LEXUS CT200H (2017 year). Instruction - part 26

411

5-22. Other function (Lexus Display Audio System)

Audio system

■

Availability of service
Lexus Enform Remote is available in the contiguous United States, Washington D.C. and

Alaska.

■

Lexus Enform Remote Information

●

Lexus Enform Remote should only be used by authorized users.

●

Laws in some communities may require that the vehicle be within view of the user when

operating Lexus Enform Remote.

In some states, use of Lexus Enform Remote may violate state or local laws. Before

using Lexus Enform Remote, check your state and local laws.

●

Any malfunction of the Lexus should be repaired by your Lexus dealer.

●

Lexus Enform Remote is designed to work at temperatures above -22

F (-30C). This

specification is related to the Lexus Enform Remote operation, but is dependent on the

vehicle’s operating temperature range which may be different.

●

Content is subject to change without notice.

●

Some features of the Lexus Enform Remote may not be available on some models.

●

Additional information can be found at www.lexus.com/enform/.

●

Availability of functions of the Lexus Enform service is dependent on network reception

level.

■

Safety information for Lexus Enform Remote
P. 463

412

5-22. Other function (Lexus Display Audio System)

413

Interior features

6-1. Using the air conditioning

system and defogger

Automatic air conditioning

system (Vehicles with a
navigation system or Lexus
Display Audio System)........... 414

Automatic air conditioning

system (Vehicles without a
navigation system or Lexus
Display Audio System)..........422

Heated steering wheel/

seat heaters................................429
• Heated steering wheel...... 430
• Seat heaters........................... 430

6-2. Using the interior lights

Interior lights list .......................... 431

• Personal/interior light

main switch.............................. 431

• Front personal/

interior lights ..........................432

• Rear interior light .................432

6-3. Using the storage features

List of storage features ............433

• Glove box ...............................434
• Console box...........................434
• Cup holders/

bottle holders/
door pockets..........................434

• Auxiliary boxes .....................436

Luggage compartment

features........................................438

6-4. Using the other interior features

Other interior features ............443

• Sun visors ................................443
• Vanity mirrors ........................443
• Clock ........................................444
• Power outlet ...........................444
• Assist grips..............................446

Garage door opener................ 447
Compass .......................................454
LEXUS Enform Safety

Connect......................................460

414

6-1. Using the air conditioning system and defogger

Automatic air conditioning system (Vehicles with a
navigation system or Lexus Display Audio System)

Air outlets and fan speed are automatically adjusted according to the temper-
ature setting.
Vehicles with a Lexus Display Audio System: Press the “MENU” button on the
Lexus Display Audio controller, then select “Climate” to display the air condi-
tioning operation screen.
For details on the Lexus Display Audio controller, refer to “Lexus Display
Audio controller” on P. 326.
Vehicles with a navigation system: Press the “MENU” button on the Remote
Touch, then select “Climate” to display the air conditioning control screen.
For details on the Remote Touch, refer to the “NAVIGATION SYSTEM
OWNER’S MANUAL”.

415

6-1. Using the air conditioning system and defogger

Inte
rior fe

ature

■

Adjusting the temperature setting

Press

to increase the temperature and

to decrease the tem-

perature.

■

Adjusting the fan speed setting

Press

to increase the fan speed and

to decrease the fan

speed.
Press the “OFF” button to turn the fan off.

■

Change the airflow mode
To change the airflow, press

The air outlets used are switched

each time the button is pressed.

Air flows to the upper body.
Air flows to the upper body and
feet.
Air flows to the feet.
Air flows to the feet and the wind-
shield defogger operates.

Control panel

3
4

416

6-1. Using the air conditioning system and defogger



Vehicles with a Lexus Display Audio System
Adjust the left-hand side tempera-
ture setting
Adjust the fan speed setting
“AUTO”: Select to set automatic
mode on/off
“OFF”: Turn the fan off

: Display the option control

screen (

P. 417)

Select the air flow mode
Adjust the right-hand side temperature setting
Move the Lexus Display Audio controller left/right to select the desired item
(

When ,

selected:

Move the controller forward/backward or turn it left/right for adjusting.
When

is selected:

Move the controller forward/backward or turn it left/right to select a screen
button, then press the controller.



Vehicles with a navigation system
Adjust the left-hand side tempera-
ture setting
Adjust the fan speed setting
Select the air flow mode
Adjust the right-hand side tempera-
ture setting
Display the option control screen
(

P. 417)

Turn the fan off
Select to set automatic mode on/off

To adjust or select settings, move the Remote Touch knob to select the screen
button, and then press the Remote Touch knob to enter the selected function.

Control screen

2
3

4
5

2
3
4

6
7

417

6-1. Using the air conditioning system and defogger

Inte
rior fe

ature

■

Option control screen
Select

on the climate screen to display the option control screen. The

functions can be switched on and off.

Select to set cooling and dehumidification function on/off
Adjust the temperature for driver and passenger seats separately (“DUAL”
mode) (

P. 417)

Prevent ice from building up on the windshield and wiper blades (if
equipped) (

P. 419)

Remove pollen from the air (Micro dust and pollen filter) (

P. 418)

■

Using the automatic mode

Press the “AUTO” button.
Adjust the temperature setting.
To stop the operation, press the “OFF” button.

■

Automatic mode indicator
If the fan speed setting or air flow modes are operated, the automatic mode
indicator goes off. However, automatic mode for functions other than that
operated is maintained.

■

Adjusting the temperature for driver and passenger seats separately
(“DUAL” mode)
To turn on the “DUAL” mode, perform any of the following procedures:

●

Press the “DUAL” button.

●

Select “DUAL” on the option control screen.

●

Adjust the passenger’s side temperature setting.
The indicator comes on when the “DUAL” mode is on.



Vehicles with a Lexus Display Audio
System



Vehicles with a navigation system

Air conditioning controls

2
3

418

6-1. Using the air conditioning system and defogger

■

Switching between outside air and recirculated air modes

Press .

The mode switches between

(recirculated air mode) and

(outside

air mode) modes each time the button is pressed.

■

Defogging the windshield
Defoggers are used to defog the windshield and front side windows.

Press .

Set

to outside air mode if the recirculated air mode is used. (It may

switch automatically.)
To defog the windshield and the side windows early, turn the air flow and tempera-

ture up.

To return to the previous mode, press

again when the windshield is

defogged.

■

Defogging the rear window and outside rear view mirrors
Defoggers are used to defog the rear window and to remove raindrops, dew
and frost from the outside rear view mirrors.

Press .

The defoggers will automatically turn off after a period of time.

■

Micro dust and pollen filter
Pollen is removed from the air and the air flows to the upper part of the body.

Press

or select

on the operation screen.

When the micro dust and pollen filter is on,

is displayed on the air condition-

ing control screen.
In order to prevent the windshield from fogging up when the outside air is cold, the

dehumidification function may operate.
The pollens are filtered out even if the micro dust and pollen filter is turned off.

Other functions

419

6-1. Using the air conditioning system and defogger

Inte
rior fe

ature

■

Windshield wiper de-icer (if equipped)
This feature is used to prevent ice from building up on the windshield and
wiper blades.
Select

on the option control screen.

When the windshield wiper de-icer is on,

is displayed on the air condition-

ing control screen.
The windshield wiper de-icer will automatically turn off after a period of time.

■

Location of air outlets
The air outlets and air volume
changes according to the selected
air flow mode.

■

Adjusting the position of and opening and closing the air outlets

Direct air flow to the left or right,
up or down.
Turn the knob to open or close
the vent.

■

Registering air conditioning settings to electronic keys

●

Unlocking the vehicle using an electronic key and turning the power switch to ON

mode will recall that key’s registered air conditioning settings.

●

When the power switch is turned off, the current air conditioning settings will automati-

cally be registered to the electronic key that was used to unlock the vehicle.

The system may not operate correctly if more than one electronic key is in the vicinity or

if the smart access system is used to unlock a passenger door.
Settings for the electronic key and the corresponding door can be changed.
Contact your Lexus dealer.

Air outlets

420

6-1. Using the air conditioning system and defogger

■

Using automatic mode
Fan speed is adjusted automatically according to the temperature setting and the ambi-

ent conditions.

Therefore, the fan may stop for a while until warm or cool air is ready to flow immediately

after the “AUTO” button is pressed or “AUTO” is selected.

■

When the outside temperature exceeds 75

F (24C) and the air conditioning system

is on

●

In order to reduce the air conditioning power consumption, the air conditioning system

may switch to recirculated air mode automatically.

This may also reduce fuel consumption.

●

Recirculated air mode is selected as a default mode when the power switch is turned to

ON mode.

●

It is possible to switch to outside air mode at any time by pressing

■

Fogging up of the windows

●

The windows will easily fog up when the humidity in the vehicle is high. Pressing “A/C”

button or selecting “A/C” will dehumidify the air from the outlets and defog the wind-

shield effectively.

●

If you turn “A/C” off, the windows may fog up more easily.

●

The windows may fog up if the recirculated air mode is used.

■

Outside/recirculated air mode

●

When driving on dusty roads such as tunnels or in heavy traffic, set

the recirculated air mode. This is effective in preventing outside air from entering the

vehicle interior. During cooling operation, setting the recirculated air mode will also

cool the vehicle interior effectively.

●

Outside/recirculated air mode may automatically switch depending on the tempera-

ture setting or the inside temperature.

■

When the outside temperature is low
The dehumidification function may not operate even when “A/C” is pressed or “A/C” is

selected.

■

Operation of the air conditioning system in Eco drive mode

●

In the Eco drive mode, the air conditioning system is controlled as follows to prioritize

fuel efficiency
• Engine speed and compressor operation controlled to restrict heating/cooling

capacity

• Fan speed restricted when automatic mode is selected

●

To improve air conditioning performance, perform the following operations
• Adjust the fan speed

• Turn off Eco drive mode

• Customize the air conditioning control of Eco drive mode. (

P. 603)

421

6-1. Using the air conditioning system and defogger

Inte
rior fe

ature

■

Ventilation and air conditioning odors

●

To let fresh air in, set the air conditioning system to the outside air mode.

●

During use, various odors from inside and outside the vehicle may enter into and accu-

mulate in the air conditioning system. This may then cause odor to be emitted from the

vents.

●

To reduce potential odors from occurring:
• It is recommended that the air conditioning system be set to outside air mode prior

to turning the vehicle off.

• The start timing of the blower may be delayed for a short period of time immediately

after the air conditioning system is started in automatic mode.

■

Air conditioning filter
P. 507

■

Customization
Settings (e.g. A/C automatic mode switch operation) can be changed.

(Customizable features:

P. 598)

WARNING

■

To prevent the windshield from fogging up

●

Do not use

during cool air operation in extremely humid weather. The differ-

ence between the temperature of the outside air and that of the windshield can cause

the outer surface of the windshield to fog up, blocking your vision.

■

To prevent burns

●

Do not touch the rear view mirror surfaces when the outside rear view mirror defog-

gers are on.

●

Do not touch the glass at lower part of the windshield or to the side of the front pillars

when the windshield wiper de-icer is on. (vehicles with windshield wiper de-icer)

NOTICE

■

To prevent 12-volt battery discharge
Do not leave the air conditioning system on longer than necessary when the hybrid sys-

tem is off.

●

Do not place anything on the instrument

panel which may cover the air outlets. Other-

wise, air flow may be obstructed, preventing

the windshield defoggers from defogging.

422

6-1. Using the air conditioning system and defogger

Automatic air conditioning system (Vehicles without a
navigation system or Lexus Display Audio System)

■

Adjusting the temperature setting

Press

to increase the temperature and

to decrease the tem-

perature.

■

Adjusting the fan speed setting

Press

to increase the fan speed and

to decrease the fan

speed.
Press the “OFF” button to turn the fan off.

Air outlets and fan speed are automatically adjusted according to the temper-
ature setting.

Control panel

423

6-1. Using the air conditioning system and defogger

Inte
rior fe

ature

■

Change the airflow mode
To change the airflow, press

The air outlets used are switched

each time the button is pressed.

Air flows to the upper body.
Air flows to the upper body and
feet.
Air flows to the feet.
Air flows to the feet and the wind-
shield defogger operates.

■

Using the automatic mode

Press the “AUTO” button.
Adjust the temperature setting.
To stop the operation, press the “OFF” button.

■

Automatic mode indicator
If the fan speed setting or air flow modes are operated, the automatic mode
indicator goes off. However, automatic mode for functions other than that
operated are maintained.

■

Adjusting the temperature for driver and passenger seats separately
(“DUAL” mode)
To turn on the “DUAL” mode, perform any of the following procedures:

●

Press the “DUAL” button.

●

Adjust the passenger’s side temperature setting.
The indicator comes on when the “DUAL” mode is on.

3
4

Air conditioning controls

2
3

424

6-1. Using the air conditioning system and defogger

■

Switching between outside air and recirculated air modes

Press .

The mode switches between

(recirculated air mode) and

(outside

air mode) modes each time the button is pressed.

■

Defogging the windshield
Defoggers are used to defog the windshield and front side windows.

Press .

Set

to outside air mode if the recirculated air mode is used. (It may

switch automatically.)
To defog the windshield and the side windows early, turn the air flow and tempera-

ture up.

To return to the previous mode, press

again when the windshield is

defogged.

■

Defogging the rear window and outside rear view mirrors
Defoggers are used to defog the rear window and to remove raindrops, dew
and frost from the outside rear view mirrors.

Press .

The defoggers will automatically turn off after a period of time.

■

Micro dust and pollen filter
Pollen is removed from the air and the air flows to the upper part of the body.

Press .

In order to prevent the windshield from fogging up when the outside air is cold, the

dehumidification function may operate.
The pollens are filtered out even if the micro dust and pollen filter is turned off.

Other functions

425

6-1. Using the air conditioning system and defogger

Inte
rior fe

ature

■

Windshield wiper de-icer (if equipped)
This feature is used to prevent ice from building up on the windshield and
wiper blades.
Turns on/off.

The indicator comes on when the

windshield wiper de-icer is on.
The windshield wiper de-icer will

automatically turn off after a period

of time.

■

Location of air outlets
The air outlets and air volume
changes according to the selected
air flow mode.

■

Adjusting the position of and opening and closing the air outlets

Direct air flow to the left or right,
up or down.
Turn the knob to open or close
the vent.

Air outlets

426

6-1. Using the air conditioning system and defogger

■

Registering air conditioning settings to electronic keys

●

Unlocking the vehicle using an electronic key and turning the power switch to ON

mode will recall that key’s registered air conditioning settings.

●

When the power switch is turned off, the current air conditioning settings will automati-

cally be registered to the electronic key that was used to unlock the vehicle.

The system may not operate correctly if more than one electronic key is in the vicinity or

if the smart access system is used to unlock a passenger door.

■

Using automatic mode
Fan speed is adjusted automatically according to the temperature setting and the ambi-

ent conditions.

Therefore, the fan may stop for a while until warm or cool air is ready to flow immediately

after the “AUTO” button is pressed.

■

When the outside temperature exceeds 75

F (24C) and the air conditioning system

is on

●

In order to reduce the air conditioning power consumption, the air conditioning system

may switch to recirculated air mode automatically.

This may also reduce fuel consumption.

●

Recirculated air mode is selected as a default mode when the power switch is turned to

ON mode.

●

It is possible to switch to outside air mode at any time by pressing

■

Fogging up of the windows

●

The windows will easily fog up when the humidity in the vehicle is high. Pressing “A/C”

button on will dehumidify the air from the outlets and defog the windshield effectively.

●

If you turn “A/C” off, the windows may fog up more easily.

●

The windows may fog up if the recirculated air mode is used.

■

Outside/recirculated air mode

●

When driving on dusty roads such as tunnels or in heavy traffic, set

the recirculated air mode. This is effective in preventing outside air from entering the

vehicle interior. During cooling operation, setting the recirculated air mode will also

cool the vehicle interior effectively.

●

Outside/recirculated air mode may automatically switch depending on the tempera-

ture setting or the inside temperature.

Content .. 24 25 26 27 ..
