subsequent vehicle start-ups as long as the

malfunction exists. When the malfunction indicator is illuminated, the system may not

be able to detect or signal low tire pressure as intended.
TPMS (tire pressure warning system) malfunctions may occur for a variety of reasons,

including the installation of replacement or alternate tires or wheels on the vehicle that

prevent the TPMS (tire pressure warning system) from functioning properly. Always

check the TPMS (tire pressure warning system) malfunction telltale after replacing one

or more tires or wheels on your vehicle to ensure that the replacement or alternate

tires and wheels allow the TPMS (tire pressure warning system) to continue to function

properly.

NOTICE

■

To ensure the tire pressure warning system operates properly
Do not install tires with different specifications or makers, as the tire pressure warning

system may not operate properly.

661

8-2. Steps to take in an emergency

When trouble

ari

ses

RX350/RX350L_U

Master warning light

The master warning light also comes on or flashes in order to indicate that a message

is currently being displayed on the multi-information display.

Multi-information display

If any of the warning messages are shown again after the appropriate actions
have been performed, contact your Lexus dealer.

The warning lights and warning buzzers operate as follows depending on the
content of the message. If a message indicates the need for inspection by a
dealer, have the vehicle inspected by your Lexus dealer immediately.

If a warning message is displayed

The multi-information display shows warnings of system malfunctions, incor-
rectly performed operations, and messages that indicate a need for mainte-
nance. When a message is shown, perform the correction procedure
appropriate to the message.



Except F SPORT models



F SPORT models

Messages and warnings

System

warning

light

Warning buzzer

Warning

Comes



Sounds

Indicates an important situation, such

as when a system related to driving is

malfunctioning or that danger may

result if the correction procedure is not

performed



Comes on

or flashes

Sounds

Indicates an important situation, such

as when the systems shown on the

multi-information display may be mal-

functioning

662

8-2. Steps to take in an emergency

RX350/RX350L_U

: A buzzer sounds the first time a message is shown on the multi-information display.

●

If the following messages are shown, there may be a malfunction.
Immediately stop the vehicle in a safe place and contact your Lexus dealer.
Continuing to drive the vehicle may be dangerous.

• “Braking Power Low Stop in a Safe Place See Owner’s Manual”
• “Oil Pressure Low Stop in a Safe Place See Owner’s Manual”
• “Charging System Malfunction See Owner's Manual”

●

If the following message is shown, there may be a malfunction.
Immediately have the vehicle inspected by your Lexus dealer.

• “Access System with Elec. Key Malfunction See Owner’s Manual”

●

If “Engine Coolant Temp High Stop in a Safe Place See Owner’s Manual” is
displayed, following the instructions, accordingly. (

P. 692)

●

If “Transmission Fluid Temp High See Owner’s Manual” is shown, the auto-
matic transmission fluid temperature may be too high.
Immediately stop the vehicle in a safe place, shift the shift lever to P with the
engine running and wait until the message is cleared.
If the message is not cleared, contact your Lexus dealer.

Flashes



Sounds

Indicates a situation, such as when

damage to the vehicle or danger may

result

Comes



Does not sound

Indicates a condition, such as malfunc-

tion of electrical components, their

condition, or indicates the need for

maintenance

Flashes



Does not sound

Indicates a situation, such as when an

operation has been performed incor-

rectly, or indicates how to perform an

operation correctly

If a message instructing to refer to the Owner’s Manual is displayed

System

warning

light

Warning buzzer

Warning

663

8-2. Steps to take in an emergency

When trouble

ari

ses

RX350/RX350L_U

Take the appropriate actions as instructed in the message displayed.
If any of the following messages are displayed, also refer to this Owner’s Manual.

■

If “Shift to P Before Exiting Vehicle” is shown
Message is displayed when the driver’s door is opened without turning the
engine switch off with the shift lever in any position other than P.
Shift the shift lever to P.

■

If “Power Turned Off to Save Battery” is displayed
This message is displayed when the power was cut off due to the automatic
power off function.
The next time the engine is started, increase the engine speed slightly and
maintain it at that speed for approximately 5 minutes to recharge the battery.

■

If “AWD System Overheated Switching to 2WD Mode” or “AWD System
Overheated 2WD Mode Engaged” is displayed (AWD models)
This message may be displayed when driving under extremely high load con-
ditions.
Drive the vehicle at low speeds or stop the vehicle in a safe place with the
engine running until the message is cleared.
If the message is not cleared, have the vehicle inspected by your Lexus dealer.

■

If “A New Key has been Registered Contact Your Dealer for Details” is dis-
played
This message will be displayed each time the driver’s door is opened when the
doors are unlocked from the outside for approximately one week after a new
electronic key has been registered.
If this message is displayed but you have not had a new electronic key regis-
tered, ask your Lexus dealer to check if an unknown electronic key (other than
those in your possession) has been registered.

■

When “Headlight System Malfunction Visit Your Dealer” is displayed
The following systems may be malfunctioning. Have the vehicle inspected by
your Lexus dealer immediately.

●

The LED headlight system

●

The automatic headlight leveling system

●

Automatic High Beam

●

AFS (Adaptive Front-lighting System) (if equipped)

Other messages displayed on the multi-information display

664

8-2. Steps to take in an emergency

RX350/RX350L_U

■

If “Forward Camera System Unavailable” or “Forward Camera System
Unavailable Clean Windshield” is displayed
The following systems may be suspended until the problem shown in the mes-
sage is resolved. (

P. 290)

●

PCS (Pre-Collision System)

●

LKA (Lane-Keeping Assist)

●

Dynamic radar cruise control with full-speed range

●

Automatic High Beam

■

If “Oil Maintenance Required Soon” is shown
Indicates that the engine oil is scheduled to be changed.
Check the engine oil, and change if necessary. After changing the engine oil,
the message should be reset. (

P. 597)

■

If “Oil Maintenance Required” is shown
Indicates that the engine oil should be changed.
Check and change the engine oil, and oil filter by your Lexus dealer. After
changing the engine oil, the message should be reset. (

P. 597)

■

If “Maintenance Required Soon” is displayed (U.S.A. only)
Indicates that all maintenance according to the driven distance on the mainte-
nance schedule

should be performed soon.

Comes on approximately 4500 miles (7200 km) after the message has been
reset.
If necessary, perform maintenance. Please reset the message after the main-
tenance is performed. (

P. 585)

: Refer to the separate “Scheduled Maintenance” or “Owner’s Manual Supplement”

for the maintenance interval applicable to your vehicle.

665

8-2. Steps to take in an emergency

When trouble

ari

ses

RX350/RX350L_U

■

If “Maintenance Required Visit Your Dealer” is displayed (U.S.A. only)
Indicates that all maintenance is required to correspond to the driven distance
on the maintenance schedule

Comes on approximately 5000 miles (8000 km) after the message has
been reset.
(The indicator will not work properly unless the message has been reset.)
Perform the necessary maintenance. Please reset the message after the main-
tenance is performed. (

P. 585)

: Refer to the separate “Scheduled Maintenance” or “Owner’s Manual Supplement”

for the maintenance interval applicable to your vehicle.

■

System warning lights
The master warning light does not come on or flash in the following cases. Instead, a sep-

arate system warning light will come on along with a message shown on the multi-infor-

mation display.

●

“Antilock Brake System Malfunction Visit Your Dealer”:

The ABS warning light comes on. (

P. 654)

●

“Charging System Malfunction See Owner’s Manual” (F SPORT models):

The charging system warning light comes on. (

P. 654)

■

Warning buzzer
P. 658

NOTICE

■

“High Power Consumption Partial Limit On AC/Heater Operation” is frequently

shown
There is a possible malfunction relating to the charging system or the battery may be

deteriorating. Have the vehicle inspected by your Lexus dealer.

666

8-2. Steps to take in an emergency

RX350/RX350L_U

●

Stop the vehicle in a safe place on a hard, flat surface.

●

Set the parking brake.

●

Shift the shift lever to P.

●

Stop the engine.

●

Turn on the emergency flashers. (

P. 644)

If you have a flat tire

Your vehicle is equipped with a spare tire. The flat tire can be replaced with
the spare tire.
For details about tires:

P. 604

WARNING

■

If you have a flat tire
Do not continue driving with a flat tire.

Driving even a short distance with a flat tire can damage the tire and the wheel beyond

repair, which could result in an accident.

Before jacking up the vehicle

667

8-2. Steps to take in an emergency

When trouble

ari

ses

RX350/RX350L_U



RX350

: Documentation relating to the wheel lock key, such as the registration and I.D. card, is

inside the glove box.

Location of the spare tire, jack and tools

Jack handle
Wheel nut wrench
Spare tire

Jack
Towing eyelet (if equipped)
Wheel lock key* (if equipped)

2
3

4
5
6

668

8-2. Steps to take in an emergency

RX350/RX350L_U



RX350L

Jack handle
Wheel nut wrench
Spare tire

Jack
Towing eyelet
Adapter socket

WARNING

■

Using the tire jack
Observe the following precautions.

Improper use of the tire jack may cause the vehicle to suddenly fall off the jack, leading

to death or serious injury.

●

Do not use the tire jack for any purpose other than replacing tires or installing and

removing tire chains.

●

Only use the tire jack that comes with this vehicle for replacing a flat tire.

Do not use it on other vehicles, and do not use other tire jacks for replacing tires on

this vehicle.

●

Put the jack properly in its jack point.

●

Do not put any part of your body under the vehicle while it is supported by the jack.

●

Do not start the engine or drive the vehicle while the vehicle is supported by the jack.

●

Do not raise the vehicle while someone is inside.

●

When raising the vehicle, do not put an object on or under the jack.

●

Do not raise the vehicle to a height greater than that required to replace the tire.

●

Use a jack stand if it is necessary to get under the vehicle.

●

When lowering the vehicle, make sure that there is no-one near the vehicle. If there

are people nearby, warn them vocally before lowering.

2
3

4
5
6

Content .. 39 40 41 42 ..
