LEXUS GS 300 (2019 year). Instruction

522

8-1. Specifications

Maintenance data (fuel, oil level, etc.)



GS350/GS300

: Unladen vehicle

: Vehicles with 265/35R19 tires



GS F

: Unladen vehicle

Dimensions and weight

Overall length

190.9 in. (4850 mm)

Overall width

72.4 in. (1840 mm)

Overall height

2WD

57.3 in. (1455 mm)

AWD

57.9 in. (1470 mm)

Wheelbase

112.2 in. (2850 mm)

Tread

Front

62.0 in. (1575 mm)

Rear

62.6 in. (1590 mm)
61.4 in. (1560 mm)

Vehicle capacity weight

(Occupants + luggage)

825 lb. (370 kg)

Overall length

193.5 in. (4915 mm)

Overall width

72.6 in. (1845 mm)

Overall height

56.7 in. (1440 mm)

Wheelbase

112.2 in. (2850 mm)

Tread

Front

61.2 in. (1555 mm)

Rear

61.4 in. (1560 mm)

Vehicle capacity weight

(Occupants + luggage)

865 lb. (390 kg)

523

8-1. Specifications

icl

e spe

cif

atio

■

Vehicle identification number
The vehicle identification number (VIN) is the legal identifier for your vehicle.
This is the primary identification number for your Lexus. It is used in register-
ing the ownership of your vehicle.
This number is stamped on the top
left of the instrument panel and in the
engine compartment.

Vehicle identification



GS350



GS300



GS F

525

8-1. Specifications

icl

e spe

cif

atio



GS350



GS300



GS F

Engine

Model

3.5 L 6-cylinder (2GR-FKS)

Type

6-cylinder V type, 4-cycle, gasoline

Bore and stroke

3.70

 3.27 in. (94.0  83.0 mm)

Displacement

210.9 cu.in. (3456 cm

)

Valve clearance

Automatic adjustment

Drive belt tension

Model

2.0 L 4-cylinder with turbocharger (8AR-FTS)

Type

4-cylinder in line, 4-cycle, gasoline

Bore and stroke

3.39

 3.39 in. (86.0  86.0 mm)

Displacement

121.9 cu. in. (1998 cm

)

Valve clearance

Automatic adjustment

Drive belt tension

Model

5.0 L 8-cylinder (2UR-GSE)

Type

8-cylinder V type, 4-cycle, gasoline

Bore and stroke

3.70

 3.52 in. (94.0  89.5 mm)

Displacement

303.2 cu. in. (4969 cm

)

Valve clearance

(engine cold)

Intake: 0.006 in. (0.15 mm)

Exhaust: 0.009 in. (0.22 mm)

Drive belt tension

Automatic adjustment

Fuel

Fuel type

Unleaded gasoline only

Octane Rating

91 (Research Octane Number 96) or higher

Fuel tank capacity (Reference)

17.5 gal. (66.3 L, 14.6 Imp.gal.)

526

8-1. Specifications



GS350/GS300

: The engine oil capacity is a reference quantity to be used when changing the engine

oil. Warm up and turn off the engine, wait more than 5 minutes, and check the oil level
on the dipstick.

■

Lubrication system

GS350

GS300

2WD

AWD

Oil capacity

(Drain and refill



reference

)

With filter

Without filter

6.0 qt.

(5.7 L, 5.0 Imp.qt.)

5.8 qt.

(5.5 L, 4.8 Imp.qt.)

6.8 qt.

(6.4 L, 5.6 Imp.qt.)

6.3 qt.

(6.0 L, 5.3 Imp.qt.)

4.9 qt.

(4.6 L, 4.0 Imp.qt.)

4.5 qt.

(4.3 L, 3.8 Imp.qt.)

527

8-1. Specifications

icl

e spe

cif

atio

Recommended viscosity: SAE 0W-20
SAE 0W-20 is the best choice for
good fuel economy and good start-
ing in cold weather.
If SAE 0W-20 is not available, SAE
5W-20 oil may be used. However, it
must be replaced with SAE 0W-20
at the next oil change.

Oil viscosity (0W-20 is explained here as an example):

• The 0W in 0W-20 indicates the characteristic of the oil which allows cold

startability. Oils with a lower value before the W allow for easier starting of
the engine in cold weather.

• The 20 in 0W-20 indicates the viscosity characteristic of the oil when the

oil is at high temperature. An oil with a higher viscosity (one with a higher
value) may be better suited if the vehicle is operated at high speeds, or
under extreme load conditions.

How to read oil container label:
The International Lubricant Specifi-
cation Advisory Committee
(ILSAC) Certification Mark is added
to some oil containers to help you
select the oil you should use.



GS F

: The engine oil capacity is a reference quantity to be used when changing the engine

oil. Warm up and turn off the engine, wait more than 5 minutes, and check the oil level
on the dipstick.

Outside temperature

Oil capacity

(Drain and refill — reference

)

With filter

Without filter

9.3 qt. (8.8 L, 7.7 Imp.qt.)

8.3 qt. (7.9 L, 7.0 Imp.qt.)

528

8-1. Specifications

■

Engine oil selection
“Toyota Genuine Motor Oil” is used in your Lexus vehicle. Use Lexus
approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following
grade and viscosity.
Oil grade: ILSAC GF-5 multigrade engine oil
Recommended viscosity: SAE 5W-30
SAE 5W-30 is the best choice for
good fuel economy and good start-
ing in cold weather.
If SAE 5W-30 is not available, SAE
10W-30 oil may be used. However,
it should be replaced with SAE 5W-
30 at the next oil change.

Oil viscosity (5W-30 is explained here as an example):

• The 5W in 5W-30 indicates the characteristic of the oil which allows cold

startability. Oils with a lower value before the W allow for easier starting of
the engine in cold weather.

• The 30 in 5W-30 indicates the viscosity characteristic of the oil when the

oil is at high temperature. An oil with a higher viscosity (one with a higher
value) may be better suited if the vehicle is operated at high speeds, or
under extreme load conditions.

How to read oil container label:
The International Lubricant Specifi-
cation Advisory Committee
(ILSAC) Certification Mark is added
to some oil containers to help you
select the oil you should use.

Outside temperature

529

8-1. Specifications

icl

e spe

cif

atio

Cooling system

Capacity

GS350

9.9 qt.(9.4 L, 8.3 Imp.qt.)

GS300



Engine coolant

9.5 qt.(9.0 L, 7.9 Imp.qt.)



Intercooler

2.7 qt.(2.6 L, 2.3 Imp.qt.)

GS F

11.9 qt. (11.3 L, 9.9 Imp.qt.)

Coolant type

Use either of the following:

• “Toyota Super Long Life Coolant”

• Similar high-quality ethylene glycol-based non-

silicate, non-amine, non-nitrite, and non-borate

coolant with long-life hybrid organic acid tech-

nology

Do not use plain water alone.

Ignition system

GS350

GS300

GS F

Spark plug

Make

Gap

DENSO

FK20HBR8

0.031 in. (0.8 mm)

NGK

DILFR7K9G

0.04 in. (0.9 mm)

DENSO

FK20HBR-J8

0.031 in. (0.8 mm)

NOTICE

■

Iridium-tipped spark plugs
Use only iridium-tipped spark plugs. Do not adjust the spark plug gap.

530

8-1. Specifications

: The fluid capacity is the quantity of reference.

If replacement is necessary, contact your Lexus dealer.

Electrical system

Battery

Open voltage at 68

F (20C):

12.3 V or higher

(Voltage is checked 20 minutes after the engine

and all lights are turned off.)

Charging rates

5 A

Automatic transmission

Fluid capacity

GS350 (2WD)

10.0 qt. (9.5 L, 8.4 Imp.qt.)

GS350 (AWD) 10.6 qt. (10.0 L, 8.8 Imp.qt.)

GS300

9.2 qt. (8.7 L, 7.7 Imp.qt.)

GS F

11.8 qt. (11.2 L, 9.9 Imp.qt.)

Fluid type

Toyota Genuine ATF WS

NOTICE

■

Automatic transmission fluid type
Using transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration

in shift quality, locking up of your transmission accompanied by vibration, and ulti-

mately damage the transmission of your vehicle.

Front differential (AWD models)

Oil capacity

0.74 qt. (0.70 L, 0.62 Imp.qt.)

Oil type and viscosity

Toyota Genuine Differential gear oil GL-5 or equivalent

Above 0

F (-18C): SAE90

Below 0

F (-18C): SAE80W or SAE80W-90

531

8-1. Specifications

icl

e spe

cif

atio



GS350/GS300



GS F

: Your Lexus vehicle is filled with “Toyota Genuine Differential Gear Oil” at the factory.

Use Lexus approved “Toyota Genuine Differential Gear Oil” or an equivalent oil of
matching quality to satisfy the above specification. Please contact your Lexus dealer
for further details.

: Torque transfer modules are located on the right and left sides of the rear differential

unit.

: Using torque transfer module fluid other than “Toyota Genuine ATF WS” may cause

deterioration of performance, vibration, or ultimately damage the TVD system of your
vehicle.

: Minimum pedal clearance when depressed with a force of 112.4 lbf (500 N, 51.0 kgf)

while the engine is running.

Rear differential

Oil capacity

1.43 qt. (1.35 L, 1.19 Imp.qt.)

Oil type and viscosity

Vehicles without LSD (Limited Slip Differential):

Toyota Genuine Differential gear oil LT

75W-85 GL-5 or equivalent

Vehicles with LSD (Limited Slip Differential):

Toyota Genuine Differential gear oil LX 75W-85 GL-5

or equivalent

Differential

Torque transfer module

Oil capacity

1.43 qt. (1.35 L, 1.19 Imp. qt.)

Left-hand side:

0.74 qt. (0.70 L, 0.62 Imp. qt.)

Right-hand side:

0.74 qt. (0.70 L, 0.62 Imp. qt.)

Oil type and

viscosity

Toyota Genuine Differential gear

oil LT

75W-85 GL-5 or equivalent

Toyota Genuine ATF WS

Brakes

Pedal clearance

GS350/GS300

4.0 in. (102 mm) Min.

GS F

4.4 in. (112 mm) Min.

Pedal free play

0.04 — 0.24 in. (1.0 — 6.0 mm)

Brake pad wear limit

0.04 in. (1.0 mm)

Parking brake lining wear limit

0.04 in. (1.0 mm)

Fluid type

SAE J1703 or FMVSS No. 116 DOT 3

532

8-1. Specifications



GS350/GS300 (Type A)



GS350/GS300 (Type B)

Steering

Free play

Less than 1.2 in. (30 mm)

Tires and wheels

Tire size

225/50R17 94W

Tire inflation

pressure

(Recommended

cold tire inflation

pressure)

Vehicle speed

Front tire

psi (kPa, kgf/cm

or bar)

Rear tire

psi (kPa, kgf/cm

or bar)

More than 118 mph

(190 km/h)

45 (310, 3.1)

118 mph (190 km/h)

or less

35 (240, 2.4)

Wheel size

 7 1/2J

Wheel nut torque

76 ft•lbf (103 N•m, 10.5 kgf•m)

Tire size

235/45R18 94Y

Tire inflation

pressure

(Recommended

cold tire inflation

pressure)

Vehicle speed

Front tire

psi (kPa, kgf/cm

or bar)

Rear tire

psi (kPa, kgf/cm

or bar)

More than 137 mph

(220 km/h)

45 (310, 3.1)

137 mph (220 km/h)

or less

35 (240, 2.4)

Wheel size

 8J

Wheel nut torque

76 ft•lbf (103 N•m, 10.5 kgf•m)

533

8-1. Specifications

icl

e spe

cif

atio



GS350/GS300 (Type C)



GS350/GS300 (Type D)



GS350/GS300 (Type E)

Tire size

P235/45R18 94V

Tire inflation

pressure

(Recommended

cold tire inflation

pressure)

Vehicle speed

Front tire

psi (kPa, kgf/cm

or bar)

Rear tire

psi (kPa, kgf/cm

or bar)

More than 99 mph

(160 km/h)

45 (310, 3.1)

99 mph (160 km/h)

or less

35 (240, 2.4)

Wheel size

 8J

Wheel nut torque

76 ft•lbf (103 N•m, 10.5 kgf•m)

Tire size

235/40R19 96Y XL (front), 265/35R19 94Y (rear)

Tire inflation

pressure

(Recommended

cold tire inflation

pressure)

Vehicle speed

Front tire

psi (kPa, kgf/cm

or bar)

Rear tire

psi (kPa, kgf/cm

or bar)

More than 137 mph

(220 km/h)

45 (310, 3.1)

137 mph (220 km/h)

or less

35 (240, 2.4)

36 (250, 2.5)

Wheel size

 8J (235/40R19), 19  9J (265/35R19)

Wheel nut torque

76 ft•lbf (103 N•m, 10.5 kgf•m)

Tire size

235/40R19 96Y XL

Tire inflation

pressure

(Recommended

cold tire inflation

pressure)

Vehicle speed

Front tire

psi (kPa, kgf/cm

or bar)

Rear tire

psi (kPa, kgf/cm

or bar)

More than 137 mph

(220 km/h)

45 (310, 3.1)

137 mph (220 km/h)

or less

35 (240, 2.4)

36 (250, 2.5)

Wheel size

 8J

Wheel nut torque

76 ft•lbf (103 N•m, 10.5 kgf•m)

534

8-1. Specifications



GS350/GS300 (Type F)



GS350/GS300 (Compact spare tire)

Tire size

235/40R19 96V XL

Tire inflation

pressure

(Recommended

cold tire inflation

pressure)

Vehicle speed

Front tire

psi (kPa, kgf/cm

or bar)

Rear tire

psi (kPa, kgf/cm

or bar)

More than 99 mph

(160 km/h)

45 (310, 3.1)

99 mph (160 km/h)

or less

35 (240, 2.4)

36 (250, 2.5)

Wheel size

 8J

Wheel nut torque

76 ft•lbf (103 N•m, 10.5 kgf•m)

Tire size

T155/70D17 110M, T145/70D18 107M

Tire inflation pressure

(Recommended cold tire

inflation pressure)

60 psi (420kPa, 4.2kgf/cm

or bar)

Wheel size

 4T (T155/70D17), 18  4T (T145/70D18)

Wheel nut torque

76 ft•lbf (103 N•m, 10.5 kgf•m)

535

8-1. Specifications

icl

e spe

cif

atio



GS F

: If equipped

Tire size

255/35ZR19 (92Y) (front), 275/35ZR19 (96Y) (rear),
225/40ZR19 (93Y) XL (spare)

Tire inflation pressure

(Recommended

cold tire inflation

pressure)

Vehicle speed

Front tire

psi (kPa, kgf/cm

or bar)

Rear tire

psi (kPa, kgf/cm

or bar)

More than 137 mph

(220 km/h)

44 (300, 3.0)

137 mph (220 km/h)

or less

36 (250, 2.5)

Tire inflation pressure

(spare)

(Recommended

cold tire inflation

pressure)

42 psi (290kPa, 2.9kgf/cm

or bar)

Wheel size

 9J (255/35ZR19), 19  10J (275/35ZR19),

 8 1/2J (225/40ZR19)

Wheel nut torque

76 ft•lbf (103 N•m, 10.5 kgf•m)

Light bulbs

Bulb No.

Type

Exterior

Front turn signal lights

7444NA

Outer foot lights

W5W

Interior

Vanity lights



Trunk light



3.8

A: Wedge base bulbs (amber)

B: Wedge base bulbs (clear)

: Vehicles with single-beam headlights

LEXUS GS 300 (2019 year). Instruction - part 33
