LEXUS IS 350 (2019 year). Instruction - part 7





104

2. Instrument cluster

IS350 AWD/IS350/IS300 AWD/IS300_U

■

 PCS (Pre-collision system) (

P. 229)

The following pre-collision system settings can be changed:

■

AFS (Adaptive Front-lighting System) (if equipped) (

P. 203)

Item

Settings

Details

PCS

On

Select to enable/disable the pre-colli-

sion system.

Off

Warning sensitivity

Select to change the warning timing.

Item

Settings

Details

AFS

On

Select to enable/disable the AFS

(Adaptive Front-lighting System).

Off

105

2. Instrument cluster

2

Instrument cl

uste
r

IS350 AWD/IS350/IS300 AWD/IS300_U

■

Speed indicator (F SPORT models) (

P. 91)

The following speed indicator settings can be changed:

*

: Always observe the legal speed limit when driving on public roads.

■

Clock (on multi-information display) (

P. 89)

Vehicles with a navigation system

The following clock setting can be changed:

Vehicles with a Lexus Display Audio system

The following clock settings can be changed:

Press the

/

 switch to select an item and then press the

/

 switch to

change the setting or adjust the time.

Item

Settings

Details

Speed Indicator

On

Select to enable/disable the speed

indicator.

Off

Speed Setting

30 mph to 100 mph

(50 km/h to 160

km/h)

*

Select to set the desired vehicle

speed at which the speed indicator

will begin to be displayed.

Item

Settings

Details

Display mode

12-hour display

Select to set the display mode of the

clock.

24-hour display

Item

Settings

Details

Display mode

12-hour display

Select to set the display mode of the

clock.

24-hour display

Adjust time

Select to adjust the hour/minute.

106

2. Instrument cluster

IS350 AWD/IS350/IS300 AWD/IS300_U

■

Vehicle settings

■

Meter settings

Item

Settings

Details

Scheduled maintenance

Maintenance data reset

Select to reset the message indicating

maintenance is required, after the

required maintenance is performed.

(

P. 462)

Oil maintenance

Engine oil maintenance data reset

Select to reset the engine oil mainte-

nance information (message indicat-

ing maintenance is required and

distance until the next oil change)

after engine oil maintenance is per-

formed. (

P. 477)

Item

Settings

Details

Language

Select to change the language dis-

played.

Units

Select to change the units of measure

displayed.

 (Eco Driving

Indicator Light)

On

Select to enable/disable the Eco Driv-

ing Indicator Light. (

P. 109)

Off

 Switch settings (except F SPORT mod-

els)

Select to display how to change the

top screen.

Drive information 1

Select to select up to 2 items that will

be displayed on each Drive informa-

tion screen (Drive information 1

screen, Drive information 2 screen,

and Drive information 3 screen)

respectively.

(Selectable items:

P. 100)

Drive information 2

Drive information 3

107

2. Instrument cluster

2

Instrument cl

uste
r

IS350 AWD/IS350/IS300 AWD/IS300_U

Pop-up display

Intersection guid-

ance (if equipped)

Select to enable/disable the pop-up

display.

Incoming calls

Brightness adjust-

ment

Color (except F

SPORT models)

2 available colors

Select to set the color of the cursor on

the multi-information display.

Needle (F SPORT

models)

3 available colors

Select to set the tachometer needle

color.

Rev indicator (F

SPORT models)

On

Select to enable/disable the Rev indi-

cator. (

P. 91)

Off

Rev setting

Select to set the desired engine speed

at which the Rev indicator will begin

to be displayed.

Selectable engine speed range:

IS350 AWD/IS350/IS300 AWD:

2000 rpm to 6800 rpm

IS300: 2000 rpm to 6100 rpm

Rev peak (F SPORT

models)

On

Select to enable/disable the Rev peak.

(

P. 91)

Off

Default setting

Select to reset the meter display set-

tings to the default setting.

Item

Settings

Details

108

2. Instrument cluster

IS350 AWD/IS350/IS300 AWD/IS300_U

◆

Display items

■

Odometer
Displays the total distance the vehicle has been driven.

■

Trip meter A/trip meter B
Displays the distance the vehicle has been driven since the meter was last
reset. Trip meters A and B can be used to record and display different dis-
tances independently.

To reset, display the desired trip meter and press and hold the odometer/trip meter

and trip meter reset button.

■

 Distance until next engine oil change

Displays the distance the vehicle can be driven until an oil change is neces-
sary.

◆

Pop-up display

In some situations the following will be temporarily displayed:

■

 Distance until next engine oil change

Displays the distance until the next engine oil change. This display will be dis-
played in the following situations:

• When the engine switch is turned to IGNITION ON mode.

• When a warning message indicating that oil maintenance should be performed

soon or is required is displayed.

Odometer/trip meter display area

109

2. Instrument cluster

2

Instrument cl

uste
r

IS350 AWD/IS350/IS300 AWD/IS300_U

■

Eco Driving Indicator

Eco Driving Indicator will not operate under the following conditions:

●

The shift lever is in any position other than D.

●

A paddle shift switch is operated.

●

Neither normal mode nor Eco drive mode is selected. (

P. 297)

●

The vehicle speed is approximately 80 mph (130 km/h) or higher.

■

Background color of the indicator/shift position display area (except F SPORT models)
The background color of the indicator/shift position display area is changed according to

the driving mode as follows (

P. 297):

●

Eco drive mode: Blue

●

Sport mode: Red

■

G-force display (if equipped)
The G-force values may not be zero even when the vehicle is parked, such as when it is

parked on an incline.

■

Suspension of the settings display

●

Some settings cannot be changed while driving. When changing settings, park the

vehicle in a safe place.

●

If a warning message is displayed, operation of the settings display will be suspended.

■

Tire pressure

●

It may take a few minutes to display the tire inflation pressure after the engine switch is

turned to IGNITION ON mode. It may also take a few minutes to display the tire infla-

tion pressure after inflation pressure has been adjusted.

●

“---” may be displayed if the tire position information cannot be determined due to

unfavorable radio wave conditions.

●

Tire inflation pressure changes with temperature. The displayed values may also be dif-

ferent from the values measured using a tire pressure gauge.

Eco Driving Indicator Light

During Eco-friendly acceleration (Eco driv-

ing), the Eco Driving Indicator Light will turn

on. When the acceleration exceeds the Zone

of Eco driving, or when the vehicle is stopped,

the light turns off.
Eco Driving Indicator Zone Display

Suggests the Zone of Eco driving with current

Eco driving ratio based on acceleration.
Eco driving ratio based on acceleration

If the acceleration exceeds the Zone of Eco

driving, the right side of the Eco Driving Indi-

cator Zone Display will illuminate.
Zone of Eco driving

1

2

3

4

110

2. Instrument cluster

IS350 AWD/IS350/IS300 AWD/IS300_U

■

Liquid crystal display
Small spots or light spots may appear on the display. This phenomenon is characteristic

of liquid crystal displays, and there is no problem continuing to use the display.

■

Customization
Some functions can be customized. (

P. 103, 613)

WARNING

■

Caution for use while driving

●

When operating the multi-information display while driving, pay extra attention to the

safety of the area around the vehicle.

●

Do not look continuously at the multi-information display while driving as you may fail

to see pedestrians, objects on the road, etc. ahead of the vehicle.

■

The information display at low temperatures
Allow the interior of the vehicle to warm up before using the liquid crystal information

display. At extremely low temperatures, the information display monitor may respond

slowly, and display changes may be delayed.

For example, there is a lag between the driver’s shifting and the new gear number

appearing on the display. This lag could cause the driver to downshift again, causing

rapid and excessive engine braking and possibly an accident resulting in death or

injury.

■

Cautions during setting up the display
As the engine needs to be running during setting up the display, ensure that the vehicle

is parked in a place with adequate ventilation. In a closed area such as a garage,

exhaust gases including harmful carbon monoxide (CO) may collect and enter the

vehicle. This may lead to death or a serious health hazard.

NOTICE

■

While setting up the display
To prevent battery discharge, ensure that the engine is running while setting up the dis-

play features.

111

2. Instrument cluster

2

Instrument cl

uste
r

IS350 AWD/IS350/IS300 AWD/IS300_U

Audio system screen
“MENU” button
Lexus Display Audio controller
Remote Touch knob
“ENTER” button

*

1

: Vehicles with a Lexus Display Audio sys-

tem

*

2

: Vehicles with a navigation system

Fuel consumption information

Fuel consumption information can be displayed on the audio system.
Vehicles with a navigation system (10.3-inch display): The fuel consumption
information can be displayed and operated on the side display.

*

1

*

2

1

2
3
4
5

112

2. Instrument cluster

IS350 AWD/IS350/IS300 AWD/IS300_U

Lexus Display Audio screen

Press the “MENU” button on the Lexus Display Audio controller, then select
“Info” on the “Menu” screen, and then select “Fuel Consumption”.

If the “Trip Information” screen does not appear, move the controller to the right and

select “Trip Information”.

Fuel consumption in the past 15 min-
utes
Current fuel consumption
Average vehicle speed since the
engine was started.
Elapsed time since the engine was
started.
Cruising range (

P. 114)

Navigation system screen

Press the “MENU” button on the Remote Touch, then select

 on the “Menu”

screen, and then select “Fuel Consumption”.

If the “Past Record” screen is displayed, select “Trip Information”.

Resetting the consumption data
Fuel consumption in the past 15 min-
utes
Current fuel consumption
Average vehicle speed since the
engine was started.
Elapsed time since the engine was
started.
Cruising range (

P. 114)

Average fuel consumption for the past 15 minutes is divided by color into past
averages and averages attained since the engine switch was last turned to IGNI-
TION ON mode. Use the displayed average fuel consumption as a reference.
The image is an example only.

Trip information

1

2
3

4

5

1

2

3
4

5

6

113

2. Instrument cluster

2

Instrument cl

uste
r

IS350 AWD/IS350/IS300 AWD/IS300_U

Lexus Display Audio screen

Press the “MENU” button on the Lexus Display Audio controller, then select
“Info” on the “Menu” screen, and then select “Fuel Consumption”.

If the “Past Record” screen does not appear, move the controller to the right and

select “Past Record”.

Previous fuel consumption record
Current fuel consumption
Best recorded fuel consumption

Navigation system screen

Press the “MENU” button on the Remote Touch, then select

 on the “Menu”

screen, and then select “Fuel Consumption”.

If the “Trip Information” screen is displayed, select “Past Record”.

Resetting the past record data
Best recorded fuel consumption
Average fuel consumption
Previous fuel consumption record
Updating the average fuel con-
sumption data

The average fuel consumption history is divided by color into past averages and
the average fuel consumption since the last updated. Use the displayed average
fuel consumption as a reference.
The image is an example only.

Past record

1

2
3

1

2
3
4
5

114

2. Instrument cluster

IS350 AWD/IS350/IS300 AWD/IS300_U

■

Updating the past record data

Vehicles with a Lexus Display Audio system

Update the average fuel consumption by moving the controller to the left and select

“Update” to measure the current fuel consumption again.

Vehicles with a navigation system

Update the average fuel consumption by selecting “Update” to measure the current fuel

consumption again.

■

Resetting the data

Vehicles with a Lexus Display Audio system

The fuel consumption data can be deleted by moving the controller to the left and select

“Clear”.

Vehicles with a navigation system

The fuel consumption data can be deleted by selecting “Clear”.

■

Cruising range
Displays the estimated maximum distance that can be driven with the quantity of fuel

remaining.
This distance is computed based on your average fuel consumption.

As a result, the actual distance that can be driven may differ from that displayed.

115

2. Instrument cluster

2

Instrument cl

uste
r

IS350 AWD/IS350/IS300 AWD/IS300_U

Vehicle information can be displayed on the side display (

P. 416), then select

“<” or “>” to select the desired screen.

Fuel consumption

Displays the average fuel consumption
for the past 10 minutes in 1 minute inter-
vals, as well as the cruising range.

Past record

Displays the average fuel consumption
and highest fuel consumption.

Trip information

Displays the cruising range, average
fuel consumption and the amount of
time elapsed since the engine was
started.

The image is an example only, and may vary slightly from actual conditions.

Using the side display (vehicles with a navigation system [10.3-inch dis-
play])

116

2. Instrument cluster

IS350 AWD/IS350/IS300 AWD/IS300_U

118

IS350 AWD/IS350/IS300 AWD/IS300_U

3-1. Key information

The following keys are provided with the vehicle.

Electronic keys

• Operating the smart access system

with push-button start (

P. 135)

• Operating the wireless remote con-

trol function

Mechanical keys
Key number plate
Card key (electronic key) (if
equipped)

Operating the smart access system with

push-button start (

P. 135)

Locks the doors (

P. 124)

Unlocks the doors (

P. 124)

Opens the windows and moon roof

*

(

P. 124)

Opens the trunk (

P. 130)

Sounds the alarm (

P. 120)

*

: This setting must be customized at your

Lexus dealer.

Keys

The keys

1

2
3
4

Wireless remote control

1

2
3

4
5

119

3-1. Key information

3

Op
era
tio

n of
 ea

ch

 co

m

po

ne

nt

IS350 AWD/IS350/IS300 AWD/IS300_U

To take out the mechanical key, push
the release button and take the key out.

The mechanical key can only be

inserted in one direction, as the key only

has grooves on one side. If the key can-

not be inserted in a lock cylinder, turn it

over and re-attempt to insert it.
After using the mechanical key, store it

in the electronic key. Carry the mechan-

ical key together with the electronic key.

If the electronic key battery is depleted

or the entry function does not operate

properly, you will need the mechanical

key. (

P. 572)

Using the mechanical key















Content   ..  5  6  7  8   ..
