LEXUS IS 350 (2019 year). Instruction

408

5-12. Other function

IS350 AWD/IS350/IS300 AWD/IS300_U

Some recognizable voice commands and their actions are shown below as
examples.



Basic



Phone

Command list

Command

Action

“Help”

Prompts voice guidance to offer examples of com-

mands or operation methods

“Go Back”

Returns to the previous screen

“Go to <tab>”

Displays the command list of the selected tab

Command

Action

“Redial”

Places a call to the phone number of the latest outgo-

ing call

“Call Back”

Places a call to the phone number of latest incoming

call

“Show Recent Calls”

Displays the call history screen

“Dial <phone number>”

Places a call to the said phone number

“Call <contacts>

<phone types>”

Place a call to the said phone type of the contact from

the phone book

409

5-12. Other function

xus
Dis
play Audi

o syst

IS350 AWD/IS350/IS300 AWD/IS300_U



Radio



Audio



Info

Command

Action

“Tune to <frequency> AM”

Changes the radio to the specified AM frequency

“Tune to <frequency> FM”

Changes the radio to the specified FM frequency

“Play <genre> station”

Changes the radio to an FM station of the specified

genre

“Tune to FM <frequency>

HD <number>”

Changes the radio to the specified HD radio station

“Tune to preset <number>”

Changes the radio to the specified preset radio station

“Tune to <name>”

Changes the radio to the satellite radio channel with

the specified name

“Tune to channel <number>” Changes the radio to the specified satellite radio chan-

nel number

“Play <genre> satellite sta-

tion”

Changes the radio to a satellite radio channel of the

specified genre

“AM Radio”

Selects AM radio mode

“FM Radio”

Selects FM radio mode

“Sirius XM”

Selects satellite radio mode

Command

Action

“Play Playlist <name>”

Plays tracks from the selected playlist

“Play Artist <name>”

Plays tracks from the selected artist

“Play Song <name>”

Plays the selected track

“Play Album <name>”

Plays tracks from the selected album

“Turn Music On/Off”

Turns the audio system on/off

“Play the <audio sources>”

Selects audio source

Command

Action

“Show Forecast”

Displays weather information

“Show Traffic”

Displays traffic information

412

IS350 AWD/IS350/IS300 AWD/IS300_U

6-1. Basic operation of the Remote Touch screen

“MAP” button

Press this button to display the vehicle’s current position.

“

•” button

Press this button to change map scale and scroll through lists.

Back button

Press to display the previous screen.

“MENU” button

Press to display the “Menu” screen. (

P. 414)

Remote Touch knob

Move in the desired direction to select a function, letter and screen button.
Press the knob to enter the selected function, letter or screen button.

“ENTER” button

Press to enter the selected function, letter or screen button.

Remote Touch



: If equipped

The Remote Touch can be used to operate the Remote Touch screens.
Owners of models equipped with a navigation system should refer to the
“NAVIGATION SYSTEM OWNER’S MANUAL”.

413

6-1. Basic operation of the Remote Touch screen

Inte
rior fe

ature

IS350 AWD/IS350/IS300 AWD/IS300_U

Select: Move the Remote Touch
knob in the desired direction.
Enter: Push the Remote Touch knob
or an “ENTER” button.

■

Screen display during low temperatures
When the ambient temperature is extremely low, screen response may be delayed even

if the Remote Touch is operated.

Remote Touch operation

WARNING

■

When using the Remote Touch

●

Do not allow fingers, fingernails or hair to become caught in the Remote Touch as this

may cause an injury.

●

Be careful when selecting the Remote Touch in extreme temperatures as it may

become very hot or cold due to the temperature inside the vehicle.

NOTICE

■

To prevent damage to the Remote Touch

●

Do not allow the Remote Touch to come into contact with food, liquid, stickers or lit

cigarettes as doing so may cause it to change color, emit a strange odor or stop func-

tioning.

●

Do not subject the Remote Touch to excessive pressure or strong impact as the knob

may bend or break off.

●

Do not allow coins, contact lenses or other such items to become caught in the

Remote Touch as this may cause it to stop functioning.

●

Items of clothing may rip if they become caught on the Remote Touch knob.

●

If your hand or any object is on the Remote Touch knob when the engine switch is in

ACCESSORY mode, the Remote Touch knob may not operate properly.

414

6-1. Basic operation of the Remote Touch screen

IS350 AWD/IS350/IS300 AWD/IS300_U

Press the “MENU” button on the
Remote Touch to display the “Menu”
screen.
The display may differ depending on
the type of the system.

When the split-screen display is

selected, the “Menu” screen will be dis-

played on the main display. (

P. 415)

: Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.

“Menu” screen

Switch

Function

Select to display the “Destination” screen.

Select to display the radio control screen.

Select to display the media control screen.

Select to display the hands-free operation screen.

Select to display the “LEXUS App Suite” screen.

Select to display the “Information” screen.

Select to display the air conditioning control screen. (

P. 417)

Select to display the “Setup” screen.

“Display”

Select to adjust the contrast and brightness of the screens, turn the

screen off, etc.

415

6-1. Basic operation of the Remote Touch screen

Inte
rior fe

ature

IS350 AWD/IS350/IS300 AWD/IS300_U

■

Full screen display
The following functions can be displayed full screen:

• Initial screen
• “Menu” screen (

P. 414)

• Map screen

*: Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.

■

Split-screen display
Different information can be displayed on the left and right of the screen. For
example, audio screen can be displayed and operated while the fuel con-
sumption information screen is being displayed. The large screen on the left of
the display is called the main display, and the small screen to the right is called
the side display.

10.3-inch display (vehicles with a navigation system)

10.3-inch display overview

416

6-1. Basic operation of the Remote Touch screen

IS350 AWD/IS350/IS300 AWD/IS300_U

■

Selecting the operation screen
When selecting the main display, move the Remote Touch knob to the left.
When selecting the side display, move the Remote Touch knob to the right.

■

Main display
For details about the functions and operation of the main display, refer to the
respective section and “NAVIGATION SYSTEM OWNER’S MANUAL”.

■

Side display



Basic screens

To change the screen displayed on the side display, use the screen buttons on
the right side of the display.

Navigation system

Audio

Phone

Vehicle information (

P. 115)

Air conditioning system
(

P. 420)



Interruption screens

Each of the following screens is displayed automatically in accordance with
conditions.

• Intuitive parking assist (if equipped) (

P. 261)

• Phone

• Destination Assist

• Driving mode (

P. 297)

: Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.

Split-screen display operation

2
3
4
5

417

IS350 AWD/IS350/IS300 AWD/IS300_U

Inte
rior fe

ature

6-2. Using the air conditioning system

■

Adjusting the temperature setting
To adjust the temperature setting,
touch and slide your finger up or
down on the sensor.

The temperature setting can also be

adjusted by touching on the sensor.
When the temperature setting is

changed, a buzzer sounds.
If

is not pressed, the system

will blow ambient temperature air or

heated air.

Automatic air conditioning system

Air outlets and fan speed are automatically adjusted according to the tem-
perature setting.
Vehicles with a Lexus Display Audio system: Press the “MENU” button on the
Lexus Display Audio controller, then select “Climate” to display the air condi-
tioning operation screen.
For details on the Lexus Display Audio controller, refer to “Lexus Display
Audio controller” on P. 314.
Vehicles with a navigation system: Press the “MENU” button on the Remote
Touch, then select

to display the air conditioning control screen. The air

conditioning system can be displayed and operated on the side display.
(

P. 416)

Air conditioning controls

418

6-2. Using the air conditioning system

IS350 AWD/IS350/IS300 AWD/IS300_U

■

Fan speed setting

Press

to increase the fan speed.

Press

to decrease the fan speed.

■

Change the airflow mode

To change the airflow, press

The air outlets used are switched each time the button is pressed.

Air flows to the upper body.
Air flows to the upper body and feet.
Air flows to the feet.
Air flows to the feet and the windshield defogger operates

■

Other functions

●

Switching between outside air and recirculated air modes (

P. 421)

●

Defogging the windshield (

P. 422)

●

Defogging the rear window and outside rear view mirrors (

P. 422)



With a Lexus Display Audio



With a navigation system

2
3
4

419

6-2. Using the air conditioning system

Inte
rior fe

ature

IS350 AWD/IS350/IS300 AWD/IS300_U



With a Lexus Display Audio

Adjust the left-hand side tem-
perature setting
Adjust the fan speed setting
Select to set auto mode on/off
Select to set eco mode on/off
(

P. 424)

Select to set cooling and dehu-
midification function on/off

If the “A/C” indicator is turned off, the system will blow ambient temperature air or

heated air.

Adjust the temperature for driver and passenger seats separately (“DUAL”
mode) (

P. 421)

Display the option control screen (

P. 420)

Select the air flow mode
Adjust the right-hand side temperature setting



With a navigation system

Adjust the left-hand side tem-
perature setting
Adjust the fan speed setting
Select the air flow mode
Adjust the right-hand side tem-
perature setting
Display the option control screen
(

P. 420)

Select to set automatic mode on/off
Select to set cooling and dehumidification function on/off

If the “A/C” indicator is turned off, the system will blow ambient temperature air or

heated air.

Adjust the temperature for driver and passenger seats separately (“DUAL”
mode) (

P. 421)

Select to set eco mode on/off (

P. 424)

Air conditioning control screen

2
3
4

8
9

2
3
4

6
7

420

6-2. Using the air conditioning system

IS350 AWD/IS350/IS300 AWD/IS300_U

■

Option control screen
Select

on the air conditioning control screen to display the option

control screen. The functions can be switched on and off.

■

Side display operation screen (vehicles with a navigation system)

Select the air flow mode
Adjust the left-hand side tem-
perature setting
Adjust the fan speed setting
Adjust the right-hand side tem-
perature setting
Select to set auto mode on/off
Select to set cooling and dehu-
midification function on/off

If the “A/C” indicator is turned off, the system will blow ambient temperature air or

heated air.

Adjust the temperature for driver and passenger seats separately (“DUAL”
mode) (

P. 421)



With a Lexus Display Audio



With a navigation system

Removing pollen from the air (Micro dust and pollen filter) (

P. 421)

3
4

5
6

421

6-2. Using the air conditioning system

Inte
rior fe

ature

IS350 AWD/IS350/IS300 AWD/IS300_U

Press

, or select “AUTO” on the air conditioning control screen.

Adjust the temperature setting.

To stop the operation, press

■

Automatic mode indicator
If the fan speed setting or air flow modes are operated, the automatic mode
indicator goes off. However, automatic mode for functions other than that
operated is maintained.

■

Adjusting the temperature for driver and passenger seats separately
(“DUAL” mode)
To turn on the “DUAL” mode, perform any of the following procedures:

●

Press

or select “DUAL” on the air conditioning control screen.

●

Select “DUAL” on the side display operation screen.(vehicles with a navi-
gation system)

●

Adjust the passenger’s side temperature setting.

The indicator comes on when the “DUAL” mode is on.
While in “DUAL” mode, the temperature of the rear air outlets is set at the right-

hand side temperature setting.

■

Switching between outside air and recirculated air modes

Press

to change to recirculated air mode.

Press

to change to outside air mode.

The indicator above the selected button comes on.

■

Micro dust and pollen filter
Pollen is removed from the air and the air flows to the upper part of the body.
Select

on the option control screen.

When the micro dust and pollen filter is on,

is displayed on the air condition-

ing control screen.
In order to prevent the windshield from fogging up when the outside air is cold, the

dehumidification function may operate.
The pollens are filtered out even if the micro dust and pollen filter is turned off.

Using automatic mode

Other functions

422

6-2. Using the air conditioning system

IS350 AWD/IS350/IS300 AWD/IS300_U

■

Defogging the windshield
Defoggers are used to defog the windshield and front side windows.

Press .

Set the outside/recirculated air mode button to outside air mode if the recirculated

air mode is used. (It may switch automatically.)
To defog the windshield and the side windows early, turn the air flow and tempera-

ture up.
To return to the previous mode, press

again when the windshield is

defogged.

■

Defogging the rear window and outside rear view mirrors
Defoggers are used to defog the rear window, and to remove raindrops, dew
and frost from the outside rear view mirrors.

Press .

The defoggers will automatically turn off after a period of time.

■

Windshield wiper de-icer (if equipped)
This feature is used to prevent ice from building up on the windshield and
wiper blades.
Turns on/off.

The indicator comes on when the

windshield wiper de-icer is on.
The windshield de-icer will automati-

cally turn off after a period of time.

423

6-2. Using the air conditioning system

Inte
rior fe

ature

IS350 AWD/IS350/IS300 AWD/IS300_U

■

Location of air outlets
The air outlets and air volume
changes according to the selected
airflow mode.

■

Adjusting the position of and opening and closing the air outlets

Direct air flow to the left or right, up or down

To close the vent, move the knob to the most outside position. (rear outlets)

Turn the knob to open or close the vent

■

Registering air conditioning settings to electronic keys (vehicles with driving position

memory)

●

Unlocking the vehicle using an electronic key and turning the engine switch to IGNI-

TION ON mode will recall that key's registered air conditioning settings.

●

When the engine switch is turned off, the current air conditioning settings will automat-

ically be registered to the electronic key that was used to unlock the vehicle.

●

The system may not operate correctly if more than one electronic key is in the vicinity or

if the smart access system with push-button start is used to unlock a passenger door.

●

The doors that can recall the air conditioning setting

when unlocked using the smart

access system with push-button start can be changed. For details, contact your Lexus

dealer.

: The doors that can recall the driving position memory are changed at the same time.

Air outlets



Front



Rear

LEXUS IS 350 (2019 year). Instruction - part 26
