LEXUS RX 350 L (2019 year). Instruction - part 6

2. Instrument cluster

Instrument cl

uste
r

RX350/RX350L_U

◆

Using the odometer/trip meter display area

Items in this area are operated using the “ODO/TRIP” switch.
Press: Change displayed item

Each time the switch is pressed, the

displayed item will be changed.

Press and hold: Reset

Display the desired trip meter and

press and hold the switch to reset the

trip meter.

Select a menu icon to display its content.

Drive information (

P. 94)

Select to display various drive data.

Navigation system-linked display (if equipped)

Select to display the following navigation system-linked information.

• Route guidance

• Compass display (heading-up display)

Audio system-linked display

Select to enable selection of an audio source or track on the meter using the meter

control switches.

Driving assist system information

Select to display the operational status of the following systems:

• Dynamic radar cruise control with full-speed range (

P. 300)

• LKA (Lane-Keeping Assist) (

P. 291)

Warning message display (

P. 661)

Select to display warning messages and measures to be taken if a malfunction is

detected.

Settings display (

P. 97)

Select to change the meter display settings and other settings.

Menu icons

2. Instrument cluster

RX350/RX350L_U

■

Drive information 1/Drive information 2/Drive information 3
Displays drive information such as the following:

●

Drive information 1

• Current fuel consumption
• Average fuel economy (after reset)

●

Drive information 2

• Distance (driving range)
• Average vehicle speed (after reset)

●

Drive information 3

• Average fuel economy (after refuel)
• Elapsed time (after start)

Displayed items (listed below) can be changed on

. (

P. 97)

Drive information (

)

Item

Content

Current fuel consumption

Displays instantaneous current fuel consumption

Average fuel

economy

After reset

Displays average fuel consumption since the dis-
play was reset

1, 2

After start

Displays average fuel consumption since engine
start

After refuel

Displays average fuel consumption since refuel

2, 3

Average

vehicle

speed

After reset

Displays average vehicle speed since the display
was reset

After start

Displays average vehicle speed since engine start

Elapsed time

After reset

Displays elapsed time since the display was reset

After start

Displays elapsed time since engine start

Distance

Driving range

Displays driving range with remaining fuel

3, 4

After start

Displays drive distance since vehicle start

Other

Blank

No item

2. Instrument cluster

Instrument cl

uste
r

RX350/RX350L_U

: Resetting:

P. 92

: Use the displayed fuel consumption as a reference.

: When only a small amount of fuel is added to the tank, the display may not be

updated.
When refueling, turn the engine switch off. If the vehicle is refueled without turning the
engine switch off, the display may not be updated.

: This distance is computed based on your average fuel consumption. As a result, the

actual distance that can be driven may differ from that displayed.

■

Eco Driving Indicator
P. 105

■

Sway warning
Detects the sway of the vehicle within a lane, which is often associated with a
decrease in the driver's attention level, and displays the decrease in attention
using a bar display.
The shorter the bar length, the more the driver may need to rest.

This display is a part of the LKA (Lane-Keeping Assist) system. The display is

enabled when the operating conditions of the vehicle sway warning are met.

(

P. 291)

■

AWD Control (if equipped)
Displays the driving force applied to each wheel using segments.
The greater the number of segments displayed, the greater the driving force
applied.

2. Instrument cluster

RX350/RX350L_U

■

G-force (if equipped)
Displays lateral G-forces on the vehicle.
Also displays, around the periphery of the G-force display, the left and right
steering amount, accelerator pedal input, and brake fluid pressure.

Acceleration G-force on the
vehicle
Current G-force value (analyzed
value of front/rear and left/right
G-forces)
Record of the maximum G-forces
Accelerator pedal input
Brake fluid pressure
Steering amount

This display is intended for use as a guideline. Depending on factors such as the

road surface condition, temperature and vehicle speed, the display may not show

the actual condition of the vehicle.

●

Resetting the record of maximum G-forces
Press and hold

to reset the record.

●

Peak hold function
If lateral G-forces of 0.5 G or greater are generated, the G-force value
display will turn amber and be held for 2 seconds.

■

Tire pressure
P. 605

■

Units (if equipped)
The units of measure used can be changed while driving.

Unlike the units setting performed on

, the units setting performed on

can

be changed while driving.

■

Blank (No items)
Displays no drive information contents.

3
4
5
6

2. Instrument cluster

Instrument cl

uste
r

RX350/RX350L_U

◆

Changing settings

Use the meter control switches on the steering wheel to change settings.

Press

select .

Operate the switches to select a desired item.
Change the setting by referring to the message displayed on the screen.

◆

Setting items

■

LKA (Lane-Keeping Assist) (

P. 291)

The following LKA system settings can be changed:

: If the lane centering function is enabled/disabled, steering wheel assistance will also

be enabled/disabled accordingly.

: If the steering wheel assistance is disabled, lane centering function will also be dis-

abled automatically.

Settings display (

)

2
3

Item

Settings

Details

Lane center tracing

Select to enable/disable the lane cen-
tering function.

Off

Steering assist

Select to enable/disable steering
wheel assistance.

Off

Alert

Select to set a vibrator or buzzer as

the notification method used to warn

the driver.

Alert sensitivity

High

Select to set the warning sensitivity.

Normal

Sway warning

Select to enable/disable the vehicle

sway warning.

Off

Sway sensitivity

High

Select to set the vehicle sway warning

sensitivity.

Medium

Low

2. Instrument cluster

RX350/RX350L_U

■

PCS (Pre-Collision System) (

P. 281)

The following pre-collision system settings can be changed:

■

BSM (Blind Spot Monitor) (if equipped) (

P. 313)

The following Blind Spot Monitor settings can be changed:

: The Rear Cross Traffic Alert function can be enabled/disabled only when the Blind

Spot Monitor function is enabled.

■

Intuitive parking assist (if equipped) (

P. 326)

Item

Settings

Details

PCS

Select to enable/disable the pre-colli-

sion system.

Off

Warning sensitivity

Select to change the warning timing.

Item

Settings

Details

BSM

Select to enable/disable the Blind

Spot Monitor function.

Off

RCTA

Select to enable/disable the Rear

Cross Traffic Alert function.

Off

Item

Settings

Details

Intuitive parking assist

Select to enable/disable the intuitive

parking assist.

Off

2. Instrument cluster

Instrument cl

uste
r

RX350/RX350L_U

■

ICS (Intelligent Clearance Sonar) (if equipped) (

P. 336)

■

HUD (Head-up display) (if equipped) (

P. 108)

The following head-up display settings can be changed:

Item

Settings

Details

ICS

Select to enable/disable the Intelli-

gent Clearance Sonar system.

Off

Item

Settings

Details

Brightness/Position

Select to adjust the brightness/posi-

tion of the head-up display.
• Press the

switch to adjust

the display brightness.

• Press the

switch to adjust

the display position.

Gauge information

No display

Select to set the content displayed on

the head-up display.

Eco Driving Indica-

tor

Tachometer

Driving support

Navigation system

(if equipped)

Select to enable/disable head-up dis-

play content.

Driving Assist (if

equipped)

Compass (if

equipped)

Audio system

100

2. Instrument cluster

RX350/RX350L_U

■

Clock (on the multi-information display) (

P. 86)



Vehicles with a navigation system

The following clock setting can be changed:



Vehicles with a Lexus Display Audio system

The following clock settings can be changed:

Press the

switch to select an item and then press the

switch to

change the setting or adjust the time.

Item

Settings

Details

Display mode

12-hour display

Select to set the display mode of the

clock.

24-hour display

Item

Settings

Details

Display mode

12-hour display

Select to set the display mode of the

clock.

24-hour display

Adjust time

Select to adjust the hour/minute.

101

2. Instrument cluster

Instrument cl

uste
r

RX350/RX350L_U

■

Vehicle settings

Item

Settings

Details

PBD (Power back door) (

P. 130)

The following power back door settings can be changed:

System settings

All On

Select to enable the power back door

system.

Touchless Sensor

Off (if equipped)

Select to disable the touchless sensor.

(Other power back door functions

remain enabled.)

All Off

Select to disable the power back door

system.

Open position adjust-

ment

Select to set the open position at

which the power back door will stop

when opened automatically.

Volume

3 (Loud)

Select to set the volume of the buzzer

which sounds when the power back

door is operated.

2 (Medium)

1 (Low)

TPMS (Tire pressure warning system) (

P. 605)

Tire pressure warning system initialization

Select to initialize the tire pressure

warning system. To perform initializa-
tion, press and hold the
switch.

Before performing initialization, make

sure to adjust the inflation pressure of

each tire to the specified level.

(

P. 606)

102

2. Instrument cluster

RX350/RX350L_U

■

Meter settings

Scheduled maintenance (U.S.A. only)

Maintenance data reset

Select to reset the message indicating

maintenance is required, after the

required maintenance is performed.

(

P. 585)

Oil maintenance

Engine oil maintenance data reset

Select to reset the engine oil mainte-

nance information (message indicat-

ing maintenance is required and

distance until the next oil change)

after engine oil maintenance is per-

formed. (

P. 597)

Item

Settings

Details

Item

Settings

Details

Language

Select to change the language dis-

played.

Units

Select to change the units of measure

displayed.

(Eco Driving

Indicator Light)

Select to enable/disable the Eco Driv-

ing Indicator Light. (

P. 105)

Off

Switch settings

Select to display how to change the

top screen.

Drive information 1

Select to select up to 2 items that will

be displayed on each Drive informa-

tion screen (Drive information 1

screen, Drive information 2 screen,

and Drive information 3 screen)

respectively.

(Selectable items:

P. 94)

Drive information 2

Drive information 3

103

2. Instrument cluster

Instrument cl

uste
r

RX350/RX350L_U

Pop-up display

Intersection guid-

ance (if equipped)

Select to enable/disable the pop-up

display.

Incoming calls

Brightness adjust-

ment

Color (except F

SPORT models)

2 available colors

Select to set the color of the cursor on

the multi-information display.

Needle (F SPORT

models)

3 available colors

Select to set the tachometer needle

color.

Rev indicator (F

SPORT models)

Select to enable/disable the Rev indi-

cator. (

P. 88)

Off

Rev setting

Select to set the desired engine speed

at which the Rev indicator will begin

to be displayed.

Selectable engine speed range:

2000 rpm to 6500 rpm

Rev peak (F SPORT

models)

Select to enable/disable the Rev peak.

(

P. 88)

Off

Default setting

Select to reset the meter display set-

tings to the default setting.

Item

Settings

Details

104

2. Instrument cluster

RX350/RX350L_U

◆

Display items

■

Odometer
Displays the total distance the vehicle has been driven.

■

Trip meter A/trip meter B
Displays the distance the vehicle has been driven since the meter was last
reset. Trip meters A and B can be used to record and display different dis-
tances independently.

To reset, display the desired trip meter and press and hold the “ODO/TRIP”

switch.

■

Distance until next engine oil change

Displays the distance the vehicle can be driven until an oil change is neces-
sary.

◆

Pop-up display

In some situations the following will be temporarily displayed:

■

Distance until next engine oil change

Displays the distance until the next engine oil change. This display will be dis-
played in the following situations:

• When the engine switch is turned to IGNITION ON mode.

• When a warning message indicating that oil maintenance should be performed

soon or is required is displayed.

Odometer/trip meter display area

105

2. Instrument cluster

Instrument cl

uste
r

RX350/RX350L_U

Displays suggestions to the driver in the following situations. To select a response
to a displayed suggestion, use the meter control switches.

The suggestion function can be turned on/off. (Customizable features:

P. 723)

■

Suggestion to enable the power back door
If the power back door system is disabled (setting on

set to off) and the

power back door switch on the instrument panel is operated, a suggestion
message will be displayed asking if you wish to enable the power back door
system. To enable the power back door system, select “Yes”.

After enabling the power back door system, press the power back door switch

again to open or close the power back door.

■

Suggestion to turn off the headlights
If the headlights are left on for a certain amount of time after the engine switch
has been turned off, a suggestion message will be displayed asking if you wish
to turn the headlights off. To turn the headlights off, select “Yes”.

If a front door is opened after the engine switch is turned off, this suggestion mes-

sage will not be displayed.

■

Eco Driving Indicator

Eco Driving Indicator will not operate under the following conditions:

●

The shift lever is in any position other than D.

●

A paddle shift switch (if equipped) is operated.

●

Sport mode is selected.

●

The driving mode is set to customized mode and the powertrain control is set to power

(

P. 373)

●

The vehicle speed is approximately 80 mph (130 km/h) or higher.

Suggestion function

Eco Driving Indicator Light

During Eco-friendly acceleration (Eco driv-

ing), the Eco Driving Indicator Light will turn

on. When the acceleration exceeds the Zone

of Eco driving, or when the vehicle is stopped,

the light turns off.
Eco Driving Indicator Zone Display

Suggests the Zone of Eco driving with current

Eco driving ratio based on acceleration.
Eco driving ratio based on acceleration

If the acceleration exceeds the Zone of Eco

driving, the right side of the Eco Driving Indi-

cator Zone Display will illuminate.
Zone of Eco driving

106

2. Instrument cluster

RX350/RX350L_U

■

Background color of the indicator/shift position display area (except F SPORT models)
The background color of the indicator/shift position display area is changed according to

the driving mode as follows (

P. 373):

●

Eco drive mode: Blue

●

Sport mode: Red

■

G-force display (if equipped)

●

The G-force values may not be zero even when the vehicle is parked, such as when it is

parked on an incline.

●

Depending on the vehicle usage conditions, the brake fluid pressure display may not

reach its maximum reading even though the brake pedal is fully depressed.

●

If a battery terminal is disconnected and reconnected, the steering amount display may

be disabled temporarily. After driving the vehicle for a while, the display will be enabled.

■

Suspension of the settings display

●

Some settings cannot be changed while driving. When changing settings, park the

vehicle in a safe place.

●

If a warning message is displayed, operation of the settings display will be suspended.

■

Tire pressure

●

It may take a few minutes to display the tire inflation pressure after the engine switch is

turned to IGNITION ON mode. It may also take a few minutes to display the tire infla-

tion pressure after inflation pressure has been adjusted.

●

“---” may be displayed if the tire position information cannot be determined due to

unfavorable radio wave conditions.

●

Tire inflation pressure changes with temperature. The displayed values may also be dif-

ferent from the values measured using a tire pressure gauge.

■

Liquid crystal display
Small spots or light spots may appear on the display. This phenomenon is characteristic

of liquid crystal displays, and there is no problem continuing to use the display.

■

Customization
Some functions can be customized. (

P. 97, 722)

107

2. Instrument cluster

Instrument cl

uste
r

RX350/RX350L_U

WARNING

■

Caution for use while driving

●

When operating the multi-information display while driving, pay extra attention to the

safety of the area around the vehicle.

●

Do not look continuously at the multi-information display while driving as you may fail

to see pedestrians, objects on the road, etc. ahead of the vehicle.

■

The information display at low temperatures
Allow the interior of the vehicle to warm up before using the liquid crystal information

display. At extremely low temperatures, the information display monitor may respond

slowly, and display changes may be delayed.

For example, there is a lag between the driver’s shifting and the new gear number

appearing on the display. This lag could cause the driver to downshift again, causing

rapid and excessive engine braking and possibly an accident resulting in death or

injury.

■

Cautions during setting up the display
As the engine needs to be running during setting up the display, ensure that the vehicle

is parked in a place with adequate ventilation. In a closed area such as a garage,

exhaust gases including harmful carbon monoxide (CO) may collect and enter the

vehicle. This may lead to death or a serious health hazard.

NOTICE

■

While setting up the display
To prevent battery discharge, ensure that the engine is running while setting up the dis-

play features.

108

2. Instrument cluster

RX350/RX350L_U

The head-up display is linked to the meters and navigation system (if equipped)
and projects a variety of information in front of the driver, such as the current
vehicle speed and route guidance to a set destination.

Navigation system-linked display area (if equipped) (

P. 111)

Displays the following items, which are linked to the navigation system:

• Street name

• Route guidance to destination

• Compass

Message display area (

P. 110)

Displays the following items:

• Warning/Message (if equipped)

• Audio system operation status

• Outside temperature
