LEXUS CT200H (2017 year). Instruction - part 7

Side doors

◆

Smart access system with push-button start

Carry the electronic key to enable this function.

Grip the driver’s door handle to
unlock the door. Grip the passen-
ger’s door handle to unlock all the
doors.

Make sure to touch the sensor on the

back of the handle.
The doors cannot be unlocked for

3 seconds after the doors are locked.

: The door unlock settings can be

changed. (

Touch the lock sensor (the indentation on the upper part of the front door
handle) to lock the doors.

Check that the door is securely locked.

◆

Wireless remote control

Locks all the doors

Check that the door is securely

locked.

Unlocks all the doors

Pressing the button unlocks the

driver’s door. Pressing the button

again within 3 seconds unlocks the

other doors.
Press and hold to open the windows

: This setting must be customized at your Lexus dealer.

The vehicle can be locked and unlocked using the entry function, wireless
remote control or door lock switch.

Locking and unlocking the doors from the outside

108

■

Operation signals
Doors:

A buzzer sounds and the emergency flashers flash to indicate that the doors have been

locked/unlocked. (Locked: Once; Unlocked: Twice)
Windows:

A buzzer sounds to indicate that the windows are opening.

■

Security feature
If a door is not opened within approximately 60 seconds after the vehicle is unlocked, the

security feature automatically locks the vehicle again.

■

Welcome light illumination control
The side marker, parking, tail and license plate lights automatically turn on at night when

the doors are unlocked using the entry function or wireless remote control if the light

switch is in the “AUTO” position.

■

When the door cannot be locked by the lock sensor on the upper part of the door han-

dle

■

Door lock buzzer
If an attempt to lock the doors is made when a door is not fully closed, a buzzer sounds

continuously for 5 seconds. Fully close the door to stop the buzzer, and lock the vehicle

once more.

■

Setting the alarm
Locking the doors will set the alarm system. (

P. 78)

■

If the smart access system with push-button start or the wireless remote control does

not operate properly

●

Use the mechanical key to lock and unlock the doors. (

P. 566)

●

Replace the key battery with a new one if it is depleted. (

P. 509)

If the door will not lock even when the topside

sensor area is touched, try touching both the

topside and underside sensor areas at the same

time.

109

◆

Door lock switch

Locks all the doors
Unlocks all the doors

◆

Inside lock buttons

Locks the door
Unlocks the door

The front doors can be opened by

pulling the inside handle even if the

lock buttons are in the lock position.

Locking and unlocking the doors from the inside

110

Move the inside lock button to the lock position.
Close the door.

The door cannot be locked if the power switch is in ACCESSORY or ON mode,
or the electronic key is left inside the vehicle.

The key may not be detected correctly and the door may be locked.

The door cannot be opened from inside
the vehicle when the lock is set.

Unlock
Lock

These locks can be set to prevent chil-

dren from opening the rear doors. Push

down on each rear door switch to lock

both rear doors.

The following functions can be set or canceled:

For instructions on customizing, refer to P. 598.

Locking the front doors from the outside without a key

Rear door child-protector lock

Automatic door locking and unlocking systems

Function

Operation

Shift position linked door locking

function

Shifting the shift position to any positions other

than P locks all the doors.

Shift position linked door unlocking

function

Shifting the shift position to P unlocks all the

doors.

Speed linked door locking function All the doors are locked when the vehicle speed

is approximately 12 mph (20 km/h) or higher.

Driver’s door linked door unlocking

function

All the doors are unlocked when the driver’s

door is opened within approximately 45 sec-

onds after turning the power switch off.

111

■

Impact detection door lock release system
In the event that the vehicle is subject to a strong impact, all the doors are unlocked.

Depending on the force of the impact or the type of accident, however, the system may

not operate.

■

Using the mechanical key
The doors can also be locked and unlocked with the mechanical key. (

P. 566)

■

If a wrong key is used
The key cylinder rotates freely to isolate inside mechanism.

■

Customization
Settings (e.g. unlocking function using a key) can be changed.

(Customizable features:

WARNING

■

To prevent an accident
Observe the following precautions while driving the vehicle.

Failure to do so may result in a door opening and an occupant throwing out of the vehi-

cle, resulting in death or serious injury.

●

Ensure that all doors are properly closed and locked.

●

Do not pull the inside handle of the doors while driving.
Be especially careful for the front doors, as the doors may be opened even if the

inside lock buttons are in locked position.

●

Set the rear door child-protector locks when children are seated in the rear seats.

■

When opening or closing a door
Check the surroundings of the vehicle such as whether the vehicle is on an incline,

whether there is enough space for a door to open and whether a strong wind is blow-

ing. When opening or closing the door, hold the door handle tightly to prepare for any

unpredictable movement.

■

When using the wireless remote control and operating the power windows
Operate the power window after checking to make sure that there is no possibility of

any passenger having any of their body parts caught in the window. Also, do not allow

children to operate the wireless remote control. It is possible for children and other

passengers to get caught in power window.

112

Back door

◆

Smart access system with push-button start

Carry the electronic key to enable
this function.

Locks all the doors

Check that the door is securely

locked.

Unlocks all the doors

The doors cannot be unlocked for 3

seconds after the doors are locked.

◆

Wireless remote control

P. 102

◆

Door lock switch

P. 109

The back door can be locked/unlocked and opened by the following proce-
dures.

Locking and unlocking the back door

113

Raise the back door while pushing up
the back door opener switch.

Lower the back door using the back
door handle, and make sure to push the
back door down from the outside to
close it.

■

Luggage compartment light
The luggage compartment light turns on when the back door is opened with the luggage

compartment light switch on.

■

If the back door opener is inoperative
The back door can be unlocked from the inside.

Opening the back door from outside the vehicle

When closing the back door

Off
On
When the power switch is turned off, the light

will go off automatically after 20 minutes.

Lift the center deck board and then push up the

lever in the hole.

114

WARNING

Observe the following precautions.

Failure to do so may result in death or serious injury.

■

Before driving

●

Make sure that the back door is fully closed. If the back door is not fully closed, it may

open unexpectedly while driving and hit near-by objects or luggage in the luggage

compartment may be thrown out, causing an accident.

●

Do not allow children to play in the luggage compartment.

If a child is accidentally locked in the luggage compartment, they could have heat

exhaustion or other injuries.

●

Do not allow a child to open or close the back door.

Doing so may cause the back door to open unexpectedly, or cause the child’s hands,

head, or neck to be caught by the closing back door.

■

Important points while driving

●

Keep the back door closed while driving.

If the back door is left open, it may hit near-by objects or luggage in the luggage com-

partment may be thrown out, causing an accident.

●

Never let anyone sit in the luggage compartment. In the event of sudden braking,

sudden swerving or a collision, they are susceptible to death or serious injury.

■

Operating the back door
Observe the following precautions.

Failure to do so may cause parts of the body to be caught, resulting in death or serious

injury.

●

Remove any heavy loads, such as snow and ice, from the back door before opening it.

Failure to do so may cause the back door to suddenly shut again after it is opened.

●

When opening or closing the back door, thoroughly check to make sure the sur-

rounding area is safe.

●

If anyone is in the vicinity, make sure they are safe and let them know that the back

door is about to open or close.

●

Use caution when opening or closing the back door in windy weather as it may move

abruptly in strong wind.

●

The back door may suddenly shut if it is not

opened fully. It is more difficult to open or

close the back door on an incline than on a

level surface, so beware of the back door

unexpectedly opening or closing by itself.

Make sure that the back door is fully open and

secure before using the luggage compart-

ment.

115

WARNING

●

Do not pull on the back door damper stay to close the back door, and do not hang on

the back door damper stay.

Doing so may cause hands to be caught or the back door damper stay to break, caus-

ing an accident.

●

If a bicycle carrier or similar heavy object is attached to the back door, it may sud-

denly shut closed again after being opened, causing someone’s hands, head or neck

to be caught and injured. When installing an accessory part to the back door, using a

genuine Lexus part is recommended.

NOTICE

■

Back door damper stays
The back door is equipped with damper stays that hold the back door in place.
Observe the following precautions.

Failure to do so may cause damage to the back door damper stay, resulting in malfunc-

tion.

●

When closing the back door, take extra care

to prevent your fingers etc. from being

caught.

●

When closing the back door, make sure to

press it lightly on its outer surface. If the back

door handle is used to fully close the back

door, it may result in hands or arms being

caught.

●

Do not attach any foreign objects, such as

stickers, plastic sheets, or adhesives to the

damper stay rod.

●

Do not touch the damper stay rod with gloves

or other fabric items.

●

Do not attach any accessories other than

genuine Lexus parts to the back door.

●

Do not place your hand on the damper stay or

apply lateral forces to it.

Damper stays

116

Smart access system with push-button start

●

Locks and unlocks the doors (

P. 107)

●

Locks and unlocks the back door (

P. 112)

●

Starts and stops the hybrid system (

P. 159)

■

Antenna location

■

Effective range (areas within which the electronic key is detected)

The system can be operated when the electronic key is inside the vehicle.

The following operations can be performed simply by carrying the electronic
key (including the card key) on your person, for example in your pocket. The
driver should always carry the electronic key.

Antennas outside the cabin
Antennas inside the cabin
Antenna inside the luggage compartment
Antenna outside the luggage compartment

When locking or unlocking the doors
The system can be operated when the elec-

tronic key is within about 2.3 ft. (0.7 m) of

either of the outside front door handles or

back door opener switch. (Only the doors

detecting the key can be operated.)
When starting the hybrid system or chang-

ing power switch modes

2
3
4

117

■

Alarms and warning messages
An alarm sounds and warning message displays shown on the multi-information display

are used to protect against unexpected accidents or theft of the vehicle resulting from

erroneous operation. When a warning message is displayed, take appropriate measures

based on the displayed message. (

P. 542)

When only an alarm sounds, circumstances and correction procedures are as follows.

■

Battery-saving function
The battery-saving function will be activated in order to prevent the electronic key bat-

tery and the 12-volt battery from being discharged while the vehicle is not in operation

for a long time.

●

In the following situations, the smart access system with push-button start may take

some time to unlock the doors.
• The electronic key has been left in an area of approximately 6 ft. (2 m) of the outside

of the vehicle for 10 minutes or longer.

• The smart access system with push-button start has not been used for 5 days or

longer.

●

If the smart access system with push-button start has not been used for 14 days or

longer, the doors cannot be unlocked at any doors except the driver’s door. In this case,

take hold of the driver’s door handle, or use the wireless remote control or the mechan-

ical key, to unlock the doors.

■

Conditions affecting operation
The smart access system with push-button start, wireless remote control and immobilizer

system use weak radio waves. In the following situations, the communication between the

electronic key and the vehicle may be affected, preventing the smart access system with

push-button start, wireless remote control and immobilizer system from operating prop-

erly. (Ways of coping:

P. 566)

●

When the electronic key battery is depleted

●

Near a TV tower, electric power plant, gas station, radio station, large display, airport or

other facility that generates strong radio waves or electrical noise

●

When carrying a portable radio, cellular phone, cordless phone or other wireless com-

munication devices

Alarm

Situation

Correction procedure

Exterior alarm

sounds once for 5

seconds

An attempt was made to lock

the vehicle while a door was

open.

Close all of the doors and

lock the doors again.

Interior alarm pings

repeatedly

The power switch was turned to

ACCESSORY mode while the

driver’s door was open (The

driver’s door was opened when

the power switch was in

ACCESSORY mode).

Turn the power switch off

and close the driver’s door.

118

●

When the electronic key is in contact with, or is covered by the following metallic

objects
• Cards to which aluminum foil is attached

• Cigarette boxes that have aluminum foil inside

• Metallic wallets or bags

• Coins

• Hand warmers made of metal

• Media such as CDs and DVDs

●

When other wireless key (that emit radio waves) is being used nearby

●

When carrying the electronic key together with the following devices that emit radio

waves
• Another vehicle’s electronic key or a wireless key that emits radio waves

• Personal computers or personal digital assistants (PDAs)

• Digital audio players

• Portable game systems

●

If window tint with a metallic content or metallic objects are attached to the rear win-

dow

■

Note for the entry function

●

Even when the electronic key is within the effective range (detection areas), the system

may not operate properly in the following cases:
• The electronic key is too close to the window or outside door handle, near the

ground, or in a high place when the doors are locked or unlocked.

• The electronic key is near the ground or in a high place, or too close to the rear

bumper center when the back door is opened.

• The electronic key is on the instrument panel, luggage room, floor, or in the door

pockets or glove box when the hybrid system is started or power switch modes are

changed.

●

Do not leave the electronic key on top of the instrument panel or near the door pockets

when exiting the vehicle. Depending on the radio wave reception conditions, it may be

detected by the antenna outside the cabin and the door will become lockable from the

outside, possibly trapping the electronic key inside the vehicle.

●

As long as the electronic key is within the effective range, the doors may be locked or

unlocked by anyone.

●

Even if the electronic key is not inside the vehicle, it may be possible to start the hybrid

system if the electronic key is near the window.

●

The doors may unlock if a large amount of water splashes on the door handle, such as in

the rain or in a car wash when the electronic key is within the effective range. (The door

will automatically be locked after approximately 60 seconds if the doors are not

opened and closed.)

●

If the wireless remote control is used to lock the doors when the electronic key is near

the vehicle, there is a possibility that the door may not be unlocked by the entry func-

tion. (Use the wireless remote control to unlock the doors.)

●

Touching the door lock sensor while wearing gloves may delay or prevent lock opera-

tion. Remove the gloves and touch the lock sensor again.

●

When the lock operation is performed using the lock sensor, recognition signals will be

shown up to two consecutive times. After this, no recognition signals will be given.

●

If the door handle becomes wet while the electronic key is within the effective range,

the door may lock and unlock repeatedly. Place the key in a position 6 ft. (2 m) or more

separate from the vehicle while the vehicle is being washed. (Take care to ensure that

the key is not stolen.)

119

●

If the electronic key is inside the vehicle and a door handle becomes wet during a car

wash, a message may be shown on the multi-information display and a buzzer will

sound outside the vehicle. To turn off the alarm, lock all the doors.

●

The lock sensor may not work properly if it comes into contact with ice, snow, mud, etc.

Clean the lock sensor and attempt to operate it again, or use the lock sensor on the

lower part of the door handle.

●

A sudden approach to the effective range or door handle may prevent the doors from

being unlocked. In this case, return the door handle to the original position and check

that the doors unlock before pulling the door handle again.

●

If there is another electronic key in the detection area, it may take slightly longer to

unlock the doors after the door handle is gripped.

●

Fingernails may scrape against the door during operation of the door handle. Be care-

ful not to injure fingernails or damage the surface of the door.

■

When the vehicle is not driven for extended periods

●

To prevent theft of the vehicle, do not leave the electronic key within 6 ft. (2 m) of the

vehicle.

●

The smart access system with push-button start can be deactivated in advance.

(

■

To operate the system properly
Make sure to carry the electronic key when operating the system. Do not get the elec-

tronic key too close to the vehicle when operating the system from the outside of the

vehicle.
Depending on the position and holding condition of the electronic key, the key may not

be detected correctly and the system may not operate properly. (The alarm may go off

accidentally, or the door lock prevention may not operate.)

■

If the smart access system with push-button start does not operate properly

●

Locking and unlocking the doors: Use the mechanical key. (

P. 566)

●

Starting the hybrid system:

P. 567

■

Customization
Settings (e.g. smart access system with push-button start) can be changed.

(Customizable features:

■

If the smart access system with push-button start has been deactivated in a customized

setting

●

Locking and unlocking the doors:

Use the wireless remote control or mechanical key. (

P. 107, 566)

●

Starting the hybrid system and changing power switch modes:

P. 567

●

Stopping the hybrid system:

P. 160

120

■

Certification for the smart access system with push-button start



For vehicles sold in the U.S.A., Hawaii, Guam, Puerto Rico and NATO Germany

: For U.S. mainland and NATO Germany only



For vehicles sold in Canada

FCC ID: HYQ13CZD

FCC ID: HYQ13CZE

FCC ID: HYQ14ACX

FCC ID: HYQ14ADF

FCC ID: HYQ14AEB

FCC ID: HYQ14AEF

121
