413

5-3. Using the audio system

5

Le

xus
Dis
play Audi

o syst

em

RX350/RX350L_U

Go to “Sound Settings”: Move the controller to the left on the audio top screen
 “Sound Settings”
To change between the sound setting screen and DSP setting screen, move the
controller to the right then select the desired screen.



“Sound Settings”

Adjusts the treble, mid or

bass.

Adjusts the front/rear audio bal-
ance.
Adjusts the left/right audio bal-
ance.



“DSP”

Sets the automatic sound level-
izer (ASL) on/off
Sets the surround function on/off

■

The sound quality level is adjusted individually
The treble, mid and bass levels can be adjusted for each audio mode separately.

■

About Automatic Sound Levelizer (ASL)
ASL automatically adjusts the volume and tone quality according to the vehicle speed.

Optimal use of the audio system

On the “Sound Settings” screen, sound quality (Treble/Mid/Bass), volume
balance and DSP settings can be adjusted.

How to adjust the sound settings and sound quality

1 2 3

4

5

1

2

414

5-3. Using the audio system

RX350/RX350L_U

Go to “Audio Settings”: “MENU” button

 “Setup”  “Audio”

Change radio settings (

P. 414)

Change iPod settings (

P. 415)

Change A/V settings (

P. 415)

Change the cover art settings
(

P. 416)

Change USB settings (

P. 416)

To display the radio settings screen in a different way, select “Radio Settings” on
the audio menu screen. (

P. 417)

Set the displaying RBDS text mes-
sage on/off
Change the number of radio presets

Audio settings

Screen for audio settings

1

2
3
4

5

Changing radio settings

1

2

415

5-3. Using the audio system

5

Le

xus
Dis
play Audi

o syst

em

RX350/RX350L_U

To display the iPod settings screen in a different way, select “iPod Settings” on the
audio menu screen. (

P. 417)

Change the screen size (video
mode)
Change the cover art settings
(

P. 416)

Adjust the screen quality (video
mode) (

P. 411)

Change video sound input port

To display the A/V settings screen in a different way, select “External Video Set-
tings” on the audio menu screen. (

P. 417)

Change the screen size
Change the video signal
Adjust the screen quality (video
mode) (

P. 411)

Changing iPod settings

1

2

3

4

Changing A/V settings

1

2
3

416

5-3. Using the audio system

RX350/RX350L_U

To display the cover art settings screen in a different way, select “Cover Art Set-
tings” on the audio menu screen. (

P. 417)

Select to set the cover art display
on/off.
Select to set the priority of the Gra-
cenote database on/off.

To display the USB settings screen in a different way, select “USB Settings” on
the audio menu screen. (

P. 417)

Change the cover art settings
(

P. 416)

Changing the cover art settings

1

2

Changing USB settings

1

417

5-3. Using the audio system

5

Le

xus
Dis
play Audi

o syst

em

RX350/RX350L_U

Go to audio menu screen: Move the controller to the left on the audio top screen



Radio mode

Audio menu screen operation

You can change the settings and control functions for each audio source.

Audio menu screen

Button

Function

Target

radio mode

“SCAN”

Scans for receivable stations

AM, FM

“SEEK”

Seeks a station of the nearest frequency (stops

when a station is found)

AM, FM

“Tag”

Captures the song title and artist name information

for potential purchase (when the “HD)” indicator

on the selected station is appears)

FM

“Multicast”

Changes the channel of HD Radio (HD2, HD3,

HD4 where applicable)

FM

“Traffic”

Seeks a station of the traffic announcement

FM

“HD Radio”

Selects to set the station list shows of HD radio on/

off

AM, FM

“Radio Settings”

Changes radio settings (

P. 414)

All mode

“Sound Settings”

Changes sound settings (

P. 413)

All mode

418

5-3. Using the audio system

RX350/RX350L_U



Media mode

Button

Function

Target audio source

“Play”

Plays or pauses a track/file

All media (except

A/V)

“Pause”

“Track Up”

Selects a track/file

All media (except

A/V)

“Track Down”

“File Up”

“File Down”

“Folder Up”

Selects a folder/album

MP3/WMA/AAC

disc, USB

“Folder Down”

“Fast Forward”

Selects and hold: Fast-forward or rewind a

track/file

All media (except

A/V)

“Rewind”

“Repeat”

Selects a repeat mode (

P. 419)

All media (except

A/V)

“Random”

Selects a random/shuffle play mode

(

P. 419)

All media (except

A/V)

“Shuffle”

“Full Screen”

Selects a full screen mode

iPod, A/V

“Connect”

Connects a Bluetooth

®

 device (

P. 443) Bluetooth

®

“Cover Art Set-

tings”

Changes the cover art settings (

P. 416)

CD, MP3/WMA/

AAC disc,

Bluetooth

®

“iPod Settings”

Changes iPod settings (

P. 415)

iPod

“USB Settings”

Changes USB settings (

P. 416)

USB

“External Video

Settings”

Changes A/V settings (

P. 415)

A/V

419

5-3. Using the audio system

5

Le

xus
Dis
play Audi

o syst

em

RX350/RX350L_U

“Sound Settings”

Changes sound settings (

P. 413)

All media

Repeat play

Mode

Action

“Track Repeat”

File/track repeat

“Repeat”

“RPT”

“On”

“Folder Repeat”

Folder/album repeat

“Album Repeat”

Random/shuffle playback

Mode

Action

“1 DISC”

Random/shuffle play of the disc/folder/album

“Random”

“Shuffle”

“Folder Random”

Random/shuffle play of all folders/albums

“ALBUM RAND”

“Album Shuffle”

Button

Function

Target audio source

420

RX350/RX350L_U

5-4. Using the radio

Pressing the “RADIO” button displays the radio top screen from any screen of
the selected source.

■

Menu screen
P. 417

Tune in to the desired station using one of the following methods.

■

Seek tuning
Press and hold then release the “

 PRST” or “TRACK ” button.

Seek tuning can also be operated on the menu screen. (

P. 417)

The radio will begin seeking up or down for a station of the nearest frequency
and will stop when a station is found.

■

Manual tuning
Turn the “TUNE•SCROLL” knob.

■

Preset stations
Select the desired preset station by pressing the “

 PRST” or “TRACK ” but-

ton, or turning and pressing the controller.

■

Station list

Move the controller to the right and selecting “Station List”.
AM radio: Selecting a desired station.
FM radio: Selecting a desired type of station and selecting a desired sta-
tion.

To refreshing the station list, select “Refresh”. Select “Source” on the refresh

screen, can be change to the other audio source while refreshing.

Radio operation

Select “AM”, “FM” or “SAT” on the audio source selection screen to begin lis-
tening to the radio.

Radio top screen

Selecting a station (AM or FM radio)

1

2

421

5-4. Using the radio

5

Le

xus
Dis
play Audi

o syst

em

RX350/RX350L_U

When “HD Radio” is set to “On”, available stations with HD Radio channels are
marked with “HD)”.

In AM or FM mode, select a station marked with “HD)”.
Turn the “TUNE•SCROLL” knob to select an HD Radio channel.

HD Radio channels can also be selected by selecting “Multicast” on the menu screen.

(

P. 417)

Select in to the desired channel using one of the following methods.

■

Turning up/down the channel
Press and hold the “

 PRST” or “TRACK ” button or turn the

“TUNE•SCROLL” knob.

■

Preset channels
Select the desired preset channel by pressing the “

 PRST” or “TRACK ”

button or controller.

■

Channel list

Move the controller to the right and selecting “Select a SAT Category”.
Selecting a desired category of channel and selecting a desired channel.

Search for desired stations or channel.
Select and hold one of the preset until you hear a beep.

■

Display the song information
Move the controller to the right and selecting “Text”.

■

Display the Additional information (HD radio)
Move the controller to the right and selecting “Additional Information”.

Selecting an HD Radio channel

Selecting a channel (XM Satellite Radio)

Setting presets

Display the text message

1

2

1

2

1

2

422

5-4. Using the radio

RX350/RX350L_U

HD Radio™ Technology is the digital evolution of analog AM/FM radio. Your
radio product has a special receiver which allows it to receive digital broadcasts
(where available) in addition to the analog broadcasts it already receives.
Digital broadcasts have better sound quality than analog broadcasts as digital
broadcasts provide free, crystal clear audio with no static or distortion. For more
information, and a guide to available radio stations and programming, refer to
www.hdradio.com.
“HD Radio features included in Lexus radios:
Digital Sound - HD Radio broadcasts deliver crystal-clear, digital audio quality to
listeners.
HD2/HD3 Channels - FM stations can provide additional digital only audio pro-
gramming with expanded content and format choices on HD2/HD3 channels.
PSD - Program Service Data (PSD) gives you on-screen information such as art-
ist name and song title.
iTunes Tagging - Listeners can tag (store) songs they like for later review and pur-
chase through iTunes.
Artist Experience - Images related to the broadcast are displayed on the radio
screen, such as album cover art and station logos.”

HD Radio™ Technology

HD Radio Technology manufactured under license from iBiquity Digital Corpora-

tion. U.S. and Foreign Patents. HD Radio™ and the HD, HD Radio, and “Arc” logos

are proprietary trademarks of iBiquity Digital Corp.

423

5-4. Using the radio

5

Le

xus
Dis
play Audi

o syst

em

RX350/RX350L_U

■

HD Radio™ Technology troubleshooting guide

■

Reception sensitivity

●

Maintaining perfect radio reception at all times is difficult due to the continually chang-

ing position of the antenna, differences in signal strength and surrounding objects, such

as trains, transmitters, etc.

●

The radio antenna is mounted inside the rear window. To maintain clear radio reception,

do not attach metallic window tinting or other metallic objects to the antenna wire

mounted inside the rear window.

Experience

Cause

Action

Mismatch of time align-

ment- a user may hear a

short period of program-

ming replayed or an echo,

stutter or skip.

The radio stations analog

and digital volume are not

properly aligned or the sta-

tion is in ballgame mode.

None, radio broadcast

issue. A user can contact

the radio station.

Sound fades, blending in

and out.

Radio is shifting between

analog and digital audio.

Reception issue, may

clear-up as the vehicle

continues to be driven. Set

“HD Radio” to off, can

force radio in an analog

audio.

Audio mute condition

when an HD2/HD3 multi-

cast channel had been

playing.

The radio does not have

access to digital signals at

the moment.

This is normal behavior,

wait until the digital signal

returns. If out of the cover-

age area, seek a new sta-

tion.

Audio mute delay when

selecting an HD2/HD3

multicast channel preset.

The digital multicast con-

tent is not available until

HD Radio™ broadcast can

be decoded and make the

audio available. This takes

up to 7 seconds.

This is normal behavior,

wait for the audio to

become available.

Text information does not

match the present song

audio.

Data service issue at the

radio broadcaster.

Broadcaster should be

notified. Complete the

form: www.ibiquity.com/

automotive/

report_radio_station_

experiences.

No text information shown

for the present selected

frequency.

Data service issue by the

radio broadcaster.

Broadcaster should be

notified. Complete the

form: www.ibiquity.com/

automotive/

report_radio_station_

experiences.

424

5-4. Using the radio

RX350/RX350L_U

425

5-4. Using the radio

5

Le

xus
Dis
play Audi

o syst

em

RX350/RX350L_U

426

5-4. Using the radio

RX350/RX350L_U

■

If the satellite radio does not operate normally
If a problem occurs with the XM tuner, a message will appear on the screen. Refer to the

table below to identify the problem, and take the suggested corrective action.

Contact the XM Listener Care Center at 1-877-447-0011 (U.S.A.) or 1-877-438-9677

(Canada).

SAT Check Antenna

The XM antenna is not connected. Check whether the XM

antenna cable is attached securely.

There is a short-circuit in the antenna or the surrounding

antenna cable. See a Lexus certified dealer.

SAT Ch Unauthorized

You have not subscribed to XM Satellite Radio. The radio is

being updated with the latest encryption code. Contact XM

Satellite Radio for subscription information. When a con-

tract is canceled, you can choose “Ch000” and all free-to-

air channels.

The premium channel you selected is not authorized. Wait

for about 2 seconds until the radio returns to the previous

channel or “Ch001”. If it does not change automatically,

select another channel. To listen to the premium channel,

contact XM Satellite Radio.

SAT No Signal

The XM signal is too weak at the current location. Wait until

your vehicle reaches a location with a stronger signal.

SAT Loading

The unit is acquiring audio or program information. Wait

until the unit has received the information.

SAT Channel Off Air

The channel you selected is not broadcasting any program-

ming. Select another channel.

-----

There is no song/program title or artist name/feature asso-

ciated with the channel at that time. No action is required.

SAT Chan Unavailable

The channel you selected is no longer available. Wait for

about 2 seconds until the radio returns to the previous

channel or “Ch001”. If it does not change automatically,

select another channel.

427

5

Le

xus
Dis
play Audi

o syst

em

RX350/RX350L_U

5-5. Playing an audio CD and MP3/WMA/AAC discs

Pressing the “MEDIA” button displays the CD top screen from any screen of the
selected source.

■

Menu screen
P. 417

■

Selecting a track/file
Press the “

 PRST” or “TRACK ” button or turn the “TUNE•SCROLL” knob

to select the desired track/file number.
To fast-forward or rewind, press and hold the “

 PRST” or “TRACK ” button.

■

Selecting the track by the list (CD)
Move the controller to the right and then select the desired track.

■

Selecting a folder (MP3/WMA/AAC disc)

Move the controller to the right and then select “Folders”.
Select the desired folder. Then select a file to begin using the selected
folder.

■

Selecting a file by the selected folder (MP3/WMA/AAC disc)

Move the controller to the right and then select “Files”.
Select the desired file.

CD player operation

Insert a disc, press the “MEDIA” button or select “DISC” on the “Source”
screen with a disc inserted to begin listening to a CD.

CD top screen

1

2

1

2

428

5-5. Playing an audio CD and MP3/WMA/AAC discs

RX350/RX350L_U

■

Error messages
If the following error messages appear on the screen, refer to the table and take the

appropriate measures. If the problem is not rectified, take the vehicle to your Lexus

dealer.

■

Discs that can be used
Discs with the marks shown below can be used.

Playback may not be possible depending on recording format or disc features, or due to

scratches, dirt or deterioration.

CDs with copy-protection features may not play correctly.

■

CD player protection feature
To protect the internal components, playback is automatically stopped when a problem is

detected.

■

If a disc is left inside the CD player or in the ejected position for extended periods
Disc may be damaged and may not play properly.

■

Lens cleaners
Do not use lens cleaners. Doing so may damage the CD player.

■

MP3, WMA and AAC files
MP3 (MPEG Audio LAYER3) is a standard audio compression format.
Files can be compressed to approximately 1/10 of their original size by using MP3 com-

pression.
WMA (Windows Media Audio) is a Microsoft audio compression format.
This format compresses audio data to a size smaller than that of the MP3 format.
AAC is short for Advanced Audio Coding and refers to an audio compression technol-

ogy standard used with MPEG2 and MPEG4.
MP3, WMA and AAC file and media/formats compatibility are limited.

Message

Cause

Correction procedures

“Check disc”

• The disc is dirty or dam-

aged.

• The disc is inserted

upside down.

• The  disc  is  not  playable

with the player.

• Clean  the  disc.

• Insert the disc correctly.

• Confirm  the  disc  is  play-

able with the player.

“DISC Error”

There is a malfunction

within the system.

Eject the disc.

“No music files found.”

No playable data is

included on the disc.

Eject the disc.
